Regency Panorama PG33NG4-R Quick start guide

Models:
PG33NG4-R
PG33LPG4-R
Owners &
Installation
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Manual
12.19.16
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4533-2000, NZS
5262 and have been certied by the
Australian Gas Association for installa-
tion and operation as described in these
Installation and Operating Instructions.
Your unit should be serviced annu-
ally by an authorised service person.
918-649d
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
Panorama
®
PG33
Gas Inbuilt
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the re
department.

TO THE NEW OWNER:
Congratulations!
You are the owner of a state-of-the-art Gas Stove by FPI FIREPLACE PRODUCTS INTERNATIONAL. The
PG33 has been designed to provide you with all the warmth and charm of a wood replace. The model
PG33 has been approved by the Australian Gas Association for both safety and e󰀩ciency. As it also bears
our own mark, it promises to provide you with economy, comfort and security for many trouble free years
to follow. Please take a moment now to acquaint yourself with these instructions and the many features of
your Regency Fireplace.

Regency PG33NG4-R Gas Inbuilt 3
table of
contents
Data Badge
Copy of Data Badge ................................................... 4
Installation
IMPORTANT: SAVE THESE INSTRUCTIONS..............5
Before You Start ............................................................5
General Safety Information............................................5
Manufactured Mobile Home Additional Requirements ..5
Installation checklist.......................................................6
Locating your gas stove.................................................6
Unit dimensions.............................................................7
Clearances ....................................................................7
Combustible mantels.....................................................7
Mantel leg clearances....................................................7
Framing and nishing ....................................................8
Unit assembly................................................................9
Prior to installation.........................................................9
Flueing introduction .......................................................9
Exterior Flue Termination Locations ............................10
Regency Direct Flue System (Flex)............................ 11
Horizontal Terminations Only....................................... 11
Minimum Flex Kit Center-Line (NG & LPG)................. 11
Minimum Flex Kit Center-Line (ULPG)........................ 11
Installation procedures ................................................12
Simpson Dura-Flue ueing..........................................13
Horizontal or Vertical Terminations ..............................13
Flueing arrangements - Vertical terminations .............14
Simpson dura-ue direct ue gs system......................14
(NG, LPG & ULPG) .....................................................14
Flueing arrangements - horizontal terminations ..........16
Simpson dura-ue direct ue gs system and..............16
REGENCY DIRECT FLUE SYSTEM (FLEX) .............16
(NG, LPG & ULPG with ULPG Burner) .......................16
Minimum......................................................................16
Simpson Dura-Flue Center-Line..................................16
Minimum Flex Kit Center-Line .....................................16
Flueing arrangements - horizontal terminations ..........17
Simpson dura-ue direct ue gs system and..............17
Regency direct ue system (ex) ...............................17
(ULPG with NG/LPG Burner).......................................17
Horizontal installations.................................................21
Vertical Termination .....................................................22
Gas connection............................................................23
Gas pipe pressure Testing...........................................23
Aeration adjustment.....................................................23
Conversion from NG to LPG........................................24
Optional brick panels...................................................26
LOG SET INSTALLATION ...........................................26
Flush louvers ...............................................................27
Standard Flush Door ...................................................28
Wiring ..........................................................................29
Operating Instructions
Copy of the Lighting Plate instructions .......................30
Remote control ...........................................................31
Lighting instructions.....................................................31
Resetting the unit.........................................................31
Shutdown instructions .................................................31
First re........................................................................31
Operating instructions .................................................31
Fan operation ..............................................................32
Summary of controls ...................................................32
Maintenance
Normal Operating Sounds of Gas Appliances .............32
Gold-plated or brass louvers/trim ................................34
Log replacement..........................................................34
Glass Gasket...............................................................34
Door Glass...................................................................34
Fan replacement..........................................................35
Removing Valve tray....................................................36
Parts List
Electronic components parts list..................................37
Main Assembly ............................................................38
Burner & Log Assembly ...............................................39
Flush Front & Louvers .................................................40
Warranty
Warranty ......................................................................41

4Regency PG33NG4-R Gas Inbuilt
SAFETY LABEL
data badge
This is a copy of the label that accompanies each PG33 Gas Fireplace. We have printed a copy of the contents here for your review.
DATA BADGE NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a di󰀨erence, the label on the unit is
the correct one.
(Australia Only)
Part #: 918-326e
Colour: Black on Grey
Size: 100%
July 11/06: added mm under injector size.
July 10/13: Updated standard
Jan. 9/14:Rev. D - updated E. Aus address
Sept. 27/16:Rev. E - updated model name
Electrical:240VAC50Hz1.0ampmax.
Serial
Number
918-326e
N2134
Regency Gas Fireplace
269
Gas Type NG LPG ULPG
Model
PG33NG4-R PG33LPG4-R PG33ULPG4-R
Gas Consumption 23.7mj. 23.5mj. 20.3mj.
Manifold Pressure 0.95 kPa 2.61 kPa 2.40 kPa
Injector Size 1x#44 1x#54 1x#55
2.18mm 1.4mm 1.32mm
Model
AGA 6702 G
AS 4553
Distributed by:
Western Australia:
Air Group Australia
28 Division St
Welshpool, WA 6106
Eastern Australia:
Fireplace Products
Australia Pty. Ltd.
1 Conquest Way
Hallam, VIC 3803
To be installed by an authorised person in
accordance with installation instructions
provided with the appliance.

