Redline Communications AN80IE User manual

70-00072-01-07 Proprietary Redline Communications © 2010 Page 1 of 106 Sept 18, 2008
&
AN-80i System
PTP & PMP
User Manual

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 2 of 106 Sept 18, 2008
Copyright Information
All rights reserved Sept 18, 2008. The information in this document is proprietary to
Redline Communications Inc. This document may not in whole or in part be copied,
reproduced, or reduced to any medium without prior consent, in writing, from Redline
Communications Incorporated.
Contact Information:
Redline Communications Inc.
302 Town Centre Blvd. Suite 100
Markham, ON
Canada L3R 0E8
Web site: http://www.redlinecommunications.com
Sales Inquiries:
North American [e-mail]
Toll-free sales 1-866-633-6669
International [e-mail]
Support: www.redlinecommunications.com/support/support_portal.html
Document Control:
70-00072-01-06-AN-80i_User_Manual-20080918c.doc
Disclaimer
The statements, configurations, technical data, and recommendations in this document
are believed to be accurate and reliable, but are presented without express or implied
warranty. Additionally, Redline makes no representations or warranties, either expressed
or implied, regarding the contents of this product. Redline Communications shall not be
liable for any misuse regarding this product. The information in this document is subject
to change without notice.

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 3 of 106 Sept 18, 2008
TABLE OF CONTENTS
1Important Safety & Service Notices......................................................9
1.1 Safety Warnings ......................................................................................9
1.2 Important Warning Symbols...................................................................10
1.3 Important Service Information................................................................10
1.4 Lightning Protection...............................................................................10
1.5 Deployment in the USA -- FCC Notices .................................................11
1.5.1 FCC & IC Notice ................................................................................11
1.5.2 Installation and Operation ..................................................................12
1.5.3 FCC Power Settings...........................................................................12
1.6 UL Information.......................................................................................12
1.7 Product Information................................................................................13
2System Overview.................................................................................14
2.1 Ethernet Port..........................................................................................15
2.2 RF Port..................................................................................................15
2.3 Mounting Brackets.................................................................................15
2.4 Grounding Connection...........................................................................15
2.5 Indoor Power Block (PoE Power Adapter) .............................................16
2.5.1 AC Power Adapter .............................................................................16
2.5.2 DC Power Adapter.............................................................................16
2.6 Antenna Alignment.................................................................................17
2.6.1 Web Page Alignment .........................................................................17
2.6.2 Audible Alignment..............................................................................17
3Web Interface - PTP .............................................................................18
3.1 System Login.........................................................................................18
3.2 System Menu.........................................................................................19
3.3 System Information................................................................................20
3.3.1 General Information ...........................................................................20
Dashboard.........................................................................................20
3.3.2 General Information ...........................................................................23
General..............................................................................................23
Ethernet.............................................................................................24
Wireless.............................................................................................24
3.4 System Status........................................................................................25
General information ...........................................................................25
Ethernet LAN Statistics......................................................................26
Wireless Statistics..............................................................................26
Controls .............................................................................................26
3.5 System Logs Screen..............................................................................27
3.6 System Configuration Screen.................................................................30
Ethernet Configuration.......................................................................30
Wireless Configuration.......................................................................33
Controls .............................................................................................38
3.7 Users Management................................................................................39
3.8 AN-80i Product Options Screen.............................................................41
3.9 Upload Software ....................................................................................42

