Regulus CSE2 MIX F W 1F User manual

www.regulus.eu
CSE2 MIX F W8 1F
CSE2 MIX F W8 1F
EN
Installation and Operation Manual
CSE2 MIX F W8 1F PUMP STATION

│2
Regulus CSE2 MIX F W8 1F - www.regulus.eu
Contents
1. INTRODUCTION ..................................................................................... 3
2. PUMP STATION DESCRIPTION AND DATA ........................................... 3
3. PUMP STATION COMPONENTS ............................................................ 4
3.1. Wilo-Para 25/8 PUMP .................................................................... 5
3.2. MIXING VALVE W. ACTUATOR ..................................................... 10
3.3. CHECK VALVE ............................................................................. 10
3.4. FILTER WITH MAGNET ................................................................. 10
3.5. BALL VALVES ............................................................................... 10
4. PUMP STATION CONNECTION EXAMPLES ......................................... 12
5. PUMP STATION INSTALLATION ............................................................. 14
6. TEMPERATURE SENSOR INSTALLATION ............................................ 15
7. OPTIONAL ACCESSORIES ................................................................... 17
APPENDIX – ACTUATOR ADJUSTMENT .............................................. 21

3 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
1. INTRODUCTION
CSE2 MIX F W8 1F twin-line pump station is designed for mixed heating circuits. It provides
flow through the heating system, mixes to the outlet temperature using a motorized mixing
valve (controlled by an external controller). The pump station includes a filter with magnet,
so it is also suitable for older steel pipe systems. It can be easily mounted on a wall or on a
manifold for multiple heating circuits.
2. PUMP STATION DESCRIPTION AND DATA
Main Features
Description The twin-line pump station consists of:
● Wilo Para pump
● 2 ball valves w. sensor sheath
● check valve
● filter with strainer&magnet
● LK 840 mixing valve w. actuator
● thermometers, insulation
Working fluid water, antifreeze heat-transfer fluid for heating systems
Installation vertically on a wall or manifold (125 mm pitch)
Connections 4 x G 1“ F
Code 17937
Data for CSE2 MIX F W8 1F Pump Station
Fluid working temperature 5 - 95 °C
Max. working pressure 10 bar
Min. working pressure 0.5 bar
Ambient temperature 5 - 40 °C
Max. relative humidity 80% non condensing
Pump power supply 1 ~ 230 V, 50 - 60 Hz
Pump station max. power input 78 W
Mixing valve Kvs 6.3 m3/h
Max. pressure difference 5 m H2O (at mixing valve inlets)
Leak rate < 1% Kvs at 5 mH2O pressure difference (at mixing valve inlets)
Mixing valve power supply 230 V, 50 Hz; Mixing valve power supply
Valve shift time 120 s
Insulation material EPP RG 60 g/l
Overall dimensions 360 x 181 x 245 mm
Total weight 6.7 kg
Connections 4 x G 1“ F
Pump Station Pressure Drop Graph

│4
Regulus CSE2 MIX F W8 1F - www.regulus.eu
3. PUMP STATION COMPONENTS
1 – Thermometer at the heating circuit return
2 – Thermometer at the heating circuit flow
3 – Wilo-Para 25/8 circulation pump
4 – Mixing valve w. actuator
5 – T-piece w. check valve
6 – Filter with magnet
7 – Lever for ball valves
8 – Ball valve w. sheath for temperature sensor (heating circuit return)
9 – Ball valve w. sheath for temperature sensor (heating circuit flow)
2
4
3
5
8
7
1
6
9
3
4

5 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
3.1. Wilo-Para 25/8 SC PUMP
Wilo Para 25/8 SC circulation pump is a wet-running circulation pump permitting to
set speed control to Δp-v, Δp-c or n=constant. The operating status and possible faults
of the pump are displayed by means of LEDs directly on the pump display. It is used
exclusively for the circulation of liquids in hot water heating systems. Operating the
pump in other systems or in systems lacking water, containing air bubbles or not
pressurized can lead to its rapid destruction.
Wilo Para 25/8 SC Pump Data
Power supply 230 V, 50 Hz, from an external controller
Power input (min./max) 2 / 75 W
Current (min./max) 0.03 – 0.66 A
Max. speed 4800 rpm
Speed control frequency converter
Energy Efficiency Index (EEI) ≤ 0.21 by EN 16297/3
IP rating IPX4D
Motor protection integrated
Operating Parameters
Fluid working temperature 0 - 100°C at 58 °C ambient temperature
Max. static pressure 10 bar
Max. head 8.4 m
Pump Wiring
1. POWER SUPPLY (1 ~ 230V, 50 Hz)
brown (L)
blue (N)
yellow-green (PE)
green is lit
red is lit
ashing red
ashing red and green
1 - pump is running in trouble-free operation
2 - electric motor winding defect
3 - pump overheated
2 - electric short circuit in pump
1 - power supply lower/higher than 230 V
1 - rotor is blocked
1 - unforced uid circulation through the pump
2 - pump speed lower than desired
3 - air in pump
LED indication state description and possible fault reasons