Regency PG33NG4-R Gas Inbuilt 5
installation
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The P33-NG or P33-LPG Direct Flue Fireplace must
be installed in accordance with these instructions.
Carefully read all the instructions in this manual
rst. Consult the "authority having jurisdiction" to
determine the need for a permit prior to starting the
installation. It is the responsibility of the installer
to ensure this replace is installed in compliance
with manufacturer's instructions and all applicable
codes.
BEFORE YOU START
Safe installation and operation of this appliance
requires common sense, however, we are required
by the Canadian Safety Standards and ANSI Stand-
ards to make you aware of the following:
MANUFACTURED
MOBILE HOME
ADDITIONAL
REQUIREMENTS
1) Ensure that structural members are not cut or
weakened during installation.
2) Ensure proper grounding using the #8 ground
lug provided. See page 35.
GENERAL SAFETY IN-
FORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions,local gas tting regulations, mu-
nicipal building codes, water supply regulations,
electrical wiring regulations, withAS5601-2004
(AGA gas installation code) NZS 5261 (New
Zealand)
2) Installation and repair should be done ONLY
by an authorised person.
3) THIS APPLIANCE IS NOT INTENDED AS A
FIREPLACE INSERT. DO NOT CONNECT TO
MASONARY FLUE.
4) This appliance must be connected to the
specied ue and termination cap to the
outside of the building envelope. Never ue
to another room or inside a building. Make
sure that the ue is tted as per Flueing
instructions.
5) Inspect the ueing system annually for blockage
and any signs of deterioration.
6) Flueing terminals shall not be recessed into a
wall or siding.
7) Any safety glass removed for servicing must
be replaced prior to operating the appliance.
8) To prevent injury, do not allow anyone who is
unfamiliar with the operation to use the replace.
9) Wear gloves and safety glasses for protection
while doing required maintenance.
10) Be aware of electrical wiring locations in walls
and ceilings when cutting holes for termination.
11) Under no circumstances should this appliance
be modied. Parts that have to be removed for
servicing should be replaced prior to operating
this appliance.
12) Installation and any repairs to this appliance
should be done by an authorised service per-
son. An authorised service person should be
called to inspect this appliance annually. Make
it a practice to have all of your gas appliances
checked annually.
13) Do not slam shut or strike the glass door.
14) Under no circumstances should any solid fuels
(wood, paper, cardboard, coal, etc.) be used in
this appliance.
15) The appliance area must be kept clear and
free of combustible materials, (gases and other
ammable vapours and liquids).
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC.IT IS IMPERATIVETHAT
CONTROLCOMPARTMENTS,BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IFTHERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OF THE ROOM AND AWAY FROM HOT
SURFACES.

6Regency PG33NG4-R Gas Inbuilt
installation
INSTALLATION
CHECKLIST
1) Locate appliance
a) Room location, page 6
b) Clearances to Combustibles, page 7
c) Mantle Clearances, page 7
d) Framing & Finishing Requirements,
page 8
e) Flueing Requirements, pages 10 to 15.
2) Assemble Top Facing Support and Side
Nailing Strips, page 9. (NOTE: must be done
before installing unit into replace.)
3) Install ue, pages 10 to 25.
4) Make gas and electrical connections. Test
the pilot. Must be as per diagram. Page 26.
Convert to LPG if desired, page 27.
5) Install brick panels (optional), page 33.
6) Install logs and embers and rockwool where
indicated on page 33.
7) Install Flush Door Front (Standard) and
optional Flush Gold Trim, page 35.
8) Install optional Double Screen Door, page
36.
9) Install Louvers
10) Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is r-
ing correctly and operation fully explained
to customer.
This includes:
1) Clocking the appliance to ensure the correct
ring rate (rate noted on label) after burning
appliance for 15 minutes.
2) If required, adjusting the primary air to ensure
that the ame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
LOCATING YOUR
GAS STOVE
Diagram 1
1) When selecting a location for your stove,
ensure that the clearances outlined on this
page are met.
2) Provide adequate clearances for servicing.
3) The appliance must be installed on a at,
solid, continuous surface (e.g. wood, metal,
concrete). This may be the oor, or raised up
on a platform to enhance its visual impact.
If the appliance is going to be installed on
carpeting, combustible linoleum tile or other
combustible material other than wood oor-
ing, the appliance must be installed on a
metal or wood panel extending the full width
and depth of the appliance.
4) The PG33 can be installed in a recessed
position or framed out into the room as in
A, B, C, D. See Diagram 1.
5) This appliance is Listed for bedroom instal-
lations when used with a Listed Millivolt
Thermostat. Some areas may have further
requirements, check local codes before
installation.
6) The PG33 Direct Flue Gas Fireplace is ap-
proved for alcove installations, which meet
the clearances listed on this page.
7) We recommend that you plan your instal-
lation on paper using exact measurements
for clearances and oor protection before
actually installing this appliance. Have a
qualied inspector, dealer, or installer review
your plans before installation.
Note: For ue terminations see page 10.
A) Flat on Wall
B) Flat on Wall Corner
C) Recessed into Wall/Alcove
D) Corner
33"(838mm)
33"(838mm)
23"(584mm)
12-3/4"(324mm)
29"(737mm)
28-1/2"(724mm)
31-1/2"(800mm)

