APPLICATION NOTE
R01AN2831EJ0100 Rev. 1.00 Page 1 of 51
May 28, 2015
RL78/G13
Clock Generator (Clock Switching) CC-RL
Introduction
This application note explains how to use the clock generator of the RL78/G13.
The clock from the clock generator is switched when a switch is pressed. The clock generator uses the high-speed
on-chip oscillator clock, (32 MHz), X1 oscillation clock (20 MHz), or XT1 oscillation clock (32.768 kHz) as the
CPU/peripheral hardware clock (fCLK).
Target Device
RL78/G13 (40 pins or more)
When applying the sample program covered in this application note to another microcomputer, modify the program
according to the specifications for the target microcomputer and conduct an extensive evaluation of the modified
program.
R01AN2831EJ0100
Rev. 1.00
May 28, 2015

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 2 of 51
May 28, 2015
Contents
1. Specifications......................................................................................................................................4
2. Operation Check Conditions.................................................................................................................6
3. Related Application Note......................................................................................................................6
4. Description of the Hardware.................................................................................................................7
4.1 Hardware Configuration Example .........................................................................................................7
4.2 List of Pins to be Used .........................................................................................................................8
5. Software Description............................................................................................................................9
5.1 Operation Overview.............................................................................................................................9
5.2 File Configuration..............................................................................................................................10
5.3 List of Option Byte Settings................................................................................................................11
5.4 List of Constants................................................................................................................................12
5.5 List of Variables................................................................................................................................13
5.6 List of Functions................................................................................................................................13
5.7 Function Specifications ......................................................................................................................14
5.8 Flowcharts ........................................................................................................................................21
5.8.1 Initialization Function..............................................................................................................................22
5.8.2 System Function......................................................................................................................................23
5.8.3 I/O Port Setup..........................................................................................................................................24
5.8.4 CPU Clock Setup.....................................................................................................................................25
5.8.5 Timer Array Unit 0 (TAU0) Setup..........................................................................................................29
5.8.6 Setting up 12-bit Interval Timer ..............................................................................................................30
5.8.7 Setting up External Interrupt Input..........................................................................................................31
5.8.8 Main Processing ......................................................................................................................................32
5.8.9 Setting to Start INTP0 External Interrupt Processing..............................................................................33
5.8.10 Setting to Start Operation of Channel 0 of TAU0 ...................................................................................34
5.8.11 Switching Clock ......................................................................................................................................35
5.8.12 Switching from HOCO Clock to X1 Oscillation Clock...........................................................................36
5.8.13 Switching from X1 Oscillation Clock to XT1 Oscillation Clock ............................................................37
5.8.14 Switching from XT1 Oscillation Clock to HOCO Clock ........................................................................38
5.8.15 Getting Clock Status................................................................................................................................39
5.8.16 Getting X1 Oscillation Clock Status........................................................................................................40
5.8.17 Getting XT1 Oscillation Clock Status .....................................................................................................41
5.8.18 Getting HOCO Clock Status....................................................................................................................42
5.8.19 Stopping Clock........................................................................................................................................43
5.8.20 Getting Parameters of Channel 0 of TAU0..............................................................................................44
5.8.21 Restarting Channel 0 of TAU0................................................................................................................45
5.8.22 Changing Interval of Channel 0 of TAU0 ...............................................................................................46
5.8.23 Setting to Stop Channel 0 of TAU0.........................................................................................................47
5.8.24 Processing of Interval Timer Interrupt of Channel 0 of TAU0................................................................48
5.8.25 Processing of INTP0 External Interrupt ..................................................................................................49
5.8.26 Waiting in Units of 1 ms..........................................................................................................................50
6. Sample Code.....................................................................................................................................51

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 3 of 51
May 28, 2015
7. Documents for Reference ...................................................................................................................51
Revision Record ........................................................................................................................................52
General Precautions in the Handling of MPU/MCU Products ........................................................................53

