Regency Fireplace Products HUME F250B Quick start guide

Model: F250B
Owners &
Installation
PLEASE KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE
Manual
May-5-2021
918-697g
WARNING:
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual. For assistance or
additional information consult an authorised installer, service agency or
the distributor.
FOR YOUR SAFETY
Do not store or use petrol or other flammable vapours and liquids in the
vicinity of this or any other appliance.
Installation and service must be performed by an authorised installer or
service agency.
HUME FREESTANDING WOOD FIRE
FPI - FIREPLACE PRODUCTS AUSTRALIA PTY LTD.
1 CONQUEST WAY HALLAM VICTORIA 3803

2Regency Hume Freestanding Wood Fire
Thank-you for purchasing a
REGENCY FIREPLACE PRODUCT.
The pride of workmanship that goes into each of our products will give you years of trouble-free
enjoyment. Should you have any questions about your product that are not covered in this manual,
please contact the REGENCY DEALER in your area.
Keep those REGENCY FIRES burning.
SAFETY NOTE: If this wood fire is not properly installed, a house fire may result. For your safety,
follow the installation instructions, contact local building, fire officials, or authority having jurisdiction
about restrictions and installation inspection requirements in your area.
The authority having jurisdiction should be consulted before installation to determine the need to
obtain a permit.
ONLY CLEAN THE APPLIANCE WITH A DAMP CLOTH
(NEVER WHEN UNIT IS HOT)
DO NOT USE ANY ABRASIVE CLEANERS
DO NOT BURN (WILL VOID WARRANTY):
• Treated wood • Tea Tree • Oil Based woods • Coal • Garbage
• Cardboard • Solvents • Colored Paper • Trash

Regency Hume Freestanding Wood Fire 3
table of
contents
MAINTENANCE
Maintenance ..........................................................................9
Creosote ................................................................................9
- Ways to Prevent & Keep Units Free of Creosote ..........9
Glass Maintenance ................................................................9
Door Latch Adjustment ..........................................................9
Wood Storage ........................................................................9
PARTS LIST
Heater Assembly .................................................................10
WARRANTY
Warranty ..............................................................................12
Compliance Plate ..................................................................4
Unit Dimensions ....................................................................5
INSTALLATION
Residential Installation ...........................................................6
Safety Guidelines and Warnings ...........................................6
Brick & Cast Installation .........................................................6
Clearance to Combustibles ....................................................7
Floor Protection .....................................................................7
OPERATING INSTRUCTIONS
Operating Instructions ...........................................................8
Air Slide Control .....................................................................8
First Fire ................................................................................8

4Regency Hume Freestanding Wood Fire
SAFETY LABEL
data badge
This is a copy of the label that accompanies
each F250B Freestanding Wood Fire. We have
printed a copy of the contents here for your review.
NOTE: Regency units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is the
correct one.
Part #: 918-681e
Colour: Black on Grey
Size: 100%
Sept. 11/07: Changed Maximum Average Heat Output
from 17.5kW to 13kW as per Matthew M.
Aug.7/12: Updated manufacture dates.
Aug.28/13: Updated test report date
Jan. 6/14: Rev. C Updated E. Aus address
Apr. 15/15: Rev. D Added data as per Matt M
Sept. 25/17: Rev. E--Updated manufacturing date + testing dates
Model: HUME F250B
JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC 2021 2022 2023 2024 2025
TESTED BY:
HRL TECHNOLOGY PTY LTD.
TRAMWAY ROAD MORWELL VICTORIA 3840 (2013)
MAXIMUM AVERAGE HEAT OUTPUT BURNING HARDWOOD: 13kW
OVERALL AVERAGE EFFICIENCY BURNING HARDWOOD: 65%
Date of Manufacture:
Serial
Number
918-681e
330
WHEN TESTED IN ACCORDANCE WITH AS/NZS 4012:2014 & AS/NZS 4013:2014
PARTICULATE EMISSION FACTOR: 1.5 g/kg
CATALYTIC COMBUSTOR: NO
TEST REPORT NUMBER: HCMG/13/038
MAKE: REGENCY
TYPE: FREESTANDING WOODFIRE
MANUFACTURER/DISTRIBUTOR: FIREPLACE PRODUCTS AUSTRALIA PTY. LTD.
1 CONQUEST WAY, HALLAM VIC 3803