Regency PG33NG4-R Gas Inbuilt 7
installation
COMBUSTIBLE MANTELS
Because of the extreme heat this replace emits, the mantel clearances are critical.
Combustible mantel clearances from top of unit are shown in the diagram below.
Note: A non-combustible mantel may be installed at a lower height if the framing is made of
metal studs covered with a non-combustible board.
This drawing is to scale at 1:6 (one inch = 6 inches). Mantel can be installed anywhere in shaded
Clearances for Bay or Flush Front
UNIT DIMENSIONS
The clearances listed below are Minimum dis-
tances unless otherwise stated:
area or higher using the above scale.
Note: Ensure the paint that is used on the mantel and the facing is "heat
resistant" or the paint may discolour.
MANTEL LEG CLEARANCES
Combustible mantel leg clearances as per diagram below:
Maximum
CLEARANCES
A major cause of chimney related res is
failure to maintain required clearances (air
space) to combustible materials. It is of the
greatest importance that this replace and
ue system be installed only in accordance
with these instructions.
Clearance to Combustibles from:
Back 0" (0mm)
Side 0" (0mm)
Floor 0" (0mm)
NOTE: The minimum oor clearance must be
maintained from the top surface of the carpet-
ing, tile, etc.
Minimum Clearance from Top of Unit to:
Mantel* min. 7" (177mm)
Ceiling 30" (762mm)
from top of unit.
Side Wall Clearance
Bay or Flush Front 7-1/2" (191mm)
Minimum Flue Clearances:
2-1/2" (64mm) Horizontal Top
1-1/2" (38mm) Horizontal Side
1-1/2" (38mm) Horizontal Bottom
1-1/2" (38mm) projection
at 2" (51mm) minimum
clearance.
1-1/4" (32mm) Vertical Flue Clearance
(Simpson)
1-1/2" (38mm) Vertical Flue Clearance
(Flex)
Alcove Clearances:
Max. Depth 36" (914mm)
Min. Width 48" (1219mm)
Min. Height 59" (1499mm)
* see mantel clearance instructions.
WARNING
Fire hazard is an extreme risk
if these clearances are not ad-
hered to.

8Regency PG33NG4-R Gas Inbuilt
installation
1) Determine the total thickness of facing mate-
rial (e.g. drywall plus ceramic tiles) to allow
the nished surface to be ush with the front
of the unit. Total facing thickness can vary
from 1/2" (13mm) to 1-1/4" (32mm) thick.
Install Side Nailing Strips, and Top Facing
Support before unit is slipped into position.
See page 9 for assembly details.
2) Frame in the enclosure for the unit with
framing material.
3) For exterior walls, insulate the enclosure to
the same degree as the rest of the house,
apply vapour barrier and drywall, as per lo-
cal installation codes. (Do not insulate the
replace itself.)
4) The top of the unit must not be closer than
30" (762mm) to the ceiling.
5) Combustible material may be brought up to
the top and sides of the unit and be covered
with ceramic tiles, bricks, rock or other suit-
able combustible nishing materials.
Note: The unit does not have to be complete-
ly enclosed in a chase. The clearance
on top of the unit is 0" to the stando󰀨s
so combustible building materials can
be laid directly on top of the stando󰀨s.
You must maintain clearance from the
ue to combustible materials for ex
for Simpson Dura-Flue, see page 7.
6) Use steel studs for framing where the
1-1/2" (38mm) clearance from the ue to
combustible material cannot be maintained.
FRAMING AND FINISHING
16-1/2”
(419mm)
Minimum
4"
(102mm)
3"
(76mm)
1-1/2"
(38mm)
30”
(762mm)
10" (254mm)
dia. Hole through
wall for Dura-Vent
1/2"
(13mm)
Drywall
Top Header
Opening for gas
connection
12-3/4”
(324mm)
Minimum
4"
(102mm)
3"
(76mm)
1-1/2"
(38mm)
26”
(660mm)
10" (254mm)
dia. Hole through
wall for Flex
1/2"
(13mm)
Drywall
Top Header
Opening for gas
connection
Simpson Dura-Flue
Minimum Clearances
Flex Pipe
Minimum Clearances
NOTE: If this is an outside corner, the minimum
distance between the ue and the outside corner
is 6" (15cm) with AstroCap termination cap or
12" (30cm) with Dura-Flue termination cap.
Vertical Termination or
Vertical Rise with Horizontal
Termination
For Both Simpson & Flex
Rear Termination
NOTE: If this is an outside corner, the minimum
distance between the ue and the outside corner
is 6" (15cm) with AstroCap termination cap or 12"
(30cm) with Dura-Flue termination cap.
Simpson Dura-Flue Piping
Flex Piping
For Both Simpson & Flex

