RECKMANN TTS User manual

www.reckmann.com
Instructions for use
Titanium Top swivel for torsional headstays
TTS

Pos: 2 /ZINDEL/D okument/Copyr ight Reckmann @ 1\mod_14673585624 09_6.docx @ 1720 5 @ @ 1
=== Ende der Liste für Textmar ke Copyright = ==
Reckmann Yacht Equipment GmbH
Siemensstr. 37-39
25462 Rellingen
Germany
Tel. [phone]
Fax.[phone]
[e-mail]
www.reckmann.com
Revised: 2021-09-09
© Reckmann Yacht Equipment GmbH
Siemensstr. 37-39
25462 Rellingen
Germany

Inhaltsverzeichnis
TTS 2021-09-09 3
1Packing list .........................................................................................................4
2About this manual .............................................................................................5
2.1 Introduction .....................................................................................................................5
2.2 Display conventions ........................................................................................................5
3Safety......................................................................................................................6
3.1 Intended use ..................................................................................................................6
3.2 Information for safe use ..................................................................................................6
3.3 Dangers of improper use ................................................................................................6
3.4 Safety instructions for maintenance ...............................................................................7
4Design and function...........................................................................................8
4.1 TTS-XL/TOG .....................................................................................................................8
4.2 TTS-X/TOG ....................................................................................................................8
5Inspection and service .....................................................................................9
5.1 Service and repair .........................................................................................................9
5.2 Weekly inspection .........................................................................................................9
5.3 Trimonthly functional test ..............................................................................................9
5.3.1 Functional test without load ............................................................................................. 9
5.3.2 Functional test under load ................................................................................................9
5.4 Triannual service .........................................................................................................10
5.5 Storage .......................................................................................................................10
6Disposal ..........................................................................................................10
7Technical data ...............................................................................................11
8Test log ..........................................................................................................12

Packing list
TTS
2021-09-09
4
1 Packing list
Reckmann order number:
Date: Customer order number:
Dealer: Customer:
complied by:
___________________________________________
on: _______________ ___________________________________________
signature
Pos: 5 /ZINDEL/D okument/headline_ Über diese Be triebsanleitung @ 1\mod_14004 98832886_6.doc x @ 9823 @ 1 @ 1
Type
☐ TTS-2L/TOG
☐ TTS-3L/TOG
☐ TTS-4L/TOG
☐ TTS-2/TOG
☐ TTS-3/TOG
☐ TTS-4/TOG
☐ TTS-5L/TOG
☐ TTS-7/TOG
☐ TTS-7L/TOG
☐ TTS-6/TOG
☐ TTS-6L/TOG
☐ TTS-5/TOG

About this manual
5
2021-09-09
TTS
2 About this manual
Pos: 6 /ZINDEL/D okument/Zielgrupp e Topwirbel @ 1\mod_15154188539 49_26.doc x @ 18641 @ 2 @ 1
2.1 Introduction
These instructions are intended for owners and users of a top swivel listed on the packing list.
Sailing skills are required for use. Inexperienced persons on board must be trained and supervised
by an experienced person on board.
Pos: 7 /ZINDEL/Doku ment/Darste llungskonvention en @ 1\mod_1400502 131053_26.doc x @ 9834 @ 2 @ 1
2.2 Display conventions
Warnings are specially indicated:
Warning
'Warning' is used to indicate information which may lead to serious injury or death if not followed.
Caution
'Caution' is used to indicate information which may lead to minor or moderate injury if not followed.
Notice
'Notice' is used to indicate the possibility of material damage.
Pos: 8 /ZINDEL/R ollreffanlage n/Sicherheit/ headline_Sicherhei t @ 1\mod_14005 06586530_26.doc x @ 9845 @ 1 @ 1

