Introduction
Thank you for purchasing your REED R5600 Insulation Tester. Please
read the following instructions carefully before using your instrument. By
following the steps outlined in this manual your meter will provide years of
reliable service.
Product Quality
This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet stated product
specications. If a certicate of calibration is required please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.
Safety
• Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
• Do not use the meter or test leads if they look damaged. Use extreme
caution when working around bare conductors or bus bars as
accidental contact with conductors could result in electric shock.
• Use the meter only as specied in this manual; otherwise, the protection
provided by the meter may be impaired.
• Use caution when working near voltages above 60V DC or 30V AC
RMS. as such voltages pose a shock hazard.
• Circuits being tested must be de-energized and isolated before
connections are made (This does not apply for voltage measurements).
continued...
3
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

4
Safety Symbols:
Caution
Refer to this manual before using the meter.
Dangerous voltages.
Meter is protected throughout by double insulation or
reinforced insulation.
Features
• Backlit dual displays insulation resistance and test voltage simultaneously
• 250V, 500V or 1000V test voltages and insulation resistance up
to 2000MΩ
• Lock function and hanging strap for handfree operation
• Lo Ω function for testing connections
• Datahold function
• Double molded plastic housing for added protection
• Low battery indicator and auto shut off
• Cat. III, 1000V safety rating
Included
• Test Leads
• Alligator Clip
• Hanging Strap
• Hard Carrying Case
• Batteries
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

5
Specifications
Voltage
Ranges: 250V, 500V, 1000V
Accuracy: DC: ±(0.8% rdg. + 3 dgt.)
AC: ±(1.2% rdg. + 10 dgt.)
Resolution: 1V
OHMS
Ranges: 200Ω, 200kΩ
Accuracy: ±(1.0% rdg. + 2 dgt.)
Resolution: 0.1Ω, 0.1kΩ
Meg OHMS
Ranges: 200MΩ/250V, 2000MΩ/500V,
0 to 1000MΩ/1000V, 1000 to 2000MΩ/1000V
Accuracy: ±(3.0% rdg. + 5 dgt.)
Test Current: 250KΩ, 500KΩ, 1MΩ
Resolution: 0.1MΩ, 1MΩ, 1mA
General Specifications
Range Selection: Autoranging/Manual
Display: LCD with dual display
Display Hold: Yes
Sampling Rate: 2.5 times/seconds
Backlit Display: Yes
Continuity Check: Audible signal if resistance ≤40Ω
Kick Stand: Yes
Auto Power Off: Yes (after 15 minutes)
Power Supply: 6 AAA Batteries
Low Battery Indicator: Yes
Fuse Protection: Yes
Replaceable Test Leads: Yes
Overange Indicator: Yes
continued...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

6
Overvoltage Category: CAT. III 1000V
Product Certications: CE
Operating Temperature: 32 to 104°F (0 to 40°C)
Storage Temperature: -4 to 140°F (-20 to 60°C)
Dimensions: 7.9 x 3.6 x 2.0" (200 x 92 x 50mm)
Weight: 25oz (700g)
Instrument Description
3
4
5
6
7
8
9
HOLD LOCK
CONTINUOUS
TEST
V
v
HOLD
LOCK
DC
AC
R5600 Insulation Tester
K
M
1. LCD Display
2. HOLD Button
3. TEST Button
4. Rotary Switch
5. VΩ Input Jack
6. LOCK Button
7. Backlight Button
8. Battery Compartment
9. COM Input Jack
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

7
Operating Instructions
Connecting the Test Leads
Connect the red test lead to the VΩ Input Jack and the black test lead to
the COM Input Jack.
Checking Test Leads
1. Set the rotary switch to the 200Ω range.
2. Touch both test lead tips together.
3. Resistance should read less than 00.5Ω and audible tone
should sound.
4. The display should read innity as indicated by "1" when the tips are
not in contact or are not connected to the meter.
Note: Readings other than those described indicate faulty test leads.
The test leads will need to be replaced prior to using the meter. Failure
to follow these instructions could result in damage to the equipment
and electrical shock.
Insulation Resistance Measurements
Warning: Do not perform any Insulation Resistance measurements if
there is AC Voltage present on the device being tested.
1. Connect the test leads to the meter (see Connecting the Test Leads
section for details).
2. Set the rotary switch to the required MΩ test voltage.
3. Connect the tips of the test leads to the equipment being tested.
Note: If voltage is present, the meter will emit a constant beeping sound
while displaying the voltage.
4. The LCD display will show "1"until a test is performed.
5. Press and hold the TEST button to begin.
Note: Do not release the TEST button until testing is complete and make
sure not to turn the rotary switch while the test button is pressed, or the
meter will be damaged.
continued...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