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 4 of 51
May 28, 2015
1. Specifications
The sample code covered in this application note switches its operating clock when the switch on the target board is
pressed according to the sequence below.
(1) High-speed on-chip oscillator clock (32 MHz) X1 oscillation clock (20 MHz)
(2) X1 oscillation clock (20 MHz) XT1 oscillation clock (32.768 kHz)
(3) XT1 oscillation clock (32.768 kHz) High-speed on-chip oscillator clock (32 MHz)
Subsequently, steps (1) to (3) are repeated.
The sample code takes the following actions according to its operating state:
When the high-speed on-chip oscillator clock (HOCO clock) operates: Stops the X1 oscillation clock.
When the X1 oscillation clock operates: Stops the HOCO clock.
When the XT1 oscillation clock operates: Stops the X1 oscillation clock and the HOCO clock.
The XT1 oscillation clock is always generated.
The sample code also changes the LED blinking period on the target board as shown below according to the operating
clock. This allows the operating clock to be visually checked.
LED blinking period of the HOCO clock (32 MHz): 0.5 seconds
LED blinking period of the X1 oscillation clock (20 MHz): 1 seconds
LED blinking period of the XT1 oscillation clock (32.768 kHz): 2 seconds
Table 1.1 summarizes the peripheral functions to be used and their uses. Figure 1.1 shows the outline of the clock
switching.
Table 1.1 Peripheral Functions to be Used and their Uses
Peripheral Function Use
Clock generator Generates oscillation clocks and switches the operating
clocks.
External interrupt input (INTP0) Detects the press of the switch.
Timer array unit 0 channel 0 Generates the timing signal to determine the LED blinking
period.
12-bit interval timer Generates the wait time to deal with chattering.
P62 Generates the output signal to the LED.

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 5 of 51
May 28, 2015
Figure 1.1 Outline of Clock Switching
Switch input
(INTP0)
RL78/G13
Change the LED blinking period
ON
Change the CPU/peripheral hardware clock
(fCLK) to one of the following clocks:
Switch clock
HOCO clock (32 MHz)
X1 oscillation clock (20 MHz)
XT1 oscillation clock (32.768 kHz)

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 6 of 51
May 28, 2015
2. Operation Check Conditions
The sample code contained in this application note has been checked under the conditions listed in the table below.
Table 2.1 Operation Check Conditions
Item Description
Microcontroller used RL78/G13 (R5F100LEA)
Operating frequency CPU/peripheral hardware clock:
Switches the operating clock when the switch on the target board is pressed.
When the HOCO clock is selected: 32 MHz
When the X1 oscillation clock is selected: 20 MHz
When the XT1 oscillation clock is selected: 32.768 kHz
Operating voltage 5.0 V (can run on a voltage range of 2.9 V to 5.5 V.)
LVD operation (VLVD): Reset mode 2.81 V (2.76 V to 2.87 V)
Integrated development
environment (CS+) CS + V3.01.00 from Renesas Electronics Corp.
C compiler (CS+) CC-RL V1.01.00 from Renesas Electronics Corp.
Integrated development
environment (e2studio) e2studio + V4.0.0.26 from Renesas Electronics Corp.
C compiler (e2studio) CC-RL V1.01.00 from Renesas Electronics Corp.
Board used RL78/G13 target board (QB-R5F100LE-TB)
3. Related Application Note
The application note that is related to this application note is listed below for reference.
RL78/G13 Initialization (R01AN2575E) Application Note

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 7 of 51
May 28, 2015
4. Description of the Hardware
4.1 Hardware Configuration Example
Figure 4.1 shows an example of hardware configuration that is used for this application note.
Figure 4.1 Hardware Configuration
Cautions: 1. The purpose of this circuit is only to provide the connection outline and the circuit is simplified
accordingly. When designing and implementing an actual circuit, provide proper pin treatment and make
sure that the hardware's electrical specifications are met (connect the input-only ports separately to VDD
or VSS via a resistor).
2. Connect any pins whose name begins with EVSS to VSS and any pins whose name begins with EVDD to
VDD, respectively.
3. VDD must be held at not lower than the reset release voltage (VLVD) that is specified as LVD.
4. The LED connected to P63 is always off.
RESET
EVDD
VDD
EVss
Vss
REGC
P137/INTP0
P40/TOOL0
P62
XT1
XT2
32.768 kHz
X1
X2
20 MHz
10 k
VDD
P63
EVDD
RL78/G13
EVDD
For on-chip debu
gg
er
VDD
VDD

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 8 of 51
May 28, 2015
4.2 List of Pins to be Used
Table 4.1 lists the pins to be used and their functions.
Table 4.1 Pins to be Used and their Functions
Pin Name I/O Description
P137/INTP0 Input Switch input
P62 Output LED output

