Preface
Thank you for purchasing this user system interface cable (HS2214ECB61H) for the Renesas’s
original microcomputer H8S/2214series.
The HS2214ECB61H is a user system interface cable that connects an H8S/2214 series E6000
emulator (HS2214EPI61H; hereinafter referred to as the emulator) to the IC socket for a TBP-112
package for the H8S/2214 series MCU on the user system.

ii
Contents
Section 1 Configuration....................................................................................1
Section 2 Connection Procedures......................................................................3
2.1 Connecting User System Interface Cable to Emulator Station .........................................3
2.2 Connecting User System Interface Cable to User System................................................5
2.2.1 Soldering the IC Socket.......................................................................................5
2.2.2 Inserting Cable Head ...........................................................................................8
2.2.3 Fastening Cable Head..........................................................................................9
2.2.4 Fastening Cable Body..........................................................................................11
2.3 Recommended Dimensions for User System Mount Pad.................................................12
2.4 Dimensions for User System Interface Cable Head..........................................................13
2.5 Resulting Dimensions after Connecting User System Interface Cable.............................14
Section 3 Installing the MCU to the User System.............................................15
Section 4 Verifying Operation...........................................................................17
Section 5 Notice ................................................................................................18

Section 1 Configuration
CAUTION
Use an CSPACK112A1110H01 socket (socket
(manufactured by Tokyo Eletech Corporation) for the
TBP-112 package IC socket on the user system.
Figure 1 shows the configuration of the HS2214ECB61H user system interface cable for the
TBP-112 package.
User system
IC socket
To emulator station
Cable body
Cable head
Screws (M1.6 x 8 mm)
Cover
(for fastening cable head)
Spacer
Figure 1 HS2214ECB61H User System Interface Cable
1

2
Table 1 lists the HS2214ECB61H components. Please make sure you have all of these components
when unpacking.
Table 1 HS2214ECB61H Components
No. Component Quantity Remarks
1 Cable body 1 Includes flat cable
2 Cable head 1
3 IC socket 1 For the TBP-112 package
4 Spacer 1 For installing an TBP-112 packaged MCU
5 Cover 1 For installing an TBP-112 packaged MCU
6 Screws (M1.6 x 8 mm) 4 For fastening cable head and for installing an
TBP-112 packaged MCU
7 Driver 1 Dedicated screwdriver to fasten the screws.
8 Documentation 1 User’s manual for HS2214ECB61H (this manual)

Section 2 Connection Procedures
2.1 Connecting User System Interface Cable to Emulator Station
WARNING
Observe the precautions listed below. Failure to do so
will result in a FIRE HAZARD and will damage the user
system and the emulator product or will result in
PERSONAL INJURY. The USER PROGRAM will be
LOST.
1. Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE CABLE
is connected to or removed from any part. Before
connecting, make sure that pin 1 on both sides are
correctly aligned.
2. The user system interface cable dedicated to the
emulator must be used.
To connect the cable body to the emulator station, follow the instructions below.
1. Make sure the user system and emulator station are turned off.
CAUTION
When connecting or removing the user system interface
cable, apply force only in the direction suitable for
connection or removal, while making sure not to bend or
twist the cable or connectors. Otherwise, the connectors
will be damaged.
2. After making sure the direction of the cable body connector is correct, firmly insert the cable
body connector into the emulator station socket (figure 2).
3

Figure 2 Connecting User System Interface Cable to Emulator Station
4

2.2 Connecting User System Interface Cable to User System
WARNING
Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE CABLE
is connected to or removed from any part. Before
connecting, make sure that pin 1 on both sides are correctly
aligned. Failure to do so will result in a FIRE HAZARD and
will damage the user system and the emulator product or
will result in PERSONAL INJURY. The USER PROGRAM will
be LOST.
To connect the cable head to the user system, follow the instructions below.
2.2.1 Soldering the IC Socket
Install the socket for TBP-112-packaged ICs on the user system.
(1) Gently apply solder to the BGA pads of the user system. Be careful to keep the thickness of
the solder within 100 to 150 µm. Too much solder will cause short-circuiting of the pins.
(2) The IC socket is vacuum-packed to avoid oxidization of the surfaces of the solder balls. It is
thus recommended that the IC socket be installed on the user system if you don’s install the
socket immediately after the package it comes in is opened. After the package’s seal has been
broken, store the socket in a desiccator. Do not touch the solder balls. If they are touched,
solder may not adhere to the solder surface.
The IC socket is covered by a protective cover. Socket and cover are fastened together by
four screws before the whole is vacuum packed to prevent bending of the IC socket’s pins.
To avoid the scattering (dispersal) of flux from other components to the IC socket, keep the
protective cover on the IC socket until solder reflow has been completed.
(3) Install the provided guide pins into the holes for the guide pins on the user system. Check
that the pads are correctly aligned with the IC socket.
5

6
(4) Notes on soldering the IC socket
a) The IC socket is larger than the actual IC package; therefore, refer to figure 7 for the
installation of other components.
b) Do not install components that occupy large volume close to the IC socket. Such
components will prevent the convective flow of heat during reflow.
c) Since the IC socket has a greater volume than the IC package, it is recommended that the
temperature profile under the conditions used in installation be measured by attaching a
temperature sensor to the back side of the IC socket.
d) Under the reflow conditions for soldering the IC socket, specify the actual heating to
more than 210°C for 30 to 60 seconds.
Recommended Reflow Conditions
Surface temperature of IC-socket connector
Preheating: 150 to 180°C for 180 seconds
Actual heating: To more than 210°C, for 30 to 60
seconds

