Regency Classic C34 Quick start guide

WARNING:
If the information in these instructions are not followed ex-
actly,afireorexplosionmayresultcausingpropertydamage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
donotuseanyphoneinyourbuild-
ing.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fire department.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-512a
MODELS: C34-NG3 Natural Gas C34-LP3 Propane
C34 Classic Direct Vent
Freestanding Gas Stove
Classic C34 model shown above features optional
gold plated door and gold legs.
04/12/11
Owners &
Installation Manual
www.regency-fire.com
Tested by: Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.

2Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
REGENCY
Classic Direct Vent Freestanding Gas Stove
To the New Owner:
Congratulations! You are the owner of a state-of-the-art Gas Stove by Fireplace Products International Ltd. The Regency®Gas Series
of hand crafted appliances has been designed to provide you with all the warmth and charm of a woodstove, at the flick of a switch.
The models C34-NG1 and C34-LP1 of this series have been approved by Warnock Hersey for both safety and efficiency. As it also
bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take
a moment now to acquaint yourself with these instructions and the many features of your CLASSIC Direct Vent Freestanding Gas
Stove.

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 3
ThisRegency®Mobile/ManufacturedHomelisted
appliance comes equipped with a dedicated #8
groundlugto which an8 gaugecopper wirefrom
the steel chassis ground must be attached.
ThisRegency®Mobile/ManufacturedHomeListed
appliance comes factory equipped with a means
to secure the unit.
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE
This Regency®product has been tested and listed by Warnock Hersey as a Direct Vent Room Heater to the following standards: CAN/CGA-2.17-
M91, ANSI Z21.88a-2007/CSA 2.33a-2007.
This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations,
Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of local codes follow
the current National Fuel Gas Code,ANSI Z223.1 and the current National Electrical Code ANSI/NFPA70 in the U.S.A., and the current CAN/CGA
B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada.

4Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
DIMENSIONS

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 55
TABLE OF CONTENTS
SAFETY LABEL
Serial No. Decal.............................................................6
REQUIREMENTS
MA Code - CO Detector.................................................7
INSTALLATION
Important Message ......................................................9
Specifications ................................................................9
Before You Start ............................................................9
General Safety Information............................................9
Installation Checklist....................................................10
Locating Your Gas Stove.............................................10
Manufactured Mobile Home Additional Requirements 10
Combustion and Ventilation Air....................................10
Clearances to Combustibles........................................10
Optional Fan Installation..............................................11
Pedestal Assembly......................................................12
Leg and Bottom Shield Assembly................................12
Venting Introduction.....................................................13
Installation Precautions ...............................................13
Safety Precautions for the Installer..............................13
Vent Restrictor Position...............................................13
Exterior Vent Terminal Locations.................................14
4” x 6-5/8” Rigid Pipe Cross Reference Chart.............15
Rigid Pipe Venting Systems ........................................17
Venting Arrangements ................................................18
Horizontal Terminations for
All Venting Systems.............................................18
Vertical Termination Systems for
Residential Manufactured and Mobile Homes.....19
DV Stove Horizontal Vent Kit.......................................20
Dura-Vent Termination Kit............................................22
Dura-Vent Horizontal Installations...............................23
Vertical Termination.....................................................24
Cathedral Ceilings.......................................................25
Converting Class-A Metal Chimney
or Masonry Chimney to Direct Vent System................26
System Data................................................................28
Gas Connection...........................................................28
High Elevation .............................................................28
Gas Pipe Pressure Testing..........................................28
Installation of the DC Sparker......................................29
Valve Description.........................................................29
Log Installation ............................................................30
Door and Glass Frame................................................30
Door Handle ................................................................31
Remote Control Installation.........................................31
Remote Wall Switch ....................................................31
Wall Thermostat ..........................................................31
Final Check..................................................................31
Wiring Diagrams..........................................................32
OPERATING INSTRUCTIONS
Operating Instructions .................................................34
Lighting Procedure ......................................................34
Shutdown Procedure...................................................34
First Fire ......................................................................34
Pilot Adjustment...........................................................34
Copy of the Lighting Plate Instructions .......................35
Aeration Adjustment ....................................................35
MAINTENANCE
Normal Operating Sounds of Gas Appliances.............36
Thermopile / Thermocouple.........................................36
Maintenance Instructions.............................................36
General Vent Maintenance..........................................36
Log Replacement ........................................................36
Gold-Plated Doors.......................................................37
Glass Gasket...............................................................37
Glass Replacement.....................................................37
Removing Valve Assembly..........................................37
Installing Valve Assembly............................................37
PARTS LIST
Main Assembly ............................................................38
Burner Assembly & Log Set.........................................39
Base Options...............................................................40
WARRANTY
Warranty .....................................................................43

6Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
SAFETY LABEL
This is a copy of the label that accompanies
each CLASSIC Direct Vent Freestanding Gas
Stove. We have printed a copy of the contents
hereforyourreview.Thesafety label islocated
on the back panel.
NOTE: Regency®units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is
the correct one.
Listed:
Certified for/Certifi e pour:
Tested to:
WN# 16477
CANADA and U.S.A.
CGA-2-17-M91, ANSI Z21.88a-2007 / CSA 2.33a-2007
VENTED GAS FIREPLACE HEATER / FOYER AU GAZ À ÉVACUATION
é
P
L
12" WC (2.98 kpa)
11" WC (2.73 kpa)
2.9" WC (0.72 kpa)
#52 (1.61mm)
16000 BTUH (4.69 kw/h)
32000 BTUH (9.38 kw/h)
0-4500 ft/pi (0-1372m)
PROPANE GAS STOVE:
Minimum supply pressure
Manifold pressure high
Manifold pressure low
Orifice size
Minimum input
Maximum input
Altitude
Model C34-LP3
L
APPAREIL FONCTIONNANT AU PROPANE
CONCU POUR ETRE POELE:
Pression d'allimentation minimum
Pression à la tubulure d' chappement lev e
Pression à la tubulure d' chappement basse
Grandeur de l'injecteur
D bit minimum selon
D bit maximum selon
l'altitude
Calorifique
Calorifique
Modéle C34-LP3
ééé
é
é
é
Model/Modele:
C34-LP3
P
L
5" WC (1.25kpa)
3.8" WC (0.94kpa)
1.1" WC (0.27kpa)
#36 (2.71mm)
16000 BTUH (4.69 kw/h)
32000 BTUH (9.38 kw/h)
0-4500 ft/pi (0-1372m)
NATURAL GAS STOVE:
Minimum supply pressure
Manifold pressure high
Manifold pressure low
Orifice size
Minimum input
Maximum input
Altitude
Model C34-NG3
L
APPAREIL FONCTIONNANT AU NATURAL
CONCU POUR ETRE POELE:
Pression d'allimentation minimum
Pression à la tubulure d' chappement lev e
Pression à la tubulure d' chappement basse
Grandeur de l'injecteur
D bit minimum selon
D bit Calorifique maximum selon
l'altitude
Calorifique
GAZ
Modéle C34-NG3
ééé
é
é
é
Model/Modele:
C34-NG3
DOOR SEAL:
Please check that the door is properly sealed.
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE
297
DUPLICATE SERIAL NO.
FPI Fireplace Products International Ltd.
Delta, BC, Canada
Made in Canada/
Fabrique au Canada
Minimum Clearances to Combustibles /
Degagement Minimum
De Materiaux Combustibles
A 10"/250mm
B 6"/150mm
E 1.5"/38mm
Minimum ceiling height from
top of unit:36"/914mm
Minimum plafond hauteur en
haut de l'appareil: 36"/914mm
Minimum clearance to vent 1.25“/32mm
Serial No./ No de serie
918-490a
Back wall
Side wall
E
Back wall
Side wall
Side wall
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation
Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety
Standard, Title 24 CFR, Part 3280, in the United States, or when such a standard is not applicable, ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations
Standard orANSIA119.2 ou NFPA501C Standard for Recreational Vehicles
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where
not prohibited by local codes. See owner's manual for details.
Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installation ANSI Z223.1, National Fuel Gas Code ou CSA-B149.1
en vigueur.
Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured
Home Construction and Safety Standard. Si ces normes ne sont pas pertinentes, utilisez la norme ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations
Standard, ouANSIA119.2 ou NFPA501C Standard for Recreational Vehicles.
For use with glass doors certified with the appliance only
This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.
Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquée ou mobile (É.-U.
seulement) installée à demeure si les règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Cet appareil ne peut pas être utilisé avec
d'autres gaz sauf si une trousse de conversion certifiée est fournie.
Pour utilisation uniquement avec les portes en verre certifiées avec l'appareil
297
Electrical supply / Électrique 115VAC, 1.13 A, 60Hz.
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS.
NE PAS UTILISER AVEC DUCOMBUSTIBLE SOLIDE.FOYER AU GAZ À ÉVACUATION -
Forthe Stateof Massachusetts, installation
and repair must be done by a plumber or
gasfitter licensed in the Commonwealth of
Massachusetts.
For the State of Massachusetts, flexible
connectors shall not exceed 36 inches in
length.
For the State of Massachusetts, the appli-
ances individual manual shut-off must be a
t-handle type valve.
The State of Massachusetts requires the
installation of a carbon monoxide alarm in
accordancewithNFPA720 andaCOalarm
withbatterybackupinthesameroomwhere
the gas appliance is installed.

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 7
REQUIREMENTS
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

8Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL,ETC.IT IS IMPERATIVETHAT
CONTROL COMPARTMENTS,BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IFTHERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OF THE ROOM AND AWAY FROM HOT
SURFACES.
FOR YOUR SAFETY
Thisappliancerequiresairforpropercombustion.
Always provide adequate combustion and
ventilationair. Followinstructionsandinformation
inCSAB149.1(inCanada)ortheNationalFuelGas
CodeANS Z223.1/NFPA (in the USA), regarding
requirements for combustion and ventilation air.