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 9 of 51
May 28, 2015
5. Software Description
5.1 Operation Overview
The sample code covered in this application note switches its operating clock when the switch on the target board is
pressed.
(1) Initialize the clock generator.
The sample code initializes the I/O ports, clock generator, timer array unit 0 (TAU0), 12-bit interval timer, and external
interrupt input hardware. It enables interrupt processing after the initialization.
The LED blinks at the interval of the TAU0 interval interrupts corresponding to the selected operating clock.
(2) Get the switch state.
The sample code gets the switch state. It switches the operating clock when the press of the switch is detected. The
switch state is tested when an INTP0 external interrupt occurs. If the press of the switch is not detected, the sample
code places the CPU into the HALT mode.
(3) Switch the clock.
The CPU/peripheral hardware clock (fCLK) is switched when the switch is pressed.
The CPU/peripheral hardware clock (fCLK) is switched according to the sequence below.
1) HOCO clock (32 MHz) X1 oscillation clock (20 MHz)
2) X1 oscillation clock (20 MHz) XT1 oscillation clock (32.768 kHz)
3) XT1 oscillation clock (32.768 kHz) HOCO clock (32 MHz)
Subsequently, steps (1) to (3) are repeated.
(4) Get the clock status.
The sample code gets the clock status. If the clock status is found to have been changed, the sample code takes one of
the following actions according to the clock operating state:
When the high-speed on-chip oscillator clock (HOCO clock) operates: Stops the X1 oscillation clock.
When the X1 oscillation clock operates: Stops the HOCO clock.
When the XT1 oscillation clock operates: Stops the X1 oscillation clock and the HOCO clock.
The XT1 oscillation clock is always generated.
(5) Change the LED blinking period.
The sample code changes the TAU0 interrupt interval as follows according to the operating CPU/peripheral hardware
clock (fCLK):
LED blinking period of the HOCO clock (32 MHz): 0.5 seconds
LED blinking period of the X1 oscillation clock (20 MHz): 1 seconds
LED blinking period of the XT1 oscillation clock (32.768 kHz): 2 seconds
(6) Transition to the HALT mode.
The sample code transitions to the HALT mode. It returns from the HALT mode by TAU0 interval interrupt or external
interrupt generated by the switch. After returning from the HALT mode, the sample code performs step (2).
Subsequently, it repeats a cycle of steps (2) to (6).

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 10 of 51
May 28, 2015
5.2 File Configuration
Table 5.1 lists the files that are used in this sample code. This table excludes files which are automatically generated by
the integrated development environment.
Table 5.1 File Configuration
File Name Description Remarks
r_cg_cgc.c Clock generator module CPU clock initialization
r_cg_cgc.h External reference header file for the clock generator
module
r_cgc_user.c Processing specific to the clock generator sample
code Additional functions:
R_CGC_ChangeClock,
R_CGC_HOCOToX1,
R_CGC_X1ToXT1,
R_CGC_XT1ToHOCO,
R_CGC_GetClockStatus,
R_CGC_Get_X1_Status
R_CGC_Get_XT1_Status,
R_CGC_Get_HOCO_Status,
R_CGC_StopClock
r_cg_intc.c External interrupt input module
r_cg_intc.h External reference header file for the external interrupt
input module
r_cg_intc_user.c External interrupt input module
INTP0 external interrupt
r_cg_it.c 12-bit interval timer module
r_cg_it.h External reference header file for the 12-bit interval
timer module
r_cg_it_user.c Processing specific to the 12-bit interval timer module
sample code Additional function:
R_IT_Wait_ms
r_main.c Main processing
r_cg_macrodriver.
h Common header file Type definitions,
Macro definitions about error status
r_cg_userdefine.h Macro definitions specific to the sample code
r_cg_port.c Port function module I/O port setting
r_cg_port.h External reference header file for the port function
module
r_systeminit.c System module Initialization and system functions
r_cg_timer.c Timer module
r_cg_timer.h External reference header file for the timer module
r_cg_timer_user.c Processing specific to the timer module sample code
TAU0 channel 0 interrupt Additional functions: R_TAU0_Channel0_GetParameter,
R_TAU0_Channel0_Restart,
R_TAU0_Channel0_ChangeInterval,
r_tau0_channel0_interrupt