Regency PG33NG4-R Gas Inbuilt 9
installation
For a facing material depth of
1-1/4"(32mm), the top facing
support must be reversed.
The Top Facing Support, the Side Nailing Strips
and the 2 Top Stando󰀨s must be correctly po-
sitioned and attached to the top before the unit
is put into position.
Top Stando󰀨 Assembly
The top stando󰀨s are shipped in a at position
and must be pulled up and bent into the cor-
rect shape.
1) Remove the stando󰀨s from on top of the
rebox by undoing the screws.
2) Take each stando󰀨 and bend into the cor-
rect shape. Bend up at the bend lines until
the screw holes in the stando󰀨 and the
pre-punched screw holes on the rebox top
line-up.
3) Attach the stando󰀨s securely to the top with
4 screws per stando󰀨.
Note: Secure the stando󰀨s to the holes
closest to the edge of the rebox top.
Top Facing Support &
Side Nailing Strips
Determine the total thickness of facing mate-
rial (e.g. drywall plus ceramic tiles) to allow the
nished surface to be ush with the front of the
unit. Total facing thickness can vary from 1/2"
(13mm) to 1-1/4" (32mm) thick.
The Top Facing Support & Side Nailing Strips
can be mounted in various positions depending
on the thickness of the facing material.
1) Mount Top Facing Support using the 3
supplied screws into the three pre-punched
screw holes on the top front of the unit.Adjust
support to desired facing material depth.
2) Mount Side Nailing Strip using the 3 supplied
screws into the three pre-punched screw
holes at the front sides of the unit. Adjust
support to desired facing material thickness.
UNIT ASSEMBLY
PRIOR TO INSTALLATION
Top Facing
Support
Side
Nailing
Strips
(folded out)
FLUEING INTRODUCTION
The PG33 uses the "balanced ue" technology Co Axial system. The inner liner ues products of combustion to the outside while the outer liner
draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm
room air up the chimney.
There are 2 ue systems approved for use with the PG33: the Regency Direct Flue System (Flex) for Horizontal Terminations only (see pages 11-
12), and the Simpson Dura-Flue Systems for Horizontal and Vertical Terminations (see pages 13-25).
Note: These ue pipes must not be connected to any other appliance.
The gas appliance and ue system must be ueed directly to the outside of the building, and never be attached to a chimney serving a separate
solid fuel or gas burning appliance. Each direct ue gas appliance must use it's own separate ue system. Common ue systems are prohibited.
NOTE: Ensure compliance with the outside ue terminal location before cutting hole as both dimensions must be met.

10 Regency PG33NG4-R Gas Inbuilt
installation
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced ue terminals or
the ue terminals of outdoor appliances
according to AS5601-2004 (AGA gas installation code) or NZS 5261 (New Zealand)
Minimum
Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other ue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-oor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-oor ventilation
(see also Note (I)): see table below
NOTES:
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest par
to of the terminal.
(III) Prohibited area below electricity meter or fuse box extends to ground level.
(IV) A ue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on
at least two sides and a free ow of air at the appliance is achieved.
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h input Up to 50 MJ/h input Over 50 MJ/h input
to 150 MJ/h input
Over 150 MJ/h input
150 500 1000 1500