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 4 of 106 Sept 18, 2008
3.10 SNMP Settings Screen ..........................................................................43
3.10.1 Change SNMP Community................................................................44
3.10.2 Change SNMP Trap Configuration.....................................................45
3.11 Spectrum Sweep....................................................................................46
4PMP Operation.....................................................................................48
4.1 Introduction............................................................................................48
4.2 PMP Menu.............................................................................................48
4.3 Functional Description ...........................................................................49
4.3.1 Overview............................................................................................49
4.3.2 Minimum Setup Requirements...........................................................50
4.3.3 Packet Classification..........................................................................50
4.4 PMP Screens.........................................................................................51
4.4.1 Configuration Screen .........................................................................51
4.4.2 Link Screen........................................................................................52
4.4.3 Group Screen.....................................................................................53
Group.................................................................................................53
Wireless Traffic Parameters...............................................................54
4.4.4 Connection Screen.............................................................................55
Connection Configuration...................................................................55
Wireless Traffic Parameters...............................................................56
4.5 Browse Screens.....................................................................................57
4.5.1 Links Screen......................................................................................57
4.5.2 Groups Screen...................................................................................58
4.5.3 Connections Screen...........................................................................59
4.6 Statistics Screens ..................................................................................60
4.6.1 Link Statistics.....................................................................................60
4.6.2 Group Statistics ................................................................................61
4.6.3 Connection Statistics..........................................................................62
4.6.4 System Status - PMP Wireless Statistics ...........................................63
4.7 Quick Configuration Guide.....................................................................63
4.7.1 Configure Pass-Through Operation....................................................64
Step 1: Create New Link for Each Subscriber ....................................64
Step 2: Create Single Pass-through Group........................................64
Step 3: Create Connections...............................................................64
Step 4: Save Configuration ................................................................65
4.7.2 VLAN Configuration ...........................................................................65
Step 1: Change Group to VLAN Tagged............................................65
Step 2: Change Connections to VLAN Tagged..................................65
Step 3: Save Configuration ................................................................65
5CLI Interface.........................................................................................66
5.1 CLI Command Summary........................................................................66
5.2 Connecting with Telnet ..........................................................................67
5.3 CLI Command Set .................................................................................67
5.3.1 Chgver...............................................................................................67
5.3.2 Clear..................................................................................................68
5.3.3 Del.....................................................................................................68
5.3.4 Enable................................................................................................68

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 5 of 106 Sept 18, 2008
5.3.5 Freq ...................................................................................................69
5.3.6 Generate............................................................................................69
5.3.7 Get.....................................................................................................69
5.3.8 Load...................................................................................................71
5.3.9 Logout................................................................................................72
5.3.10 New ...................................................................................................72
5.3.11 Ping ...................................................................................................72
5.3.12 Reboot...............................................................................................72
5.3.13 Reset .................................................................................................72
5.3.14 Save ..................................................................................................73
5.3.15 Script..................................................................................................73
5.3.16 Set.....................................................................................................73
5.3.17 Show..................................................................................................79
5.3.18 Snmpcommunity................................................................................82
5.3.19 Snmptrap...........................................................................................82
5.3.20 Test....................................................................................................82
5.3.21 Upgrade.............................................................................................83
5.3.22 User...................................................................................................83
5.3.23 Whoami..............................................................................................83
6Diagnostics and Troubleshooting ......................................................84
6.1 Factory Default Settings.........................................................................84
6.2 Procedure to Restore Factory Settings ..................................................85
6.3 Testing and Saving System Parameters................................................86
6.3.1 CLI Interface ......................................................................................86
6.3.2 Web Interface.....................................................................................86
6.4 Status Codes.........................................................................................88
6.4.1 PTP Status Codes..............................................................................88
6.4.2 PMP Status Codes.............................................................................89
7Appendices ..........................................................................................90
7.1 AN-80i Technical Specifications.............................................................90
7.2 AN-80i PoE Power Adapter Specifications.............................................92
7.3 Antenna / Mounting Bracket Matrix........................................................92
7.4 Legacy Products (Not Available to Order)..............................................93
7.5 ETSI Certified Antennas.........................................................................94
7.5.1 3.3 - 3.8 GHz Radio: ETSI Certified Antennas....................................94
7.5.2 5.8 GHz Radio: ETSI Certified Antennas............................................94
7.5.3 5.4 GHz Radio: ETSI Certified Antennas............................................95
7.5.4 5.15 - 5.35 GHz Radio: ETSI Antennas..............................................95
7.6 FCC & IC Certified Antennas.................................................................96
7.6.1 5.8 GHz Radio: FCC & IC Certified Antennas ....................................96
7.6.2 5.4 GHz Radio: FCC & IC Certified Antennas ....................................97
7.6.3 5.25 - 5.35 GHz Radio: FCC & IC Antennas.......................................97
7.6.4 4.94 - 4.99 GHz Radio: FCC & IC Antennas.......................................97
7.6.5 3.650 - 3.700 GHz Radio: FCC & IC Antennas...................................98
7.7 Regional Codes.....................................................................................99
7.8 Security Keys and Certificates .............................................................101
7.9 Security Certificate and Key CLI Commands .......................................102