Regency Hume Freestanding Wood Fire 5
DIMENSIONS
dimensions

6Regency Hume Freestanding Wood Fire
installation
1) Please read this entire manual before you
install and use your new wood fire. Failure
to follow instructions may result in property
damage, bodily injury or even death. Be
aware that local Codes and Regulations may
override some items in this manual. Check
with your local inspector.
2) THE APPLIANCE AND FLUE-SYSTEM
SHALL BE INSTALLED IN ACCORDANCE
WITH AS/NZS 2918:2001 AND THE AP-
PROPRIATE REQUIREMENTS OF THE
RELEVANT BUILDING CODE OR CODES.
APPLIANCES INSTALLED IN ACCORD-
ANCE WITH THIS STANDARD SHALL
COMPLYWITHTHE REQUIREMENTS OF
AS/NZS 4013WHERE REQUIRED BYTHE
REGULATORY AUTHORITY.
ANY MODIFICATION OFTHE APPLIANCE
THAT HAS NOT BEEN APPROVED IN
WRITING BY THE TESTING AUTHORITY
IS CONSIDERED TO BE IN BREACH OF
THE APPROVAL GRANTED FOR COMPLI-
ANCE WITH AS/NZS 4013.
CAUTION: MIXING OF APPLIANCE OR
FLUE-SYSTEM COMPONENTS FROM
DIFFERENT SOURCES OR MODIFYING
THE DIMENSIONAL SPECIFICATION OF
COMPONENTS MAY RESULT IN HAZ-
ARDOUS CONDITIONS. WHERE SUCH
ACTION IS CONSIDERED, THE MANU-
FACTURER SHOULD BE CONSULTED
IN THE FIRST INSTANCE.
3) Select a position for your Regency Heater.
Consult the minimum clearance chart for
your model and set the heater in place. For
close clearance installation use listed double
wall connector systems.
4) To ensure vertical alignment, suspend a
plumb bob from the ceiling over the exact
center of your heater flue and mark a spot
on the ceiling to indicate the center of the
flue.
5) Check that the area above the ceiling is
clear for cutting. Re-confirm the clearance
from the heater to combustibles to ensure
that they are within the prescribed limits.
6) Mark the location of the pedestal base on
the floor, then move the heater aside and
mark the position of the floor protector.
7) Install flue according to flue manufacturers
instructions. The performance of your wood
fire is governed to a very large part by the
flue system. Too short a flue can cause
difficult start-up, dirty glass, backsmoking
when door is open, and even reduced heat
RESIDENTIAL
INSTALLATION
SAFETY GUIDELINES AND
WARNINGS
1) Never use petrol, petrol type lantern fuels,
kerosene, charcoal lighter fuel, or similar
liquids to start or ‘freshen up’ a fire in your
heater. Keep all such liquids well away from
the heater while it is in use.
2) Keep the door closed during operation and
maintain all seals in good condition.
3) Do not burn any quantities of paper, garbage,
and never burn flammable fluids such as
petrol, naptha or engine oil in your heater.
4) If you have smoke detectors, prevent smoke
spillage as this may set off a false alarm.
5) Do not overfire heater. If the flue connector,
flue baffle or the heater top begin to glow, you
are overfiring. Stop adding fuel and close the
draft control. Overfiring can cause extensive
damage to your heater including warpage
and premature steel corrosion. Overfiring
will void your warranty.
6) Do not permit creosote or soot build-up in
the flue system. Check and clean flue at
regular intervals. Failure to do so can result
in a serious flue fire.
7) Your Regency heater can be very hot. You
may be seriously burned if you touch the
heater while it is operating, keep children,
clothing and furniture away. Warn children
of the burn hazard. For safety reasons a
guard around the fire is recommended.
8) The heater consumes air while operating,
provide adequate ventilation with an air duct
or open a window while the heater is in use.
9) Do not connect this unit to a flue serving
another appliance.
10) Do not use grates or andirons or other
methods for supporting fuel. Burn directly
on the base or bricks where supplied.
11) Open the draft control fully for 10 to 15
seconds prior to slowly opening the door
when refuelling the fire.
12) Do not connect your unit to any air distribu-
tion duct.
13) Your wood fire should burn dry, standard
firewood only. The use of cut timber, ply-
wood, “mill ends”, etc. is not allowed as this
fuel can easily overheat your wood fire.
Evidence of excessive overheating will void
your warranty. As well, a large portion of
sawmill waste is chemically treated timber,
which is illegal to burn in many areas. Salt
drift wood and chemically treated fire logs
also must not be burned in your wood fire.
14) No combustible material should be closer
than the clearances as specified on page 7.
15) DO NOT OPERATE WITH BROKEN
GLASS.
WARNING
Ensure that curtains, blinds and drapes can-
not extend to or anywhere near the fire as this
could cause an extremely dangerous operating
condition.
These must be secured by any means possible.
Examples not limited to :
If a window or door is opened, the wind/breeze
could cause them to move.
Physical movement by an adolescent child.
output. Too tall a flue may prompt excessive
draft which can result in very short burn times
and excessive heat output.
8) The floor protector must be of non-com-
bustible material. Refer to page 7 for floor
protector clearances.
9) When the floor protection is complete, posi-
tion the heater with the flue collar centered
under the installed flue.
10) In seismically active areas, Regency recom-
mends that your unit is secured to the floor
by using the bolt down holes inside the
pedestal.
11) Do not connect this unit to a flue serving
another appliance.
BRICK & CAST
INSTALLATION
Insert the rear cast plate first and then the side
plates ensuring the cut out sections lock in firmly.
The bricks can then be placed on the base of the
firebox between the cast side and rear plates.
Firebrick is included to extend the life of your
heater and radiate heat more evenly.