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 9
INSTALLATION
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
The CLASSIC Direct Vent Freestanding Gas
Stovemustbeinstalledinaccordancewiththese
instructions.Carefullyreadalltheinstructionsin
this manual first. Consult the building authority
having jurisdiction to determine the need for a
permit prior to starting the installation.
- WARNING -
Failure to follow the instructions
could cause a malfunction of the
heater which could result in death,
serious bodily injury, and/or prop-
ertydamage.Failuretofollowthese
instructionsmayalsovoidyourfire
insurance and/or warranty.
Note: These instructions take precedence
overSimpsonDura-Ventinstructions
SPECIFICATIONS
Fuels: C34-NG is approved for use with
natural gas. C34-LP is approved for
use with liquefied petroleum gases
(propane).
Electrical: 120V. A.C. system.
Optional circulation fan: Two speed,
125/75 CFM.
Log Sets: Ceramic fibre, 4 per set.
Vent System: Coaxial (6 5/8" outer/ 4" inner
liner) rigid flue and termination cap.
GENERAL SAFETY
INFORMATION
1) The appliance installation must conform with
local codes or, in the absence of local codes,
withthecurrentCanadianorNationalElectrical
Codes,CAN1-B149orANSIZ223.1Installation
Codes.
2) The appliance when installed, must be electri-
cally grounded in accordance with local codes,
orintheabsence of localcodeswiththe current
NationalElectricalCode,ANSI/NFPA70orCSA
C22.1 Canadian Electrical Code.
3) Theappliance should beinspectedfor shipping
damage before use and serviced annually by
a professional service person. More frequent
cleaning may be required due to excessive lint
fromcarpeting,beddingmaterial,etc.Itisimpera-
tive that control compartments, and circulating
airpassagewaysoftheappliancebekeptclean.
4) See general construction and assembly in-
structions. The appliance and vent should be
enclosed when installed in or passing through
a living area.
5) Thisappliance must beconnected to the speci-
fied vent and termination cap to the outside of
the building envelope.
6) Never vent to another room or inside a build-
ing. Make sure that the vent is fitted as per the
instructions starting in "Venting Introduction"
section.
7) Inspecttheventingsystemannuallyforblockage
and any signs of deterioration.
8) Venting terminals shall not be recessed into a
wall or siding.
9) Anysafety glassremoved for servicingmust be
replaced prior to operating the appliance.
10) To prevent injury, do not allow anyone who is
unfamiliarwiththeoperationtousethefireplace.
SHOULD OVERHEATING OC-
CUR,ORTHEGASSUPPLYFAIL
TO SHUT OFF, SHUT OFF THE
MANUAL GAS VALVE TO THE
APPLIANCE BEFORE SHUT-
TING OFF THE ELECTRICAL
SUPPLY.
- WARNING -
Risk of fire or electric shock. Only
qualifiedservicepersonnelshallbe
usedto installandprovide mainte-
nance of this appliance.
1) Provide adequate clearances for servicing,
proper operation and around the air openings
into the combustion chamber.
2) The appliance may be installed on a flat, solid,
continuoussurface(e.g.wood,metal,concrete).
This may be the floor, or it can be raised up on
a platform to enhance its visual impact. If the
appliance is going to be installed on carpeting,
see clearances to combustibles in "Clearances
to Combustibles" section.
The CLASSIC Direct Vent Freestanding Gas
Stove can be installed in a wide variety of ways
and will fit nearly any room layout. It may be
installed in a recessed position, framed out into
the room, or across a corner. This appliance is
ListedforAlcoveinstallations,maintainminimum
Alcove clearances as follows, minimum ceiling
height of 65-11/16", minimum width of 48" and
a maximum depth of 36".
3) The CLASSIC Direct Vent Freestanding Gas
Stove is approved for alcove installations, which
meet the clearances listed in "Clearances to
Combustibles"section.Thisunitcanbeinstalled
inabedroom,wheninstalledwithamillivoltther-
mostat. This unit is approved for manufactured
homeinstallations,see"VentingArrangements"
section for the required vent arrangements. If
installed into a manufactured or mobile home
the unit must be bolted down to the floor.
4) Werecommendthatyouplanyourinstallationon
paperusingexact measurementsforclearances
andfloorprotectionbeforeactuallyinstallingthis
appliance. Have a qualified building inspector
review your plans before installation.
Emissions from burning wood or gas could
contain chemicals known to the State of Cali-
fornia to cause cancer, birth defects or other
reproductive harm.

10 Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
COMBUSTION AND
VENTILATION AIR
Thecombustionairfromthisapplianceisdrawn
from outside the building through the outer
flue. Extra provision for combustion air is
not required.
CLEARANCES TO
COMBUSTIBLES
The clearances listed below are MINIMUM
distances. Measure the clearance to both the
appliance and the chimney connector. The
farthestdistanceiscorrectifthetwoclearances
do not coincide. For example, if the appliance
is set as indicated in one of the diagrams but
the back is too close, move the stove until the
correct clearance to the back is obtained.
Thisunitcanbeinstalledonasolidcombustible
surface like a wood floor. This unit can also be
installed directly on carpeting or vinyl when the
bottom pedestal cover plate (provided with the
unit) is installed.
This appliance may be installed only with the
clearances as shown in the situations pictured.
Do not combine clearances from one type of
installation with another in order to achieve
closer clearances.
Use the minimum clearances shown in the
diagrams below:
INSTALLATION
CHECKLIST
1) Locate your appliance. Refer to the
following sections:
a. Locating Your Classic Gas Stove
b. Clearances to Combustibles
c. Venting. See "Exterior Vent Terminal
Locations" to " Venting Arrangments"
sections.
2) Install Optional Fan. Refer to "Optional Fan
Installation" section.
3) Assemble stove base - pedestal or bottom
shield and legs. Refer to "Pedestal
Assembly" or "Leg and Bottom Shield
Assembly" sections.
4) Choose a venting option and Install
accordingly. Refer to the following sections
where applicable:
a. DV Stove Horizontal Vent Kit
b. Dura-Vent Termination kits
c. Vent Restrictor setting
d. Converting CLass-A Metal Chimney or
Masonry Chimney to Direct Vent
System.
5) Make gas and electrical connections.
Refer to "Gas Connection" section. Test
the pilot. Must be as per diagram in "Pilot
Adjustment" section.
6) Test gas pressure. Refer to "Gas Pipe
Pressure Testing" section.
7) Install standard and optional features.
Refer to the following sections where
applicable:
a. Log Installation
b. Door and Glass Frame
c. Door Handle
d. Remote Control
e. Remote Wall switch
f. Wall Thermostat
8) Final check. Refer to "Final Check" section.
Before leaving this unit with the customer, the
installer must ensure that the appliance is fir-
ing correctly and operation fully explained to
customer.
This includes:
1) Clockingtheappliancetoensurethecorrect
firingrate(ratenotedonlabel)afterburning
appliance for 15 minutes.
2) Ifrequired,adjustingtheprimaryairtoensure
that the flame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
3) Check for proper draft.
CAUTION: Any alteration to the product that
causessootingorcarboningthatresultsindam-
ageisnottheresponsibilityofthemanufacturer.
LOCATING YOUR
GAS STOVE
Whenselectingalocationforyourstove,ensure
thattheclearancesonthispageare met as well
as ensuring that there is adequate accessibility
for servicing and proper operation.
ForVentTerminationrequirements,see"Exterior
Vent Terminal Locations" section.
MANUFACTURED
MOBILE HOME
ADDITIONAL
REQUIREMENTS
1) Ensure that structural members are not cut
or weakened during installation.
2) Ensure proper grounding using the #8
ground lug provided. See "Optional Fan
Installation" section.
3) Appliancemustbeanchoredtothefloor.See
"Pedestal Assembly" & "Leg and Bottom"
sections.
A) Cross Corner
B) Room Divider
C) Island
D) Flat on Wall
E) Flat on Wall Corner
F) Flush with Wall/Alcove
C34 Clearance to Combustibles
A Side Wall to Unit 10"/ 250 mm
B Back Wall to Unit 6" / 150 mm
E Side Wall to Unit 1.5"/ 38 mm
C34 Reference Dimensions
C Back Wall to Flue Centerline 13" / 330 mm
D Side Wall to Flue Centerline 22"/ 559 mm
F Side Wall to Flue Centerline 14"/ 356 mm
Minimum ceiling height is 36" / 914 mm from
top of unit.
Minimum clearance to vent 1-1/4" (32mm).

