BIO 55 MIX W–PWM 1F TRS6K
BIO 55 MIX W–PWM 1F TRS6K
EN
Installation and Operation Manual
BIO 55 MIX W–PWM 1F TRS6K
LOAD UNIT
VARIANT 1A VARIANT 1B VARIANT 1C VARIANT 2

│2
CONTENTS
A. Safety Instructions ............................................................................................ 3
B. Safety Instructions ............................................................................................ 3
B.1. Load Unit Components ............................................................................ 4
B.2. Load Unit Data ......................................................................................... 5
B.3. Pressure Drop Graph ................................................................................ 6
B.4. Dimensions ............................................................................................... 7
C. Load Unit Installation ....................................................................................... 7
C.1. Hydraulic Connection of the Load Unit ...................................................... 10
C.2. Overview of Basic Hydraulic Variants ........................................................ 11
C.2.1.Variant 1, Option A ........................................................................... 11
C.2.2.Variant 1, Option B .......................................................................... 14
C.2.3.Variant 1, Option C .......................................................................... 16
C.2.4.Variant 2 .......................................................................................... 18
D. Accessory Installation ...................................................................................... 20
D.1. RC Caleon & RC Caleon WIFI Room Units .............................................. 21
D.2. Room Temperature Sensor ....................................................................... 22
D.3. Electric Heating Element for DHW Afterheating ........................................ 23
D.4. Electric Heating Element for DHW Afterheating ........................................ 24
D.5. DHW Recirculation Pump ......................................................................... 26
D.6. Heat Transfer Pump .................................................................................. 27
D.7. Temperature Sensor in Thermal Store ...................................................... 28
E. System Settings ................................................................................................ 29
E.1. Controller Operation .................................................................................. 29
E.2. Setup Wizard ............................................................................................. 30
E.3. Free Commissioning ................................................................................. 33
E.4. General Settings ....................................................................................... 34
E.5. Adjusting Temperatures & Time Programs ................................................ 34
E.6. Auxiliary Heat Source (el. heating element) .............................................. 39
E.7. DHW Recirculation Pump ......................................................................... 40
E.8. Complete Controller Menu ........................................................................ 41
F. Servicing, Maintenance .................................................................................... 68
F.1. Overall Electrical Wiring Diagram of the Load Unit ................................... 68
F.2. Status Indication and Error Messages ...................................................... 69
F.3. Replacing the Controller Fuse ................................................................... 70
F.4. Servicing & Maintenance of Hydraulic Components ................................. 71
G. Legislation ......................................................................................................... 72
G.1. Declaration of Conformity .......................................................................... 72
G.2. Controller Disposal .................................................................................... 72

3 │
A. Declaration of Conformity
● The hydraulic connection of the load unit must be carried out by a person qualified according
to the applicable standards and regulations.
● Any interventions in the electrical installation must be carried out by a person qualified
according to the applicable standards and regulations.
● Before starting work on the wiring (e.g. when connecting accessories to the controller), the
load unit and the connected electrical equipment (e.g. electric heating element) must be
disconnected from the power supply!
● The BIO 55 MIX W-PWM 1F TRS6K load unit is in no way a replacement for the safety
components of the heating system, hot water system and boiler. These safety elements
must always be installed in accordance with the applicable standards and regulations. The
diagrams published in this manual represent wiring examples and may not be complete.
Carry out the actual installation according to the heating design and ensure that all prescribed
safety features are fitted.
● Any tampering with the controller, adjusting the controller or connecting accessories must
be done in accordance with the instructions in this manual. Only accessories recommended
in this manual may be connected to the controller.
B. INTRODUCTION, DESCRIPTION
BIO 55 MIX W–PWM 1F TRS6K Load Unit includes a complete hydraulic and electrical
connections for the installation of a heating system with a solid fuel boiler. The load unit has
a complete electrical installation and is fitted with a power cord with a plug. All you need to
do is connect the boiler, the heating system, a thermal store(s) (depending on the selected
hydraulic variant), then place the sensors and plug the load unit into a socket. Then select the
corresponding hydraulic variant in the controller using the setup wizard and set other required
parameters. The basic connection diagram can be upgraded with optional accessories.
For more information on optional accessories see the Chapters “Overview of Basic Hydraulic
Variants”, “Accessory Installation” and “System Settings”.
The Load Unit involves
● TRS6 BIOMIX controller with hydraulic variant selection for smart control of the entire system
● Two Wilo Para 25/8 iPWM1 circulation pumps with continuous performance control via
PWM signal for boiler circuit and heating system
● TSV3BM load valve with automatic bypass balancing to protect the boiler against low
temperature corrosion by keeping return water temperature to boiler at 55 °C
● Motorised three-way mixing valve including actuator to maintain the required temperature
in the heating circuit
● Two ball valves and two drain valves for shutting off and draining the heating system
● Check valve integrated in the ball valve body located at the return line from the heating
system
● Two ball valves to shut off the boiler circuit
● Lever for ball valves, placed inside the insulation
● 3m power cord, 1.5 mm2 cable cross section
● Three Pt 1000 temperature sensors with 4 m cable
● Pt 1000 heating circuit temperature sensor (factory-installed in a sheath in the load unit)
● 10 m cable for the outdoor temperature sensor (the sensor itself is enclosed)
● Four thermometers
● Two mini drain valves to drain the load unit
● Outlets to connect optional accessories (e.g. a pressure switch)
The Load Unit delivery includes a package containing:
● Mounting kit for an easy installation of the load unit on a wall
● Two DN 20 ball valves to be installed at the thermal store inlet/outlet
● Pt1000 outdoor temperature sensor to be installed on the northern wall of the building