Regency Hume Freestanding Wood Fire 7
installation
MINIMUM CLEARANCE TO
COMBUSTIBLE MATERIALS
A 400mm 400mm 450mm
B 210mm 180mm 300mm
C 200mm 200mm 200mm
D 181mm 181mm 181mm
E 123mm 123mm 123mm
F 400mm 400mm 400mm
G 1015mm 1015mm 1015mm
H 1120mm 1120mm 1120mm
Floor Protection
A combustible floor must be protected by non-combustible material (like
tile, concrete board, or as defined by local codes) extending beneath
the heater as follows;
From Sides: 123mm
From Front: 400mm
From Back: 181mm
The floor protector should consist of 6mm thick cement fibre sheet which
has a thermal resistance of 0.8m2 k/w for 4mm sheets of cement fibre sheet.
The flue pipe shall extend not less than 4.6m above the top of the floor protector.
NOTE: Installation must be carried out by a licensed installer in accordance
with AS/NZS 2918:2001.
Flo-Met
Super Single *(1)
Hawkwind
Standard
AHD Special
Insulated *(2)
IMPORTANT
* (1) The Flomet Super Single flue kit must be installed with a 130o x
900mm stainless reflective shield between decromesh.
* (2) The AHD Special Insulated flue kit must be installed with a
40mm air gap around the flue to any combustible surfaces and the
ceiling ring must be spaced as such to provide an air gap of 20mm to
the ceiling. The AHD Special Insulated flue kit must be installed with
a perforated ceiling plate and 250mm dia. x 195mm high heatshield
positioned directly above the ceiling plate.
NOTE: A minimum clearance of 180mm (flat wall) or 200mm (corner wall) must be retained for all wall surfaces to allow for fan access and maintenance.

8Regency Hume Freestanding Wood Fire
operating
instructions
4) After about 45 minutes, when your wood
has begun to burn strongly, adjust your draft
control down to keep the fire at a moderate
level.
WARNING: Never build a roaring fire in
a cold heater. Always warm your heater
up slowly!
5) Once a bed of coals has been established
on the base of the firebox, you may adjust
the draft control to a low setting to operate
the unit at its most efficient mode.
6) During the first few fires, keep the combus-
tion rate at a moderate level and avoid a
large fire. Only after 5 or 6 such fires can
you operate the heater at its maximum
setting, and only after the metal has been
warmed.
7) For the first few days, the heater will give
off an odour from the paint. This is to be
expected as the high temperature paint
becomes seasoned. Windows and/or doors
should be left open to provide adequate
ventilation while this temporary condition
exists. Burning the heater at a very high
temperature the first few times may damage
the paint. Burn fires at a moderate level the
first few days.
8) Do not place anything on the heater top
during the curing process. This may result
in damage to your paint finish.
Pull - Open
WARNING: To build a fire in ignorance
or to disregard the information con-
tained in this section can cause serious
permanent damage to the unit and void
your warranty.
AIR SLIDE CONTROL
Both the primary and air wash drafts are con-
trolled by the control rod located on the right side
of the unit (when facing the unit). To increase
your draft - pull open, and to decrease - push
closed. All units have a secondary draft system
that continually allows combustion air to the
induction ports at the top of the firebox, just
below the flue baffle.
OPERATING
INSTRUCTIONS
With your unit now correctly installed and safety
inspected by your local authority, you are now
ready to start a fire. Before establishing your
first fire, it is important that you fully understand
the operation of your draft control.
CAUTION:THIS APPLIANCE MUST BE MAIN-
TAINED AND OPERATED AT ALL TIMES IN
ACCORDANCEWITHTHESE INSTRUCTIONS.
CAUTION: THE USE OF SOME TYPES OF
PRESERVATIVE-TREATEDWOOD AS A FUEL
CAN BE HAZARDOUS.
WARNING: ANY MODIFICATION OFTHE AP-
PLIANCE THAT HAS NOT BEEN APPROVED
INWRITING BYTHETESTING AUTHORITY IS
CONSIDERED AS BREACHING AS/NZS 4013.
WARNING: DO NOT USE FLAMMABLE LIQ-
UIDS OR AEROSOLS TO START OR REKIN-
DLE THE FIRE.
WARNING: DO NOT USE FLAMMABLE LIQ-
UIDS OR AEROSOLS IN THE VICINITY OF
THIS APPLIANCE WHEN IT IS OPERATING.
WARNING: DO NOT STORE FUEL WITHIN
HEATER INSTALLATION CLEARANCES.
WARNING: OPEN AIR CONTROL (AND
DAMPERWHEN FITTED) BEFORE OPENING
FIRING DOOR.
FIRST FIRE
When your installation is completed and in-
spected you are ready for your first fire.
1) Open control fully.
2) Open firebox door and build a small fire us-
ing paper and dry kindling on the firebrick
hearth. Secure door on the firebox and wait
a few minutes for a good updraft in the flue to
establish the fire. (Leaving the door slightly
open will help your fire start more rapidly.)
CAUTION: Never leave unit unattended
if door is left open. This procedure is for
fire start-up only, as unit may overheat if
door is left open for too long.
3) With the draft still in the fully open position
add two or three seasoned logs to your fire.
Form a trench in the ash bed to allow air to
reach the rear of the firebox prior to closing
the door.
Push - Closed
3 Speed Internal Fan Wiring Diagram (240V)
HOT -"BROWN"
NEUTRAL -"BLUE"
GREEN-YELLOW
RED
BLACK
ATTACH TO FAN
WHITE
BLUE
For safety reasons and in order to
avoid over firing of your unit do not
burn your fire with the door open
or ajar.