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 11
INSTALLATION
Diagram 3
Caution: Ensure that the wires do not
touch any hot surfaces.
Note: The#8ground lug is adedicated
ground for mobile home use only.
9) Lift the fan assembly in through the pedes-
tal and up through the cut out as shown in
diagrams 3 and 4.
2) Remove valve cover plate by removing 2
screws.
3) Remove wire from piezo ignitor.
4) Screw the four 8-32 x 3/4 screws provided
intothe nutserts as shown in diagram 3.Do
not tighten screws.
5) Push all the fan wires through the hole on
the fan assembly. See diagram 2.
Diagram 2
OPTIONAL FAN INSTALLATION
Diagram 1
1) Openpedestaldoorandremovedoorcover
plate by removing 4 screws. See diagram
1.
IMPORTANT
Disconnect power supply
before servicing
Forlegunit:remove7screws, removebottom
accesspanelandinstallfanassembly,
follow steps 4 to 17.
For pedestal unit: To install the fan in an
installed stove-access from front
through the pedestal by following the
directions below. If the stove is not
installed - access through rear and
follow steps 4 to 17.
6) Putpowercord(shownindiagram3)through
the hole and pull through to the front of the
unit for easier installation of ground wire.
7) Place the fan assembly partially in door
cover plate hole. See diagram 2.
8) Attach the 2 ground wires (green) to the
ground lug as per diagram 2.
Note: Ground lug is located on the bottom
of the fan assembly. See diagram
2.
Diagram 4

12 Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
PEDESTAL ASSEMBLY
1) Foreasierassembly,tipthestoveonitsback
(preferably onto a soft surface to prevent
scratching).
2) Unscrew the 4 bolts in the underside of the
stove. Align the holes in the corners of the
pedestaltopwiththecorrespondingholesin
the base of the stove. Use washers which
are supplied with the pedestal as shown in
diagram. Reinstall bolts.
Anchoring Brackets Hold Down
Package Part# 846-585
10) Put the insulation gasket on the back of
the fan. Line up the keyhole slots with the
matching screws and pull back slightly to
lock into place. While holding fan assembly
in place, tighten screws.
11) Remove thedummyplug from therightside
of the bottom shield or pedestal and install
the supplied fan switch.
12) Attach the hot wire from power cord to the
thermodisc.
13) Slide thermodisc under the thermodisc
bracket.
14) Connecting wires to the 3 way switch:
a. Connect the red wire from the fan to the
top of the 3 way switch.
b.Connectblackwirefromfantothebottom
of the 3 way switch.
c. Connect white jumper wire to middle of
thethreewayswitch.Seewiringdiagram
below.
15) Connectwhitewirefromfanmotortoneutral
on the power cord.
16) Pull power wire back and put strain relief
grommet in place as per diagram 4.
17) Reverse steps 3-1 to complete installation.
Fan Removal
1) Disconnect the power to the fan.
2) Allow the stove to cool to room tempera-
ture.
3) Open the pedestal door and remove the
screws on the door cover plate. (Leg units:
remove the bottom access panel.)
4) Loosen the screws of the nutserts.
5) Removethefanassemblyfromthekeyslots
at the fan base and pull fan out through the
rectangular opening. (Diagram 3).
6) Turnfan 90degrees.(Diagram2).(Pedestal
units only).
7) Disconnect the green ground wires to the
grounding lug.
8) Disconnect the white wire of the fan from
the power cord.
9) Disconnecttheredwireandblackwire(from
fan to Fan Switch).
10) Take fan out from the stove body. (Diagram
1).
LEG AND BOTTOM
SHIELD ASSEMBLY
Theseinstructionsapplytothesteelleg,painted
cast leg and the gold plated cast leg. It will be
easier to attach the legs to the stove if it is
tipped on its back (preferably on a soft surface
to prevent scratching).
1) Remove the 4 bolts in the underside of the
base and discard.
2) Slide the bolt and washer (supplied with the
bottom shield) through the leg, then slide
the bottom shield in between the leg and
the base of the stove. Tighten the bolts.
3) Hook up the Burner ON/OFF switch.
4) Level the stove by adjusting the levelling
bolts in the bottom of each leg.
3) Hook up wires to Burner ON/OFF switch
andvalveassembly(becarefulnottopinch
wires). See diagram above.
4) Push the Regency®logo into the two holes
inthefrontbottomleftcornerofthepedestal
cover plate.
Note: Any paint touch up should be done
prior to placing logo on pedestal.

