ReelCraft E9200 OLP User manual

1. Models designed for fuel are coded with the prefix “F” i.e., “FE9400 OLP.”
Check name plate on the reel before installing.
2. Do not use reel at higher pressures or temperatures than listed on the back
of this bulletin.
3. Remove all spring tension before beginning dissassembly process.
4. Reel spring motor case is permanently sealed. Any attempt to remove the
spring motor may cause serious injury.
SAFETY
E9200 OLP E9330 OLP E9305 OLP E9450 OLP
E9275 OLP E9340 OLP E9399 OLP
E9299 OLP E9350 OLP E9400 OLP
E9300 OLP E9375 OLP E9430 OLP
Operating Instructions
Series E9000 Spring Driven Hose Reels
Low Pressure Model Numbers:
Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: [phone]
Customer Service: 855-634-9109 • [email protected] • www.reelcraft.com
Dimensions
Form# 613-193 Rev: 6/2018
INSTALLATION: The swivel union is packed separately in the reel carton, use teflon tape to assure a satisfactory seal. A flexible hose
connection must be used between the hose reel inlet and the source of supply to prevent possible misalignment and
binding. Non flexible connections will void the warranty, pressure rating of inlet hose must be equal to or more than
the pressure rating of the reel. Consult factory for proper spring when installing reels above 16 ft.
LUBRICATION: Hose reel spring and bearings are factory lubricated and require no further lubrication.
REPLACING HOSE: 1. Wind spool flange clockwise-facing swivel-until spring is tight.
2. Back off three turns and latch.
3. Insert hose through roller guide.
4. Connect hose fitting to female outlet ell.
ADJUSTMENTS: To adjust spring tension, add or remove wraps of hose from the spool, one wrap at a time until desired tension is
obtained.
REPAIRS: Extensive repairs should be performed only by an authorized serviceman or factory to avoid damage which may
void your warranty. Remove all spring tension before beginning disassembly process.
MODIFICATION: Hose latching mechanism can be removed for constant tension applications.
A26 1/4”
B24 1/8”
C4 3/4”
D 12”
E7 3/4”
F22 1/4”
G12 1/4”

Series E9000 Spring Driven Hose Reels
Page 2 www.reelcraft.com
Item
#Part # # Req Description Item #Part # # Req Description
1 S2-41 16 1/4-20 x 1/2” hex screw 24 S600454 1 Latch pawl assembly
2 270009 2 Side frame 25 S260067 1 Latch spring
3 S281-6 12 3/8-16 hex flange nut 27 S393-2 1 10-32 shoulder screw
4 S600416 2 Pillow block 30 S270016 2 Guide roller pin - long
5 270012 1 End frame support 31 S270015 2 Guide roller pin - short
6 S44-2 8 3/8-16 x 5/8” mach. screw 32 262436-5.468 2 Guide roller
7 S44-8 4 3/8-16 x 1 3/4” screw 33 262436-2.968 2 Guide roller
8 602377 1 Support shaft 34 S270014 4 Guide roller post
9 S140-34 6 Snap ring 36 270011 1 Hose guide roller plate
11 260888 1 Spring arbor 37 S2-51 4 5/16-18 x 1/2” hex screw
13 602364 1 Inlet tube 38 S281-4 8 1/4-20 hex nut
14 270029 1 Hose outlet support 39 270045 1 Guide roller plate SW
15 S32-136 1 #10 x 3/8” self tap screw 40 270043 1 SW support bracket
17 270028 1 90° female NPT ell 41 270042 1 SW support bracket
18 260889 1 Latch ratchet 42 270044 1 Guide roller plate TW
21 S280-8 1 1/2-20 hex flange nut 43 270041 1 TW support bracket
22 260934 1 Latch bracket 44 270040 1 TW support bracket
23 S82-15 1 10-32 x 3/8” nyloc nut
1
2
3
3
4
5
6
7
8
9
10 11 12 113
4
21
22
23
2
24
25
26
27
28
29
303132
3334
6
37
38
42
43
6
3
44
6
39
40
3
41
14 15 16 17 9 1 18 7 19 20
36

Series E9000 Spring Driven Hose Reels
www.reelcraft.com Page 3
Item
#Description # Req E9200 OLP E9275 OLP E9299 OLP E9300 OLP E9330 OLP E9340 OLP E9350 OLP
5End frame support 1 270012 270012 270012 270012 270012 270012 270012
10 Spring case assembly 1 S600413-1 S600413-1 S602722 S600413-2 S600413-2 S600413-2 S600413-2
11 Spring arbor 1 260888 260888 396888 260888 260888 260888 260888
12 Sheave assembly 1 600415 600415 600415 600415 600415 600415 600415
16 Reducing bushing 1 300080 300080 300080 270025 270025 270025 270025
19 Swivel assembly 1 S600888-1 S600888-1 S600888-1 S602026 S602026 S602026 S602026
20 Reducing coupling 1 S289-5 S289-5 S289-5 S289-6 S289-6 S289-6 S289-6
28 Hose assembly 1 None 601020-75 601020-100 None S601026-30 S601026-40 S601026-50
29 Bumper stop assembly 1 None 2-HR1005 2-HR1005 None 3-HR1005 3-HR1005 3-HR1005
39 Guide roller plate SW 1 270045 270045 270045 270045 270045 270045 270045
42 Guide roller plate TW 1 270044 270044 270044 270044 270044 270044 270044
-- Hose ID and length -- None 1/2” x 75’ 1/2” x 100’ None 3/4” x 30’ 3/4” x 40’ 3/4” x 50’
-- Working pressure -- 500 PSI 300 PSI 300 PSI 500 PSI 300 PSI 300 PSI 300 PSI
-- Max. temperature -- 210 °F 150 °F 150 °F 210 °F 150 °F 150 °F 150 °F
Item
#Description # Req E9375 OLP E9305 OLP E9399 OLP E9400 OLP E9430 OLP E9450 OLP
5End frame support 1 270012 262104 262104 270012 270012 270012
10 Spring case assembly 1 S600413-2 S602722 S602722 S600413-2 S600413-2 S600413-2
11 Spring arbor 1 260888 396888 396888 260888 260888 260888
12 Sheave assembly 1 600415 601081 601081 600414 600414 600414
16 Reducing bushing 1 270025 270025 270025 None None None
19 Swivel assembly 1 S602026 S602026 S602026 S600682 S600682 S600682
20 Reducing coupling 1 S289-6 S289-6 S289-6 None None None
28 Hose assembly 1 S601026-75 None S601026-100 None S601027-30 S601027-50
29 Bumper stop assembly 1 3-HR1005 None 3-HR1005 None 4-HR1005 4-HR1005
39 Guide roller plate SW 1 270045 262680 262680 270045 270045 270045
42 Guide roller plate TW 1 270044 262679 262679 270044 270044 270044
-- Hose ID and length -- 3/4” x 75’ None 3/4” x 100’ None 1” x 30’ 1” x 50’
-- Working pressure -- 300 PSI 500 PSI 300 PSI 500 PSI 300 PSI 300 PSI
-- Max. temperature -- 150 °F 210 °F 150 °F 210 °F 150 °F 150 °F