Regency Hume Freestanding Wood Fire 9
maintenance
9) During the first few days it may be more
difficult to start the fire. As you dry out your
firebrick and your masonry flue, your draft
will increase.
10) For those units installed at higher elevations
or into sub-standard masonry fireplaces,
drafting problems may occur. Consult an
experienced dealer or mason on methods
of increasing your draft.
11) Some cracking and popping noises may be
experienced during the heating up process.
These noises will be minimal when your unit
reaches temperature.
12) Before opening your door to reload, open
draft fully for approximately 10 to 15 seconds
until fire has been re-established. This will
minimize any smoking.
13) All fuel burning appliances consume oxygen
during operation. It is important that you
supply a source of fresh air to your unit
while burning. A slightly opened window is
sufficient for the purpose. If you also have
a fireplace in your home, a downdraft may
be created by your Regency Heater causing
a draft down your flue. If this occurs, slightly
open a window near your unit.
CAUTION: If the body of your unit, ue ba󰀪e
or any part of the ue connector starts to
glow, you are overring. Stop loading fuel
immediately and close the draft control until
the glow has completely subsided.
14) Green or wet wood is not recommended for
your unit. If you must add wet or green fuel,
open the draft control fully until all moisture
has been dispersed by the intense fire.
Once all moisture has been removed, the
draft control may be adjusted to maintain
the fire.
15) If you have been burning your heater on
a low draft, use caution when opening the
door. After opening the damper, open the
door a crack, and allow the fire to adjust
before fully opening the door.
16) The controls of your unit or the air supply
passages should not be altered to increase
firing for any reason.
17) If you burn the unit too slowly or at too low
a setting your unit will not be operating as
efficiently as it can. An easy rule of thumb
says that if your glass is clean, then your
flue is clean and your exhaust is clean.
Burn the heater hot enough to keep your
glass clean and you won't need to clean
your flue as often.
CREOSOTE
When wood is burned slowly, it produces tar and
other organic vapours, which when combined
with moisture, form creosote. The creosote
vapours condense in the relatively cool flue of a
slow burning fire. As a result, creosote residue
accumulates on the flue lining. When ignited,
this creosote can result in an extremely hot fire.
WARNING: Things to remember in case
of a flue fire:
1. Close all draft and damper controls.
2. CALL THE FIRE DEPARTMENT.
Ways to Prevent and Keep Unit
Free of Creosote
1) Burn heater with the draft control wide open
for about 10-15 minutes every morning
during burning season.
2) Burn heater with draft control wide open
for about 10 - 15 minutes every time you
apply fresh wood. This allows the wood to
achieve the charcoal stage faster and burns
up any unburned gas vapours which might
otherwise be deposited within the system.
3) Only burn seasoned wood! Avoid burning
wet or green wood. Seasoned wood has
been dried at least one year.
4) A small hot fire is preferable to a large
smouldering one that can deposit creosote
within the system.
5) The flue and flue connector should be
WOOD STORAGE
Store wood under cover, such as in a shed, or
covered with a tarp, plastic, tar paper, sheets
of scrap plywood, etc., as uncovered wood can
absorb water from rain or snow, delaying the
seasoning process.
MAINTENANCE
It is very important to carefully maintain your
heater, including burning seasoned wood and
maintaining a clean heater and flue system. Have
the flue cleaned before the burning season and
as necessary during the season, as creosote
deposits may build up rapidly. Moving parts of
your heater require no lubrication. The integrity
of all heater parts including baffle plates, cast
iron liners, fire bricks, air tubes, air bars, door
rope seals, and door glass is imperative for the
correct operation and longevity of your Regency
Wood heater. They should be inspected on a
regular basis and replaced if they show any
signs of undue wear or damage. Failure of any
of these componenets can damage the heater
and void warranty.
inspected at least once every two months
during the heating season to determine is
a creosote buildup has occurred.
6) Have flue system and unit cleaned by
competent flue sweeps twice a year dur-
ing the first year of use and at least once
a year thereafter or when a significant
layer of creosote has accumulated (3
mm) it should be removed to reduce the
risk of a flue fire.
GLASS MAINTENANCE
Your Regency heater is supplied with 5 mm
Neoceram ceramic glass that will withstand
the highest heat that your unit will produce. In
the event that you break your glass by impact,
purchase your replacement from an authorized
Regency dealer only, and follow our step-by-step
instructions for replacement.
Allow the heater to cool down before cleaning
the glass, do not clean the glass when it is hot.
Do not use abrasive cleaners.
Rear View of Door shown
Allen
Screw Latching
Sleeve
Set Screw
DOOR LATCH
ADJUSTMENT
The door latch may require adjustment as the
door gasket material compresses over time.
Follow the steps below to allow the latch to
be moved closer to the door frame, causing a
tighter seal;
1) Unscrew latching sleeve.
2) Remove allen screw.
3) Spin door handle clockwise to desired depth.
4) Re-install allen screw and latching sleeve.
5) Adjust set screw to proper depth to ensure
that the handle does not rotate 360 degrees.

