Regulus CSE2 MIX F W 1F User manual

www.regulus.eu
CSE2 MIX F G60 1F
CSE2 MIX F G60 1F
EN
Installation and Operation Manual
CSE2 MIX F G60 1F PUMP STATION

│2
Regulus CSE2 MIX F G60 1F - www.regulus.eu
Contents
1. INTRODUCTION ...................................................................................... 3
2. PUMP STATION DESCRIPTION AND DATA ........................................... 3
3. PUMP STATION COMPONENTS ............................................................ 4
3.1. GRUNDFOS UPM3 AUTO 25-60 PUMP ....................................... 5
3.2. MIXING VALVE WITH ACTUATOR ................................................ 8
3.3. CHECK VALVE .............................................................................. 8
3.4. FILTER WITH MAGNET ................................................................ 8
3.5. BALL VALVES ................................................................................ 8
4. EXAMPLES OF PUMP STATION CONNECTION ................................... 10
5. PUMP STATION INSTALLATION ............................................................. 12
6. TEMPERATURE SENSOR INSTALLATION ............................................ 13
7. OPTIONAL ACCESSORIES .................................................................... 15
APPENDIX – ACTUATOR ADJUSTMENT ............................................... 19

3 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
1. INTRODUCTION
CSE2 MIX F G60 1F twin-line pump station is designed for mixed heating circuits. It provides
flow through the heating system, mixes to the outlet temperature using a motorized mixing
valve (controlled by an external controller). The pump station includes a filter with magnet,
so it is also suitable for older steel pipe systems. It can be easily mounted on a wall or on
a manifold for multiple heating circuits.
2. PUMP STATION DESCRIPTION AND DATA
Main Features
Description The twin-line pump station consists of:
● Grundfos UPM3 AUTO pump
● 2 ball valves w. sensor sheath
● check valve
● filter with strainer&magnet
● LK 840 mixing valve w. actuator
● thermometers, insulation
Working fluid water, antifreeze heat-transfer fluid for heating systems
Installation vertically on a wall or manifold (125 mm pitch)
Connections 4 x G 1“ F
Code 19103
Data for CSE2 MIX F G60 1F Pump Station
Fluid working temperature 5 - 95 °C
Max. working pressure 10 bar
Min. working pressure 0.5 bar
Ambient temperature 5 - 40 °C
Max. relative humidity 80%, non condensing
Pump power supply 1 ~ 230 V, 50 - 60 Hz
Pump station max. power input 42 W
Mixing valve Kvs 6.3 m3/h
Max. pressure difference 5 m H2O (at mixing valve inlets)
Leak rate < 1% Kvs at 5 mH2O pressure difference (at mixing valve inlets)
Mixing valve power supply 230 V, 50 Hz; from external controller w. 3-point control
Valve shift time 120 s
Insulation material EPP RG 60 g/l
Overall dimensions 360 x 181 x 245 mm
Total weight 6.7 kg
Connections 4 x G 1“ F
Pump Station Pressure Drop Graph

│4
Regulus CSE2 MIX F G60 1F - www.regulus.eu
3. PUMP STATION COMPONENTS
1 – Thermometer at the heating circuit return
2 – Thermometer at the heating circuit flow
3 – Grundfos UPM3 AUTO 25-60 circulation pump
4 – Mixing valve w. actuator
5 – T-piece with check valve
6 – Filter w. magnet
7 – Lever for ball valves
8 – Ball valve w. sheath for temperature sensor (heating circuit return)
9 – Ball valve w. sheath for temperature sensor (heating circuit flow)
9
3
2
4
3
5
8
7
1
6
4

5 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
3.1. GRUNDFOS UPM3 AUTO 25-60 130 MM PUMP
Wet-running circulation pump with G 6/4“ M connection.
Pump Connection
socket for power supply (A)
and signal transmission (B) –
not used in this pump
power supply connector (A)
N (blue)
L (brown)
PE (yellow-green)
Pump control
The circulation pump can be controlled by selecting a suitable prole and performance curve.
Performance curves
Line type Profile
Constant
speed
Proportional
pressure
Constant
pressure

