Renesas Stream it User manual

J-Link Debugger
Quick Start Stream it! - RZ solution kit
based on RZ/A1-LU
Reset
Switch
User LED User
Switch
Potentiometer
USB0
Host
Power
LED
SD
Card
Ethernet
Port
Pmod
Header
Display
Connector
USB Power &
Serial
Console
Camera
Module (fitted)
1. Installation
Do not connect the J-Link LITE debugger module until the software support has been installed.
1. Insert the DVD into your computer. If you do not have a DVD drive, you can obtain the installation package fromthe
Renesas website.
2. The DVD should auto-run, but if thisis disabled, navigate to the root of the DVD andopen the file “setup.hta”.
Note: This file is an html page knownas the Web interface that allows launching of batch files. Youcan open the file
in a text editor to review the scripts.
3. This page containssetup instructionsand linksto required tools;please install thetools if you do not alreadyhave
them installed.
Note:
Windows™10 / 8.1 / 8 / 7 users may see “User Account Control”dialog box.If applicable, enter the administrator
password and click ‘Yes’.
The Windows™driver signing dialog box may be displayed. Please accept the driver to continue.
2. Connections
4. To connect the camera:
a. Lift up the dark brown flap on connector CN12 evenly.
b. Slide the flex cable into the connector(make sure to insert it in the correct direction; see photo above).
c. Push the flap down again to secure the camera module.
d. Remove the plasticcover from the camera lens.
5. Connect the J-Link LITE to the Stream it! board’s JTAG connector and then to your PC.
6. Connect the Ethernet cable from the Stream it! board’s RJ45 connector to your network.

7. Connecta USB cable from PCto the miniB connector on the underside of theboard. Theboard will power up.
8. In Control Panel,open the “Devices and Printers” page to identify the COM port numberassigned to the board.
9. Open a serial terminal program to connect to the board’s console output. Recent versions of Windows™ do not
includea serial terminal program. Renesas cannot provide any recommendations;however, we have tested PuTTY,
TeraTerm with this product. Other terminal programs are available.
3. Running the Demonstrations
10. The demonstrationsassume that yournetwork is configured for DHCP and an internet connection is configured.
a. If your network cannot support this configuration, please seethe support section below for fixed IP
configuration.
11. On the Web Interface, (see 2) select the “Demos” tab.
12. Select one of the Demonstrations presented.
13. Followthe instructions on the page. Detailed instructions for each application are included in an associated
Application Note.
4. Next Steps
14. When you have experienced the demonstrations, to go furtherby reviewing the code and making any changes,
please return to the “Setup” tab.
15. Press the Install e2studio button, and the installation of the tools and demonstration source code will begin.
16. Please refer to “description.txt”in each sample project for sample code specification and operating procedure.
17. The Hardware Manual supplied with this Stream it! kit is current at the time of publication. Please check for any
updatesto the manual fromthe Renesas website.
18. To learn more on how to use e2 studio, open the program’s help filesby using Help > Help Contents.

5. Support
19. The following stepsare only requiredif you areunable to connect toa DHCP internet connection.
20. To specify a fixed IP in thedemonstrations, seethe application note for the specific demonstration.
21. To use the demonstrations locally and test the Stream it! kit, you will need to allocate a fixed IP for your PC.
22. Please follow the procedure below.
23. Disconnect your PC from the network.
24. Open your PC network properties control.
25. Select TCP/IPv4 properties.
26. Make a note of the current fixed IP settings.
If you change them, you will need to return
them to the original settings when you have
finished.
27. This example uses 192.168.0.1 as the PC
address; youshould select an appropriate
address in your network.
Online technical support and information is available at:https://www.renesas.com/
Technical Contact Details
America: [e-mail]
Europe: https://www.renesas.com/en-eu/support/contact.html
Global & Japan: https://www.renesas.com/support/contact.html
© 2017 Renesas Electronics Europe Limited. All rights reserved
© 2017 Renesas Electronics Corporation. All rights reserved.
© 2017 Renesas System Design Co., Ltd. All rights reserved.
Website: https://www.renesas.com/
R12QS0013EG0100
