Regency U32-LP5 User manual

U32 Regency Gas Insert
Model U32-NG5 U32-LP5
Fuel Type Natural Gas Propane
Minimum Supply Pressure 5” W.C. (1.25 kPa) 12” W.C. (2.99 kPa)
Manifold Pressure - High 3.8” W.C. (0.95 kPa) 11” W.C. (2.74 kPa)
Manifold Pressure - Low 1.1” W.C. (0.27 kPa) 2.9” W.C. (0.72 kPa)
Orifice Size -Altitude 0-4500 ft. #37 DMS #52 DMS
Minimum Input
Altitude 0-4500 ft. (0-1372m)
15,300 BTU/h
(4.48 kW)
15,000 BTU/h
(4.40 kW)
Maximum Input
Altitude 0-4500 ft. (0-1372m)
30,000 BTU/h
(8.79 kW)
30,000 BTU/h
(8.79 kW)
Vent Sizing 3” Co-linear 3” Co-linear
Minimum Fireplace Dimensions
The minimum fireplace dimensions for the FPI gas fireplace insert are
shown in the following diagrams:
A
C
B
D
E
F
G
I
H
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
aaaaa
L
aaaaaaaaaa
a
aaaaaaaa
a
a
aaaaaaaa
a
a
aaaaaaaa
a
a
aaaaaaaa
a
a
aaaaaaaa
a
aaaaaaaaaa
M
J
K
N
Dimension Description Contour
Faceplate
Molded
Faceplate
J Height 22” (559mm) 22” (559mm)
K Width 26-1/2” (673mm) 29” (737mm)
L Depth 14” (356mm) 15” (381mm)
M Max. Lintel Bar Depth 9” (229mm) 10” (254mm)
N Rear Width 22-1/2” (572mm) 22-1/2” (572mm)
Dimension Description U32
A Faceplate Width 40-1/4” (1022mm)
B Faceplate Height 26-1/4” (667mm)
C Unit Width 28” (711mm)
D Unit Height 20” (508mm)
E Unit Depth 13-3/4” (349mm)
F Faceplate to Vent Centerline 10-3/4” (273mm)
G Faceplate Depth 1-3/8” (35mm)
H Height to Vent Collar 21-1/16” (535mm)
I Optional or Standard Front Depth 3-3/4” (95mm)
U32 Regency Gas Insert
Approved Venting Systems
Flex Vent Systems: FPI AstroCap™ Flex Vent
125August 2008 Product Specifications Book
Gas Inserts
Gas Inserts

Clearances
Unless otherwise stated the clearances listed below are Minimum
distances to combustible materials. Please Note: A major cause
of chimney related fires is due to a failure to maintain required
clearances (air space) to combustible materials. It is of the greatest
importance that this fireplace and vent system be installed only in
accordance with these instructions.
Combustible Mantels
Because of the extreme heat this fireplace emits, the mantel
clearances are critical. Combustible mantel clearances from top of
the louvers are shown in the diagram below. Mantel may be installed
anywhere in the shaded area or higher.
Note: A non-combustible mantel may be installed at a lower
height.
Note: Ensure the paint that is used on the mantel and the facing
is “heat resistant” or the paint may discolour.
Faceplate
Flush
with
Floor
Combustible
Flooring
Mantle
C
12" Max.
G
G
H
I
A
D
B
E
C
Clearances to Combustibles
Dimension Description U32
A From Unit to Sides 10” (254mm)
B From Unit to Ceiling 47.5” (1207mm)
C From Unit to Mantel see diagram 2 & 3
D From Standard Surround to Sides 4” (102mm)
E From Standard Surround to Ceiling 41.5” (1054mm)
also see diagram 2 & 3
G Maximum Mantel Depth 12” (305mm)
see diagram 2
H Minimum Alcove Width 48” (1219mm)
I Maximum Alcove Depth 36” (914mm)
* No Hearth Required