│6
Regulus CSE2 MIX F W8 1F - www.regulus.eu
TROUBLESHOOTING, RESTART, FACTORY SETTINGS
If air is present in the pump:
Activate the pump venting function by pressing and holding the
operating button for 3 sec. The upper and lower rows of LEDs will
ash in 1sec interval, see Fig.
Pump venting takes 10 minutes, after that the pump returns to
current mode. In order to cancel pump venting, press and hold the
operating button for 3 sec.
Operating button locking/unlocking
To lock the operating button, press it for 8 seconds.
The selected setting then starts ashing and cannot be changed.
To unlock, hold down the operating button again for 8 seconds
and the LEDs will stop ashing.
Manual restart
If the pump has been inactive for a long time or is blocked, activate
the manual restart by holding the operating button for 5 seconds.
The LEDs ash sequentially clockwise. The manual restart takes
max. 10 minutes before the pump returns to normal operation.
To cancel the manual restart, hold down the operating button for
5 seconds.
If the pump does not get unblocked, contact a qualied technician.
Factory settings
To return to the factory settings, press and hold the operating button for at least
4 seconds (all LEDs ash for 1 second) and turn off the pump by unplugging. When
switched on again, the pump will run at the factory settings.
sec3
min
10
sec5
min
10
sec8

7 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
PUMP CONTROL
Constant speed operating mode and pump performance curve III are preset as
factory settings for the PARA SC pump. After switching on, the pump runs at the
factory setting or at the last setting. The settings can
be changed using the operating button, see below.
Briey press the control button to:
select the pump operating mode: constant speed, Δp-v
or Δp-c and the pump performance curve (I,II,III).
Press and hold the operating button for the specied time to activate:
- Pump venting function - hold the control button for 3 seconds.
- Manual restart - hold the operating button for 5 seconds.
- Locking/unlocking the operating button - hold the button for 8 seconds.
- Factory setting - hold the control button for at least 4 seconds and switch off the
pump by disconnecting it from the mains.
SETTING THE PUMP SPEED CONTROL MANNER
Briey press the operating button for 1 second to select the pump speed control manner
and pump performance curve. LEDs show pump settings (operating mode Δp-v / Δp-c
/ n=const and the respective performance curve).
OPERATING KNOB
LED indicators Operating mode Performance curve
constant speed
constant speed
Δp-v variable
Δp-v variable
Δp-v variable
Δp-c constant
Δp-c constant
Δp-c constant
constant speed

│8
Regulus CSE2 MIX F W8 1F - www.regulus.eu
PUMP SPEED CONTROL
The following speed control can be selected:
Variable differential pressure ∆p-v
Constant differential pressure ∆p-c
Constant speed n=const.
Variable differential pressure (∆p-v)
This prole is suitable for use with two-
line radiator heating systems to reduce
the noise caused by the ow of liquid
through thermostatic valves. If the ow
in the pipe network decreases, the
pump reduces the head in half. This
saves electrical energy by adapting
the head to the pumping capacity
requirement and lower ow velocities.
Constant differential pressure (∆p-c)
This prole is suitable for use in
underoor heating or for piping of
bigger diameters. It is also suitable
for all applications without variable
characteristics (e.g. pumps for HW
storage tank heating) and for single-
line heating systems with radiators.
The pump maintains a constant set
delivery head regardless of pumping
capacity.
(variable)
(constant)

9 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
Constant speed (n=const.)
This prole is suitable for use in
constant resistance systems that
require constant pumping capacity. The
pump runs uncontrolled in three preset
constant speed stages.
constant speed I, II, III

│10
Regulus CSE2 MIX F W8 1F - www.regulus.eu
ACTUATOR ELECTRICAL WIRING
1 – (blue)
2 – (black)
3 – (brown)
The actuator is factory set to motorized control and ready for operation.
Should it be inevitable to remove it or replace, please follow the instructions
in the appendix.
230 V, 50 Hz
3.2. MIXING VALVE W. ACTUATOR
The LK 840 mixing valve is equipped with a 3-point control actuator. The current valve member
position is obvious from the position of the line in the sightglass of the control knob. The slide
switch on the actuator housing can be used to switch between motorized and manual control.
When the manual control is set, the actuator is controlled by turning the knob.
3.3. CHECK VALVE
The check valve downstream of the filter prevents natural circulation in the heating circuit.
3.4. FILTER WITH MAGNET
The filter located in the return line of the pump station is designed to collect particles from
heating water. It consists of a brass housing, removable stainless-steel strainer collecting
coarse dirt, and a brass lid with a magnet that attracts magnetic particles.
The filter needs to be checked regularly, and cleaned when needed. Turn off the circulation
pump, close the ball valve upstream of the filter. Water inlet downstream of the magnet is
closed by the check valve. Unscrew the filter lid, remove the stainless steel strainer and flush
thoroughly. Wipe the impurities on the magnet and re-assemble the filter by inserting the
strainer, screwing in and tightening the lid.
3.5. BALL VALVES
Ball valves are intended to isolate the pump station from the heating circuit. Then it is not
necessary to drain the heating circuit for servicing (incl. cleaning the filter). In order to have
a more solid hydraulic section of the pump station, they are fixed to the rear mounting plate.
The ball valves are controlled by a lever that is placed inside the pump station insulation. The
valve is closed or opened by turning the lever by 90°. The state of the valve is indicated by
the groove on the control hexagon of the valve. The ball valve can be accesses only after the
front section of the insulation is removed. As a result, unintentional closure of the system by
an unauthorized person is not possible.
control mode switch line in sightglass
motorized control
manual control
control knob

