User Guide
ZMID4200MLIN01201
Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 1
© 2021 Renesas Electronics
Description
The ZMID4200 application modules provide an easy
demonstration of Renesas’ ZMID4200 inductive
sensing solutions for a specific application case. The
typical sensor performance for a defined application
use case can be evaluated via reference
measurements performed with the application
module.
Renesas’ ZMID4200MLIN01201 Linear Application
Module demonstrates inductive linear position
sensing. The Application Module can be
programmed for a specific application range using
Renesas’ ZMID-COMBOARD, which is separately
available.
The Linear Application Module Sensor PCB can be
easily attached to an existing mechanical
configuration for prototyping.
Kit Contents
■Linear Application Module Sensor PCB
■Sensor Target, Target Holder, and Knob
■Module Connection Cable
■Quick Start Guide and Disclaimer
Features
■Easy application prototyping
■Measurement report available
■Programmable output slope and linearization
■Tolerance for mechanical misalignment
■No magnets required; reduced cost
■Module design data, ZMID4200 EVK Application
Software, and user manual available online
depending on the module:
www.renesas.com/ZMID4200stkit
●Linear Module Summary
■Measurement range: 12mm (using a 50% target)
■Output resolution:
●10-bit Analog = 12µm
●10-bit PWM = 12µm
●12-bit SENT = 3µm
ZMID4200MLIN01201 Linear Application Module Sensor PCB
ZMID4200 Sensor
IC
P1 Application Module
Connector for the
ZMID-COMBOARD
(Separately Available)
P2 Application Module
InterfaceHeader
NC, GND, OUT, VDD D1 Power Indicator LED Measurement Range
12mm (50% Target)
30mm
75mm

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 2
© 2021 Renesas Electronics
Important Notes
Disclaimer
Integrated Device Technology, Inc. and its affiliated companies (herein referred to as “Renesas”) shall not be liable
for any damages arising out of defects resulting from
(i) delivered hardware or software
(ii) non-observance of instructions contained in this manual and in any other documentation provided to user,
or
(iii) misuse, abuse, use under abnormal conditions, or alteration by anyone other than IDT.
TO THE EXTENT PERMITTED BY LAW, IDT HEREBY EXPRESSLY DISCLAIMS AND USER EXPRESSLY
WAIVES ANY AND ALL WARRANTIES, WHETHER EXPRESS, IMPLIED, OR STATUTORY, INCLUDING,
WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A
PARTICULAR PURPOSE, STATUTORY WARRANTY OF NON-INFRINGEMENT, AND ANY OTHER WARRANTY
THAT MAY ARISE BY REASON OF USAGE OF TRADE, CUSTOM, OR COURSE OF DEALING.
Restrictions in Use
IDT’s ZMID4200MLIN01201 Linear Application Module, consisting of the Linear Application Module Sensor PCB,
Sensor Target, Target Holder, Knob, and Module Connection Cable, and the ZMID4200 EVK Application Software
are designed for use only in a laboratory for evaluation purposes. The hardware and software must not be used for
characterization measurements in terms of replacing calibrated laboratory environment and measurement devices.
It must not be used with any setup where there is a risk of injury or death.
Important Safety Warning: These procedures can result in high currents, which can cause severe
injury or death and/or equipment damage. Only trained professional staff should connect external
equipment and operate the software.
Important Equipment Warning: Ensure the correct connection of all cables. Supplying the board
using the wrong polarity could result in damage to the board and/or the equipment.
Contents
1. Introduction.................................................................................................................................................... 4
1.1 Module Description................................................................................................................................ 4
1.1.1. Electrical Data......................................................................................................................... 4
1.1.2. Electrical Connections to Interfacing an Application MCU...................................................... 5
1.1.3. Design Documentation............................................................................................................ 5
1.2 Getting Started....................................................................................................................................... 5
1.2.1. Module Hardware Connections............................................................................................... 5
1.2.2. Target Holder Assembly Instructions...................................................................................... 6
1.2.3. Sensor Configuration and Calibration..................................................................................... 7
2. Application Measurement............................................................................................................................. 7
2.1 Output Measurement at 1.0mm Airgap ................................................................................................. 7
3. Linear Application Module Sensor PCB...................................................................................................... 9
!
!