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 6 of 106 Sept 18, 2008
7.10 Glossary Of Terms...............................................................................104
LIST OF TABLES
Table 1: FCC & IC RF Recommended Safe Separation Distances....................11
Table 2: Wireless Link LED Diagnostics............................................................20
Table 3: Wireless Signal LED Indication............................................................21
Table 4: Wireless Signal LED Diagnostics.........................................................21
Table 5: Ethernet Link/Act LED Diagnostics......................................................21
Table 6: Ethernet 100 LED Diagnostics.............................................................21
Table 7: Ethernet Link/Collision LED Diagnostics..............................................22
Table 8: Web - System Log Messages..............................................................27
Table 9: Web - 802.1p Priority Settings .............................................................31
Table 10: Maximum TX Power Settings (dBm) for AN-80i Radio.......................35
Table 11: Web - Ethernet Status Indication .......................................................37
Table 12: Web - Screens and User Access.......................................................40
Table 13: Web - Default System Users..............................................................40
Table 14: Web - Performing a Spectrum Sweep................................................47
Table 15: PMP - Basic Pass-Through Group Settings.......................................50
Table 16: PMP - Packet Classification...............................................................50
Table 17: PMP Maximum Achievable UBR........................................................52
Table 18: PMP - Basic Pass-Through Group Configuration Settings.................65
Table 19: CLI - Command Summary.................................................................66
Table 20: CLI - Root Mode Commands .............................................................67
Table 21: CLI - chgver.......................................................................................67
Table 22: CLI - clear..........................................................................................68
Table 23: CLI - del.............................................................................................68
Table 24: CLI - enable.......................................................................................68
Table 25: CLI - freq............................................................................................69
Table 26: CLI - generate....................................................................................69
Table 27: CLI - get.............................................................................................69
Table 28: CLI - load...........................................................................................71
Table 29: CLI - logout........................................................................................72
Table 30: CLI - new...........................................................................................72
Table 31: CLI - ping...........................................................................................72
Table 32: CLI - reboot........................................................................................72
Table 33: CLI - reset..........................................................................................72
Table 34: CLI - save..........................................................................................73
Table 35: CLI - script.........................................................................................73
Table 36: CLI - set.............................................................................................73
Table 37: CLI - show .........................................................................................79
Table 38: CLI - snmpcommunity........................................................................82
Table 39: CLI - snmptrap...................................................................................82
Table 40: CLI - test............................................................................................82
Table 41: CLI - upgrade.....................................................................................83
Table 42: CLI - user...........................................................................................83
Table 43: CLI - whoami .....................................................................................83
Table 44: Diag. - Factory Default Settings.........................................................84