8
6. During testing, the upper right of the LCD display will show the test
voltage applied while a high voltage symbol will ash every 2 to 3
seconds. The main display will indicate the resistance.
7. When the reading is stable, note the measured value.
8. When testing is complete, release the TEST button and make sure to
keep the test leads connected to the equipment under test
during discharge.
Note: The charge stored in the insulation meter will be automatically
discharged when the TEST button is released.
Insulation Resistance Measurement Notes:
1. The maximum measurement range is 2000MΩ. When insulation
resistance exceeds this value, the LCD display will indicate "1",
meaning that the resistance is very high and the insulation being
tested is good.
2. Make sure that the circuit being tested does not include components
which will be damaged by the 1000V applied. Many normal
components of an installation are likely to be damaged if tested at
1000V. Examples are power factor correction capacitors, low voltage
mineral insulated cables, electronic light dimmers, electronic ballasts
and starters for uorescent lamps etc.
Lock Power Function
The R5600 features a lock power function to allow hands free operation
during insulation resistance testing. To enable, follow the steps below:
1. Once the meter is ready for testing, simultaneously press the TEST
and LOCK buttons to enable hands free operation.
2. While in this mode, the LOCK icon will appear on the LCD display
and the meter will emit a beeping sound every 2 seconds conrming
it is in lock mode.
3. To exit the lock power function and end testing, press the
LOCK button.
Note: The charge stored in the insulation meter will be automatically
discharged.
continued...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

9
Low Resistance (Continuity) Measurements
1. Set the rotary switch to the 200Ω •))) Position.
2. Connect the test leads to the meter (see Connecting the Test Leads
section for details).
3. Connect the tips of the test leads to both ends of the circuit
under test.
4. Read the resistance in Ω on the LCD.
5. When the resistance on a circuit is below approximately 40Ω, the
meter will emit a continuous beep.
AC/DC Voltage Measurement
1. Connect the test leads the meter (see Connecting the Test Leads
section for details).
2. Set the Rotary switch to the ACV or DCV position.
3. Connect the test leads IN PARALLEL to the circuit being measured.
4. Note the measured value.
Auto Power Off
To preserve battery life, the meter is programmed to turn off after 15
minutes of inactivity. To turn the meter back on, turn the rotary switch to
OFF, then back to the desired function.
Data Hold
1. While taking a measurement, press the HOLD button to freeze the
current readings on the display.
2. While in this mode a "HOLD" symbol will appear on the LCD.
3. Press the button again to resume normal operation.
Backlight
Press the button to turn the LCD display backlight on. The backlight
will automatically turn off after approx. 15 seconds.
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

10
Battery Replacement
When the low battery symbol appears on the LCD, the batteries
must be replaced.
1. Turn the meter off and remove the test leads.
2. Carefully remove the tilt stand located in the rear of the meter.
3. Remove the 4x Phillips head screws holding the battery cover.
4. Remove the battery cover.
5. Replace the 6x AA batteries.
6. Properly secure the cover and tighten the screws.
7. Reattach the tilt stand.
Applications
• Power Tools
• Appliances
• Motors
• Cables
Application Notes
Power Tools & Small Appliances
This test applies to any device being tested that uses a line cord. For
double insulated power tools, connect one lead to the device's housing
(i.e. chuck, blade, etc.) and the other lead to the end of the power cord.
AC Motors Testing
Disconnect the motor from the line by disconnecting the wires from the
motor terminals or opening the mains switch. If the main switch is used
and the motor also has a starter then the starter must be held, by some
means, in the "ON" position. In the latter case, the measured resistance
will include the resistance of the motor, wire and all other components
between the motor and the main switch. If a weakness is in indicated, the
motor and other components should be checked individually. If the motor
is disconnected at the motor terminals, connect one lead to the grounded
motor housing and the other lead to one of the motor leads.
continued...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com