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 3
© 2021 Renesas Electronics
3.1 Schematic.............................................................................................................................................. 9
3.2 Layout.................................................................................................................................................... 9
3.3 Bill of Materials (BOM)......................................................................................................................... 10
4. Mechanical Components ............................................................................................................................ 11
4.1.1. Sensor Target ....................................................................................................................... 11
4.1.2. Target Holder ........................................................................................................................ 11
4.1.3. Target Holder Knob............................................................................................................... 12
5. Ordering Information................................................................................................................................... 12
6. Revision History .......................................................................................................................................... 12
Figures
Figure 1. Application Module Connections...............................................................................................................6
Figure 2. Target Holder Assembly............................................................................................................................7
Figure 3. Accuracy with Linearization at 1mm Airgap (AG100)................................................................................8
Figure 4. Accuracy with Linearization at 1mm Airgap and Effects of Airgap Changes............................................8
Figure 5. Accuracy with Linearization at 1mm Airgap and Effects of Displacement ................................................9
Figure 6. Linear Application Module Sensor PCB Schematic..................................................................................9
Figure 7. Linear Application Module Sensor PCB Layout and Dimensions ...........................................................10
Figure 8. Sensor Target Dimensions......................................................................................................................11
Figure 9. Sensor Target Holder Dimensions..........................................................................................................11
Figure 10. Sensor Target Knob Dimensions ..........................................................................................................12
Tables
Table 1. System Data...............................................................................................................................................4
Table 2. Electrical Data.............................................................................................................................................4
Table 3. Evaluation Kit Connection Descriptions......................................................................................................6
Table 4. Sensor Configuration for the Measurement ...............................................................................................7
Table 5. Linear Application Module Sensor PCB BOM......................................................................................10

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 4
© 2021 Renesas Electronics
1. Introduction
This user manual describes the ZMID4200MLIN01201 Linear Application Module. This application module is
designed to measure a linear movement of a sensor target using the ZMID4200 Inductive Position Sensor IC,
which is connected to an application-specific coil design and located on the Linear Application Module Sensor
PCB.
For a first evaluation of the Application Module, the kit contains a target holder to locate and move the sensor
target over the sensor coils. Using the separately available ZMID-COMBOARD, the Application Module can be
connected to the user’s computer. Using the ZMID4200 EVK Application Software, the module can be
programmed and configured. To download the software and its user manual, visit the
www.renesas.com/ZMID4200 web page.
After the first evaluation of the Application Module performance, the Linear Application Module Sensor PCB and
the sensor target can be mounted on any application for rapid prototyping. The design data of the Application
Module is available (see section 1.1.3). The following sections describe technical details of the Application
Module.
1.1 Module Description
The following tables provide the system, electrical, and mechanical parameters for the Application Module.
Note: For detailed information about the expected accuracy, refer to section 2.
Table 1. System Data
Symbol
Parameter
Conditions
Typical
Unit
TR
Linear Measurement Range1
12
mm
TA_W
Target Width1
12.5
mm
COIL_L
RX Coil Length
25
mm
AG
Recommended Airgap Between Coil and
Target
1
mm
RES_DIG
Internal Digital Resolution
16
Bit
RES_OUT
Output Resolution
ZMID4200 Analog
10
Bits
ZMID4200 PWM
10
Bits
ZMID4200 SENT
12
Bits
T_R
Output Update Rate
10
kHz
T_A
Data Acquisition Time
50
µs
1. The Linear Application Module Sensor PCB can also be used with a smaller width. Using a smaller target will increase the
measurement range.
1.1.1. Electrical Data
For detailed information about the electrical data, refer to the ZMID4200 Datasheet. See the connection
diagrams in section 1.2.
Table 2. Electrical Data
Symbol
Parameter
Conditions
Typical
Unit
VDD
Supply Voltage
4.5 to 5.5
V
I_CC
Typical Current Consumption, No Load
12 to 21.5 (typical: 13)
mA
ZMID4200 Analog Output
R_PUA
Output Pull-Up Resistor
3 to 10 (typical: 4.7)
kΩ

