CSE1 SOL G P
CSE1 SOL G P
EN
Installation and Operation Manual
CSE1 SOL G P SOLAR PUMP STATION

1. Introduction
Thanks to its design, CSE1 SOL G P solar pump station enables a simple and quick conenction
into a solar circuit. It is tted with a high-e󰀩ciency solar pump of the latest generation that permits
continous ow control.
This pump station is intended for controllers with PWM control or with 230 V switching (ON/OFF).
2. Pump Station Description
Main Features
Application This single-line solar pump station contains all components (except for a
controller) necessary for current and e󰀩cient operation.
Description The pump station consist of a UPM3 Hybrid 25-70 pump, check and safety
valves, 2 ball valves, ow indicator, pressure gauge, thermometer, installa-
tion kit and insulation.
The pump station further involves:
● connection point for an expansion vessel
● safety valve outlet
● ball valves for lling, draining and topping up a solar thermal system
Installation on a tank or wall
Working uid water-glycol mixture (max. 1:1)
Codes corresponding to connection sizes
Connection G 3/4“ M G 1“ M
Flow measurement range 2-12 l/min 8-28 l/min
Code 19987 19984
3. Pump Station Data
Data for CSE1 SOL G P Pump Station
Max. uid working temperature 110 °C
Max. working pressure 6 bar
Power supply 230 V, 50 Hz
IP rating IP20
Ambient temperature 5 - 40 °C
Max. relative humidity 85 % at 25 °C
Insulation material EPP RG 60 g/l
Overall dimensions (H x W x D) 510 x 195 x 155 mm
Total weight 4.4 kg
Min. values of working pressure*
Values of min. working pressure
at the pump suction port
depending on temperature
0.8 bar at 50 °C
1.2 bar at 90 °C
1.8 bar at 110 °C
* this condition is met for current installations when the initial system pressure is set following the formula (see the Instructions for
solar collectors): p = 1,3 + 0,1·h [bar], where h… is the height from pressure gauge to the middle of collector array [m]

3.1 Pressure drop diagram
1 - FLOWRATE INDICATOR W. BALL VALVE
2 - CIRCULATION PUMP
3 - CHECK VALVE
4 - BALL VALVE W. SIDE OUTLET FOR
SAFETY GROUP
5 - THERMOMETER (IN THE UPPER PART
OF INSULATION)
6 - PRESSURE GAUGE
7 - EXPANSION VESSEL CONNECTION
POINT, 3/4“ M
8 - 6 BAR SAFETY VALVE
9 - 3/4“ M FILL/DRAIN BALL VALVE
10 - 3/4“ M FILL/DRAIN BALL VALVE
11 - SPANNER FOR CONTROL OF BALL
VALVE
4. Pump Station Components
1
2
1
4
6
9
57
8
10
3
Ukazatel průtoku:
11
G 3/4“ M connection - code 19987 G 1“ M connection - code 19984
Flow indicator:
When reading the ow rate, the value at the lower
edge of the sliding indicator applies (see g.)..
Flow indicator
(here it shows 8 l/min.)

4.1 Check valve
The check valve prevents the tank from cooling down due to gravity circulation when the sun is not
shining. It is located between the ball valves and can therefore be removed and cleaned without
having to drain the solar uid from the entire circuit.
4.2 Ball valves
Ball valves are used to separate the pump station from the solar circuit. During servicing (including
cleaning of the check valve) there is no need to drain the uid from the solar system. For greater
rigidity of the hydraulic part of the pump station, the upper ball valve is attached to the xing back
plate.
The upper ball valve is operated by a lever which is not located on the valve during operation. A spa-
nner or pliers must be used to operate the lower ball valve, which is part of the ow indicator. Turning
the lever or the spanner or pliers a quarter turn to the right closes the ball valve. It opens when the
lever is turned to the left. Before closing / opening the ball valve, it is necessary to remove the top
part of the insulation. As a result, closing the system is reserved for installation or service technici-
ans only. Thus, the user cannot simply close the solar circuit and cause stagnation and subsequent
degradation of the solar uid.
The ball valves are equipped with a packing with two O-rings with dimensions of 8.7x1.8 mm that
can be easily replaced by removing the control element with stop ends and loosening the packing
nut with a # 21 spanner.
WARNING! IMPORTANT!
The safety valve, expansion vessel and upper ll/drain ball valve always remain connected to the
solar thermal system, even if the ball valves are closed! For this reason, never try to separate them
from the lled solar system, as there is a risk of serious injury and damage to the solar system!
Never close the drain line of the safety valve, it must always be free for any liquid leaking from the
safety valve!

