Renesas Pmod RYZ012A1 User manual

Quick Start Guide
R21QS0002EG0101 Rev.1.01 Page 1 of 4
May.25.22
Renesas Bluetooth Low Energy Modules
RYZ012A1 Pmod™ Expansion Board
1. Product Overview
This Pmod™ expansion board provides a quick and easy way to interface with the RYZ012A1 module.
More information about this module can be found on the Renesas website:
https://www.renesas.com/eu/en/products/interface-connectivity/wireless-communications/bluetooth-low-
energy-modules/ryz012x1-bluetooth-le-module
2. Pmod™ Interface
2.1 Overview
The RYZ012A1 Bluetooth Low Energy Pmod™ Expansion Board provides an interface using a 12-pin
Digilent Pmod™ compatible connector (CN1).
This provides access to:
•A high-speed UART interface (MSTR_CTS)
•An SPI interface (MSTR_SS)
•A mode reset pin (NRST)
•VDD and GND connections for module power
Pmod™ is registered to Digilent Inc. and its specification can be found at the link below:
https://digilent.com/reference/pmod/start
2.2 Pin Diagram
Figure 1. Pin Diagram
2.3 Pin Descriptions and Directions
Table 1. Pin Descriptions and Directions
Pin Number
Pin Name
Description
Direction
1
MSTR_CTS/SS
SPI SS / UART CTS
UART CTS output, or SPI SS output
2
MSTR_TX
SPI DI / UART RX
TX Input to Pmod
3
MSTR_RX
SPI DO / UART TX
RX Output from Pmod
4
MSTR_CK
SPI CK / UART RTS
CLK input to Pmod
5
GND
GND
NA

Renesas Bluetooth Low Energy Modules RYZ012A1 Pmod™ Expansion Board – Quick Start Guide
R21QS0002EG0101 Rev.1.01 Page 2 of 4
May.25.22
Pin Number
Pin Name
Description
Direction
6
VDD
3.3 V
NA
7
GPIO_IRQ
INTERRUPT
Input
8
NRST
RESET
Input
9
GPIO_10
UART / SPI Select
Low = UART
High = SPI
10
GPIO_16
GPIO
Input/Output
11
GND
GND
NA
12
VDD
3.3 V
NA
Note: RTS/CTS are not supported by the RYZ012A1 Pmod™ Expansion Board.
2.4 Connector CN1 Pin Assignment
Figure 2. Connector CN1 Pin Assignment
2.5 Electrical Specification
Table 2. Recommended Operating Conditions
Item
Min.
Typ.
Max.
VDD
+1.8 V
+3.3 V
+3.6 V
Please refer to the module data sheet for full electrical specifications.
2.6 Module Control
The high-speed UART or SPI interface can be used to communicate with the module using the Renesas
SPP Bluetooth LE Commands.
Software resources are available here:
RTKYZ012A1B00000BE - PMOD Expansion Board for RYZ012x1
2.7 CN2 Connector
CN2 is not fitted, this connector is for programming the module and is not used.
3. Support
For further information about this product and to access further resources such as Application Notes and
software from Renesas, please go to: renesas.com/pmod_ryz012a1
4. Note
Third party links in this document may change at any time and are the responsibility of the third party, not
Renesas.