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 5
© 2021 Renesas Electronics
Symbol
Parameter
Conditions
Typical
Unit
R_PDA
Output Pull-Down Resistor
3 to 10 (typical: 4.7)
kΩ
C_ANA
Output Capacitor for Analog
0.47 to 27
nF
ZMID420 PWM Output
R_PUB
V_PU = 5V
1 to10
kΩ
V_PU = 16V
3 to 10
C_PWM
1 to 20
nF
F_PWM
PWM Output Frequency Depending on
Module Configuration
Programming options: 0.125,
0.25, 0.50, 0.75, 1.00, 1.25,
1.50, 2.00 (default)
kHz
Normal Operating Range
Limits are
programmable
5 to 95
% duty
cycle
ZMID420 SENT Output (see the ZMID4200Datasheet regarding circuit options)
R_01
SENT Output pi (π) Filter Resistor
Circuit option A, B, or C
120
Ω
C_11
SENT Output pi (π) Filter First Capacitor
Circuit option A, B, or C
2.2
nF
T_TICK
Clock Tick Time
3.0 to 3.67
µs
C_12
SENT Output pi (π) Filter, Second Capacitor
Circuit option C
2.2
nF
Circuit option A or B
3.9
nF
1.1.2. Electrical Connections to Interfacing an Application MCU
If the Application Module is connected to an application host MCU, additional components might be required.
The connection diagrams and additional components required for the different output interface options are given
in the ZMID4200 Datasheet.
1.1.3. Design Documentation
The design data are available on the Renesas webpage (see page 1) or can be requested via Renesas’ sales
team (see contact information on the last page). The support package contains the design files as well as the
fabrication outputs for the ZMID4200MLIN01201 Linear Application Module including the following:
■3-D Data (.step)
■Fabrication outputs (Gerber)
■PCB design files (Altium)
■Mechanical dimensions (.dxf)
1.2 Getting Started
1.2.1. Module Hardware Connections
Follow these procedures to set up the kit as shown in Figure 1:
1. Connect the Application Module to a ZMID-COMBOARD or to an external application using the sensor cable
using the connectors shown in Figure 1. See Table 3 for the details for the connectors.
2. If using the ZMID-COMBOARD, connect it to the user’s computer using a USB cable or power up the user’s
application controller.

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 6
© 2021 Renesas Electronics
User s Computer
with ZMID4200 EVK
Application Software
Application Module
Connect to
Application MCU
Connect to
ZMID-COMBOARD
Option A: Connect P2 to Application Controller
Or
Option B: Connect P1 to ZMID-COMBOARD
for demonstration and programming
Figure 1. Application Module Connections
Table 3. Evaluation Kit Connection Descriptions
Connector
Type
Description
P1
4-Pin Molex Picoflex
Header to connect the Application Module
to the ZMID-COMBOARD
4 VDD
3 OUT
2 GND
1 Not connected
P2
4-Pin Header
Header to connect the Application Module
to an existing application
4 VDD (4.5 to 5.5 V)
3 OUT
2 GND
1 Not connected
1.2.2. Target Holder Assembly Instructions
The target holder is assembled as shown below.
1. Place target holder on the Linear Application Module Sensor PCB.
2. Insert the sensor target into the target holder.
3. Add the knob to define the start and stop position.

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 7
© 2021 Renesas Electronics
Figure 2. Target Holder Assembly
1.2.3. Sensor Configuration and Calibration
The Application Module is preconfigured for the mechanical configuration when using the target holder. If the
Linear Application Module Sensor PCB is mounted on any existing application with a mechanical configuration
different from the Application Module mechanics, the sensor IC must be configured and programmed for the new
setup. This can be done using the ZMID-COMBOARD and the ZMID4200 EVK Application Software.
2. Application Measurement
The Application Module was measured to assess the typical sensing performance. For positioning the target at
different positions and displacements, a four axis measurement table was used. At each displacement position,
the digital output value was read to obtain the data shown in the following graphs.
2.1 Output Measurement at 1.0mm Airgap
For this measurement, the sensor was calibrated at an airgap of 1.0mm. The sensor gain, offset, and slope were
configured for the measurement range, and the output was linearized.
Table 4. Sensor Configuration for the Measurement
Name
Offset
Slope
Clamping
LinInt0
LinInt1
LinInt2
LinInt3
Register
00HEX
01HEX
02HEX
03HEX
04HEX
05HEX
06HEX
Value
21FE
0835
0000
0500
0306
8081
8584
Name
LinInt4
CoilOffset
CalMode
Trimming
AGC0
AGC1
Mask
Register
07HEX
08HEX
09HEX
0BHEX
0CHEX
0DHEX
0EHEX
Value
0082
0000
010E
B107
083A
0055
BFFF
Name
Trace0
Trace1
Misc
Register
0FHEX
10HEX
11HEX
Value
0000
0000
00C2
(1)
(2)
(3)
Assembled Application Module