5. Installation Options
The solar pump station is designed to be mounted on a wall or a tank. In the rear section of the in-
sulation there are two mounting holes with 160 mm pitch. When mounting the pump station on a
tank, use the large washers between the tank and pump station for both the holes. The washers are
included in supply.
6. Pump Station Connection Diagram
Contents of the mounting kit included in supply:
- for wall mount:
2 dowels, 8 TX
2 truss head screw, 5x50
- for tank mount:
2 socket hex pan-head screw, M6x40
2 large washers (3xD)6.4
OPENINGS IN THE REAR INSULATION SECTION
FOR MOUNTING THE PUMP STATION
KEY
1 – hot water storage tank
2 – el. heating element w. thermostat
3 – solar collectors
4 – CSE1 SOL solar pump station
5 – pump station for DHW recirculation – CSE TVMIX ZV
6 – safety kit for HW storage tank
7 – solar expansion vessel
8 – DHW expansion vessel
SV – cold water
TV – hot water
CV – hot water recirculation
KK – ball valve
ZV – check valve
AOV – automatic air vent valve
PTR – pressure temperature relief valve
REDV – pressure reducing valve (optional)
VK – drain valve
SVE – expansion vessel service valve

7. UPM3 HYBRID 25-70 Pump
Pump Control
The circulation pump can be controlled:
• internally without PWM signal by selecting a constant pressure or constant speed mode
and a desired pump curve.
• by an external PWM C control signal (prole for use in solar thermal systems)
WARNING – IMPORTANT
The pump permits to be controlled also by PWM A signal (prole for use in heating systems).
This mode must not be used for solar thermal systems.
Using the PWM A pump prole would cause system damage.
Using the proportinal pressure mode in the internal pump control is also not advisable
Performance Curves
Line type Description
Constant speed
Proportional pressure
Constant pressure

Description of Pump Frofiles
a) INTERNAL CONTROL - Proportional pressure
• Head (pressure): reduced with growing
system pressure drop and increased
with sinking system pressure drop.
• Pump operating point: moves up or down on the selected proportional pressure curve
depending on the current system pressure drop.
• Using the proportinal pressure mode for solar thermal systems is not advisable.
CONTROL MODE DESCRIPTION
Proportional pressure
IThe lowest curve of proportional pressure
II The middle curve of proportional pressure
III The highest curve of proportional pressure
AUTOADAPT
Automatically controls performance in the range from the
highest to the lowest proportional pressure curve
b) INTERNAL CONTROL - Constant pressure
• Head (pressure): kept constant, disregarded
of the system pressure drop
• Pump operating point: moves on the selected constant pressure curve depending on the
current system pressure drop.
CONTROL MODE DESCRIPTION
Constant pressure
IThe lowest curve of constant pressure
II The middle curve of constant pressure
III The highest curve of constant pressure
AUTOADAPT
Automatically controls performance in the range from the
highest to the lowest constant pressure curve.
AUTOADAPT mode mode is not advisable for solar thermal
systems.
c) INTERNAL CONTROL - Constant speed
• The pump runs at constant speed.
• Pump operating point: moves up or down on the selected constant curve depending on the
current system pressure drop.
CONTROL MODE Max. H (upper graph) Max. P1(lower graph)
Konstantní otáčky
I5 m 33 W
II 6 m 39 W
III 7 m 52 W
d) EXTERNAL CONTROL - PWM C (solar)
• The pump runs up to the max. head following the constant speed
curve set depending on the current PWM value.
• The speed will increase with the increase of the PWM value. If PWM equals 0, the pump stops.
e) EXTERNAL CONTROL - PWM A (heating)
WARNING – IT IS PROHIBITED TO USE PWM A PUMP PROFILES
Using the PWM A (I, II, III) pump proles in a solar pump station would cause system damage.