Regency PG33NG4-R Gas Inbuilt 11
installation
6-7/8"
(173mm)
dia. Flue pipe
4" (102mm)
dia. flue pipe
Wall Thimble (2 pc)
(required in
Canada only)
Termination Cap
(Part# 946-523/P)
AstroCapTM
spring
spacer
REGENCY DIRECT FLUE SYSTEM (FLEX)
HORIZONTAL TERMINATIONS ONLY
This ueing system, in combination with the PG33 Direct Flue Gas Fireplace, have been tested and listed as a direct ue heater system by AGA. The
location of the termination cap must conform to the requirements in the Flue Terminal Locations diagram on page 10.
Regency Direct Flue (Flex) System Termination Kit (Part # 946-513) includes all the parts needed to install the PG33 with a maximum
run of 2 feet. If installing the P33 with a continuous ue length of more than 2 ft (.6m) to a maximum of 10 ft. (3.0m) using Kit # 946-515 (4 ft) or
946-516 (10 ft) or see page 13 for alternate ueing arrangements.
1) 6-7/8" dia. exible liner (2 ft. length)
2) 4" dia. exible liner (2 ft. length)
3) spring spacers (3)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" drill point, stainless steel (4)
Wherever necessary due to external
location of cap, the AstroCap can
be replaced with the FPI Riser Flue
Termination Cap or the Dura-Vent
Snorkel Termination Cap.
See also
Figure 1 below.
Notes:
1) Liner sections should be continuous without any
joints or seams.
2) Only Flex pipe purchased from Regency may be
used for Flex installations.
Minimum Flex Kit Center-Line (NG
& LPG)
Vertical Height (M)
Min. 26

(660mm)
Horizontal (M)
Max. 24"(0.6m)
0.6
0
1.8
1.2 2.4
0
0.6
1.2
1.8
2.4
IMPORTANT
If using any Cabinet Mantels with Part # 510956,
510958, 510962, 510964 and 510834 the wall thimble
must be secured rst and ueing must be attached
to unit before sliding into nal position.
Also Simpson Dura-Flue ueing cannot be used with
any of the mantels noted above.
Minimum Flex Kit Center-Line
(ULPG)
0
0.6
0
1.8
1.2 2.4
Vertical Height (M)
Min. 49.6
(1260mm)
Horizontal (M)
Max. 24"(0.6m)
0.6
1.2
1.8
2.4
IMPORTANT NOTE
If the Burner is not a ULPG Burner,
a minimum ue rise of 1260mm
(total height from the oor) MUST
BE adhered to.

12 Regency PG33NG4-R Gas Inbuilt
installation
Termination Cap
Wall Thimble2pieces
(10" (254mm) Outer Diameter)
2”x4”or2”x6”
(21mmx102mm
or 21mmx152mm)
6-7/8"
(175mm)
dia. air intake
4" (102mm)
dia. flue pipe
with spring spacer
Screws
(4 per connection)
Screws
(3 per
connection)
Outside Wall
Mur extérieur
Furring
Strips
Fourrures en bois
Furstrp.eps
see also c34020a.eps
furstrpf.eps
french
INSTALLATION PROCEDURES
for Regency Direct Flue System (Flex)
1) Locate the unit in the framing, rough in the gas (preferably on the right side of the unit) and the electrical (Junction block is on the left side)
Minimum and Maximum Flue Clearances
on the left. Locate the centerline of the
termination and mark wall accordingly.
Cut a 10"(254mm) hole in the wall (inside
dimension).
Note: To make the installation more aes-
thetically pleasing, we recommend
framing out a square to mount the
terminal to.
Note: A 2-1/2" (64mm) horizontal top and
1-1/2" (38mm) horizontal sides &
bottom clearance around the liner
*If this is an outside corner, the minimum distance between the ue and the outside
corner is 6" (15cm) with AstroCap termination cap or 12" (30cm) with Dura-Flue
termination cap. See "F" on the diagram on page 10.
must be maintained except that only
a 1" (25mm) clearance is needed at
the termination end. We recommend
framing a 10"(254mm) x 10"(254mm)
(inside dimensions) hole to give
structural rigidity for mounting the
termination.
Note: If installing termination on a siding
covered wall, furring strips must be
used to ensure that the termination
is not recessed into the siding.
2) Level the replace and fasten it to the fram-
ing using nails or screws through the nailing
strips.
3) Assemble the ue assembly by applying
Mill Pac to the 4"(100mm) inner collar of the
termination and slipping the 4"(100mm) liner
over it at least 1-3/8" (35mm). Fasten with
the 3 screws (drilling pilot holes will make this
easier). Apply Mill Pac or high temperature
silicone to the 6-7/8"(175mm) ex pipe and
slip it over the 6-7/8" outer collar of the ue
terminal at least 1-3/8"(35mm) and fasten
with the 3 screws.
4) Separate the 2 halves of the wall thimble and
securely fasten the one with the tabs to the
outside wall making sure that the tabs are
on top and bottom. Fasten the other thimble
half to the inside wall. The thimble halves
slip inside each other and can be adjusted
for 2 x 4 or 2 x 6 walls. The liners must slip
over the collars a minimum of 1-3/8".
5) Slip the assembled liner and termination
assembly through the thimble making sure
the termination cap faces up (there are
markings on the cap that show which way
is up). This will position the termination cap
with proper down slope for draining water.
Fasten the cap to the outer wall with the 4
supplied screws.
6) Pull the centre 4"(100mm) liner and outer
6-7/8"(175mm) liner out enough to slip over
the ue collars of the replace.
7) Apply Mill Pac over the replace inner collar
and slip the 4"(100mm) liner down over it
and attach with 3 supplied screws.
8) Do the same with the 6-7/8"(175mm) liner.
9) Apply a bead of silicone between the thimble
and termination and around the outer edge
of the terminal at the wall in order to keep
the water out.
IMPORTANT: Do not locate termination
hood where excessive snow or ice
buildup may occur. Be sure to check
ue termination area after snow falls,
and clear to prevent accidental block-
age of ueing system. When using
snow blowers, make sure snow is not
directed towards ue termination area.

