1. INTRODUCTION
CSE2 MIX-BP F W 1F twin-line pump station is designed for mixed heating circuits.
It provides ow through the heating system, mixes to the outlet temperature. Since
the mixing valve is not tted with an actuator, any actuator may be used that will meet
the needs of the particular system and control. The pump station includes a lter with
magnet, so it is also suitable for older steel pipe systems. It can be easily mounted on
a wall or on a manifold for multiple heating circuits.
2. PUMP STATION DESCRIPTION AND DATA
Main Features
Description The pump station consists of:
● Wilo Para 25/8 SC pump
● 2 ball valves w. sensor sheath
● check valve
● lter with strainer&magnet
● LK 840 actuated mixing valve
● thermometers, insulation
Working uid water, antifreeze heat-transfer uid for heating systems
Installation vertically on a wall or manifold (125 mm pitch)
Connections 4 x G 1“ F
Code 17917
* A set of manifold connecting ttings can be purchased as optional accessories (see chapter 6)
Data for CSE2 MIX-BP F W 1F Pump Station
Fluid working temperature 5 - 90 °C
Max. working pressure 10 bar
Min. working pressure 0.5 bar
Ambient temperature 5 - 40 °C
Max. relative humidity 80 %, non condensing
Pump power supply 1 ~ 230 V, 50 - 60 Hz
Insulation material EPP RG 60 g/l
Overall dimensions 360 x 133 x 245 mm
Total weight 6.3 kg

│4
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
3. PUMP STATION COMPONENTS
1 – Thermometer at the heating circuit outlet
2 – Thermometer at the heating circuit inlet
3 – Wilo Para 25/8 SC circulation pump
4 – Check valve
5 – Dirt lter with magnet
6 – Lever for ball valves
7 – Ball valve w. sheath for temperature sensor (heating circuit outlet)
8 – Ball valve w. sheath for temperature sensor (heating circuit inlet)
9 – LK 840 mixing valve

5 │
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
3.1. Wilo Para 25/8 SC Pump Data
Wilo Para 25/8 SC circulation pump is a wet-running circulation pump permitting to
set speed control to Δp-v, Δp-c or n=constant. The operating status and possible faults
of the pump are displayed by means of LEDs directly on the pump display. It is used
exclusively for the circulation of liquids in hot water heating systems. Operating the
pump in other systems or in systems lacking water, containing air bubbles or not
pressurized can lead to its rapid destruction.
Wilo Para 25/8 SC Pump Data
Power supply 1 ~ 230 V, 50 - 60 Hz, from external controller
Power input (min./max) 2 / 75 W
Current (min./max) 0.03 – 0.66 A
Max. speed 4800 rpm
Speed control frequency converter
Energy Efciency Index (EEI) ≤ 0.21 by EN 16297/3
IP rating IPX4D
Motor protection integrated
Pump Connection
1. POWER SUPPLY (1 ~ 230V, 50 Hz)
brown (L)
blue (N)
yellow-green (PE)

│6
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
TROUBLESHOOTING, RESTART, FACTORY SETTINGS
If air is present in the pump:
Activate the pump venting function by pressing and holding the
operating button for 3 sec. The upper and lower rows of LEDs will
ash in 1sec interval, see Fig.
Pump venting takes 10 minutes, after that the pump returns to
current mode. In order to cancel pump venting, press and hold the
operating button for 3 sec.
Operating button locking/unlocking
To lock the operating button, press it for 8 seconds.
The selected setting then starts ashing and cannot be changed.
To unlock, hold down the operating button again for 8 seconds
and the LEDs will stop ashing.
Manual restart
If the pump has been inactive for a long time or is blocked,
activate the manual restart by holding the operating button for
5 seconds. The LEDs ash sequentially clockwise. The manual
restart takes max. 10 minutes before the pump returns to normal
operation. To cancel the manual restart, hold down the operating
button for 5 seconds.
If the pump does not get unblocked, contact a qualied technician.
Factory settings
To return to the factory settings, press and hold the operating button for at least 4
seconds (all LEDs ash for 1 second) and turn off the pump by unplugging. When
switched on again, the pump will run at the factory settings.
sec
3
min
10
sec
5
min10
sec
8

7 │
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
PUMP CONTROL
Constant speed operating mode and pump performance curve III are preset as
factory settings for the PARA SC pump. After switching on, the pump runs at the
factory setting or at the last setting. The settings can be changed using the operating
button, see below.
Briey press the control button to:
select the pump operating mode: constant speed, Δp-v or Δp-c
and if needed, also the pump performance curve (I,II,III).
Press and hold the operating button for the specied time to activate:
- Pump venting function - hold the control button for 3 seconds.
- Manual restart - hold the operating button for 5 seconds.
- Locking/unlocking the operating button - hold the button for 8 seconds.
- Factory setting - hold the control button for at least 4 seconds and switch off the
pump by disconnecting it from the mains.
SETTING THE PUMP SPEED CONTROL MANNER
Briey press the operating button for 1 second to select the pump speed control manner
and pump performance curve. LEDs show pump settings (operating mode Δp-v / Δp-c
/ n=const and the respective performance curve).
LED indicators Operating mode Performance curve
constant speed
constant speed
Δp-v variable
Δp-v variable
Δp-v variable
Δp-c constant
Δp-c constant
Δp-c constant
constant speed
OPERATING BUTTON