Settings Display
DISPLAY - LED MARKING
The LED marking is further omitted for better
clarity.
DISPLAY CONTROL MODE
green LED NOT FLASHING INTERNAL
1Proportional pressure AUTOADAPT - not used for
solar thermal systems
2Constant pressure AUTOADAPT - not used for solar
thermal systems
3
Proportional pressure
- not used for solar thermal
systems
I
4II
5III
6
Constant pressure
I
7II
8III
9
Constant speed
I
10 II
11 III
DISPLAY CONTROL MODE
green LED FLASHING EXTERNAL
12 PWM C
13
PWM A
IWARNING
- DO NOT
USE THESE
MODES
14 II
15 III

GREEN LEDS FLASHING
FREQUENCY CONTROL PWM SIGNAL RECEPTION
Not flashing Internal -
1 flash per second External NO
12 flashes per second External YES
WARNING: LEDs may be turned by 90° or 180°, or mirrored, depending on the specific pump type.
When switched on, the pump runs at factory settings or the last setting. The display shows the
current pump performance.
Setting selection
To select your desired setting, press the button repeatedly until you find the setting you need (see
the table above). If you pass the desired setting, you have to go one more round until it appears
again. The order of modes corresponds to the table.
Error display
DISPLAY CONTROL MODE
Seized pump
Too low power supply voltage
Electric fault
Pump wiring
socket for power supply (A)
and signal transmission (B)
power supply (A)
and signal (B) connectors
N (blue)
L (brown)
PE (yellow-green)
PWM GND (blue)
iPWM out (black)
PWM in (brown)

8. Filling a Solar Thermal System
For lling a solar thermal system, the ball valve above the pump must be closed and the ball valve
below the pump open. The ball valve above the pump is operated by means of a lever which is not
present on the ball valve during operation. Connect the lling pump to the ll and drain ball valves
using hoses – see Chap. 4, and open these valves.
Prior to commissioning the system, both the ball valves must be open!
CLOSED
OPEN
Inlet from a lling
device
Outlet into a lling
device

9. Solar System Air Venting
• During operation of the lling pump, close the drain valve and increase the pressure to about 5
bar;
• close the lling valve and turn o󰀨 the lling pump, open the ball valve above the pump, do not
disconnect the lling pump hoses!
• Set the circulation pump to the highest level and, by turning it on and o󰀨 several times, vent the
system using the automatic air vent valves, if they are installed in the system (the de-aerated
pump works almost silently);
• continuously monitor the system pressure and if it drops, increase it to 5 bar by turning on the
lling pump and opening the lling valve;
• repeat the venting until the oat of the ow indicator takes a stable position during pump opera-
tion, shows a measurable ow and no bubbles appear in the sight glass. Then let the circulation
pump run for at least 5 minutes;
• if an automatic venting valve(s) is (are) anywhere in the solar circuit, also close this valve after
venting.
After lling and air venting the solar thermal system, close the ll and drain ball valves, adj-
ust the sys tem pressure to the required value, disconnect the hoses of the lling pump and
check that both the ball valves above and under the pump are open!

©2023 We reserve the right to errors, changes and improvements without prior notice.
REGULUS spol. s r.o.
E-mail: [email protected]
Web: www.regulus.eu
v1.0-08/2023
