RealRelax FAVOR-03 ADV User manual

MASSAGE
CHAIR
USER MANUAL
FAVOR-03 ADV
C
M
Y
CM
MY
CY
CMY
K

01
02
02 - 03
03
04
05
06
07
08
09
10
12-15
16
16
17
18
18
18
18
19
19
20
Thank for your purchase of this product. Before using,please read this USER MANUAL carefully,
and pay special attention to the safety precaution toensure proper operation and use.
Please keep this USER MANUALproperly forfurther reference.
EXTERNAL STRUCTURE
INTERNAL STRUCTURE
AUTO MODE
REMOTE CONTROLLER INSTRUCTION
REMOTE CONTROLLER KEY FUNCTIONS
CUSTOM MASSAGEMODE
MUSIC SYSTEM
MEDICAL WATRNINGS
WARNING
FORBIDDEN
REMOVE PLUG
INSTALLATION METHOD
INSTALLATION POSITION
GROUNDING INSTRUCTIONS
AFTER USING THE CHAIR
METHODS OF STORAGE
MAINTENANCE
TURN ON POWER SUPPLY
MOVE METHOD
KIND REMINDING
TROUBLESHOOTING GUIDE
TECHNICAL SPECIFICATIONS
24 hours online
customer service
Welcome to be our valued customer. If you have any questions about the goods you receive,
please scan the code to enter our customer service system. Enjoy our global 24-hour online
after-sales service.
C
M
Y
CM
MY
CY
CMY
K

Before using, please read this "SAFETY PRECAUTIONS" carefully to ensure proper operation.
Following "SAFETY PRECAUTIONS" is of great help to your use of this massage chair correctly.
To clearly indicate the degrees of danger and damage, the accidents caused by incorrect use are classified
into "WARNING1' and "FORBIDDEN". Instructions marked as follows should be strictly followed.
Patients with serious hyperostosis
Swollen lump and patient thrombosis
Patients with serious heart conditions
Pregnant Women
People that consume large amounts of alcohol
People with diabetes
People suffering from high fever
Patients with malignant tumors or malignant abscesses
People with distorted joints
People with serious skin conditions
People with spinal injuries
All people should consult a physician and exercise care when operating this system
Minors under 16 years or people unable to control their behavior, such as mental patients, people with
paralysis, etc.
Should not be allowed to operate the massage chair.
Use this appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
Never operate this chair if it has a damaged cord or plug.
Keep the cord away from heated surfaces.
Please empty pockets and remove all your arm Jewellery and watch before using this chair.
Do not operate where aerosol (spray) products are being used.
To disconnect, turn all controls to the off position, then remove plug from outlet.
Connect this appliance to a properly grounded outlet only. See Grounding Instructions.
Do not remove the back cushion to modify roller mechanism.
Do not remove the bottom seat to modify actuators.
Keep the cord out of heavy traffic area.
Always unplug the power cord from the electrical outlet immediately after use.
Do not operate any equipment with damaged parts.
Any other use not recommended by the manufacturer may cause electrical shock or injury.
Do not touch or re-wire the wires connected to the master-box.
Do not attempt to repair or adjust any electrical or mechanical functions on this unit.
Doing so will void the warranty.
Do not put your hands or head under the chair
When using the massage chair, ascertain that the footrest is in the lowest position.
Do not allow children to play near the chair especially during operation
Do not leave mobility impaired or speech impaired people alone in chair
Do not place or stock this chair near damp places such as swimming pools or bathrooms
Do not presses massage rollers by force
Do not stand on the chair or put heavy items on the chair
Do not use in an environment that is dusty, greasy, or lack of oxygen
C
M
Y
CM
MY
CY
CMY
K

Do not place near steam oven, open fire, or heat
Wear suitable clothing, do not massage with bare skin
Do not place it directly in the sun.
Do not use electric blanket while using the massage chair
Do not use it outdoors
Do not use while smoking
Do no use immediately after meals
Do not sit on the back cushions, armrest, or legs
Don't use the massage chair when your body is wet or moist as it can result in electrical shock
Do not operate with more than one person
Don’t use when using head ornamentation as it can result in injury
Do not stumble over electrical wires or connections
Before maintenance, please pull out power plug. In addition,please do not insert or unplug the power plug
with damp hands, to avoid electric shock.
When the massage chair is not in use, please switch off power and remove the plug from socket.When
power is off, please cut off power supply immediately and pull out the power plug from socket.
Please avoid Massaging after drinking or when you are not feeling well.
Do not massage the head, elbow joints, knees, chest, abdomen, etc. directly on the massage ball.
Do not damage the power cord; this may result in electric shock or mechanical failure. Please contact the
service center for a detailed inspection.
Specication Label
Power Supply Box
Wheels
Power Supply Socket Electrical Fuse
Power Switch
Pillow
Backpad
Waist Heater
Armrest
Sitting cushion
Footrest
Armrest Air Massage Unit
Shoulder Units
Remote Control
C
M
Y
CM
MY
CY
CMY
K

