Regency F2500 User manual

F2500 Wood Stove | 1
F2500 Wood Medium Stove
UNIT DIMENSIONS
OUTSIDE AIR DIMENSIONS
34 5
8
"
879mm
32 3
16
"
817mm
24"
610mm
21 1
4
"
540mm
24 13
16
"
630mm
27 1
8
"
690mm
6 7
16
"
163mm
33 7
8
"
860mm
31 7
16
"
798mm
7 13
16
"
198mm
Rear
Front
Rear
4-9/16" (115mm)
6-13/16"(173mm)
Images for OUTSIDE AIR DIMENSIONS
Rear
Front
Rear
4-9/16" (115mm)
6-13/16"(173mm)
Images for OUTSIDE AIR DIMENSIONS
34 5
8
"
879mm
32 3
16
"
817mm
24"
610mm
21 1
4
"
540mm
24 13
16
"
630mm
27 1
8
"
690mm
6 7
16
"
163mm
33 7
8
"
860mm
31 7
16
"
798mm
7 13
16
"
198mm
Model F2500
Cordwood BTU’s 78,000 BTU’s
Emissions (grams/hr) EPA Certied 1 gram/hr
Eciency (EPA HHV)* 76%
Eciency (EPA LHV) 81%
Flue Size 6" (152mm)
US Biomass Tax Rebate Eligible Yes
Maximum Log Size 18” (457mm)
Firebox Size 2.3 cu.ft.
*US Biomass Tax Rebate eligibility is based on the HHV value being
greater than or equal to 75%.

2 | F2500 Wood Stove
MINIMUM CLEARANCE TO
COMBUSTIBLE MATERIALS
Please read the section below carefully as clearances depend on whether the airmate or
the rear heat deector is installed on the stove.
Measurements "From Unit" are from the top plate of the stove to a side wall or to a corner,
and from the rear heat shield to a back wall.
Clearances may only be reduced by means approved by the regulatory authority.
Minimum ceiling height - 83" (2108mm)
A
F
F
C
C
B E
D
NOTE: Be aware that local Codes and Regulations may override some clearances listed in this manual.
Check with your local inspector.
NOTE: This clearance is also required for air space between the appliance and wall/ceiling.
Residential Installation “C” Vent (Single Wall)
Unit From Unit From Corner From Flue Center-Line
A B C D E F
Medium F2500M with Airmate 16" (406mm) 8.5" (216mm) 7" (178mm) 28" (711mm) 15" (381mm) 19" (483mm)
with Rear Deector 16" (406mm) 10.5" (267mm) 7" (178mm) 28" (711mm) 17" (432mm) 19" (483mm)
Residential Close Clearance (To be installed with required pipe components)
When the stove is installed as a close clearance residential unit, a listed double wall connector is required from the stove collar to the ceiling level.
Unit From Unit From Corner From Flue Center-Line
A B C D E F
Medium F2500M with Airmate 15" (381mm) 7" (178mm) 5" (127mm) 27" (686mm) 13.5" (343mm) 17" (432mm)
with Rear Deector 15" (381mm) 9" (229mm) 5" (127mm) 27" (686mm) 15.5" (394mm) 17" (432mm)
Mobile Home Close Clearance (To be installed with required pipe components)
"C" Vent single wall pipe is not approved for Mobile Home installations. (Refer to Mobile Home Instructions.)
Unit From Unit From Corner From Flue Center-Line
A B C D E F
Medium F2500M with Airmate 15" (381mm) 7" (178mm) 5" (127mm) 27" (686mm) 13.5" (343mm) 17" (432mm)
with Rear Deector 15" (381mm) 9" (229mm) 5" (127mm) 27" (686mm) 15.5" (394mm) 17" (432mm)