10 Regency Hume Freestanding Wood Fire
PARTS LIST
parts list
HEATER ASSEMBLY
Part # Description
5
2
11
14
13
8
1
7
16 12
6
3
17
18
4
9
10
15
1) 1160106 Baffle Top
2) 1160118 Securing Pins
3) 1170202 Panel Outer Side Left
4) 1170203 Panel Outer Side Right
5) 1172001 Top Plate/ Panel
6) 1172004 Rear Panel
7) 8010301 Bricks Set (Set 9)
8) 8010302 Liner Cast Iron (Set)
9) 8010303 Liner Cast Iron Sides (L & R)
10) 8010305 Liner Cast Iron Back
11) 8010306 Air Bar Stainless Steel
12) 8010307 Glass Neoceram With Glass Gasket
13) 8010313 Door Assembly (without handle)
14) 8010309 Air Slide
15) 8010310 Ash Lip Panel
16) 8010114 Door Handle Set
17) F300-917 Fan Assembly
18) 1172003 Pedestal Assembly
19) 936-060 Door rope seal 5 ft .6" (not shown)

Regency Hume Freestanding Wood Fire 11
NOTES
notes

12 Regency Hume Freestanding Wood Fire
WARRANTY
warranty
Limited Warranty
FPI Fireplace Products International Ltd. (“the manufacturer”) through its wholly owned subsidiary, Fireplace
Products Australia Pty Ltd (for Australia and New Zealand customers) and sold under the Regency® brand of
fireplace products (collectively referred to herein as “FPI”), extends this Limited Warranty to the original purchaser
of this appliance provided the product remains in the original place of installation. The items covered by this
limited warranty and the period of such coverage is set forth in the table below.
Some conditions apply (see below).
The policy is not transferable, amendable or negotiable under any circumstances.
Wood Products Component Coverage Labor
Coverage
Components Covered
15
years
2
years
1
year
Warranty (Years)
Welded Firebox Steel

5
All Stainless Steel Components, Smoke Deflectors,
Heat Shields etc.

1
Air Tubes

1
Airmate

1
Door handle and latch assembly, all hardware
 1
Glass Thermal Breakage Only
 1
Steel Faceplates, Accessory Housings
 1
All Plating
 1
Ash Drawer, Heatshields, Pedestal

1
All Baffles-Steel, Ceramic, Vermiculite

1
All castings, firebox, surrounds, doors, panels etc.
 1
All Electrical, Fans, wiring, switches etc.

(Fan only)

1
Glass - Crazing
 1
Catalyst Assembly (see below for specific details)
6 Years
Prorated
3
Flue components
 1
Firebricks
Nil
Nil
After the original warranty coverage for any of the parts above have expired, any repair and/or replacement parts
purchased by the consumer from FPI or through an accredited distributor or dealer will carry a ninety (90) day
warranty (valid only with an original copy of the tax invoice). No labor coverage is included with any repair and/or
replacement part.
Replacement parts are limited to one per warranty term. Airtube and baffle replacements are limited to one
replacement per term.
Catalyst Assembly
IMPORTANT WARRANTY INFORMATION FOR UNITS WITH A CATALYTIC CONVERTER
FPI will replace, at no charge to the consumer, 'one' catalytic converter that ceases to function within three (3)
years from the date of purchase by the original consumer, provided that the following conditions are met:
(1) The catalytic converter must not have been mechanically abused
(2) Only recommended fuels have been used in the appliance
Revision Date: December 2016 Regency Wood Products Warranty