│4
B.1. LOAD UNIT COMPONENTS
1 – 4m cable with Pt 1000 temperature sensor
2 – Power cord
3 – Boiler return line thermometer
4 – Wilo Para 25/8 iPWM1 boiler pump
5 – TRS6 BIOMIXK Controller
6 – Return heating water thermometer
7 – Heating water ow thermometer
8 – Wilo Para 25/8 iPWM1 heating circuit pump
9 – Mixing valve actuator
10 – Boiler ow thermometer
11 – 10m cable for outdoor temperature sensor
12 – Pt 1000 outdoor temperature sensor
13 – G 1“ Fu × G 1“ F × G 1/2 “ F ball valve w. free outlet and sheath for temperature sensor
14 – G 1” F return line from thermal store
15 – DN 20 ball valve to be mounted on pos. 14 and 16 (included in the enclosed package)
16 – G 1“ F outlet to thermal store
17 – TSV3BM load valve
18 – G 1/2“ M drain valve with hose tail
19 – G 6/4“ Fu × G 1“ F × G 1/2“ F ball valve w. check valve and sheath for temperature sensor
20 – Handle for ball valves
21 – G 6/4 “ Fu × G 1“ F × G 1/2“ F ball valve w. heating circuit temperature sensor
22 – Pt 1000 heating circuit temperature sensor (connected to TRS6K BIOMIX controller
from the factory)
23 – LK 840 mixing valve
24 – Mini drain valves
25 – Wiring box
26 – Installation kit (8.4 stainless steel washer DIN 125A/A2, 2 pcs, 10mm wall plug, 2 pcs,
8x60 hex head screw, 2 pcs

5 │
B.2. LOAD UNIT DATA
Technical Data
Fluid working temperature 5-95 °C
Max. working pressure 6 bar
Min. working pressure 0.5 bar
Ambient temperature 5-40 °C
Max. relative humidity max. 80 %, non condensing
Max. temperature of sheath sensors 95 °C
Min. return water temperature to boiler 55 °C
Mixing valve actuator run time 120 s
Max. boiler output at ow of 1730 l/h 40 kW at Δt 20 °C
20 kW at Δt 10 °C
Max. heating system output at ow of 1730 l/h 40 kW at Δt 20 °C
20 kW at Δt 10 °C
Insulation material EPP RG 60 g/l
Overall dimensions (H x W x D) 640 x 350 x 231 mm
Total weight 16.7 kg
Electric Data
Load Unit power supply 230 V, 50 Hz
(power cord)
Load Unit max. power input 155 W
(basic connection, no accessories)
IP rating of BIO 55 MIX Load Unit IP20
Inner fuse of TRS6K BIOMIX controller T2A / 250V slow blow
Backup of TRS6K BIOMIX controller clock operation 24 hours
Max. permitted cable length for Pt 1000 sensors 10 m
Max. permitted length of CAN cable to Caleon unit
(standard cable) 3 m
Max. permitted length of CAN cable to Caleon unit
(shielded twisted cable) 50 m
Table of Kvs values
Mixing valve 6.3 m3/h
Ball valves 20.2 m3/h

