Reed Instruments R5500 User manual

www.REEDINSTRUMENTS.com
Circuit Breaker
Finder/
Receptacle
Tester
Instruction
Manual
R5500
1.800.561.8187[email protected] REED-Direct.ca

2
www.REEDINSTRUMENTS.com
Table of Contents
Introduction ................................................................................................... 2
Product Quality.............................................................................................. 2
Safety ............................................................................................................ 3
Warning
.................................................................................................. 3
Features......................................................................................................... 3
Included......................................................................................................... 3
Specications................................................................................................ 4
Instrument Description .................................................................................. 4
Operating Instructions................................................................................ 5-7
Circuit Breaker/Fuse Finder................................................................... 5-6
Receptacle Wiring Test............................................................................. 6
Wiring Diagram......................................................................................... 6
GFCI Socket Tester .................................................................................. 7
Battery Replacement..................................................................................... 7
Accessories and Replacement Parts ............................................................ 7
Product Care ................................................................................................. 8
Product Warranty .......................................................................................... 8
Product Disposal and Recycling ................................................................... 8
Product Support............................................................................................ 9
Introduction
Thank you for purchasing your REED R5500 Circuit Breaker Finder/
Receptacle Tester. Please read the following instructions carefully before
using your instrument. By following the steps outlined in this manual your
meter will provide years of reliable service.
Product Quality
This product has been manufactured in an ISO 9001 facility and has
been calibrated during the manufacturing process to meet stated product
specications.
1.800.561.8187[email protected] REED-Direct.ca

3
www.REEDINSTRUMENTS.com
Safety
Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
Warning
When this symbol appears, refer to the Operating Instruc-
tions to avoid misuse. This could lead to injury or damage
of the instrument.
This symbol indicates that this instrument offers double
insulation protection.
Features
• Simplyplugthetransmitterintoareceptacleandscanbreakerboxto
identify the circuit
• Detects53-wirereceptaclewiringfaults
• Built-inGFCIreceptaclecheckfunction
• Adjustablesensitivitywheelquicklyidentiesbreaker
• Audible(buzzer)andvisual(LED)indicatorsassistinidentication
Included
• Transmitter
• Battery
1.800.561.8187[email protected] REED-Direct.ca

4
www.REEDINSTRUMENTS.com
Specifications
Voltage Range: 90 to 120V AC
Bandwidth: 47 to 63Hz
PowerSupply: 1x9V
ProductCertications: ETL
OperatingTemperature: 32to104°F(0to40°C)
Operating Humidity: 0 to 85%
StorageTemperature: -4to140°F(-20to60°C)
Dimensions: 4.1x2.2x1.2"(103x56x30mm)
Weight: 3.9oz(110g)
Instrument Description
Circuit Breaker Finder
1. LEDIndicatorLight
2. Sensitivity Adjustment Wheel
3. Battery Compartment
Transmitter
4. GFCITestButton
5. IndicatorLights
ReferenceGuide
6. LEDStatusIndicator
1.800.561.8187[email protected] REED-Direct.ca

5
www.REEDINSTRUMENTS.com
Operating Instructions
Note:Allappliancesorequipmentonthecircuitundertestshouldbe
unplugged in order to avoid erroneous readings.
This instrument will not:
• Indicatequalityofground.
• Detect2hotwiresincircuit.
• Detectacombinationofdefects.
• Indicatereversalofgroundedandgroundingconductors.
Circuit Breaker/Fuse Finder
The transmitter sends a signal through the circuit which is detected by the
receiver. The receiver will beep when the transmitted signal is detected.
Thesensitivityadjustmentallowsfortracingandpinpointingoftheexact
circuit breaker or fuse.
1. Plug the transmitter into a receptacle.
2. Turn the receiver on by rotating the sensitivity adjustment wheel from
theOFFpositiontotheHiposition.TheredLEDwillturnon.Ifthe
LEDdoesnotturnon,checkthebattery.
3. Test the receiver by placing it close to the transmitter. The receiver
shouldbeepandtheLEDshouldashconrmingitisworking.
Always test on a known good circuit prior to using the meter.
Referallindicatedproblemstoaqualifiedelectrician.
continued...
1.800.561.8187[email protected] REED-Direct.ca