Regency PG33NG4-R Gas Inbuilt 13
installation
Pipe Length
Vertical
Terminal
Storm Collar
Flashing
Ceiling Firestop
24" (610mm)
Pipe Length
Adj.Pipe Length
11"-14-5/8"
(279mm-372mm)
90 Elbow
o
Horizontal
Termination
Cap
Wall Thimble
Vinyl Siding
Standoff (Optional)
Flue Adapter
45 Elbow
o
Adj.Pipe Length
11"-14-5/8"
(279mm-372mm)
Horizontal
Termination Cap
Wall Thimble
Vinyl Siding
Standoff (Optional)
Simpson Dura-Flue
Direct Flue GS
SIMPSON DURA-FLUE FLUEING
Horizontal or Vertical Terminations
The Simpson Dura-Flue Direct Flue System o󰀨ers
a complete line of component parts for installation
of both horizontal and vertical installations. Many
items are o󰀨ered in decorative black, as well as
galvanized nish. We recommend using the galva-
nized nish for installation with the PG33.
The minimum components required for a basic
horizontal termination are:
1 AstroCap Horizontal Termination Cap
1 45oElbow
1 Flue Adaptor
1 Wall Thimble
1 Length of pipe to suit wall thickness (see
chart)
For siding other than vinyl furring strips may be
used, instead of the vinyl siding stando󰀨, to cre-
ate a level surface to mount the ue terminal. The
Terminal must not be recessed into siding.
If a Vinyl Siding Stando󰀨 is required (it must be
used with vinyl siding), measure to outside surface
of wall without siding and add 2 inches.
The Regency AstroCapTM is certied for installa-
tions using FPI ueing systems as well as Simpson
Dura-Vent® and Direct Vent GS.
RegencyTM, and Regency AstroCapTM are the
proprietary trademarks of FPI Fireplace Products
International Ltd.
Dura-Vent® and Direct Vent GS are registered
and/or proprietary trademarks of Simpson Dura-
Vent Co. Inc.
Wherever necessary due to external
location of cap, the AstroCap can be
replaced with the FPI Riser Vent Ter-
mination Cap or the Dura-Vent Snorkel
Termination Cap.
Flat Wall Installation
7-1/4" (184mm)
10-1/4" (260mm)
13-1/4" (337mm)
12-1/4" - 15-7/8"
(311mm - 641mm)
18-1/4" - 25-1/4"
(464mm - 381mm)
Max. Wall Flue Length
Thickness Required
6" (152mm)
9" (229mm)
12" (305mm)
11" - 14-5/8" Adj. Pipe
(279mm - 371mm)
11" - 14-5/8" Adj. Pipe
(279mm - 371mm)

14 Regency PG33NG4-R Gas Inbuilt
installation
• Flue must be supported at o󰀨sets.
• Firestops are required at each oor level and whenever passing through a wall.
• Maintain clearances to combustibles.
Note: Must use optional ue adapter when using Simpson Dura-Vent pipe (Part # 510-994).
FLUEING ARRANGEMENTS - VERTICAL TERMINATIONS
SIMPSON DURA-FLUE DIRECT FLUE GS SYSTEM
(NG, LPG & ULPG)
The shaded area in the diagram shows all allowable combinations of straight vertical and o󰀨set to vertical terminations , using one 90oelbow, with
Simpson Dura-Flue Direct Flue GS ue systems for NG, LPG and ULPG.
Minimum
8'6 (2.6m)
Maximum 40 (12.2m)
40
8
10
12
14
16
18
20
22
24
26
28
30
6
0
2
4
2
0 6
4
Vertical Height (ft/m)
Horizontal (ft/m)
(5.5m)
(1.8m)
(3.7m)
(7.3m)
(9.1m)
(0.6m)
(1.2m)
(1.8m)
(10.9m)
(10.4m)
(9.8m)
(8.5m)
(7.9m)
(6.7m)
(6.1m)
(4.9m)
(4.3m)
(3.0m)
(2.4m)
(0.6m)
(1.2m)
(12.2m)
33.6
Vertical Height (M)
Minimum 8'6 (2.6m)
Maximum 27 (8.2m)
Horizontal (M)
Min. 12 (305mm)
3
3.6
4.2
4.8
5.4
6
6.6
7.2
8
8.6
9.2
9.8
10.4
11
11.6
Max. 10 (3m)
(centerline to centerline)
0
0.6
1.2
1.8
2.4
0.6
0
1.8
1.2 2.4