Safety
TTS
2021-09-09
6
3 Safety
Pos: 9 /ZINDEL/ Topwirbel/Sic herheit/Bestimmun gsgemäße Verwendung Topwirbel @ 1\mod_151542162 0061_26.docx @ 18647 @ 2 @ 1
3.1 Intended use
The top swivel is used to attach the upper end of the stay and the sail. It serves as a freely rotating
counter bearing for the drive at the lower end of the stay. The top swivel is designed for use with
textile stays (PBO, carbon). When rolling, the safe working load may not be exceeded. See
Technical Data.
Repairs or changes to the top swivel must not be carried out.
Do not use the top swivel:
for lifting people
for attaching objects other than the stay with a fore sail
Pos: 10 /ZINDEL/ Topwirbel/Sic herheit/Sicher heitsinformatione n @ 1\mod_1515477 726425_26.doc x @ 18656 @ 2 @ 1
3.2 Information for safe use
•Read these instructions before using the top swivel.
•Keep these instructions in a safe place so that they are always available when required.
•In addition to these instructions for use, the owner's manual and manuals for other on-board
equipment must be observed.
Pos: 11 /ZINDEL/ Topwirbel/Sic herheit/Sicher heitshinweise Bedi enung Topwirbe l @ 1\mod_1515480 496665_26.doc x @ 18661 @ 2 @ 1
3.3 Dangers of improper use
Overloading of the top swivel can lead to breakage. Persons may be seriously injured or killed.
• Observe the maximum loads in the technical data.
• Check the top swivel for damage before each use. Do not use the top swivel if it is damaged.
Incorrect connection or inadequate securing of the connection may lead to serious injury. When
hoisting, the top swivel may start to swing. This may also lead to injury.
•Sailing skills are required for use. Inexperienced individuals on board must be trained and
supervised by a trained individual.
•Always check the pin lock or Velcro tape carefully.
•Always exercise prudence on board.
Fingers may be sheared off in the pin holes.
•Never insert a finger into a pin hole when connecting the top swivel.
Pos: 12 /ZINDEL/ Topwirbel/Sic herheit/Sicher heitshinweise I nstandhaltung @ 1\mod_15154805051 41_26.docx @ 186 66 @ 2 @ 1
Pos: 13 /ZINDEL/ Rollreffanlag en/Aufbau und Funk tion/headline_A ufbau und Funk tion @ 1\mod_14 00762844571_26. docx @ 9966 @ 1 @ 1
Pos: 9 /ZINDEL/ Topwirbel/Sic herheit/Bestim mungsgemäße Ver wendung Topwirbel @ 1\mod_15154 21620061_26.doc x @ 18647 @ 2 @ 1
Warning
Disregarding the safety regulations may lead to serious injury or death if not followed!

Safety
7
2021-09-09
TTS
Pos: 13 /ZINDEL/ Rollreffanlagen/ Aufbau und Funk tion/headline_A ufbau und Funk tion @ 1\mod_14 00762844571_6. docx @ 9964 @ 1 @ 1
Improper maintenance may result in serious injury, including death.
• Perform all inspections at the intervals specified in these instructions. Do not use the top swivel
if it is damaged.
• The top swivel does not require any maintenance by the end user. It may not be disassembled.
• Repair work may only be carried out by the manufacturer or an authorised workshop.
3.4 Safety instructions for maintenance
Warning
Disregarding the safety regulations may lead to serious injury or death if not followed!

Design and function
TTS
2021-09-09
8
4.2 TTS-X/TOG
Top: Eye for toggle to be connected to the
mast fitting
Bottom: Pin/fork connection to the upper eye
of the stay
1Eye
2Protective sleeve made of hard rubber
3Pin
4 Design and function
4.1 TTS-XL/TOG
Top: Eye for toggle to be connected to the
mast fitting
Bottom: Long pin with bobbins for lashed
sail head
1Eye
2Protective sleeve made of hard rubber
3Long pin with bobbins
4 Velcro
Pos: 19 /ZINDEL/ Topwirbel/Aufbau und Funktion/A ufbau TTS- x/2:1 @ 2\mod_1515 490651024_6.doc x @ 18685 @ 2 @ 1
1
2
3
4
2
1
3