Regency Hume Freestanding Wood Fire 13
WARRANTY
warranty
If after three (3) years the catalytic converter fails to function, a prorated warranty will provide for replacement at
the following fee schedule to be paid by the consumer*:
Year 4.....................$90*
Year 5.....................$100*
Year 6.....................$110*
* Prices subject to change without notice. Conditions (1) and (2) above also apply for prorated warranty periods.
AFTER YEAR SIX (6), THE CONSUMER MUST PURCHASE ANY CATALYTIC CONVERTERS THAT NEED REPLACEMENT AT
THE CURRENT RETAIL PRICE, AND WILL BE RESPONSIBLE FOR ANY LABOUR COSTS TO REMOVE AND/OR SERVICE.
LABOR WILL ONLY BE COVERED ON THE CATALYTIC CONVERTER FOR THE FIRST THREE (3) YEARS.
Conditions:
Warranty protects against defect in manufacture or FPI factory assembled components only, unless herein
specified otherwise. This warranty will only apply to those products which are acquired at the time of this
warranty being effective. FPI will not be liable for any damage or loss that falls outside the scope of the warranty.
Any part(s) found to be defective during the warranty period as outlined above will be repaired or replaced at FPI’s
option through an accredited distributor, dealer or pre-approved and assigned agent provided that the defective
part is returned to the distributor, dealer or agent for inspection if requested by FPI. Alternatively, FPI may at its
own discretion fully discharge all of its obligations under the warranty by refunding the verified purchase price of
the product to the original purchaser. The purchase price must be confirmed by an original copy of the tax invoice.
The authorised selling dealer, or an alternative authorised FPI dealer if pre-approved by FPI, is responsible for all
in-field diagnosis and service work related to all warranty claims. This warranty does not cover dealer travel
costs for diagnostic or service work. Dealers may charge homeowner for travel and additional time. Check with
your selling dealer in advance for any costs to you when arranging a warranty call. FPI is not responsible for
results or costs of workmanship of unauthorised FPI dealers or agents in the negligence of their service work.
Additional service fees may apply if you are seeking warranty service from a dealer other than the dealer from
whom you originally purchased the product.
At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective
and determine whether the warranty will apply prior to processing or authorising of any claim. Failure to allow
this upon request will void the warranty.
All warranty claims must be submitted by the dealer servicing the claim, including an original copy of the tax
invoice (proof of purchase by you). All claims must be complete and provide full details as requested by FPI to
receive consideration for evaluation, including proof of maintenance records. Incomplete claims may be rejected.
FPI has absolute discretion to assess and determine any warranty claim and may accept or reject a claim as it
considers appropriate.Any part or parts of the unit found to be defective will be repaired or replaced at FPI's
option, through an accredited distributor or service agent provided that the defective part be returned to the
distributor or agent, Transportation Prepaid, if requested.It is the general practice of FPI to charge for larger,
higher priced replacement parts and issue credit once the replaced component has been returned to FPI and
evaluated for manufacturer defect.
If a consumer has a unit installed outside an accredited distributor, dealer or pre-approved service agent’s
service area, or the closest approved service agent is situated more than thirty (30) kilometres from the
installation, FPI is not obliged to arrange warranty repairs or shipping/transportation costs. In these cases, the
consumer must arrange warranty service with its selling dealer, and shipping, travel and/or additional labor
charges will apply.
Unit must be installed according to all manufacturers’ instructions as per the manual.
All Local and National required codes must be met.
The installer is responsible to ensure the unit is operating as designed at the time of installation.
Revision Date: December 2016 Regency Wood Products Warranty