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 13
INSTALLATION
INSTALLATION
PRECAUTIONS
Theseventingsystemsareengineeredproducts
that have been designed and tested for use
withthe C34-NG andthe C34-LP.The warranty
will be voided and serious fire, health or other
safety hazards may result from any of the fol-
lowing actions:
1) Installation of any damaged Direct Vent
component
2) UnauthorizedmodificationoftheDirectVent
System
3) Installationofanycomponentpartnotmanu-
facturedorapprovedbySimpsonDura-Vent
or Fireplace Products International Ltd.
4) Installation other than as instructed by
SimpsonDura-VentandFireplaceProducts
International Ltd.
Warning: Always maintain required
clearances(airspaces)tonearbycom-
bustibles to prevent a fire hazard. Do
not fill air spaces with insulation.
Besuretochecktheventterminationclearance
requirements from decks, windows, soffits,
gas regulators, air supply inlets and public
walkways as specified in the "Exterior Vent
Terminal Locations" section and in your local
building codes.
The gas appliance and vent system must be
venteddirectlytotheoutsideofthebuilding,
and never be attached to a chimney serving
a separate solid fuel or gas-burning appli-
ance. Each direct vent gas appliance must use
it's own separate vent system. Common vent
systems are prohibited.
SAFETY
PRECAUTIONS
FOR THE INSTALLER
1) Wear gloves and safety glasses for protec-
tion.
2) Exercise extreme caution when using lad-
ders or on roof tops.
3) Be aware of electrical wiring locations in
walls and ceilings.
VENTING
INTRODUCTION
TheDVStoveHorizontalVentKitandtheSimp-
son Dura-Vent Direct Vent venting systems,
in combination with the Classic Direct Vent
FreestandingGasStove, C34-NGandC34-LP,
havebeentestedandlistedasdirectventheater
systems by Warnock Hersey.
If converting a Class-A Metal Chimney or
Masonry Chimney to a Direct Vent system,
see instructions in "Converting Class-A Metal
Chimney or Masonry Chimney to Dreict Vent
System" section.
The C34 uses the "balanced flue" technology
Co-Axialsystem.Theinnerlinerventsproducts
ofcombustiontotheoutsidewhiletheouterpipe
draws outside combustion air into the combus-
tion chamber thereby eliminating the need to
use heated room air for combustion and losing
warm room air up the chimney.
Note: These flue pipes must not be con-
nected to any other appliance.
The gas appliance and vent system must be
vented directly to the outside of the building,
and never be attached to a chimney serving a
separate solid fuel or gas burning appliance.
Eachdirectventgasappliancemustuseit'sown
separate vent system. Common vent systems
are prohibited.
IMPORTANT
Read all instructions carefully before starting
the installation. Failure to follow these instruc-
tions may create a fire or other safety hazard,
and will void the warranty. Be sure to check the
venting and clearance to combustible require-
ments.Consultyourlocalbuildingcodesbefore
beginning installation.
Thelocationoftheterminationcapmustconform
totherequirementsintheExteriorVentTerminal
Locations diagram in "Exterior Vent Terminal
Locations" section.
VENT RESTRICTOR
POSITION
Vent restriction is required for certain venting
installations, see the diagrams in "Venting
Arrangment" section to determine if they are
required for your installation.
The vent restrictor has three settings: "C"
Center(factorysetting),"L"Left,and"R" Right.
Simply loosen the screws and push the vent
restrictor plate to the correct position. Tighten
the screws.

14 Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
EXTERIOR VENT TERMINAL LOCATIONS
Minimum Clearance Requirements Canada1USA2
AClearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm)
BClearance to window or door that may be opened 12"(30cm) 9" (23cm)
CClearance to permanently closed window **
DVertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm)
from the center line of the terminal (check with the local code)
18"(46cm) 18"(46cm)
EClearance to unventilated soffit 12"(30cm) 12"(30cm)
FClearance to outside corner: with AstroCap Termination Cap. 6"(15cm) 6"(15cm)
Clearance to outside corner: with all other approved Termination Caps. 12"(30cm) 12"(30cm)
GClearance to inside corner: with AstroCap Termination Cap 6"(15cm) 6"(15cm)
Clearance to inside corner: with all other approved Termination Caps. 12"(30cm) 12"(30cm)
HClearance to each side of center line extended above meter/regulator assembly 36"(90cm)a*
JClearance to service regulator vent outlet 36"(90cm) *
KClearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm)
LClearance to a mechanical air supply inlet (91cm) above if within 10' (3m) horizontally. 72"(1.8m) 36"(90cm)b
MClearance above paved sidewalk or a paved driveway located on public property 84"(2.1m)┼*
NClearance under veranda, porch, deck, or balcony 12"(30cm)‡*
1In accordance with current CSA B149.1, Natural Gas and Propane Installation Code
2In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code
┼A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings
‡ Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor
*Clearance in accordance with local installation codes and the requirements of the gas supplier
a3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly
b3 feet (91cm) above - if within 10 feet (3m) horizontally