Inspection and service
TTS 2021-09-09 9
5 Inspection and service
Pos: 22 /ZINDEL/ Topwirbel/Inspe ktion/Service und Reparatur @ 2\mod_1515509717 006_26.doc x @ 18827 @ 2 @ 1
Pos: 23 /ZINDEL/ Topwirbel/Inspe ktion/Wöchent liche Inspekti on Topwirbel @ 2\mod_15155091069 49_26.docx @ 18817 @ 2 @ 1
Pos: 24 /ZINDEL/ Topwirbel/Inspe ktion/Monatlic he Inspektion Topwirbel @ 2\ mod_1515511101280 _26.docx @ 1883 1 @ 233 @ 1
5.1 Service and repair
There is no maintenance to be performed by the end user. With the exception of replacing of the
Velcro strap, there are also no repairs that can be carried out by the end user. If defects are found
during inspection, send the top swivel to the manufacturer or to an authorised service partner. Do
not use the top swivel any longer.
Pos: 23 /ZINDEL/ Topwirbel/Inspe ktion/Wöchent liche Inspek tion Topwirbel @ 2\mod_1515509 106949_26.doc x @ 18817 @ 2 @ 1
5.2 Monthly inspection
•Check the shaft sealing ring (top) and the sealing screw at the bottom of the fork (if present) for
tightness.
• TTS-xL/TOG: Check the function and visual appearance of the Velcro tape.
•Check the fasteners and securing devices for correct seating and wear (screws, pins, quick-
release devices, strops, toggle).
•Check the condition of visible plastic parts for ageing due to UV radiation.
Pos: 24 /ZINDEL/ Topwirbel/Inspe ktion/Monatlic he Inspektion Topwirbel @ 2\mod_151551110 1280_26.docx @ 18831 @ 233 @ 1
5.3 Half-yearly functional test
Also carry out functional tests before longer trips and regattas.
5.3.1 Functional test without load
• Release the stay as far as possible and turn the top swivel back and forth by hand with the sail
rolled up and the sheet separated.
Especially when cold, medium to high resistance is acceptable. No rattling or snagging of the
bearing should be felt.
5.3.2 Functional test under load
Record the result of the functional test in the table at the end of these instructions.
1. Pretension the stay. Do not exceed the safe working load of the top swivel. For information on
the safe working load, see Technical Data.
2. With the sail rolled up and the sheet separated, actuate the drive unit until the top swivel begins
to rotate.
3. Actuate the drive unit in the opposite direction. Observe how many times the drive unit turns
before the top swivel begins to rotate. Enter the result in the table at the end of these
instructions.
4. Actuate the drive unit again in the opposite direction. Observe how many times the drive unit
turns before the top swivel begins to rotate. Enter the result in the table.
If the number of turns increases under similar conditions, send the top swivel to the manufacturer or
an authorised service partner.

Inspection and service
102021-09-09 TTS
5.4 Triannual service
Send the top swivel to the manufacturer or an authorised service partner. As part of the service,
sealing elements, grease and Velcro strap (if present) will be replaced. In addition, the bearings
will be checked and replaced if necessary.
Pos: 26 /ZINDEL/ Topwirbel/Lager ung/Lagerung Topwirbel @ 2\mod _1515565339248_26. docx @ 18853 @ 2 @ 1
5.5 Storage
If not used for an extended period of time, store the top swivel in a dry room, protected from
direct sunlight.
Pos: 27 /ZINDEL/ Topwirbel/Entsor gung/Entsorgun g Topwirbel @ 2\mod_15155652726 66_26.docx @ 188 48 @ 1 @ 1
6 Disposal
'Caution' is used to indicate information which may lead to minor or moderate injury if not followed.
Notice
Risk of damage to the environment
The top swivel contains lubricants that may cause serious environmental damage. Dispose of
lubricants in an environmentally sound manner in accordance with local regulations.
The top swivel contains parts made of
•Titanium
•Stainless steel
• Steel
• Plastic
Dispose of the parts of the top swivel separately by material in accordance with local regulations.
Pos: 28 /ZINDEL/ Rollreffanlagen/ headline_Techni sche Daten @ 1\mod_1416391342 849_26.docx @ 11210 @ 1 @ 1
Pos: 8 /ZINDEL/R ollreffanlage n/Sicherheit/ headline_Sicherhei t @ 1\mod_14005 06586530_26.doc x @ 9845 @ 1 @ 1
The number of turns also depends on other factors.
•The stay may twist more due to ageing. Therefore, if the number of turns increases,
always check the condition of the stay.
•At low temperatures, the stay may twist more before the top swivel begins to rotate.
Notice

Technical data
11
2021-09-09
TTS
7 Technical data
Pos: 29 /ZINDEL/ Topwirbel/Techni sche Daten/ TD_TS @ 2\mod_15155 67551452_26.doc x @ 18859 @ 2 @ 1
TTS-x/TOG
A
L
D G
W
L
D
R
W
G
d
B A
TS-xL/TOG

Test log
TTS
2021-09-09
12
8 Test log
Date Temperature
Twisting of the stay
during winding
(number of turns)
Twisting of the
stay during
unwinding
(number of turns)
Inspector

Notes