10
7
1
2
4
5
6
10
9
8
3
Shoulder Air Massage Unit
Remote Control
Armrest Air Massage Unit
Seat Air Massage Unit
Calf Air Massage Unit
Foot Air Massage Unit
Back massage track
Waist Heater
Slide Rail
Foot Roller Massage Unit
Auto mode
Kneading
Knocking
Back Intensity
Neck
Neck Intensity
Air Auto
Air Shoulder
Air Arm
Air Hip
Air Calf
Air Intensity
Massage Up Neck Up Heater Foot Roller Back Rise
Massage Down Neck Down Zero·G Foot Intensity Back Down
Select Auto massage mode
Adjust the reclining angle
1.Power:when the unit is turned on it will automatically start to massage.In automatic massage modes
intensity and strength cannot be adjusted. If you would like to adjust intensity and strength please select
a specic area. such as: arm , foot, or shoulders. Press “Power” to switch time from 15/20/25/30 Press
Power button for 2 seconds to turn off massage chair.
2.Press "AUTO" to switch six modes:We have six Automatic modes,press "AUTO" to switch six modes.
3.Auto massge mode will stop automati-cally after 15/20/25/30 minutes.
Adjust the angle between backrest and footrest.
Put footrest extend forward to suit taller individuals.
Leg extension settings
C
M
Y
CM
MY
CY
CMY
K

On/Off: Press power button to turn on the chair or adjust time frame,
press for more than 2 second to turn off.
Auto mode
Kneading
Knocking
Back Intensity
Neck
Neck Intensity
Air Auto
Air Shoulder
Air Arm
Air Hip
Air Calf
Air Intensity
Massage Up
Neck Up
Heater
Foot Roller
Back Rise
Massage Down
Neck Down
Zero·G
Foot Intensity
Back Down
Auto mode switch
Foot Roller switch / Long press for 5 seconds to clear the Bluetooth connection
Air auto mode switch
Shoulder airbag switch
Arm airbag switch
Hip airbag switch
Calf airbag switch
Back kneading switch
Back knocking switch
Adjust the massage intensity of back rollers
Adjust the massage intensity of foot rollers
Adjust the back down
Adjust the back rise
Adjust the massage intensity of neck rollers
Adjust the intensity of the airbag
In manual mode adjust massage up
In manual mode adjust massage down
In manual mode adjust neck up
In manual mode adjust neck down
Make the chair into the zero-G mode
Turn on the waist and leg heating function
Neck massage switch
Auto mode
Kneading
Knocking
Back Intensity
Neck
Neck Intensity
Air Auto
Air Shoulder
Air Arm
Air Hip
Air Calf
Air Intensity
Massage Up Neck Up Heater Foot Roller Back Rise
Massage Down
Neck Down Zero·G Foot Intensity Back Down
C
M
Y
CM
MY
CY
CMY
K

By selecting a single massage area, auto massage will stop.
You can turn on a single massage area, or multiple areas.
This allows you to give yourself a complete customizable massage.
You can also adjust the strength of the air bags and intensity of the rollers.
Massage manual function selection
Airbag massage system function selection
Auto mode
Kneading
Knocking
Back Intensity
Neck
Neck Intensity
Air Auto
Air Shoulder
Air Arm
Air Hip
Air Calf
Air Intensity
Massage Up
Neck Up Heater Foot Roller Back Rise
Massage Down
Neck Down Zero·G Foot Intensity Back Down
Our product is designed with Bluetooth audio connection function.It can play music through connect with smart
phone,tablet computer or other audio devices.
1. Open mobile-phone/ipad/computer BLUETOOTH capabilities,and access to the search state, your device will
automatically search neighboring BLUETOOTH devices.
2. In a few seconds,our massage chair name will show up under the device list,select massage chair name,enter the
password“9999”to complete the connection.
3. Long press the "foot roller" button for 5 seconds to clear the Bluetooth connection on remote control.
How to use:
MUSIC SYSTEM
Real Relax
2:04
C
M
Y
CM
MY
CY
CMY
K

PREPARATION
BEFORE USING
1
2
Step 1: Unpack the two packagesTake out the main
body, armrest fromthe carton carefully.
MAIN BODY Pillow
Pillow
ARMREST
CUSHION
This model is divided into packaging.After dismounting the package, carefully remove the Massage chair and install
it according to the instructions.(just plug in the power cord to use).
INSTALLATION STEPS
First, lift the backrest,When you hear a click,the backrest is installed.
step:1
1
2
1
C
M
Y
CM
MY
CY
CMY
K

step:2
step:3
Iinstall the hook to mainbody.
Connect the trachea and power cord by color.
2
3
4
Install the botton hook to the seat.
Fasten the armrest with screw.
The chair pad is attached at the top witha zipper.
Connect the cushion wire to the main unit.
5
6
7
C
M
Y
CM
MY
CY
CMY
K