14 Regency Hume Freestanding Wood Fire
WARRANTY
warranty
Revision Date: November 2016
Regency Wood Products Warranty
The original purchaser is responsible for annual maintenance of the unit, as outlined in the owner’s manual. As
outlined below, the warranty may be voided due to problems caused by lack of maintenance. Annual maintenance
records should be retained.
Exclusions:
This Limited Warranty does not extend to paint, rust or corrosion of any kind due to a lack of maintenance or
improper venting, combustion air provision, corrosive chemicals (i.e. chlorine, salt, air, etc.), firebrick (rear, sides or
bottom), door or glass gasket, or any other additional factory fitted gasket.
Malfunction, damage or performance based issues as a result of environmental conditions, location, chemical
damages, downdrafts, installation error, installation by an unqualified installer, incorrect chimney components
(including but not limited to cap size or type), operator error, abuse, misuse, use of improper fuels (such as
unseasoned timber, mill-ends, construction timber or debris, off-cuts, treated or painted timber, tea tree, metal or
foil, plastics, garbage, solvents, cardboard, coal or coal products, oil based products, waxed cartons, compressed
pre-manufactured logs), accidents, lack of regular maintenance and upkeep, acts of God, weather related
problems from hurricanes, tornados, earthquakes, floods, lightning strikes/bolts or acts of terrorism or war, which
result in malfunction of the appliance are not covered under the terms of this Limited Warranty.
FPI has no obligation to enhance or modify any unit once manufactured (i.e. as products evolve, field modifications
or upgrades will not be performed on existing appliances).
Any unit showing signs of neglect or misuse will not be covered under the terms of this warranty policy and may
void this warranty. This includes units with rusted or corroded fireboxes which have not been reported as rusted or
corroded within three (3) months of installation/purchase. Any alteration to the unit which causes sooting or
carboning that results in damage to the exterior fascia or over firing that can cause component or firebox/heat
exchanger failure will not be covered by this warranty.
Units which show evidence of being operated while damaged, or with problems known to the purchaser and
causing further damages will void this warranty.
Units where the serial no. has been altered, deleted, removed or made illegible will void this warranty.
Minor movement, expansion and contraction of the steel is normal and is not covered under the terms of this
warranty.
Freight damages for products or parts are not covered under the terms of the warranty.
Porcelain/Enamel: Absolute perfection is neither guaranteed nor commercially possible. Any chips must be
reported and inspected by the authorised selling dealer within three (3) days of installation. Any damage of this
type not reported after this time period will be subject to rejection and any related warranty will not apply.
Special Finishes: Expect some changes in color as the product "ages" with constant heating and cooling. The
manufacturer warranty does not cover tarnishing, changing colors and/or marks (i.e. finger prints, etc.) after the
purchase of the product. Damage from the use of abrasive cleaners is not covered by warranty.
Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior
authorisation from FPI may void this warranty.
INCORRECT INSTALLATION IS NOT COVERED BY WARRANTY. A SERVICE OR CALLOUT FEE WILL BE CHARGED IN
THESE CIRCUMSTANCES.

Regency Hume Freestanding Wood Fire 15
WARRANTY
warranty
Limitations of Liability:
1. Exclusion of implied terms
The customer may have the benefit of consumer guarantees under the Australian Consumer Law. To the maximum
extent permitted by law, all terms, conditions or warranties that would be implied into this Warranty or in
connection with the supply of any goods or services by the supplier under law or statute or custom or international
conventions are excluded.
2. Limitation of liability
(a) To the maximum extent permitted by law and subject to clauses 1 and 3, the supplier’s total liability arising out
of or in connection with its performance or its obligations pursuant to this Warranty, or arising out of or in
connection with the supply of specific goods or services (including pursuant to or for breach of this Warranty,
under statute, in equity or for tort, including negligent acts or omissions) is limited as follows: (i) the supplier shall
have no liability to the customer for any Consequential Loss; (ii) without limiting the effect of clause 2(a)(i), the
supplier’s total aggregate liability for Loss, however arising, shall not exceed the GST exclusive aggregate price paid
by the customer to the supplier for the specific goods or services that gave rise to the Loss in question.
(b) The limitations and exclusions in this sub-clause do not apply to the extent that any Loss is directly attributable
to: (i) the personal injury or death caused by the supplier’s default, breach of this Warranty or negligence; or (ii)
fraud by the supplier.
(c) Each party must take reasonable steps to mitigate any Loss it suffers or incurs.
3. Limitation of liability under Australian Consumer Law Guarantees
(a) To the extent that goods supplied by the supplier are not goods of a kind ordinarily acquired for personal,
domestic or household use and the customer is deemed to be a consumer for the purposes of section 64A of the
Australian Consumer Law, the customer agrees that the supplier’s liability for a failure to comply with a consumer
guarantee that the customer may have a benefit under the Australian Consumer Law (other than a guarantee
under sections 51 (title), 52 (undisturbed possession) and 53 (undisclosed securities)), is limited to, at the option of
the supplier, one or more of the following: (i) replacement of the goods or the supply of equivalent goods; (ii) the
repair of the goods; (iii) the payment of the cost of replacing the goods or of acquiring equivalent goods; or (iv)
equivalent goods; or (v) the payment of the cost of having the goods repaired.
(b) To the extent that services supplied by the supplier are services other than services of a kind ordinarily acquired
for personal, domestic or household use or consumption, the supplier’s liability for failure to comply with a
consumer guarantee that the customer may have the benefit of is limited to, at the option of the supplier: (i) the
supply of the services again; or (ii) the payment of the cost of having the services supplied again.
4. Subject to Change
This Limited Warranty is given at the time of sale and purchase of the relevant fireplace product. The terms of this
Limited Warranty may be amended from time to time by FPI in accordance with changes to business practices,
consumer laws or other legal requirements. The rights and protections granted under the Limited Warranty are
those in force in relation to a fireplace product at the time and in the place of sale of that product, and only those
terms will be applicable in respect of that product.
5. Severability
Any term of this Limited Warranty that is invalid or unenforceable in any jurisdiction is to be read down for the
purposes of that jurisdiction, if possible, so as to be valid and enforceable, and is otherwise capable of being
severed to the extent of the invalidity or unenforceability, without affecting the remaining provisions of this
Limited Warranty or affecting the validity or enforceability of that provision in any other jurisdiction.
6. Definitions
For purposes of clauses 1, 2 and 3:
(a) Consequential Loss means loss of expected savings, loss of use, loss of opportunity, loss of profit, loss of
revenue, increased financing costs, loss arising from delay, or any consequential, special or indirect loss or damage,
whether or not the possibility or potential extent of the loss or damage was known or foreseeable, and whether
arising from a claim under indemnity, contract, tort (including negligence), statute or otherwise.
(b) Loss means any expense, cost or damage of any kind and includes Consequential Loss and a fine or penalty
imposed by a statutory or other authority.
Revision Date: December 2016 Regency Wood Products Warranty