Regency PG33NG4-R Gas Inbuilt 15
installation
The PG33 is approved for a maximum 40 ft. straight vertical, with Simpson
Dura-Flue Direct Flue GS ue systems for LPG, ULPG and NG.
The shaded area in the diagram shows all allowable combinations of straight
vertical and o󰀨set to vertical terminations with Simpson Dura-Flue Direct Flue
GS ue systems for LPG, ULPG and NG. Maximum two 45oelbows allowed.
• Flue must be supported at o󰀨sets.
• Firestops are required at each oor level and whenever passing
through a wall.
• Maintain clearances to combustibles.
Horizontal (M)
Maximum: 40 ft. (12.2m)
Minimum 96 (2.9m)
Minimum 86 (2.6m)
Vertical Height (M)
3
3.6
4.2
4.8
5.4
6
6.6
7.2
8
8.6
9.2
9.8
10.4
11
11.6
0
0.6
1.2
1.8
2.4
12.2
0.6
0
1.8
1.2 2.4

16 Regency PG33NG4-R Gas Inbuilt
installation
0
30” (762mm)
Minimum
Height
Requirement
Horizontal (M)
8"(0.2m)
2 (0.6m)
Vertical Height (M)
3
3.6
4.2
4.8
0
0.6
1.2
1.8
2.4
0.6 1.2 1.8 2.4
3 3.6 4.2 4.8 5.4 6
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
SIMPSON DURA-FLUE DIRECT FLUE GS SYSTEM and
REGENCY DIRECT FLUE SYSTEM (FLEX)
(NG, LPG & ULPG with ULPG Burner)
This diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 45oand one 90oelbow (two 45o elbows equal
one 90o elbow).
Note: Must use optional ue adapter (Part # 510-994) when using Simpson Dura-Vent pipe. (Refer to page 13.)
• Maintain clearances to combustibles.
• Horizontal ue must be supported every 3 feet.
• Firestops are required at each oor level and whenever passing through a wall.
A ue guard should be used whenever
the termination is lower than the specied
minimum or as per local codes.
Note: Regency Direct Flue System (Flex) is
only approved for horizontal termina-
tions.
Minimum
Simpson Dura-Flue Center-Line Minimum Flex Kit Center-Line
Min. 30"
(762mm)
Max. 24"(0.6m)
0
Vertical Height (M)
0.6
1.2
1.8
2.4
0.6
0
1.8
1.2 2.4
Horizontal (M)
Min. 26
(660mm)
Max. 24"(0.6m)
Vertical Height (M)
0
0.6
1.2
1.8
2.4
Horizontal (M)
0.6
0
1.8
1.2 2.4
Important
If using any Cabinet Mantels with
Part # 510956, 510958, 510962,
510964 and 510834 the wall thimble
must be secured rst and ueing
must be attached to unit before
sliding into nal position.
Also Simpson Dura-Flue ueing can-
not be used with any of the mantels
noted above.

Regency PG33NG4-R Gas Inbuilt 17
installation
53.6” (1362mm)
Minimum
Height
Requirement
8"(0.2m)
2 (0.6m)
0
Horizontal (M)
0.6 1.2 1.8 2.4
3 3.6 4.2 4.8 5.4 6
Vertical Height (M)
3
3.6
4.2
4.8
0
0.6
1.2
1.8
2.4
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
SIMPSON DURA-FLUE DIRECT FLUE GS SYSTEM and
REGENCY DIRECT FLUE SYSTEM (FLEX)
(ULPG with NG/LPG Burner)
This diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 45oand one 90oelbow (two 45o elbows equal
one 90o elbow).
Note: Must use optional ue adapter (Part # 510-994) when using Simpson Dura-Vent pipe. (Refer to page 13.)
• Maintain clearances to combustibles.
• Horizontal ue must be supported every 3 feet.
• Firestops are required at each oor level and whenever passing through a wall.
A ue guard should be used whenever the termination is
lower than the specied minimum or as per local codes.
Note: Regency Direct Flue System (Flex) is only ap-
proved for horizontal terminations.
IMPORTANT NOTE
If the Burner is not a ULPG Burner, a
minimum ue rise of 1362mm (total height
from the oor) MUST BE adhered to.