Connect the pillow to the main unit with velcro.
First
Second
Fix the cushion to the main unit.
8
9
CAUTION
Before switching on the chair, please make sure there is no damage on the power wire
and other exposed wires.
Make sure the power switch is off before the chair is connected to electricity.
CAUTION
Don' t move it when there is people in it.
Don't use the armrest while moving the chair, only hold the moving holder in the back
and front.
There are moving rollers at the bottom of the chair.
Raise the back to the highest point.
Switch off and unplug the chair.
Lift the front part of the chair as shown in the figure (one person raises the front part via holding moving
holder, another person pushes the chair when holding the top of the chair), make wheels move.
12
1.Plug the power cord into three core socket of good grounding.
2.Press the power switch on the bottom of massage chair.
C
M
Y
CM
MY
CY
CMY
K

Before using, please tidy up well the cables to avoid twining or damage When the whole chair makes
slide movement forward or backward to original position, please check first whether there are kids,pets
or any other objects to avoid accidents.Please put carpet or other pad under the massage chair,in order
to avoid any unpredictable impression on the floor.
CAUTION
(1) Place a massage chair where there is enough space for the back of the chair to recline and the footrest to rise.
(2) Make sure that there is at least 50 cm in the back of the massage chair and at least 50 cm in front of the
massage chair.ln order to prevent from signal interference, please keep at least 1m away from the TV, radio and
other video and audio devices.
Greater than or equal to 50cm Greater than or equal to 50cm
PLEASE LEAVE THE SPACE AROUND THE MASSAGE CHAIR WHEN PREPARING THE MASSAGE
Keep the massage chair away from damp places (for example: bathroom) to avoid electric leakage
Keep the massage chair away from high temperatures sources (for example: stove) to avoid fire or
damage to leather material
Please power off the chair and unplug from power the supply socket after using, disconnect the controller
and store carefully.
Please power off the chair and unplug from the power supply socket when the chair is not in use, to avoid
children to start the chair accidentally
Please store well the chair if it is not in use for a long time.
Do not dismount the back of the chair
Keep the massage chair free of dust
Cover the chair with a dust-free cloth to prevent dust from collecting
Do not store in a hot, humid, damp place or in direct sunlight or heat
Do not store in an overly cold place
This product must be grounded. If it should malfunction or break down, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an
equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
Danger - Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not
modify the plug provided with the product - if it will not fit the outlet; have a proper outlet installed by a qualified
electrician.
Before cleaning unplug from electrical source to avoid shock
Clean the cloth surface with neutral detergent or a special mild detergent for cloth.
Dust can be cleaned off with a damp cloth or mild detergent and air dry.
Do not spray pesticide on the device.
Specified cleaner can be used on the leather, plastic, and dried with a cloth
Do not use a damp cloth on the electronic components which can cause shock and damage
The leather covers (headrest, seat cushion, foot cushion) can be removed for cleaning
C
M
Y
CM
MY
CY
CMY
K

During daily use, please check whether the following phenomenon exist: Scorched smell When touch the wire, the
power is on, but sometimes off The power supply cord is hot Other abnormal phenomenon
CAUTION
If problems happen above, please turn off power supply and contact the distributor or manufacturerfor
assistance.
KIND REMINDING
Note : Do not dismantle the produce by yourself, and our company shall shoulder no responsibility to the
damage of the product or the inquiry of people caused by improper use. Thanks for your cooperation !
TROUBLESHOOTING GUIDE
Problems/Issues Possible Cause Trouble Shooting Method
Sounds like tapping or hum sounds
Suddenly stops working
Sounds from air pump,
motor or other mechanical parts
Normal phenomenon
Does not work after power up
1. Power switch is not turned on
2. Bad connection between plug
and socket
3. Massage remote is not turned on
4. Have broken power wire plug
5. Bad fuse
6. Control unit for functioning properly
1. Turn power switch on
2. Connection power cord again
3. Press power button on remote
4. Contact professional technician
5. Replace fuse
6. Contact professional technician
Abnormal sounds suddenly
while working
Maybe from over working the
massage chair
1.Cut down usage
2. Contact professional technician
Can not recline the chair Obstruction-be sure that the chair is
allowed enough room to fully recline
Stop chair opearion, and
move obstruction
can not restore position after
reclined
Problem on electric motion pole or
plug under bad connection
Contact professional technician
1. Bad power connection
2. Auto program timers is up
1. Unplug and reinsert power cord
to he chair
2. Normal
Roller height changes Rollers work alternately Normal phenomenon
FAVOR-03 ADV
Rated Voltage : 110 V
Rated Frequency : 60 Hz
Rated Power : 100 W
Safety Design : Class I
N.W : 102.6 LB 32.6 LB
G.W : 123.5 LB 44.7 LB
MEAS : 45.7" * 28" * 27" 45.7" * 29.5" * 10.8"
Manufacturer Reserves The Right To Make Changes To Informations Published In This Document,
Including Without Limitation Specifications And Product Descriptions, At Any Time And Without Notice.
For any inquiries or quality-related issues concerning our products, please send an email to service@
realrelaxmassage.com, we will respond to you as soon as possible and give you an appropriate solution
(refund or replacement).
Contact Us
www.realrelaxmassage.com
USA: (800) 513 - 5727
Real Relax inc.
C
M
Y
CM
MY
CY
CMY
K