16 Regency Hume Freestanding Wood Fire
WARRANTY
warranty
Revision Date: November 2016
Regency Outdoor Products Warranty
How to Obtain Warranty Service:
Customers should contact the authorised selling dealer to obtain warranty service. In the event the authorised
selling dealer is unable to provide warranty service, please contact FPI by mail at the address listed below. Please
include your name, address, purchase date, selling dealer, serial #, type of unit, a brief description of the problem,
email and telephone contact information, and a copy of your original tax invoice. A representative will contact you
to make arrangements for an inspection and/or warranty service. (See below for Western Australia and/or New
Zealand)
Please note Fireplace Products Australia Pty Ltd does not provide installation services.
Fireplace Products Australia Pty Ltd
1 –3 Conquest Way
Hallam, VIC
Australia, 3803
Phone: [phone]
Fax: [phone]
To obtain warranty service in Western Australia and/or New Zealand, please contact one of our
authorised distributors in those areas:
Western Australia:
Air Group Australia
28-30 Division St.
Welshpool, WA
Australia, 6106
Phone: [phone]
Fax: [phone]
New Zealand:
Aber Holdings Ltd
PO Box 10095
Te Rapa, Hamilton
New Zealand, 3241
Freephone: 0800 161 161
Product Registration and Customer Support:
Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and
marketing of hearth products. To provide the best support for your product, we request that you complete a
product registration form at http://www.regency-fire.com.au/Customer-Care/Warranty-Registration.aspx within
ninety (90) days of purchase.

Regency Hume Freestanding Wood Fire 17
WARRANTY
warranty
Product Registration and Customer Support:
Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and
marketing of hearth products. To provide the best support for your product, we request that you complete a product
registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
For purchases made in CANADA or the UNITED STATES:
http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx
For purchases made in AUSTRALIA:
http://www.regency-fire.com.au/Customer-Care/Warranty-Registration.aspx
You may also complete the warranty registration form below to register your Regency Fireplace Product and mail and/or
fax it back to us, and we will register the warranty for you. It is important you provide us with all the information below in
order for us to serve you better.
Warranty Registration Form (or Register online immediately at the above Web Site):
Warranty Details
Serial Number (required):
Purchase Date (required) (mm/dd/yyyy):
Product Details
Product Model (required):
Dealer Details
Dealer Name (required):
Dealer Address:
Dealer Phone #:
Installer:
Date Installed (mm/dd/yyyy):
Your Contact Details (required)
Name:
Address:
Phone:
Email:
For purchases made in CANADA:
FPI Fireplace Products
International Ltd.
6988 Venture St.
Delta, British Columbia
Canada, V4G 1H4
For purchases made in the UNITED STATES:
Fireplace Products U.S., Inc.
PO Box 2189 PMB 125
Blaine, WA
United States, 98231
Phone: [phone]
Fax: [phone]
Phone: [phone]
Fax: [phone]
For purchases made in AUSTRALIA:
Fireplace Products Australia Pty
Ltd
1- 3 Conquest Way
Hallam, VIC
Australia, 3803
Phone: [phone]
Fax: [phone]
For fireplace care and tips and answers to most common questions please visit our Customer Care section on our Web Site.
Please feel free to contact your selling dealer if you have any questions about your Regency product.

18 Regency Hume Freestanding Wood Fire

Regency Hume Freestanding Wood Fire 19

Printed in Canada
© Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
Installer: Please complete the following information
Dealer Name & Address:______________________________________________
___________________________________________________________________
Installer: ___________________________________________________________
Phone #: ___________________________________________________________
Date Installed: ______________________________________________________
Serial #:____________________________________________________________