11 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
OPEN CLOSED
groove in the flow direction groove perpendicular to the flow direction

│12
Regulus CSE2 MIX F W8 1F - www.regulus.eu
4. PUMP STATION CONNECTION EXAMPLES
KEY 1 Regulus heat pump (RTC, CTC) 2 heating system expansion vessel 3 Regulus HSK 350 K P-B thermal store 4 HV 60/125-2 manifold/collector 5 pump station for heating circuit 2 – CSE2 MIX 6 pump station for heating circuit 1 – CSE2 7 pump station for DHW recirculation – CSE TVMIX ZV 8 safety kit for HW storage tank 9 DHW expansion vessel 10 RegulusBOX indoor unit SV cold water TV hot water CV hot water recirculation ÚT central heating (heating system) KK ball valve ZV check valve AOV automatic air vent valve PTR pressure temperature relief valve REDV pressure reducing valve (optional) VK drain valve SVE expansion vessel service valve PV-ÚT safety valve for heating system MFB Magnet Filterball
BRAIDED HOSE
COMPENSATOR

13 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
KEY 1 HV 60/125-2 manifold/collector 2 hydraulic pressure balancer 3 heating system expansion vessel 4 hot water storage tank (e.g. NBC 170 HP) 5 DHW expansion vessel 6 safety kit for HW storage tank 7 pump station for DHW recirculation – CSE TV ZV 8 boiler (natural gas, electric…) 9 pump station for heating circuit 2 – CSE2 MIX 10 pump station for heating circuit 1 – CSE2 SV cold water TV hot water CV hot water recirculation ÚT central heating (heating system) KK ball valve ZV check valve AOV automatic air vent valve PTR pressure temperature relief valve REDV pressure reducing valve (optional) VK drain valve SVE expansion vessel service valve PV-ÚT safety valve for heating system MFB Magnet Filterball

│14
Regulus CSE2 MIX F W8 1F - www.regulus.eu
5. PUMP STATION INSTALLATION
The pump station is designed to be mounted on a wall or a manifold with 125 mm connection
pitch. In the rear section of the insulation there are two mounting holes for fixing the metal
plate to the wall. Mounting holes pitch is 80 mm.
The package includes a mounting kit that is used to fix the pump station to the
intended place. The mounting kit includes:
Screw 5x50, round head 2 pcs
6.4 stainless steel washer, DIN 9021/A2 2 pcs
Wall plug 8mm TX 2 pcs
340 360
125
245
Permissible and prohibited positions of the pump station
Permissible positions Conditionally permissible positions Prohibited positions
(may be used when a filter is replaced by
the filter replacement section, code 19017)
Installation dimensions are shown in the figure
below.




+
+

15 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
6. TEMPERATURE SENSOR INSTALLATION
The ball valve housings are equipped with a sheath for the temperature sensor, where the
sensor can be inserted and secured by a xing screw against being pulled out. In the top
and bottom section of the insulation there are passages to run the cables through, then it is
necessary to cut the appropriate part of the passage lock from the front part of the insulation
with a knife, so that the exiting cables are rmly wrapped around by the lock.
1.
Temperature sensor placement
2.
Securing the temperature sensor with
the screw
3.
Running the sensor cable through the
recess in the insulation

│16
Regulus CSE2 MIX F W8 1F - www.regulus.eu
4.
Trimming the cable passage lock
5.
Installed sensors

17 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
7. OPTIONAL ACCESSORIES
The following optional accessories are available for the pump station:
A – Filter replacement section for CSE2
Code 19017
Loosen the union nut above and under
the lter.. Remove the lter and mount the lter replacement section (code 19017) in its
place.

│18
Regulus CSE2 MIX F W8 1F - www.regulus.eu
B – Ball Valve w. drain valve, 1“ Fu/F
Code 17415
and Union 1“ Fu/M incl. gasket
Code 15695
Remove both the connecting ttings. Install the union 15695 in their place, then
attach the ball valve w. drain valve (17415)
to the union.

19 │
Regulus CSE2 MIX F W8 1F - www.regulus.eu
C – Union, 1“ Fu/M, extended, with check valve, incl. gasket
(for return line of CSE2 pump stations)
Code 18653
and Union, 1“ Fu/M, extended, incl. gasket
(for flow line of CSE2 pump stations)
Code 18797
Remove both the connecting ttings. Install the extended union with check valve
(18653) to the return line.
Install the extended union (18797) to
the ow line.

│20
Regulus CSE2 MIX F W8 1F - www.regulus.eu
D – Union to connect CSE2 to 5/4” manifold - 1“x5/4“ Fu/F
Code 17920
Remove both the connecting ttings. Replace them with the union 17920
intended for connection to a manifold.