│6
B.3. PRESSURE DROP GRAPH
PERFORMANCE CURVES FOR WILO PARA 25/8 iPWM1 PUMP
for various % of PWM control signal
BOILER
SIDE
HEATING
CIRCUIT
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 1,8 2,0
∆p [mH2O]
Q [m
3
/h]
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
0 0,2 0,4 0,6 0,8 1 1,2 1,4 1,6 1,8 2
∆p [mH
2
O]
Q [m3/h]

7 │
B.4. DIMENSIONS
Note: The dimensional diagram of the open load unit is rotated for illustrative purposes, the
outlets for the thermal store connection are mutually aligned (see side view).
C. LOAD UNIT INSTALLATION
The load unit is designed for wall mounting. It shall be mounted in the selected position using
the enclosed installation kit. Choose the right installation height that will enable comfortable
handling the controller. Two mounting holes in the sheet metal in the rear section of the
insulation are used for wall mounting, see dimension diagram below.
Note: In the basic version, the thermal store is supposed to be connected on the left side of
the load unit. If necessary, the load unit can be converted to be connected to a thermal store
on the right side. The conversion procedure is described on the following page.
installation openings
for wall mounting

│8
Procedure for conversion of the load unit to connect the thermal store from
the right
1Remove the top part of insulation. 2
Loosen the nut and remove the extension
for the outlet to the thermal store (this
will be used in step 8).
3
On the right and left side of the insulation
body there are insulated passage points
for connecting the thermal store; take
out the insulation pieces from both the
passage points.
4Loosen the nut and turn the elbow to
the right.
5
Take out the insulation piece for the
boiler pump. Loosen the nuts at both the
discharge and suction ports of the pump
so that you can easily handle the pump.
6Move the pump to the side to allow free
access to the elbow.

9 │
7Loosen the elbow and take it out of the
load unit. 8
Assemble the elbow with the extension
removed in step 3 and re-install it to
same location so that the outlet now
points to the right.
9
Mount the pump back to its original
place, tighten both nuts and return back
the pump insulation piece.
10 Replace all the remaining pieces of
insulation to their original places.
11 The load unit should now look like this. 12 Reinstall the top part of the insulation.

│10
C.1. HYDRAULIC CONNECTION OF THE LOAD UNIT
HOW TO PROCEED:
Make hydraulic connections of the boiler, heating system, thermal store(s) or hot water
tank(s) with the load unit, respecting the selected hydraulic variant (see the following pages)
→ Fill and air bleed the system → Perform a pressure test → Place temperature sensors to
the respective sheaths depending on the selected hydraulic variant → Mount the outdoor
temperature sensor on a north-facing wall about 1.5-3m
above the ground.
HOW TO CONNECT PIPING
The load unit has two side outlets from ball valves for
connecting optional accessories (plugged) from ball valves
11, which are connected with the boiler remain connected
with the boiler even when the ball valves are closed.
Before starting operation, make sure all ball valves
are in the open position (the open/closed position on ball
valves inside the load unit is shown by the groove position).
Piping connections Inner hydraulic connection
Pos. Description Conn. Key to components
1
2
Return from heating system
Outlet to heating system G 1“ F Ball valve w. drain
valve
3
4
Flow from boiler
Return to boiler G 1“ F Load valve
5
6
Outlet to thermal store w. ball valve
(enclosed)
Return from thermal store w. ball valve
(enclosed)
G 1“ F Mixing valve w.
actuator
7
8
Ball valve w. integrated check and drain
valves*
Ball valve w. integrated drain valve*
Ball valve w. outlet to
connect optional acce-
ssories
9
10
Load valve
Mixing valve w. actuator Ball valve w. integrated
check and drain valves
11 Ball valve w. outlet to connect optional
accessories
G 1/2“ F
(plugged
from the
factory)
1 2
3
4
5
6
7 8
9 10
11 11
* remains connected with the boiler/heating system even when the ball valve is closed
drážka kolmo
na směr proudění
zavřeno
otevřeno
drážka ve směru
proudění
groove
perpendicular to the
direction of ow
shut
groove in the
direction of ow
open