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 8
© 2021 Renesas Electronics
Figure 3. Accuracy with Linearization at 1mm Airgap (AG100)
Note: AG050 = 0.5mm airgap; AG100 = 1mm airgap; and AG150 = 1.5mm.
Figure 4. Accuracy with Linearization at 1mm Airgap and Effects of Airgap Changes
-0.5
-0.3
-0.1
0.1
0.3
0.5
0 2 4 6 8 10 12
POS1 Error in %
Displacement mm
POS1Error_%
Pos1
AG10
0_XP0
00_YP
000_
POS1
Full-Scale Error in %
-1
-0.5
0
0.5
1
0 2 4 6 8 10 12
POS1 Error in %
Displacement mm
POS1Error_% Pos1
AG10
0_XP0
00_YP
000_
POS1
Pos1
AG05
0_XP0
00_YP
000_
POS1
Pos1
AG15
0_XP0
00_YP
000_
POS1
Full-Scale Error in %

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 9
© 2021 Renesas Electronics
Figure 5. Accuracy with Linearization at 1mm Airgap and Effects of Displacement
3. Linear Application Module Sensor PCB
3.1 Schematic
The Linear Application Module Sensor PCB schematic is shown below. It contains the ZMID4200 contactless
inductive position sensor as well as the headers, power LED, and required capacitors for the integrated voltage
regulator and the integrated oscillator. Also take into consideration any components required at the receiver side
depending on the selected output variant.
Note: C5* needs to be calculated in base of TX inductance.
Figure 6. Linear Application Module Sensor PCB Schematic
3.2 Layout
The Linear Application Module Sensor PCB layout is shown in Figure 7. For an appropriate coil design, specific
tools to generate the coil pattern were used. These tools are available to Renesas customers if custom coil
designs are needed.
-0.6
-0.4
-0.2
0
0.2
0.4
0 2 4 6 8 10 12
POS1 Error in %
Displacement mm
POS1Error_% Pos1
AG100
_XP000
_YP000
_ POS1
Pos1
AG100
_XP000
_YP025
_ POS1
Pos1
AG100
_XP000
_YP050
_ POS1
Full-Scale Error in %
100nC6 DGND
RS_SIN
RS_COS
TX
100n
C3
100nC2
DGND
DGND
DGND
100n
C1
DGND
10p
C4
DGND
DGND
2.2k
R1
820p
C5
*
VDDE
DGND
Red
D1
1
2
3
4
DEV1
P1
1 2 3 4
NH1X4P2
ZMID4200
Test_D
1
Test_Ena
2
VDDD
3
SOUT
4
VDDA
5
VSSE
6
VDDE
7EN 8
EP 9
VDDT 10
R2N 11
R2P 12
R1N 13
R1P 14
U1
ZMID4200

ZMID4200MLIN01201 / Linear Application Module User Manual
Rev.1.0
Jul 21, 2021
Page 10
© 2021 Renesas Electronics
Note: Dimensions are in mm.
Figure 7. Linear Application Module Sensor PCB Layout and Dimensions
3.3 Bill of Materials (BOM)
Table 5. Linear Application Module Sensor PCB BOM
Designator
Value
Package
Manufacturer P/N
Manufacturer
Quantity
U1
ZMID4200
14-TSSOP
(Refer to the ZMID4200 Datasheet)
Renesas
1
C1, C2, C3, C6
100nF
0805
CL21B104KCFSFNG
Comet
4
C4
10pF
0805
CL21C100DBNC
Comet
1
C5
820pF
0805
CGA4F2COG2A222J085AA
Comet
1
D1
LED Red
0805
OSR50805C1E
Comet
1
P2
Header
NH1X4
HN1X4
Comet
1
P1
Header
Molex Picoflex 4pin
90325-0004
Farnell
1
R5
2kΩ
0805
R0805 2.0K 1%
Comet
1