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 7 of 106 Sept 18, 2008
Table 45: Diag. - Web Interface Diagnostics......................................................87
Table 46: Diag. - PTP Status Codes..................................................................88
Table 47: Diag. - PMP Status Code Bits............................................................89
Table 48: Diag. - PMP Status Codes.................................................................89
Table 49: Spec. - AN-80i Technical Specifications ............................................90
Table 50: Spec. - AN-80i PoE Power Adaptor Specifications.............................92
Table 51: Spec. - AN-80i Antenna / Mounting Bracket Matrix............................92
Table 52: Spec. - AN-80i Legacy Antenna / Mounting Bracket Matrix................93
Table 53: Spec. - Antenna/Tx Power Setting Combinations for ETSI.................94
Table 54: Spec. - ETSI Certified Antennas: 5.8 GHz Operation.........................94
Table 55: Spec. - ETSI Certified Antennas: 5.4 GHz Operation.........................95
Table 56: Spec. - ETSI Certified Antennas: 5.15 - 5.35 GHz Operation.............95
Table 57: Spec. - FCC & IC Certified Antennas: 5.8 GHz PTP Operation..........96
Table 58: Spec. - FCC & IC Certified Antennas: 5.8 GHz PMP Operation.........96
Table 59: Spec. - FCC & IC Certified Antennas: 5.4 GHz Operation..................97
Table 60: Spec. - FCC & IC Antennas: 5.25 - 5.35 GHz Operation....................97
Table 61: Spec. - FCC & IC Antennas: 4.94 - 4.99 GHz Operation....................98
Table 62: Spec. - Antenna/Tx Power Setting Combinations for FCC.................98
Table 63: Spec. - Regional Identification Codes................................................99
Table 64: Security -- Keys and Certificates......................................................101
Table 65: Security -- Runtime Keys and Certificates........................................102
Table 66: Security -- User Key and Certificate Files.........................................102
Table 67: Spec. - Glossary..............................................................................104

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 8 of 106 Sept 18, 2008
LIST OF FIGURES
Figure 1: Intro - AN-80i Components.................................................................14
Figure 2: Intro - AN-80i with Integrated Antenna................................................15
Figure 3: Intro - Indoor Power-over-Ethernet (PoE) Module - AC Model............16
Figure 4: Intro - Indoor Power-over-Ethernet (PoE) Module - DC Model............16
Figure 5: Web - Login Screen............................................................................18
Figure 6: Web - System Menu...........................................................................19
Figure 7: Web - General Information Dashboard...............................................20
Figure 8: Web - General Information Screen .....................................................23
Figure 9: Web - System Status Screen..............................................................25
Figure 10: Web - System Log Messages...........................................................27
Figure 11: Web - System and Network Configuration Screen............................30
Figure 12: Web - Wireless Configuration Screen...............................................33
Figure 13: Web - Wireless Configuration Screen...............................................34
Figure 14: Web - System Password Screen ......................................................39
Figure 15: Web - Product Options Screen.........................................................41
Figure 16: Web - Upload Software Screen ........................................................42
Figure 17: Web - SNMP Configuration Screen ..................................................43
Figure 18: Web - SNMP Community Configuration Screen................................44
Figure 19: Web - SNMP Trap Configuration Screen..........................................45
Figure 20: Web - Spectrum Sweep Screen........................................................46
Figure 21: Web - Spectrum Sweep Results.......................................................47
Figure 22: PMP - Main Menu.............................................................................48
Figure 23: PMP - Basic Pass-through Group Configuration...............................49
Figure 24: PMP - VLAN Tagged Traffic Example...............................................49
Figure 25: PMP - Wireless Settings...................................................................51
Figure 26: PMP - Link Configuration Screen......................................................52
Figure 27: PMP - Group Configuration Screen ..................................................53
Figure 28: PMP - Connection Configuration Screen ..........................................55
Figure 29: PMP - Links Browse Screen.............................................................57
Figure 30: PMP - Groups Browse Screen..........................................................58
Figure 31: PMP - Connections Browse Screen..................................................59
Figure 32: PMP - Link Statistics Screen.............................................................60
Figure 33: PMP - Group Statistics Screen.........................................................61
Figure 34: PMP - Connection Statistics Screen.................................................62
Figure 35: PMP - System Status Screen ...........................................................63
Figure 36: PMP - Pass-through Only Deployment .............................................64
Figure 37: CLI - Connecting via Telnet ..............................................................67
Figure 38: CLI - Recovering Lost IP Address.....................................................85
Figure 39: Diag: - Saving Parameters in NVRAM..............................................86