11 │
C.2. OVERVIEW OF BASIC HYDRAULIC VARIANTS
These basic diagrams can be extended with accessories that can always be found after the
respective diagram on the following pages.
C.2.1. Variant 1, Option A
A system with a solid fuel boiler w. manual stoking, one heating circuit and a combination
thermal store. The BIO MIX Load Unit ensures DHW and space heating and heat storage
in the combination thermal store. It is recommended to use a Caleon room unit or a room
temperature sensor for a more precise control of the room temperature. To ensure DHW
heating also in periods when the boiler is extinguished, it is recommended to install an electric
heating element tted with an adjustable and a safety thermostat for DHW afterheating in the
upper section of the thermal store.
Locations of temperature sensors
S1 – not connected, a room temperature sensor may be connected (optional accessories)
S2 – upper temperature sensor in a combination thermal store (under the separating
metal sheet)
S3 – lower temperature sensor in a combination thermal store
S4 – temperature sensor at the outlet from a solid-fuel boiler
S5 – heating water temperature sensor (in a sheath inside the load unit)
S6 – outdoor temperature sensor (installed on a north-facing wall about 1.5-3 m above the
ground)

│12
Basic hydraulic diagram
DESCRIPTION
KK ball valve 1RegulusBIO Load Unit
ZV check valve 2 boiler
VK drain valve 3 combination thermal store with DHW
REDV pressure reducing valve (5 bar) 4 heating system
SVE expansion vessel service valve 5safety kit*
DOCHV thermal safety relief valve (e.g. BVTS) *the safety kit involves a test valve,
check valve, drain valve, safety valve,
pressure gauge and outlet to connect an
expansion vessel
TSV TV anti-scald valve
PV-TOP heating system safety valve
EN-TV DHW expansion vessel
EN-TOP heating system expansion vessel
AOV automatic air vent valve
MFB Magnet Filterball
PV-TV DHW safety valve

13 │
OPTIONAL ACCESSORIES FOR HYDRAULIC VARIANT 1, OPTION A
Caleon Room Unit OR Room Temperature Sensor
For comfortable and more precise room
temperature control For more precise room temperature control
Caleon room unit
w. touchscreen and
temperature sensor (code
17150).
Caleon Wi room unit
enables also control over
the Internet from a mobile
phone app (code 18126).
For installation description
see Chapter D.1.
Room temperature
sensor in ABB TIME
design (code 16167).
For installation
description see Chapter
D.2.
El. heating element for DHW afterheating
Hot water always available.
To ensure DHW heating also in periods when the boiler
is extinguished, it is recommended to install an electric
heating element tted with an adjustable and a safety
thermostat – preferably the ETT M model.
The temperature is set directly on the element using the
control knob and thanks to its power cord with an el. plug
no professional electrician is needed for wiring.
For installation description see Chapter D.3.
El. heating element for space heating OR DHW recirculation pump
Warm even when the boiler is extinguished Controlled hot water recirculation
To ensure thermal comfort
even after the boiler is
extinguished and heat
from the thermal store
is exhausted, an electric
heating element for space
heating can be used that
is equipped with both an
adjustable and a safety
thermostat, and with a
contactor, e.g. ETT L
model.
For installation description
see Chapter D.4.
The controller is able
to switch the DHW
recirculation pump
following a time schedule.
It is recommended to use
the DHW pump station
with anti-scald valve,
code 17893.
For installation
description see Chapter
D.5.

│14
C.2.2. Variant 1, Option B
A system with a solid fuel boiler w. manual stoking, one heating circuit, a combination thermal
store and a thermal store. The BIO MIX Load Unit ensures DHW and space heating and heat
storage in the combination and standard thermal stores. It is recommended to use a Caleon
room unit or a room temperature sensor for a more precise control of the room temperature.
To ensure DHW heating also in periods when the boiler is extinguished, it is recommended to
install an electric heating element tted with an adjustable and a safety thermostat for DHW
afterheating in the upper section of the combination thermal store.
Locations of temperature sensors
S1 – not connected, a room temperature sensor may be connected (optional accessories)
S2 – upper temperature sensor in a (combination) thermal store (under the separating metal sheet)
S3 – lower temperature sensor in a thermal store
S4 – temperature sensor at the outlet from a solid-fuel boiler
S5 – heating water temperature sensor (in a sheath inside the load unit)
S6 – outdoor temperature sensor (installed on a north-facing wall about 1.5-3m above the ground)
Basic hydraulic diagram
DESCRIPTION
KK ball valve AOV automatic air vent valve
ZV check valve MFB Magnet Filterball
VK drain valve PV-TV DHW safety valve
REDV pressure reducing valve (5 bar) 1 RegulusBIO Load Unit
SVE expansion vessel service valve 2boiler
DOCHV thermal safety relief valve (e.g. BVTS) 3 combination thermal store with DHW
TSV TV anti-scald valve 4thermal store
PV-TOP heating system safety valve 5heating system
EN-TV DHW expansion vessel 6 safety kit*
EN-TOP heating system expansion vessel *the safety kit involves a test valve, check valve, drain valve, safety
valve, pressure gauge and outlet to connect an expansion vessel