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 15
INSTALLATION
4” X 6-5/8” RIGID PIPE CROSS REFERENCE CHART
Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI.
Description Simpson
Direct Vent Pro®
Selkirk
Direct Temp™
American Metal
Products®
Amerivent Direct
Metal-Fab™
Sure Seal
Security
Secure- Vent®
ICC Excel
Direct
6” Pipe Length-Galvanized 46DVA-06 4DT-6 N/A 4D6 SV4L6 TC-4DL6
6” Pipe Length-Black 46DVA-06B 4DT-6B N/A 4D6B SV4LB6 TC-4DL6B
7” Pipe Length-Galvanized N/A N/A 4D7 N/A N/A N/A
7” Pipe Length-Black N/A N/A 4D7B N/A N/A N/A
9” Pipe Length-Galvanized 46DVA-09 4DT-9 N/A N/A N/A N/A
9” Pipe Length-Black 46DVA-09B 4DT-9B N/A N/A N/A N/A
12” Pipe Length-Galvanized 46DVA-12 4DT-12 4D12 4D12 SV4L12 TC-4DL1
12” Pipe Length-Black 46DVA-12B 4DT-12B 4D12B 4D12B SV4LB12 TC-4DL1B
18” Pipe Length-Galvanized 46DVA-18 4DT-18 4D18 4D18 SV4LA TC-4DL18
18” Pipe Length-Black 46DVA-18B 4DT-18B 4D18B 4D18B SV4LA TC-4DL18B
24” Pipe Length-Galvanized 46DVA-24 4DT-24 4D24 4D24 SV4L24 TC-4DL2
24” Pipe Length-Black 46DVA-24B 4DT-24B 4D24B 4D24B SV4LB24 TC-4DL2B
36” Pipe Length-Galvanized 46DVA-36 4DT-36 4D36 4D36 SV4L36 TC-4DL3
36” Pipe Length-Black 46DVA-36B 4DT-36B 4D36B 4D36B SV4LB36 TC-4DL3B
48” Pipe Length-Galvanized 46DVA-48 4DT-48 4D48 4D48 SV4L48 TC-4DL4
48” Pipe Length-Black 46DVA-48B 4DT-48B 4D48B 4D48B SV4LB48 TC-4DL4B
60” Pipe Length-Galvanized 46DVA-60 4DT-60 N/A N/A N/A N/A
60” Pipe Length-Black 46DVA-60B 4DT-60B N/A N/A N/A N/A
Adjustable Length 3”-10”-Galvanized N/A N/A N/A 4DAL N/A TC-4DLT
Adjustable Length 3”-10”-Black N/A N/A N/A 4DALB N/A TC-4DLTB
Adjustable Length 7”-Galvanized N/A N/A 4D7A N/A N/A N/A
Adjustable Length 7”-Black N/A N/A 4D7AB N/A N/A N/A
Extension Pipe 8-1/2”-Galvanized 46DVA-08A N/A N/A N/A N/A N/A
Extension Pipe 8-1/2”-Black 46DVA-08AB N/A N/A N/A N/A N/A
Adjustable Length 12”-Galvanized N/A N/A 4D12A N/A SV4LA12 N/A
Adjustable Length 12”-Black N/A N/A 4D12A N/A SV4LBA12 N/A
Extension Pipe 16”-Galvanized 46DVA-16A N/A N/A N/A N/A N/A
Extension Pipe 16”-Black 46DVA-16AB N/A N/A N/A N/A N/A
45ºElbow-Galvanized 46DVA-E45 4DT-EL45 4D45L N/A N/A TE-4DE45
45ºElbow-Black 46DVA-E45B 4DT-EL45B 4DT-EL45B N/A N/A TE-4DE45B
45ºElbow Swivel-Galvanized See 46DVA-E45 N/A N/A 4D45L SV4E45 N/A
45ºElbow Swivel-Black See 46DVA-E45B N/A N/A 4D45LB SV4EB45 N/A
90ºElbow-Galvanized 46DVA-E90 4DT-EL90S 4DT-EL90S N/A N/A TE-4DE90
90ºElbow-Black 46DVA-E90B 4DT-EL90SB 4DT-EL90SB N/A SV4EBR90-1 TE-4DE90B
90ºElbow, Swivel-Galvanized See 46DVA-E90 N/A N/A 4D90L SV4E90-1 N/A
90ºElbow, Swivel-Black See 46DVA-E90B N/A N/A 4D90LB SV4EB90-1 N/A
90º Starter Elbow, Swivel-Galvanized N/A N/A N/A 4D90A N/A N/A
Adaptor* N/A N/A N/A 4D90L N/A N/A
Ceiling Support N/A 4DT-CS 4DFSP 4DSP SV4SD TE-4DE45
Cathedral Support Box 46DVA-CS 4DT-CSS 4DRSB 4DRS SV4CSB TE-4DE45B
Wall Support/Band 46DVA-WS 4DT-WS/B 4DWS 4DWS SV4BM N/A
Offset Support 46DVA-ES (N/A - FPI) 4DT-OS N/A N/A SV4SU N/A
Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90
Wall Thimble Support/Ceiling Support 46DVA-DC N/A N/A N/A SV4PF TE-4DE90B
Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF N/A
Trim Plate-Black N/A 4DT-TP 4DFPB 4DCP SV4LA N/A