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 9 of 106 Sept 18, 2008
Chapter
1
1
1 I Im mp po or rt ta an nt t S Sa af fe et ty y & & S Se er rv vi ic ce e
N
No ot ti ic ce es s
1.1 Safety Warnings
PoE power adapter caution:
Warning to Service Personnel: 48 VDC
Customer equipment including personal computers, routers, etc., must be connected
only to the INPUT (DATA) port on the PoE unit.
Only the outdoors Ethernet interface cable connecting to the AN-80i can be safely
connected to the OUTPUT (DATA & POWER) connector. Connecting customer
premises Ethernet equipment directly to the OUTPUT (DATA & POWER) connector
on the Power-over-Ethernet power adapter may damage customer equipment.
1. Installation of the system must be contracted to a professional installer.
2. Read this user manual and follow all operating and safety instructions.
3. Keep all product information for future reference.
4. The power requirements are indicated on the product-marking label. Do not exceed
the described limits.
5. Use only a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Disconnect
the power before cleaning.
6. Disconnect power when unit is stored for long periods.
7. The AN-80i must not be located near power lines or other electrical power circuits.
8. The system must be properly grounded to protect against power surges and
accumulated static electricity. It is the user’s responsibility to install this device in
accordance with the local electrical codes: correct installation procedures for
grounding the AN-80i, mast, lead-in wire and discharge unit, location of discharge
unit, size of grounding conductors and connection requirements for grounding
electrodes.

&User
AN-80i Manual
70-00072-01-07 Proprietary Redline Communications © 2010 Page 10 of 106 Sept 18, 2008
1.2 Important Warning Symbols
The following symbols may be encountered during installation or troubleshooting. These
warning symbols mean danger. Bodily injury may result if you are not aware of the safety
hazards involved in working with electrical equipment and radio transmitters. Familiarize
yourself with standard safety practices before continuing.
Electro-Magnetic Radiation
High Voltage
1.3 Important Service Information
1. Refer all repairs to qualified service personnel. Do not remove the covers or modify
any part of this device, as this action will void the warranty.
2. Locate the serial numbers and record these on your registration card for future
reference. Use the space below to affix serial number stickers. Also, record the MAC
address located on the AN-80i.
3. Redline does not endorse or support the use of outdoor cable assemblies: i) not
supplied by Redline, ii) third-party products that do not meet Redline's cable and
connector assembly specifications, or iii) cables not installed and weatherproofed as
specified in the Installation Guidelines manual (70-00073-01-XX). Refer to the
Redline Limited Standard Warranty and RedCare service agreements.
1.4 Lightning Protection
WARNING: The following notes are general recommendations for the system. The
wireless equipment should be installed by a qualified professional installer who must
follow local and national codes for electrical grounding and safety. Failure to meet safety
requirements and/or use of non-standard practices and procedures could result in
personal injury and damage to equipment. A direct lightning strike may cause serious
damage even if these guidelines are followed.
All outdoor wireless equipment is susceptible to lightning damage from a direct hit or
induced current from a near strike. Lightning protection and grounding practices in local
and national electrical codes serve to minimize equipment damage, service outages,
and serious injury. Reasons for lightning damage are summarized as:
a) Poorly grounded antenna sites that can conduct high lightning strike energy into
equipment.
b) Lack of properly installed lightning protection equipment that can cause equipment
failures from lightning induced currents.
A lighting protection system provides a means by which the energy may enter earth
without passing through and damaging parts of a structure. A lightning protection system
does not prevent lightning from striking; it provides a means for controlling it and
preventing damage by providing a low resistance path for the discharge of energy to
travel safely to ground. Improperly grounded connections are also a source of noise that
can cause sensitive equipment to malfunction.
A good grounding system disperses most of the surge energy from a lightning strike
away from the building and equipment. The remaining energy on the Ethernet cable
shield and center conductor can be directed safely to ground by using a lightning
arrestor in series with the cable.