15 │
OPTIONAL ACCESSORIES FOR HYDRAULIC VARIANT 1, OPTION B
Caleon Room Unit OR Room Temperature Sensor
For comfortable and more precise room
temperature control For more precise room temperature control
Caleon room unit
w. touchscreen and
temperature sensor (code
17150).
Caleon Wi room unit
enables also control over
the Internet from a mobile
phone app (code 18126).
For installation description
see Chapter D.1.
Room temperature
sensor in ABB TIME
design (code 16167).
For installation
description see Chapter
D.2.
El. heating element for DHW afterheating
Hot water always available.
To ensure DHW heating also in periods when the boiler
is extinguished, it is recommended to install an electric
heating element tted with an adjustable and a safety
thermostat – preferably the ETT M model.
The temperature is set directly on the element using the
control knob and thanks to its power cord with an el. plug
no professional electrician is needed for wiring.
For installation description see Chapter D.3.
El. heating element for space heating OR DHW recirculation pump
Warm even when the boiler is extinguished Controlled hot water recirculation
To ensure thermal comfort
even after the boiler is
extinguished and heat
from the thermal store
is exhausted, an electric
heating element for space
heating can be used that
is equipped with both an
adjustable and a safety
thermostat, and with a
contactor, e.g. ETT L
model.
For installation description
see Chapter D.4.
The controller is able
to switch the DHW
recirculation pump
following a time schedule.
It is recommended to use
the DHW pump station
with anti-scald valve,
code 17893.
For installation
description see Chapter
D.5.

│16
C.2.3. Variant 1, Option C
A system with a solid fuel boiler w. manual stoking, one heating circuit and a thermal store.
The BIO MIX Load Unit ensures space heating and heat storage in the thermal store. It is
recommended to use a Caleon room unit or a room temperature sensor for a more precise
control of the room temperature.
Locations of temperature sensors
S1 – not connected, a room temperature sensor may be connected (optional accessories)
S2 – upper temperature sensor in a thermal store
S3 – lower temperature sensor in a thermal store
S4 – temperature sensor at the outlet from a solid-fuel boiler
S5 – heating water temperature sensor (in a sheath inside the load unit)
S6 – outdoor temperature sensor (installed on a north-facing wall about 1.5-3m above the ground)
Basic hydraulic diagram
DESCRIPTION
KK ball valve 1 RegulusBIO Load Unit
ZV check valve 2boiler
VK drain valve 3 thermal store
SVE expansion vessel service valve 4heating system
DOCHV thermal safety relief valve (e.g. BVTS)
PV-TOP heating system safety valve
EN-TOP heating system expansion vessel
AOV automatic air vent valve
MFB Magnet Filterball

17 │
OPTIONAL ACCESSORIES FOR HYDRAULIC VARIANT 1, OPTION C
Caleon Room Unit OR Room Temperature Sensor
For comfortable and more precise room
temperature control For more precise room temperature control
Caleon room unit
w. touchscreen and
temperature sensor (code
17150).
Caleon Wi room unit
enables also control over
the Internet from a mobile
phone app (code 18126).
For installation description
see Chapter D.1.
Room temperature
sensor in ABB TIME
design (code 16167).
For installation
description see Chapter
D.2.
El. heating element for space heating
Warm even when the boiler is extinguished
To ensure thermal comfort even after the boiler is extinguished and heat
from the thermal store is exhausted, an electric heating element for
space heating can be used that is equipped with both an adjustable and
a safety thermostat, and with a contactor, e.g. ETT L model.
For installation description see Chapter D.4.

