INSTALLATION INSTRUCTIONS
PRODUCT: LED SMD YELLOW FLOODLIGHTS
PRODUCT CODES: FLSMD50Y-1, FLSMD100Y-1, FLSMD150Y-1,
FLSMD200Y-1
PAGE 4 (BACK PAGE)PAGE 1 (FRONT PAGE)
redarrowelectrical.co.uk
INSTALLATION INSTRUCTIONS -
1. ENSURE THERE IS ADEQUATE FREE AIR CIRCULATION
OF AT LEAST 100MM AROUND THE LUMINAIRE.
ALL LUMINAIRES RUN HOT. IT IS THE INSTALLER’S
RESPONSIBILITY TO CONSIDER ANY FIRE RISKS AND TAKE
APPROPRIATE PRECAUTIONS.
2. THE NEAREST ILLUMINATED SURFACE MUST BE AT LEAST
0.5M FROM THE FRONT OF THE FITTING.
3. DO NOT USE IF THE GLASS IS BROKEN.
REPLACE THE LUMINAIRE
4. DRILL TWO HOLES ACCORDING TO THE HOLES ON THE
BRACKET, ON A WALL OR SIMILAR HARD SURFACE.
5. FIX THE BRACKET TO THE WALL OR SIMILAR HARD
SURFACE WITH SUITABLE FIXINGS (NOT INCLUDED).
6. CONNECT THE CABLE CORRECTLY TO THE SUPPLY,
OBSERVING THE COLOUR-CODING SHOWN TO THE RIGHT.
ENSURE ALL ELECTRICAL CONNECTIONS ARE TIGHT WITH
NO LOOSE STRANDS.
L = Brown
= Green/ Yellow
N = Blue
ADDITIONAL INFORMATION
• PLEASE NOTE THIS IS AN IP65 RATED PRODUCT, TAKE CARE
NOT TO BREAK ANY SEALS AS THIS WILL AFFECT IT’S WATER
RESISTANT RATING.
• DO NOT MODIFY THIS PRODUCT. ANY MODIFICATION TO THIS
FITTING WILL VOID THE WARRANTY.
• RED ARROW WILL NOT TAKE ANY RESPONSIBILITY
FOR ANY PRODUCT DAMAGES CAUSED BY MOUNTING
PROCEDURES WHICH ARE NOT IN ACCORDANCE WITH
THESE INSTRUCTIONS.
• THESE FITTINGS COMPLY TO CE AND UKCA STANDARDS.
• POWDER COATED FINISH
INS/SITE/0010/FLSMDXXY-1/V2
G U A R A N T E E
This product is guaranteed for a period of 3 years from the date of purchase.
The guarantee is invalid in the case of improper use, tampering, removal of the
Q.C. date label, installation in an improper working environment or installation
not according to the current edition of the I.E.E. Wiring Regulations (BS7671).
The guarantee is also invalidated if the luminaire has been insulation tested.
Should this product fail during the guarantee period it will be replaced free
of charge, subject to correct installation and return of the faulty unit. We
do not accept responsibility for any installation costs associated with the
replacement of this product. Your statutory rights are not affected. We reserve
the right to alter specifications without prior notice.
M A I N T E N A N C E
• This fitting will require routine cleaning if used in adverse (dust, paint,
welding, oils etc) environments. Do not use solvents, aggressive
detergents or abrasives.
• When this fitting comes to the end of it’s life or you choose to replace it,
please do not dispose of it with your general waste. Please recycle where
the facilities exist, check with your local authority for suitable options.
• The LEDs and driver in this product can be replaced at the end of life. This
must be carried out by a professional, competent person. Alternatively,
and for best results, we would recommend replacement is done by
Red Arrow (chargeable service).

PRODUCT: LED SMD YELLOW FLOODLIGHTS
PRODUCT CODES: FLSMD50Y-1, FLSMD100Y-1, FLSMD150Y-1,
FLSMD200Y-1
Automatic Circuit
Breaker Type B6 B10 B13 B16 B20 C10 C13 C16 C20
Rated Current 6A 10A 13A 16A 20A 10A 13A 16A 20A
Installation 1.5 1.5 1.5 1.5 2.5 1.5 1.5 1.5 2.5
FLSMD50Y-1 610 16 20 24 14 20 28 34
FLSMD100Y-1 35810 12 710 14 17
FLSMD150Y-1 2357857911
FLSMD200Y-1 124564578
MAXIMUM FITTINGS PER CIRCUIT
INSTALLATION INSTRUCTIONS
T: 0800 195 0006
[email protected]
Red Arrow Electrical Distribution
Cortonwood Drive, Brampton,
Barnsley, S73 0UF
redarrowelectrical.co.uk
PAGE 1 (FRONT PAGE)
BOX CONTENTS -
1x LED SMD Yellow Floodlight
SPECIFICATION
Dimensions:
50W: L: 310 x W: 310 x D: 65mm
100W: L: 330 x W: 320 x D: 90mm
150W: L: 365 x W: 370 x D: 94mm
200W: L: 425 x W: 410 x D: 110mm
Material: Metal
Working
Temperature: -200C - 400C
50-
200
WATT
LED 6500K
86-
264V
IP65 3
YRS
GUARANTEE
4000-
16000lm IK07
SAFETY WARNING
• The installation should be carried out
by a qualified electrician in compliance
with the current edition of the IEE
Wiring Regulations.
• Prior to installation, carry out the
necessary risk assessment considering
the people who could be at risk, the
level of risk and the precautions
required to control the risk
• Ensure that the circuit supply is
isolated either by the circuit supply
fuse being removed or the applicable
circuit breaker being turned off before
installation or any maintenance.
• Check the total load on the circuit
ensuring the luminaire does not exceed
the rating of the circuit cable, fuse or
circuit breaker.
• Long-term use and voltage fluctuations
can reduce the life span of the fitting.
• If the fitting incorporates control gear,
ensure careful sizing to avoid instances
of nuisance tripping of the protective
device used in the installation.
• Follow the provided installation
instructions, using the fixings supplied
or recommended.
• Keep out of reach of children.