│8
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
PUMP SPEED CONTROL
The following speed control can be selected:
Variable differential pressure ∆p-v
Constant differential pressure ∆p-c
Constant speed n=const.
Variable differential pressure (∆p-v)
This prole is suitable for use with two-
line radiator heating systems to reduce the
noise caused by the ow of liquid through
thermostatic valves. If the ow in the pipe
network decreases, the pump reduces the
head in half. This saves electrical energy by
adapting the head to the pumping capacity
requirement and lower ow velocities.
Constant differential pressure (∆p-c)
This prole is suitable for use in underoor
heating or for piping of bigger diameters. It
is also suitable for all applications without
variable characteristics (e.g. pumps for
HW storage tank heating) and for single-
line heating systems with radiators. The
pump maintains a constant set delivery
head regardless of pumping capacity.
III
II
I
0
2
4
6
8
0
20
40
60 III
I
II
max.
Δp-c
max.
H [m]
P [W]
1
0 1 2 3 4
0 1 2 3 4
Q [m³/ h]
Q [m³/ h]
Δp-c (konstantní)
(constant)
0
1
2
3
4
5
6
7
0
20
40
60 III
I
II
III
I
II
H [m]
max.
Δp-v
max.
Q [m³/ h]
0 1 2 3 4
P [W]
1
Q [m³/ h]
0 1 2 3 4
Δp-v (variabilní)
(variable)

9 │
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
Constant speed (n=const.)
This prole is suitable for use in
constant resistance systems that
require constant pumping capacity. The
pump runs uncontrolled in three preset
constant speed stages.
0 1 2 3 4
max.
0
2
4
6
8
0
40
60
I
III
II
I
III
II
max.
Q [m³/ h]
Q [m³/ h]
H [m]
P [W]
1
0 1 2 3 4
konstantní otáčky I, II, III
20
constant speed
3.2. LK 840 MIXING VALVE
Technical Data
Max. working temperature 5 - 110 °C (120°C in short term)
Max. working pressure 10 bar
Ambient working temperature 5 - 60 °C
Valve Kvs6.3 m3/h
Max. pressure difference 5 mH2O
Leak rate < 1 % Kvsat 5 mH2O pressure difference
Connections 3 x G 1“ M
Materials
Valve housing, spindle and member brass
Gasket EPDM
Mixing Valve Pressure Drop Diagram

│10
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
3.3. CHECK VALVE
The check valve downstream of the lter prevents natural circulation in the heating circuit.
Check Valve Pressure Drop Diagram
3.4. FILTER WITH MAGNET
The lter located on the return line of the pump station is designed to collect solid particles
from the working uid. It consists of a brass housing, a removable metal strainer collecting
coarse impurities and a brass cap with magnet that collects magnetic impurities.
The lter should be checked regularly and cleaned if necessary. The lter shall be cleaned
with the circulation pump switched off and the section where the lter is installed shut off. In
the section upstream of the lter, shutting off is done by a ball valve, in the section downstream
of the lter the piping is shut off by a check valve. The lter cap needs to be unscrewed, the
metal strainer removed and rinsed thoroughly from any dirt. Dirt trapped on the magnet must
be wiped off and then reassembled by inserting the strainer, screwing in and tightening the
cap.
Filter w. Magnet Pressure Drop Diagram

11 │
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
3.5. BALL VALVES
Technical Data
Kv value 20.2 m3/h
Ball valves are intended to isolate the pump station from the heating circuit. Then it is not
necessary to drain the heating circuit for servicing (incl. cleaning the lter). In order to have
a more solid hydraulic section of the pump station, they are xed to the rear mounting plate.
The ball valves are controlled by a lever that is not present on the valve during operation.
The valve is closed by turning the lever clockwise by 90°. The open / closed position on the
ball valve is indicated by a groove on the control wheel. The groove is perpendicular to the
direction of ow when the ball valve is closed. The ball valve opens by turning the lever anti-
clockwise by 90°, the groove is then in the ow direction. Before closing / opening the ball
valve, the top section of the insulation shall be removed rst. As a result, unintentional closure
of the system by an unauthorized person is not possible.
OPEN CLOSED
groove in the ow direction groove perpendicular to the ow direction

│12
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
4. PUMP STATION INSTALLATION
The pump station is designed to be mounted on a wall or a manifold with 125 mm connection
pitch. In the rear section of the insulation there are two mounting holes for xing the metal
plate to the wall. Mounting holes pitch is 175 mm.
Installation dimensions are shown in the gure below.
The package includes a mounting kit that is used to x the pump station to the
intended place.
The mounting kit includes: Screw 5x50, round head 2 pcs
6.4 stainless steel washer, DIN 9021/A2 2 pcs
Wall plug 8mm TX 2 pcs

13 │
Regulus CSE2 MIX-BP F W 1F - www.regulus.eu
5. TEMPERATURE SENSOR INSTALLATION
The ball valve housings are equipped with a sheath for the temperature sensor, where the
sensor can be inserted and secured by a xing screw against being pulled out. In the top
and bottom section of the insulation there are passages to run the cables through, then it is
necessary to cut the appropriate part of the passage lock from the front part of the insulation
with a knife, so that the exiting cables are rmly wrapped around by the lock.
1.
Temperature sensor placement
2.
Securing the temperature sensor with
the screw
3.
Running the sensor cable through the
recess in the insulation

4.
Trimming the cable passage lock
5.
Installed sensors
6. OPTIONAL ACCESSORIES
The following optional accessories are available for the pump station:
– set of two ball valves with drain
valve G 1“ Fu x G 1“ F x G 1/2“ M
with manifold connection ttings
Code 17928
– G 1“ Fu x G 5/4“ F manifold
connection ttings
Code 17920
Code 17928
©2020 We reserve the right to errors, changes and improvements without prior notice.
REGULUS spol. sr.o.
E-mail: [e-mail]
Web: www.regulus.eu
v1.1-11/2020