6
www.REEDINSTRUMENTS.com
4. Atthebreakerbox,whilesetatthe
highest sensitivity, orient the receiver
as per the diagram to scan the
surface of the circuit breaker panel.
Move the receiver from top to bottom
on each side of the
breaker panel.
NOTE: Failure to orient the receiver as depicted may result in
faulty readings.
5. While moving the receiver, gradually reduce the sensitivity to pinpoint
theexactbreaker/fuseassociatedtothecircuitundertest.
Receptacle Wiring Test
1. Plug the transmitter into the receptacle.
2. Determine the status of the circuit connection according to the 3
LEDs.Thediagrambelowindicatesallofthepossiblecombinations
thatcouldappearforthecircuitundertest(GFCIbuttonsideofthe
transmitter)Ifobservedfromtheothersideduetothegroundhole
plugbeingontop,theorderofLEDindicatorlightswillbereversed.
Wiring Diagram
continued...
1.800.561.8187[email protected] REED-Direct.ca

7
www.REEDINSTRUMENTS.com
GFCI Socket Tester
1. Prior to using the transmitter, press the TEST button on the installed
GFCIreceptacle.ThiswillcausetheGFCItotrip.Ifittrips,pressthe
RESET button on the receptacle. If it does not trip, do not use the
circuitandcallaqualiedelectrician.
2. Plug the transmitter into the socket, check that the circuit is
connectedcorrectlyaccordingtotheLEDindicators.
3. PresstheGFCIbuttonforatleast8seconds,theindicatorlightswill
turnoffwhentheGFCItrips.
4. Ifthecircuitdoesnottrip,itcouldindicatethateithertheGFCIis
operable but the wiring is incorrect, or that the wiring is correct and
butGFCIisinoperable.
Battery Replacement
1. The battery needs to be replaced when the indicator light is not
bright or if the red light is not on.
2. Slide the battery cover according to the arrow to open the battery
compartment and remove the battery.
3. Install a new 9V battery.
4. Replace the battery cover.
Accessories and Replacement Parts
CA-05A Carrying Case
Don't see your part listed here? For a complete list of all accessories and
replacement parts visit your product page on www.reedinstruments.com.
WhentestingGFCIsinstalledin2-wiresystems(nogroundwire),the
testermaygiveafalseindicationthattheGFCIisnotfunctioning
properly.Ifthisoccurs,rechecktheGFCIreceptaclebyusingthetest
and reset buttons. This test will indicate proper operation.
1.800.561.8187[email protected] REED-Direct.ca

8
www.REEDINSTRUMENTS.com
Product Care
To keep your instrument in good working order we recommend the following:
• Storeyourproductinaclean,dryplace.
• Changethebatteryasneeded.
• Ifyourinstrumentisn'tbeingusedforaperiodofonemonthorlonger
please remove the battery.
• Cleanyourproductandaccessorieswithbiodegradablecleaner.Donot
spraythecleanerdirectlyontheinstrument.Useonexternalpartsonly.
Product Warranty
REED Instruments guarantees this instrument to be free of defects in
materialorworkmanshipforaperiodofone(1)yearfromdateofshipment.
During the warranty period, REED Instruments will repair or replace, at no
charge, products or parts of a product that proves to be defective because
of improper material or workmanship, under normal use and maintenance.
REED Instruments total liability is limited to repair or replacement of the
product. REED Instruments shall not be liable for damages to goods,
property, or persons due to improper use or through attempts to utilize the
instrumentunderconditionswhichexceedthedesignedcapabilities.In
order to begin the warranty service process, please contact us by phone at
1-877-849-2127 or by email at [email protected] to discuss the
claim and determine the appropriate steps to process the warranty.
Product Disposal and Recycling
Please follow local laws and regulations when disposing or recycling your
instrument. Your product contains electronic components and must be
disposed of separately from standard waste products.
1.800.561.8187[email protected] REED-Direct.ca

9
www.REEDINSTRUMENTS.com
Product Support
Ifyouhaveanyquestionsonyourproduct,pleasecontactyourauthorized
REED distributor or REED Instruments Customer Service by phone at
1-877-849-2127 or by email at [email protected].
Please visit www.REEDINSTRUMENTS.com for the most
up-to-date manuals, datasheets, product guides and software.
Product specifications subject to change without notice.
All rights reserved. Any unauthorized copying or reproduction of
this manual is strictly prohibited without prior written permission
from REED Instruments.