F2500 Wood Stove | 3
FLOOR PROTECTION
(EMBER PROTECTION ONLY REQUIRED)
A combustible oor must be protected by a non-combustible material (like tile, concrete board, or certied to UL-1618 Type 1 (or as dened by
local codes).
Canada: Beneath the heater and extending to at least 18" on the fuel loading side and at least 8" on the sides and back.
USA: Beneath the heater and extending to at least 16" beyond the fuel loading side and ash removal opening and at least 8" on the sides and back
and under the chimney connector extending 2" beyond each side for horizontal applications.
Minimum Overall Depth (Y) of Floor Protector
Reference only when hearth pad is
installed to rear wall at minimum pipe
clearances.
Hearth
Depth
Edge of Fuel door
opening to edge
of hearth
Hearth
Width
Edge of Fuel Door Opening
(Both Sides)
Residential Installation ''C'' Vent (Single Wall)
Unit A B C D
F2500withAirmate Canada 49-1/2" (1257mm) 18" (457mm) 33-11/16" (856mm) 8" (203mm)
USA 47-1/2" (1207mm) 16" (406mm) 33-11/16" (856mm) 8" (203mm)
F2500 with Rear
Deector
Canada 51-1/2" (1308mm) 18" (457mm) 33-11/16" (856mm) 8" (203mm)
USA 49-1/2" (1257mm) 16" (406mm) 33-11/16" (856mm) 8" (203mm)
Residential Close Clearance (To be installed with required pipe components)
Unit A B C D
F2500withAirmate Canada 48" (1219mm) 18" (457mm) 33-11/16" (856mm) 8" (203mm)
USA 46" (1168mm) 16" (406mm) 33-11/16" (856mm) 8" (203mm)
F2500 with Rear
Deector
Canada 50" (1270mm) 18" (457mm) 33-11/16" (856mm) 8" (203mm)
USA 48" (1219mm) 16" (406mm) 33-11/16" (856mm) 8" (203mm)
C
B
D
A
D
MINIMUM ALCOVE CLEARANCE AND CLEARANCE TO COMBUSTIBLE
MATERIALS
The Regency Freestanding models have been alcove approved and must be installed
with a listed double wall connector to the ceiling level.
Note: Minimum alcove ceiling height - 83"
Maximum depth of alcove - 48"
G
K
16"
405mm
HJ
I
NOTE: This clearance is also required for air space between the appliance and wall/ceiling. Where the
appliance is installed less than 8" from a rear wall, the ember pad only needs to extend to the base of
the wall based on the clearances noted in this manual.
Unit From Unit From Flue Center-Line From Wall
G H I J K
Medium F2500M with Airmate 15" (381mm) 7" (178mm) 27" (686mm) 13.5" (343mm) 54" (1372mm)
with Rear Deector 15" (381mm) 9" (229mm) 27" (686mm) 15.5" (394mm) 54" (1372mm)
Minimum Overall Depth (Y) of Floor Protector
Edge of Fuel door
opening to edge
of hearth
Edge of Fuel Door
Opening (Both
Sides)
Unit
A B C D
F2500 Canada 49" (1245mm) 18" (457mm) 33 11/16" (856 mm) 8" (203mm)
USA 47" (1194mm) 16" (406mm) 33 11/16" (856 mm) 8" (203mm)

4 | F2500 Wood Stove
Minimum Overall Depth (Y) of Floor Protector - Corner Hearth
Reference only when hearth pad is installed to rear wall at minimum pipe clearances.
Hearth Depth
F2500 L M N O
Residential Installation ''C'' Vent (Single Wall)
Canada 33-11/16" (856mm) 61-7/16" (1561mm) 51-1/8" (1299mm) 27-5/16" (694mm)
USA 33-11/16" (856mm) 59-7/16" (1510mm) 49-3/4" (1264mm) 25-7/8" (657mm)
Residential Close Clearance (To be installed with required pipe components)
Canada 33-11/16" (856mm) 57-15/16" (1472mm) 48-5/8" (1235mm) 24-13/16" (630mm)
USA 33-11/16" (856mm) 55-15/16" (1421mm) 47-1/4" (1200mm) 23-7/16" (595mm)
M
O
L
N
Z
16"
Y
X
for angled corners
6"
6"
W
W
FLOOR PROTECTION
(CORNER INSTALLATION)
A combustible oor must be protected by non-combustible
material (like tile, concrete board, or certied to UL-1618 or
as dened by local codes) extending beneath the heater and
a minimum of 8" (203mm) from each side and minimum 16"
(406mm)** from the front face of the stove and minimum 6"
(152mm)** (or the rear clearance to combustibles whichever
is smaller) from the rear of the stove.
When installed with horizontal venting, non-combustible
oor protection must beneath the ue pipe and extend 2"
(51mm) beyond each side.
Minimum Overall Width (X) of Floor
Protector for all installations:
Stove F2500M 33-11/16" (856
mm)
**NOTE: In Canada, oor protection must extend 18" (450mm)
to the front and 8" (203mm) to back of the stove.
Minimum Overall Depth (Y) of Floor Protector
Unit Residential
"C" Vent
From Edge of Fuel Door
Opening
Y Z W
Medium F2500M Canada - 49" (1245mm)
USA - 47" (1194mm)
**6"
(152mm)
8" (203mm)