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 11 of 51
May 28, 2015
5.3 List of Option Byte Settings
Table 5.2 summarizes the settings of the option bytes.
Table 5.2 Option Byte Settings
Address Value Description
000C0H/010C0H 11101111B Disables the watchdog timer.
(Stops counting after the release from the reset status.)
000C1H/010C1H 01111111B LVD reset mode, 2.81 V (2.76 V to 2.87 V)
000C2H/010C2H 11101000B HS mode HOCO: 32 MHz
000C3H/010C3H 10000100B Enables the on-chip debugger.
Erases the data in the flash memory when on-chip debugging security ID
authentication fails.

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 12 of 51
May 28, 2015
5.4 List of Constants
Table 5.3 lists the constants that are used in this sample program.
Table 5.3 Constants for Sample Program
Constant Setting Description
HOCO_NEXT_STATUS_X1 1 Clock status
: Operating on the HOCO clock and the next clock is
the X1 oscillation clock.
X1_NEXT_STATUS_XT1 2 Clock status
: Operating on the X1 oscillation clock and the next
clock is the XT1 oscillation clock.
XT1_NEXT_STATUS_HOCO 3 Clock status
: Operating on the XT1 oscillation clock and the next
clock is the HOCO clock.
X1_STATUS 1 The current status is operation on X1 oscillation clock.
XT1_STATUS 2 The current status is operation on XT1 oscillation
clock.
HOCO_STATUS 3 The current status is operation on HOCO clock.
CHATTERING_WAIT 10 Wait time to deal with chattering is 10 ms.
HOCO_LED_SETTING_CHANNEL_PRESCAL
ER 9 Frequency division ratio of channel 0 of TAU0 when HOCO clock is selected
HOCO_LED_SETTING_CHANNEL_COUNT 15625 Count value of channel 0 of TAU0 when HOCO clock
is selected
X1_LED_SETTING_CHANNEL_PRESCALER 9 Frequency division ratio of channel 0 of TAU0 when
X1 oscillation clock is selected
X1_LED_SETTING_CHANNEL_COUNT 19531 Count value of channel 0 of TAU0 when X1 oscillation
clock is selected
XT1_LED_SETTING_CHANNEL_PRESCALER 9 Frequency division ratio of channel 0 of TAU0 when
XT1 oscillation clock is selected
XT1_LED_SETTING_CHANNEL_COUNT 64 Count value of channel 0 of TAU0 when XT1
oscillation clock is selected
SWITCH_OFF 0 Switch is not pressed
SWITCH_ON 1 Switch is pressed
SWITCH_ON_PORT_LEVEL 0 Input port level when switch is on
CLOCK_NOT_OSCILLATING 0 Clock is not oscillating.
CLOCK_OSCILLATING 1 Clock is oscillating.

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 13 of 51
May 28, 2015
5.5 List of Variables
Table 5.4 lists the global variables that are used in this sample program.
Table 5.4 Global Variable
Type Variable Name Contents Function Used
uint8_t g_ClockStatus Clock status main()
r_intc0_interrupt
uint8_t g_TAU0_Channel0_C
lkdiv Frequency division ratio of channel 0 of TAU0 main()
R_TAU0_Channel0_Get
Parameter()
uint16_t g_TAU0_Channel0_C
ount Counter value of channel 0 of TAU0 main()
R_TAU0_Channel0_Get
Parameter()
uint8_t g_SwitchStatus Switch status main()
r_intc0_interrupt
5.6 List of Functions
Table 5.5 lists the functions that are used in this sample program.
Table 5.5 Functions
Function Name Outline
R_INTC0_Start Sets start of INTP0 external interrupt processing.
R_TAU0_Channel0_Start Sets start of channel 0 of TAU0.
R_CGC_ChangeClock Switches clocks.
R_CGC_HOCOToX1 Switches from HOCO clock to X1 oscillation clock.
R_CGC_X1ToXT1 Switches from X1 oscillation clock to XT1 oscillation clock.
R_CGC_XT1ToHOCO Switches from XT1 oscillation clock to HOCO clock.
R_CGC_GetClockStatus Gets clock status.
R_CGC_Get_X1_Status Gets X1 oscillation clock status.
R_CGC_Get_XT1_Status Gets XT1 oscillation clock status.
R_CGC_Get_HOCO_Status Gets HOCO clock status.
R_CGC_StopClock Stops clock.
R_TAU0_Channel0_GetParameter Gets parameters of channel 0 of TAU0.
R_TAU0_Channel0_Restart Restarts channel 0 of TAU0.
R_TAU0_Channel0_ChangeInterval Changes interval of channel 0 of TAU0.
R_TAU0_Channel0_Stop Sets stop of channel 0 of TAU0.
r_tau0_channel0_interrupt Processes an interval timer interrupt of channel 0 of TAU0.
r_intc0_interrupt Processes an INTP0 external interrupt.
R_IT_Wait_ms Waits in units of 1 ms.