│6
Regulus CSE2 MIX F G60 1F - www.regulus.eu
Description of Pump Frofiles
a) Proportional pressure
• This mode is suitable for heating systems with radiators, to reduce noise caused by
heating fluid flowing through thermostatic valves.
• Head (pressure) decreases with decreasing flow rate (increasing system pressure
drop).
• Pump operating point: lies on the selected proportional pressure curve depending on
the current system pressure drop.
CONTROL MODE DESCRIPTION
Proportional
pressure
I The lowest curve of proportional pressure
II The middle curve of proportional pressure
III The highest curve of proportional pressure
AUTOADAPT
Automatically controls performance in the range from
the highest to the lowest proportional pressure curve
b) Constant pressure
• This mode is suitable for underoor heating or for piping of a bigger size. It is also
suitable for all applications without variable characteristics (e.g. pumps for heating up
a HW storage tank) or for a circuit with a heat exchanger.
• Head (pressure) remains the same in the whole range of ow rates (does not change
with the system pressure drop).
• Pump operating point: moves on the selected constant pressure curve depending on
the current system pressure drop.
CONTROL MODE DESCRIPTION
Constant
pressure
I The lowest curve of constant pressure
II The middle curve of constant pressure
III The highest curve of constant pressure
AUTOADAPT
Automatically controls performance in the range from
the highest to the lowest constant pressure curve
c) Constant speed
• This mode is suitable for the maximum utilization of the pump performance or for use
in systems with constant resistance which require a constant pumping performance.
• Head (pressure) increases with decreasing ow rate (increasing system pressure
drop).
• Pump operating point: moves up or down on the selected curve depending on the
current system pressure drop.
CONTROL MODE Max. H (upper graph) Max. P1(lower graph)
Constant
speed
I 4 m 25 W
II 5 m 33 W
III 6 m 39 W

7 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
DISPLAY CONTROL MODE
green LED FLASHING INTERNAL
1Proportional pressure AUTOADAPT
2Constant pressure AUTOADAPT
3
Proportional pressure
I
4II
5III
6
Constant pressure
I
7II
8III
9
Constant speed
I
10 II
11 III
Settings Display
WARNING: LEDs may be turned by 90° or 180°, or mirrored, depending on the specific pump
type.
During operation, the selected pump profile is indicated by green LEDs and the power level
by yellow LEDs.
Setting selection
Pump profiles can be switched by pressing the
integrated button. The pump profiles change
in a closed loop in the order shown in the table.
Error Display
DISPLAY ERROR
Seized pump
Too low power supply voltage
Electric fault
push button

│8
Regulus CSE2 MIX F G60 1F - www.regulus.eu
ACTUATOR ELECTRICAL WIRING
1 – (blue)
2 – (black)
3– (brown)
The actuator is factory set to motorized control and ready for operation.
Should it be inevitable to remove it or replace, please follow the instructions
in the appendix.
230 V, 50 Hz
3.2. MIXING VALVE WITH ACTUATOR
The LK 840 mixing valve is equipped with a 3-point control actuator. The current valve member
position is obvious from the position of the line in the sightglass of the control knob. The slide
switch on the actuator housing can be used to switch between motorized and manual control.
When the manual control is set, the actuator is controlled by turning the knob.
3.3. CHECK VALVE
A check valve located downstream of the filter prevents natural circulation in the heating
circuit.
3.4. FILTER WITH MAGNET
The filter located in the return line of the pump station is designed to collect particles from
heating water. It consists of a brass housing, removable stainless-steel strainer collecting
coarse dirt, and a brass lid with a magnet that attracts magnetic particles.
The filter needs to be checked regularly, and cleaned when needed. Turn off the circulation
pump, close the ball valve upstream of the filter. Water inlet downstream of the magnet is
closed by the check valve. Unscrew the filter lid, remove the stainless steel strainer and flush
thoroughly. Wipe the impurities on the magnet and re-assemble the filter by inserting the
strainer, screwing in and tightening the lid.
3.5. BALL VALVES
Ball valves are intended to isolate the pump station from the heating circuit. Then it is not
necessary to drain the heating circuit for servicing (incl. cleaning the filter). In order to have
a more solid hydraulic section of the pump station, they are fixed to the rear mounting plate.
The ball valves are controlled by a lever that is placed inside the pump station insulation. The
valve is closed or opened by turning the lever by 90°. The state of the valve is indicated by
the groove on the control hexagon of the valve. The ball valve can be accesses only after the
front section of the insulation is removed. As a result, unintentional closure of the system by
an unauthorized person is not possible.
control mode switch line in sightglass
motorized control
manual control
control knob

9 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
OPEN CLOSED
groove in the flow direction groove perpendicular to the flow direction

│10
Regulus CSE2 MIX F G60 1F - www.regulus.eu
4. EXAMPLES OF PUMP STATION CONNECTION
KEY 1 Regulus heat pump (RTC, CTC) 2 heating system expansion vessel 3 Regulus HSK 350 K P-B thermal store 4 HV 60/125-2 manifold/collector 5 pump station for heating circuit 2 – CSE2 MIX 6 pump station for heating circuit 1 – CSE2 7 pump station for DHW recirculation – CSE TVMIX ZV 8 safety kit for HW storage tank 9 DHW expansion vessel 10 RegulusBOX indoor unit SV cold water TV hot water CV hot water recirculation ÚT central heating (heating system) KK ball valve ZV check valve AOV automatic air vent valve PTR pressure temperature relief valve REDV pressure reducing valve (optional) VK drain valve SVE expansion vessel service valve PV-ÚT safety valve for heating system MFB Magnet Filterball
COMPENSATOR
BRAIDED HOSE