18 Regency PG33NG4-R Gas Inbuilt
installation
Horizontal Flueing with Two (2) 90oElbows
Horizontal Flueing with Two (2) 90oElbows
Horizontal Flueing with Three (3) 90oElbows
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
Option V H + H1 With these options,
maximum total pipe
length is 30 feet with
minimum of 6 feet total
vertical and maximum 8
feet total horizontal.
Please note minimum
1 foot between 90o
elbows is required.
A) 0.3m Min. 0.9m Max.
B) 0.6m Min. 1.2m Max.
C) 0.9m Min. 1.5m Max.
D) 1.2m Min 1.8m Max.
E) 1.5m Min. 2.1m Max.
F) 1.8m Min 2.4m Max.
Option H V H + H1 +H2 With these options,
max. total pipe length
is 30 feet with min. of
11 feet total vertical
and max. 9 feet total
horizontal.
Please note min.
1 foot between 90o
elbows is required.
A) 0.3m Max. 0.3m Min. 0.9m Max.
B) 0.6m Max. 0.9m Min. 1.5m Max.
C) 0.9m Max. 1.5m Min. 1.8m Max.
D) 1.2m Max 2.1m Min 2.1m Max.
E) 1.5m Max 2.7m Min. 2.7m Max.
F) 1.8m Max 3.3m Min 2.7m Max.
Option H V H + H1 +H2 With these options, max.
total pipe length is 30 feet
with min. of 8 feet total
vertical and max. 8 feet
total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
A) 0.3m Max. 0.3m Min. 0.9m Max.
B) 0.6m Max. 0.9m Min. 1.5m Max.
C) 0.9m Max. 1.5m Min. 1.8m Max.
D) 1.2m Max 1.8m Min 2.1m Max.
E) 1.5m Max 2.4m Min. 2.4m Max.

Regency PG33NG4-R Gas Inbuilt 19
installation
Horizontal Flueing with Three (3) 90oElbows
Option V H V + V1 H + H1
Min. Max. Min. Max.
A) 0.6m 0.3m 0.9m 1.2m
B) 0.9m 0.6m 1.2m 1.5m
C) 1.2m 0.9m 1.8m 1.8m
D) 1.5m 1.2m 2.4m 2.1m
E) 1.8m 1.5m 3m 2.4m
F) 2.1m 1.8m 3.65m 2.7m
With these options,
max. total pipe length
is 30 feet with min. of
12 feet total vertical
and max. 9 feet total
horizontal.
Please note min. 1
foot between 90o
elbows is required.
Vertical Flueing with Two (2) 90oElbows
Option V H V + V1
Min. Max. Min
A) 0.3m 1.2m 0.6m
B) 0.6m 1.5m 0.9m
C) 0.9m 1.8m 1.2m
D) 1.2m 2.1m 1.5m
E) 1.5m 2.4m 1.8m
Vertical Flueing with Two (2) 90oElbows
With these options, max. total
pipe length is 30 feet with min.
of 6 feet total vertical and max.
8 feet total horizontal.
Please note min. 1 foot
between 90oelbows is re-
quired.
Option H + H1 V
Max. Min.
A) 0.6m 0.6m
B) 0.9m 0.9m
C) 1.2m 1.2m
D) 1.5m 1.5m
E) 1.8m 1.8m
With these options, max. total
pipe length is 30 feet with min.
of 6 feet total vertical and max.
6 feet total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows. One 90oelbow = Two 45oelbows.
For additional vertical ueing with
2 x 90oelbows, refer to page 15.

20 Regency PG33NG4-R Gas Inbuilt
installation
Vertical Flueing with Three (3) 90oElbows
Option V H + H1 V + V1
Min. Max. Min.
A) 0.6m 0.9m 1.2m
B) 0.9m 1.2m 1.8m
C) 1.2m 1.5m 2.1m
D) 1.5m 1.8m 2.4m
E) 1.8m 2.1m 2.7m
F) 2.1m 2.4m 3m
With these options, max. total
pipe length is 30 feet with min.
of 10 feet total vertical and
max. 8 feet total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
Vertical Flueing with Three (3) 90oElbows
Option H V H + H1 V + V1
Max. Min. Max. Min.
A) 0.3m 0.3m 0.9m 0.9m
B) 0.6m 0.6m 1.2m 1.5m
C) 0.9m 0.9m 1.5m 2.1m
D) 1.2m 1.2m 1.8m 2.7m
E) 1.5m 1.5m 2.1m 3.3m
With these options, max. total
pipe length is 30 feet with min.
of 11 feet total vertical and
max. 7 feet total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