7
CAUTION
1. Never dip the IC socket in flux or use wash to clean the IC
socket. This is because flux may remain inside the IC
socket due to the IC socket’s structure. When using the
IC socket with other DIP products, never clean the other
DIP products with flux because the flux may enter the
connector through the guide pins of the IC socket.
2. When an IC socket with guide pins is soldered to the
user system, about 1.4 mm of the guide pins will stick out
(when the user-system board is 1.6 mm thick). When a
load is applied to the guide pins from the back of the
user-system board, stress will be applied to the soldered
part of the IC socket, and this may destroy the
connectors. Do not apply any load to the guide pins after
the IC socket has been soldered on the user system.
3. When an IC socket with no guide pins is soldered to the
user system, the soldered part will crack if stress is
applied to the IC socket. Therefore, always apply
adhesive to the connector and the user system so that
there is a firm connection between them.
4. When the IC socket has guide pins, it is recommended
that epoxy resin adhesive or solder be applied to the
guide pins at the back of the user system to make sure
that no stress is applied to the soldered part

2.2.2 Inserting Cable Head
CAUTION
Check the location of pin 1 before inserting.
Align pin 1 on the IC socket for an TBP-112 package on the user system with pin 1 on the user
system interface cable head, and insert the user systeminterface cable head into the IC socket on the
user system, as shown in figure 3.
Figure 3 Connecting User System Interface Cable to User System
8

2.2.3 Fastening Cable Head
CAUTION
1. Use the screwdriver whose head matches the screw
head.
2. The tightening torque must be 0.054 N•m or less.
If the applied torque cannot be accurately measured,
stop tightening when the force required to turn the screw
becomes significantly greater than that needed when first
tightening. If a screw is tightened too much, the screw
head may break or an IC socket contact error may be
caused by a crack in the IC socket solder.
3. If the emulator does not operate correctly, cracks might
have occurred in the solder.
The user system interface cable (HS2214ECB61H) head and the IC socket for the TBP-112 package
on the user system have no pin dedicated for alignment. Use the follow procedure to fasten the
cable head.
1. Insert two screws (M1.6 x 8 mm) to ①and ③, and screw it a little so that holes at ②-②' and ④-④'
match, respectively.
21
34
2
1
34
’’
’’
Figure 4 Fastening Cable Head Procedure (1)
9

2. Next, fasten screws to ②and ④a little, so that four screw holes are aligned. Then, each screw
should be tightened a little at a time, alternating between screws on opposing corners.
2
4
Figure 5 Fastening Cable Head Procedure (2)
10

2.2.4 Fastening Cable Body
Connect the cable body to the cable head.
Figure 6 Fastening Cable Body
11

2.3 Recommended Dimensions for User System Mount Pad
Figure 7 shows the recommended dimensions for the mount pad (footprint) for the user system with
an IC socket for an TBP-112 package (CSPACK112A1110H01: socket (manufactured by Tokyo
Eletech Corporation). Note that the dimensions in figure 7 are somewhat different from those of the
actual chip's mount pad.
Figure 7 Recommended Dimensions for Mount Pad
12

2.4 Dimensions for User System Interface Cable Head
The dimensions for the user system interface cable head are shown in figure 8.
Figure 8 Dimensions for User System Interface Cable Head
13

2.5 Resulting Dimensions after Connecting User System Interface Cable
The resulting dimensions, after connecting the user system interface cable head to the user system,
are shown in figure 9.
Figure 9 Resulting Dimensions after Connecting User System Interface Cable
14

15
Section 3 Installing the MCU to the User System
CAUTION
1. Check the location of pin 1 before inserting.
2. Use a provided screwdriver.
3. The tightening torque must be 0.054 N•m or less.
If the applied torque cannot be accurately measured,
stop tightening when the force required to turn the screw
becomes significantly greater than that needed when first
tightening. If a screw is tightened too much, the screw
head may break or an IC socket contact error may be
caused by a crack in the IC socket solder.
4. If the MCU does not operate correctly, cracks might have
occurred in the solder.
1. Attach the spacer and cover to the IC socket.
2. Place the spacer on the IC socket. Place the two guide pins of the spacer in the corresponding
holes on the IC socket.
3. Place the MCU gently in the opening of the spacer. Be sure to correctly align pin 1 of the
MCU with the IC socket. The solder balls of the MCU will then be in the correct locations
relative to the connection pins of the IC socket.
4. Put the cover on the spacer. The four holes at the four corners of the spacer and of the cover
must be aligned. Use the four screws to fasten the cover to the IC socket. Each screw in turn
should be made a little tighter, alternating between screws on opposing corners. Use the
screwdriver provided with the package. The torque in tightening must be 0.054 N•m or less.
5. When removing the cover from the IC socket, hold the side of the cover so that no stress is
applied to the soldered connections between the IC socket and user system while the screws
on the cover are being unscrewed. Use tweezers to remove the MCU from the opening in the
spacer,

Figure 10 Installing MCU to User System
16