11 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
KEY 1 HV 60/125-2 manifold/collector 2 hydraulic pressure balancer 3 heating system expansion vessel 4 hot water storage tank (e.g. NBC 170 HP) 5 DHW expansion vessel 6 safety kit for HW storage tank 7 pump station for DHW recirculation – CSE TV ZV 8 boiler (natural gas, electric…) 9 pump station for heating circuit 2 – CSE2 MIX 10 pump station for heating circuit 1 – CSE2 SV cold water TV hot water CV hot water recirculation ÚT central heating KK ball valve ZV check valve AOV automatic air vent valve PTR pressure temperature relief valve REDV pressure reducing valve (optional) VK drain valve SVE expansion vessel service valve PV-ÚT safety valve for heating system MFB Magnet Filterball

│12
Regulus CSE2 MIX F G60 1F - www.regulus.eu
5. PUMP STATION INSTALLATION
The pump station is designed to be mounted on a wall or a manifold with 125 mm connection
pitch. In the rear section of the insulation there are two mounting holes for fixing the metal
plate to the wall. Mounting holes pitch is 80 mm.
The package includes a mounting kit that is used to fix the pump station to the
intended place. The mounting kit includes:
Screw 5x50, round head 2 pcs
6.4 stainless steel washer, DIN 9021/A2 2 pcs
Wall plug 8mm TX 2 pcs
340 360
125
245
Permitted and prohibited positions of the pump station
Permitted position Conditionally permissible positions Prohibited position
(may be used when a filter is replaced by
the filter replacement section, code 19017)
Installation dimensions are shown in the figure.




+
+

13 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
6. TEMPERATURE SENSOR INSTALLATION
The ball valve housings are equipped with a sheath for the temperature sensor, where the
sensor can be inserted and secured by a fixing screw against being pulled out. In the top
and bottom section of the insulation there are passages to run the cables through, then it is
necessary to cut the appropriate part of the passage lock from the front part of the insulation
with a knife, so that the exiting cables are firmly wrapped around by the lock.
1.
Temperature sensor placement
2.
Securing the temperature sensor with
the screw
3.
Running the sensor cable through the
recess in the insulation

│14
Regulus CSE2 MIX F G60 1F - www.regulus.eu
4.
Trimming the cable passage lock
5.
Installed sensors

15 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
7. OPTIONAL ACCESSORIES
The following optional accessories are available for the pump station:
A – Filter replacement section for CSE2
Code 19017
Loosen the unions above and under
the lter. Remove the lter and mount the lter replacement section (code 19017) in its
place.

│16
Regulus CSE2 MIX F G60 1F - www.regulus.eu
B – Ball Valve w. drain valve, Fu/F
Code 17415
and Union 1“ Fu/M incl. gasket
Code 15695
Remove both the connecting ttings. Install the union 15695 in their place, then
attach the ball valve w. drain valve (17415)
to the union.

17 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
C – Union, 1“ Fu/M, extended, with check valve, incl. gasket
(for return line of CSE2 pump stations)
Code 18653
and Union, 1“ Fu/M, extended, incl. gasket
(for flow line of CSE2 pump stations)
Code 18797
Remove both the connecting ttings. Install the extended union with check valve
(18653) to the return line.
Install the extended union (18797) to
the ow line.

│18
Regulus CSE2 MIX F G60 1F - www.regulus.eu
D – Union to connect CSE2 to 5/4” manifold - 1“x5/4“ Fu/F
Code 17920
Remove both the connecting ttings. Replace them with the union 17920
intended for connection to a manifold.

19 │
Regulus CSE2 MIX F G60 1F - www.regulus.eu
APPENDIX – ACTUATOR ADJUSTMENT
- The actuator is set and ready for operation from the production
- The instructions apply only if the actuator had to be removed e.g. to be replaced
1.
When fitting the actuator, turn the
D-shaft in such a manner that the
valve member is between inlets 2 and
3 at an angle of 45°.
2.
Fit the plastic adapter on the shaft.
The flat edge of the shaft and the
arrow on the plastic adapter are
located on the same side as the valve
member.
valve member position
D-shaft
D-shaft
valve member
position
arrow on
plastic adapter

3.
Prior to fitting the actuator on the
plastic adapter, switch it to manual
control, set the control knob exactly to
the middle of its movement range.
4.
Fit the actuator onto the plastic
adapter. Check its turning: the control
knob shall be able to turn freely both
to left and right by 45° (when turned to
the right by 45° the path 3 is closed,
and when turned to the left by 45° the
path 2 is closed). Having performed
the check, tighten the fastening screw
and switch back to motorized control.
5.
The actuator shall be installed in the
same manner as in the figure.
control mode switch line in sightglass
motorized control
manual control control knob
©2022 We reserve the right to errors, changes and improvements without prior notice.
REGULUS spol. s r.o.
E-mail: [email protected]
Web: www.regulus.eu
v1.1-05/2022