16 Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
Description Simpson
Direct Vent Pro®
Selkirk
Direct Temp™
American Metal
Products®
Amerivent Direct
Metal-Fab™
Sure Seal
Security
Secure- Vent®
ICC Excel
Direct
Attic Insulation Shield 12” 46DVA-IS N/A@ FPI N/A 4DAIS12 N/A SV4RSA N/A
Attic Insulation Shield - Cold Climates 36” N/A N/A 4DAIS12 N/A N/A TM-4AS
High Wind Vertical Cap 46DVA-VCH N/A N/A N/A N/A TM-4VT
High Wind Horizontal Cap 46DVA-HC N/A N/A N/A N/A TM-4DHT
Horizontal Square Termination Cap See 46DVA-HC 4DT-HHC 4DHC 4DHT SV4CHC-1 TM-4HT
Vertical Termination Cap 46DVA-VC 4DT-HVC 4DVC 4DVT SV4CGV-1 TM-4VT
Storm Collar 46DVA-08A 4DT-SC 4DSC 4DSC SV4FC TM-SC
Restrictor Disk N/A N/A N/A N/A N/A TM-4DS
Extended Vertical Termination Cap N/A N/A N/A N/A N/A N/A
Chimney Conversion Kit A (USA only) 46DVA-KCA N/A N/A N/A N/A TM-4CA6
Chimney Conversion Kit B (USA only) 46DVA-KCB N/A N/A N/A N/A TM-4CA7
Chimney Conversion Kit C (USA only) 46DVA-KCC N/A N/A N/A N/A TM-4CA8
Chimney Conversion Kit Masonry
(USA only)
46DVA-KMC N/A N/A N/A N/A N/A
Wall Firestop 46DVA-WFS N/A N/A N/A N/A TM-4TR
Colinear Flex Connectors 46DVA-ADF N/A N/A N/A N/A N/A
Adjustable Flashing 0/12-6/12 46DVA-F6 4DT-ST14 4D12S 4DST14 SV4STC14 TF-4FA
Adjustable Flashing 6/12-12/12 46DVA-FLA 4DT-ST36 4D36S 4DST36 SV4STC36 TF-4FB
Vinyl Siding Standoff 46DVA-VSS 4DT-VS N/A 4DVS SV4VS TM-VSS
Vinyl Siding Shield Plate N/A 4DT-VSP N/A N/A SV4VS N/A
Snorkel Termination 14” 46DVA-SNKL N/A N/A N/A N/A TM-4ST14
Snorkel Termination 36” N/A N/A N/A N/A N/A TM-4ST36
Basic Horizontal Termination Kit (A) Disc. 4DT-HKA 4DHTK2 4DHTKA SV-SHK N/A
Horizontal Termination Kit (B) 46DVA-KHA
(Changed Components)
4DT-HKB 4DHTK1 4DHTKB SV-HK N/A
Vertical Termination Kit Disc. 4DT-VKC 4DHTK 4DHTK SV-FK N/A
FPI
946-506/P Vent Guard (Optional) for AstroCap 946-205 Vinyl Siding Shield for Riser Vent Terminal
510-994 Rigid Pipe Adaptor (Must use with all rigid piping) 946-208/P Vent Guard (Optional) for Riser Vent Terminal
640-530/P Riser Vent Terminal 946-523/P AstroCap Horizontal Cap
946-605 Starter Collar Increaser 4” x 6-5/8” to 5” x 8” 946-206 Vinyl Siding Standoff for AstroCap
Note: When using Metal-Fab Sure Seal Rigid Piping - please note that the Adaptor (4DDA) must be used in conjunction with FPI Rigid Pipe Adaptor (510-994).
Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination.
Never allow the vent to run downward - this could cause high temperatures and may present a possible fire hazard.
Offset Pipe Selection: Use this table to determine offset pipe lengths.
Pipe Length
(L)
4” x 6-5/8” Venting For specific instructions on venting components - visit the
manufacturers website listed below.
Run (X) Rise (Y)
0” (0mm) 4-7/8” (124mm) 13-7/8” (340mm) Simpson Direct Vent Pro: www.duravent.com
6” (152mm) 8” (203mm) 16-1/2” (419mm) Selkirk Direct-Temp: www.selkirkcorp.com
9” (229mm) 10-1/8” (257mm) 18-5/8” (473mm) American Metal Products: www.americanmetalproducts.com
12” (305mm) 12-1/4” (311mm) 20-3/4” (527mm) Metal-Fab Sure Seal: www.mtlfab.com
24” (610mm) 20-5/8” (524mm) 29-1/8” (740mm) Security Secure Vent: www.securitychimneys.com
36” (914mm) 29” (737mm) 37-1/2” (953mm) Industrial Chimney Company: www.icc-rsf.com
48” (1219mm) 37-7/16” (951mm) 45-15/16” (1167mm)
Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fire.com

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 17
INSTALLATION
Pipe Length
Vertical
Termination
Cap
Storm Collar
Flashing
Ceiling Firestop
24" Pipe
Length
Adj.Pipe Length
11" - 14-5/8"
90 Elbow
o
Horizontal
Termination Cap
# 946-523/P
Wall Thimble
Vinyl Siding
Standoff (Optional)
RIGID PIPE VENTING SYSTEMS
Horizontal or Vertical Terminations
Alternate
Horizontal
Termination
Caps
ThisproducthasbeenevaluatedbyIntertekfor
use with Duravent Direct-Vent , Selkirk Direct-
Temp, Ameri Vent Direct venting and Security
Secure Vent systems.
WARNING:
Do not combine venting components from
different venting systems.
However use of the the AstroCapTM and FPI
Riser is acceptable with all systems.
When using Rigid Vent other than
Simpson Dura-Vent, 3 screws must be
used to secure rigid pipe to unit.
The FPIAstroCapTM and FPI Riser Vent terminal are certified for installations using FPI venting systems as well as Simpson Dura-Vent®Direct Vent,Ameri-
can Metal ProductsAmeri Vent Direct Vent, Security Secure Vent®, Selkirk Direct-Temp. AstroCapTM is a proprietary trademark of FPI Fireplace Products
International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc.