│18
C.2.4. Variant 2
A system with a solid fuel boiler w. manual stoking, one heating circuit, a thermal store and
a hot water storage tank. The BIO MIX Load Unit ensures space and DHW heating and
heat storage in the thermal store. It is recommended to use a Caleon room unit or a room
temperature sensor for a more precise control of the room temperature. To ensure DHW
heating also in periods when the boiler is extinguished, it is recommended to install an electric
heating element tted with an adjustable thermostat in the hot water storage tank.
Locations of temperature sensors
S1 – lower temperature sensor in a thermal store (shall be ordered separately,
code 9109)
S2 – upper temperature sensor in a thermal store
S3 – temperature sensor in a hot water storage tank
S4 – temperature sensor at the outlet from a solid-fuel boiler
S5 – heating water temperature sensor (in a sheath inside the load unit)
S6 – outdoor temperature sensor
Basic hydraulic diagram
DESCRIPTION
KK ball valve 1 RegulusBIO Load Unit
ZV check valve 2boiler
VK drain valve 3 combination thermal store
REDV pressure reducing valve (5 bar) 4hot water storage tank
SVE expansion vessel service valve 5heating system
DOCHV thermal safety relief valve (e.g. BVTS) 6 heat exchange pump station
TSV TV anti-scald valve 7 safety kit*
PV-TOP heating system safety valve *the safety kit involves a test valve,
check valve, drain valve, safety valve,
pressure gauge and outlet to connect
an expansion vessel
EN-TV DHW expansion vessel
EN-TOP heating system expansion vessel
AOV automatic air vent valve
MFB Magnet Filterball
PV-TV DHW safety valve

19 │
NECESSARY ACCESSORIES FOR HYDRAULIC VARIANT 2
Temperature sensor for thermal store
Lower temperature sensor for thermal store (to be ordered
separately, code 9109).
For installation description see Chapter D.7.
Heat transfer pump station
A heat transfer pump station ensures heating of the hot
water storage tank (by drawing heat from the thermal
store). To be ordered separately.
The recommended item is e.g. CSE OTS ZV W-SC (code
17979).
For installation description see Chapter D.6.
OPTIONAL ACCESSORIES
The following accessories are also recommended for hydraulic variant 2:
Caleon Room Unit
For comfortable and more precise room temperature control
Caleon room unit w. touchscreen and temperature sensor
(code 17150).
Caleon Wi room unit enables also control over the
Internet from a mobile phone app (code 18126).
For installation description see Chapter D.1.
El. heating element for DHW afterheating
Hot water always available.
To ensure DHW heating also in periods when the boiler
is extinguished, it is recommended to install an electric
heating element tted with an adjustable and a safety
thermostat – preferably the ETT M model.
The temperature is set directly on the element using the
control knob and thanks to its power cord with an el. plug
no professional electrician is needed for wiring.
For installation description see Chapter D.3.

│20
D. ACCESSORY INSTALLATION
If you do not intend to install any accessories, proceed directly to the controller settings.
INSTRUCTIONS FOR ELECTRICAL WIRING AND ACCESSORY SETTINGS
Electrical wiring of the accessories must be carried out by a person qualied according to the
applicable standards and regulations.
Safety warning
Before working on the unit, switch off the power supply and secure it against being
switched on again! The controller is not equipped with a mains switch. To switch
the unit off, either unplug the power cord from a power outlet, or use a circuit
breaker. Check for the absence of power! Do not use the controller if the housing
shows visible damage.
General instructions for connecting accessories
Low-voltage cables such as temperature sensor cables must be routed separately
from mains voltage cables. Connect temperature sensor cables only to the left-
hand side of the controller, and mains voltage cables and relay cables only to its
right-hand side.
The cables being connected to the unit must not be stripped by more than 55 mm,
and the cable jacket must reach into the housing to the other side of the grommet.
How to proceed:
Accessory cables are connected to free terminals S1 or R3 (see photo below) or CAN
according to the wiring diagram of the selected accessory.
1. Unplug the power cord from the power outlet before starting work.
2. Remove the top section of the load unit insulation and release the controller from the
insulation piece so that you have clear access to the controller. Unscrew the front cover of
the controller.
3. Remove the outer insulation of the cable (in the length of 55 mm max.), run it through the
opening in the rear part of the controller and fit the cable clamp.
4. Strip the last 8-9 mm of all cable cores.
5. Open the connectors with a flat-blade screwdriver and connect the wires according to the
appropriate diagram
6. Close the controller and screw the cover back.
7. Plug the power cord into a power socket and put the controller into operation.
8. Run commissioning of TRS6K BIOMIX controller following the setup wizard and then set the
desired accessories in the controller menu following instructions in the chapter Accessory
Installation.