F2500 Wood Stove | 5
Pedestal
Bolted to
Floor
Outside Air
MOBILE HOME INSTALLATION (USA ONLY)
Once you have properly marked the position of
your unit and the oor protection as outlined in
the Residential Installation items #1 through #8, a
supply of fresh air has to be supplied to your unit.
See Optional Outside Air Kit instructions in this
manual.
Place your unit in position and secure it to the
oor using two lag bolts 3/8" (10mm) x 3-1/2"
(89mm) through the two holes inside the pedestal
base. It is important to maintain the structural
integrity of the Mobile Home oor, walls and roof
when installing your unit.
For Mobile Home units installed in the U.S. the
unit must be grounded using a #8 ground wire
with approved termination and star washer.
In addition to standard installation instructions
the following requirements are mandatory for
installation in a mobile home.
1. The stove must be permanently bolted to
the oor of the Mobile Home using the oor
screws provided.
2. The stove must have a permanent outside air
source for combustion.
3. The stove must be electrically grounded to
the steel chassis of the Mobile Home.
4. A listed double-wall connector chimney
system, roof thimble, spark arrestor and roof
ashing kit suitable for use in Mobile Homes
must be used.
5. If the chimney exits the Mobile Home at a
location other than through the roof, and
exits at a point 7ft. (2130mm) or less above
the ground level on which the Mobile Home
is positioned a guard or method of enclosing
the chimney shall be tted at the point of exit
for a height up to 7ft. (2130mm).
6. The chimney shall be attached directly to the
room heater and shall extend at least 3 ft.
(914mm) above the part of the roof through
which it passes. The top of the chimney
should project at least 2ft. (610mm) above
the highest elevation of any part of the Mobile
Home within 10 ft. (3048mm) of the chimney.
7. The chimney system shall comply with Local
Requirements.
8. Any openings in a chimney guard where
required must not permit the entrance of 3/4"
(19mm) diameter rod.
9. CAUTION: THESTRUCTURAL INTEGRITY
OF THE MOBILE HOME ROOF, FLOOR,
WALLS AND CEILING MUST BE
MAINTAINED.
10. Check any other local building code as other
local codes may apply.
11. WARNING: DO NOT INSTALL IN A
SLEEPING ROOM OF A MOBILE HOME.
12. Use silicone to create an eective vapour
barrier at the location where the chimney or
other component penetrates to the exterior
of the structure.
CAUTION: At no time use unlabelled
parts, or substitute parts made for
another chimney system.
Install as per chimney manufacturer's
installation instructions.
WARNING: Operate only with door
fully closed - open feed door to feed
re only.
1. Identify the position of the outside air damper by the orientation of
the metal handle that rests outside the galvanized pipe. The metal
handle and the damper disc are in line with each other. This means
that if the metal handle is in a horizontal position, the damper is at
and fully open.
2. Open the damper fully whenever you start a re. This will allow the
outside air to be drawn in the pedestal base eliminating any potential
smoke escaping the stove and entering the room. (Negative air
pressure)
For USA Installations: see Outside Air Kit
- Part # 846-502.
There are further requirements when installing
this unit into a mobile home in the US Only.
This appliance is not approved for
mobile home installations in Canada
(USA only) .