18 Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
VENTING ARRANGEMENTS
VERTICAL TERMINATION SYSTEMS
FOR RESIDENTIAL MANUFACTURED
AND MOBILE HOMES
The shaded area in the diagram below shows all allowable combi-
nations of straight vertical and offset to vertical runs with vertical
terminations. Maximum two 45oelbows.
All vertical and offset to vertical vent installations require Vent Restrictor
Position "R" (Right). If the vent is ENCLOSED in a chase (min. size 9" x
9") maintain a 1-1/4" clearance to combustibles.
May be installed in Manufactured (Mobile) Homes after first sale.
Venting Arrangements Examples:
Example A) Venting has a horizontal termination.
A 7 ft. vertical run with 6 ft. horizontal run does not fall within the shaded area, and therefore is an allowable installation with
the factory set vent restrictor position of "C".
Example B) Offset to Vertical Vent.
A 15 ft. vertical run with 4 ft. horizontal offset distance falls within the shaded area and is an allowable installation with Vent
Restrictor Position "R" (Right).
VENTING ARRANGEMENTS
HORIZONTAL TERMINATIONS FOR
ALL VENTING SYSTEMS
The shaded areas in the diagram below show all allowable combi-
nations of vertical runs with horizontal term-inations. Maximum
one 90Oelbow (two 45o elbows equal one 90oelbow).
Propane and Natural Gas: Residential, Manufactured
and Mobile Homes Installations
The venting arrangements diagrammed below, have a min. of 75% (flue
loss)efficiencywithFanOff,asrequiredformanufacturedhomes.(Actual
efficiency may be as high as 85%)
May be installed in Manufactured (Mobile) Homes after first sale.
NOTE: See "Vent Restrictor Position" section for installation instructions for the Vent Restrictor Position.
Straight Vertical and Offset to Vertical Terminations
use Vent Restrictor Position "R" (Right)

Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove 19
INSTALLATION
Horizontal Venting with Two (2) 90oElbows
Option V H + H1
A) 4' Min. 6' Max.
B) 5' Min. 7' Max.
C) 6' Min. 8' Max.
Vertical Venting with Two (2) 90oElbows
Option V H V + V1
A) 1' Min. 4' Max. 2' Min.
B) 2' Min. 5' Max. 3' Min.
C) 3' Min. 6' Max. 4' Min.
D) 4' Min. 7' Max. 5' Min.
E) 5' Min. 8' Max. 6' Min.
With these options, max. total
pipelengthis30feetwithmin.
of6feettotalverticalandmax.
8 feet total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
Withtheseoptions,maximumtotal
pipelengthis30feetwithminimum
of6feettotalverticalandmaximum
8 feet total horizontal.
Please note minimum 1 foot be-
tween 90oelbows is required.
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
Vent restrictor position C (fully
open), refer to "Vent Restrictor
Position" section.
Vent restrictor position C (fully open), refer to "Vent Restrictor
Position" section
Lengths do not include elbow
indicated.
Lengths do not include elbow indicated.

20 Regency®CLASSIC C34-3 Direct Vent Freestanding Gas Stove
INSTALLATION
DV STOVE HORIZONTAL VENT KIT (#946-116 & #946-216) INSTALLATION
DV STOVE HORIZONTAL VENT KIT
DV 2 ft. Stove Vent Kit (Part # 946-116) and DV 4 ft. Stove Vent Kit (946-216) include
all the parts needed to install the C34 with minimum horizontal and vertical vent
dimensions. For installations that require longer vertical and/or horizontal vents use
the Dura-Vent system as shown in "Dura-Vent Termination Kit" & "Dura-Vent Venting
Components" section.
Qty. Description
1) 1 Rigid Pipe Section (Kit # 946-116: 2 ft. (1.2m) length,
Kit # 946-216: 4 ft. (1.2m) length), 6-1/2" (165mm) inside diameter
2) 1 Flex Liner, compressed aluminium 2 ply liner, 4" (102mm) inside diameter
3) 4 spring spacers
4) 1 90 deg. Elbow
5) 1 Adjustable pipe section 13-1/2" to 24" (343mm x 610mm), 2 pieces
6) 1 Thimble Cover
7) 1 Wall Thimble (2 pcs.)
8) 1 Adapter
9) 1 AstroCap Termination Cap
10) 2 Trim Collar
11) 1 tube of Mill-Pac, high temperature sealant
12) 12 Screws, #8 x 1/2" Self tapping, Stainless Steel
13) 14 Screws, #8 x 1/2" Self tapping, Black
14) 4 Screws #8 x 1-1/2" Drill Point, Black
15) 4 Screws #8 x 1-1/2" Drill Point, Stainless Steel
16) 8 Wood screws #8 x 1"
Optional:
946-206 Vinyl Siding Standoff for AstroCap
Note:
a) Liner sections should be continuous without any joints or seams.
b) This is an approved system, therefore components in this system must not be
substituted for any other manufacturer's products.
Review the following sequence of instructions
which are typical of most installations. The
sequence may vary depending on wall thick-
ness.
See "Locating Your Gas Stove" to "Exterior
Vent Terimnal Locations" sections for vent
location and clearance dimensions.
1) Set the unit in its desired location. Check
to determine if wall studs will be in the way
of the venting system, adjust location until
all clearances are met and there are no
obstructions.
Note: A1-1/2"(38mm)clearancearoundthe
outerpipemustbemaintainedexcept
that only a 1" (25mm) clearance is
needed at the termination end.
IMPORTANT:
Do not locate termination hood where
excessive snow or ice buildup may
occur. Be sure to check vent termina-
tion area after snow falls, and clear to
preventaccidental blockage of venting
system. When using snow blowers,
makesuresnowisnotdirectedtowards
vent termination area.
2) Assembleatrialfittodeterminetheverti-
cal center-line for the vent termination.
a) Cut a 9-1/2" x 9-1/2" (241mm x 241
mm) square hole on both the interior
and exterior wall.
b) Install wall thimbles on both interior
and exterior wall with 4 wood screws
(#8 x 1") per thimble.
c) Attachthe2pieceadjustablepipesec-
tionto the ventterminal and slide into
position from the exterior. The larger
diameterendoftheadjustablepipe
goes to the vent terminal.
d) Install the 90oelbow onto the adjust-
able pipe to determine the vertical
centerline of the starter collar on the
unit.
Note: if the centerline cannot be
met, the adjustable sections will
have to be cut.