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 14 of 51
May 28, 2015
5.7 Function Specifications
This section describes the specifications for the functions that are used in the sample code.
[Function Name R_INTC0_Start
Synopsis Sets start of INTP0 external interrupt processing.
Header #include "r_cg_macrodriver.h"
#include "r_cg_intc.h"
#include "r_cg_userdefine.h"
Declaration void R_INTC0_Start(void)
Explanation Releases mask of INTP0 interrupts to enables them.
Arguments None
Return value None
Remarks None
[Function Name] R_TAU0_Channel0_Start
Synopsis Sets start of channel 0 of TAU0.
Header #include "r_cg_macrodriver.h"
#include "r_cg_timer.h"
#include "r_cg_userdefine.h"
Declaration void R_TAU0_Channel0_Start(void)
Explanation Releases mask of INTP0 interrupts to start counting.
Arguments None
Return value None
Remarks None
[ Function Name ] R_CGC_ChangeClock
Synopsis Switches clocks.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration void R_CGC_ChangeClock(uint8_t status)
Explanation Switches clocks.
Arguments First argument: status : Clock status (1 to 3)
Set one of the following constants:
HOCO_NEXT_STATUS_X1
Switches to X1 oscillation clock.
X1_NEXT_STATUS_XT1
Switches to XT1 oscillation clock.
XT1_NEXT_STATUS_HOCO
Switch to HOCO clock.
Return value None
Remarks None

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 15 of 51
May 28, 2015
[Function Name] R_CGC_HOCOToX1
Synopsis Switches from HOCO clock to X1 oscillation clock.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration void R_CGC_HOCOToX1 (void)
Explanation Switches the CPU/peripheral hardware clock (fCLK) from the HOCO clock to the X1 oscillation
clock.
Arguments None
Return value None
Remarks None
[Function Name] R_CGC_X1ToXT1
Synopsis Switches from X1 oscillation clock to XT1 oscillation clock.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration void R_CGC_X1ToXT1(void)
Explanation Switches the CPU/peripheral hardware clock (fCLK) from X1 oscillation clock to XT1 oscillation
clock.
Arguments None
Return value None
Remarks None
[Function Name] R_CGC_XT1ToHOCO
Synopsis Switches from XT1 oscillation clock to HOCO clock.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration void R_CGC_XT1ToHOCO(void)
Explanation Switches the CPU/peripheral hardware clock (fCLK) from XT1 oscillation clock to HOCO clock.
Arguments None
Return value None
Remarks None

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 16 of 51
May 28, 2015
[Function Name] R_CGC_GetClockStatus
Synopsis Gets clock status.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration uint8_t R_CGC_GetClockStatus(uint8_t status)
Explanation Gets the clock status.
Gets the status of the clock specified in the argument so that the user can check if the clock
oscillates.
Arguments First argument: status : Clock status (1 to 3)
Set one of the following constants:
X1_STATUS
Gets the status of X1 oscillation clock.
XT1_STATUS
Gets the status of XT1 oscillation clock.
HOCO_STATUS
Gets the status of HOCO clock.
Return value If the clock has not been switched:
CLOCK_NOT_OSCILLATING (0x00)
If the clock has been switched:
CLOCK_OSCILLATING (0x01)
Remarks None

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 17 of 51
May 28, 2015
[Function Name] R_CGC_Get_X1_Status
Synopsis Gets X1 oscillation clock status.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration uint8_t R_CGC_Get_X1_Status(void)
Explanation Gets the X1 oscillation clock status.
Arguments None
Return value When the clock has not been switched:
CLOCK_NOT_OSCILLATING (0x00)
When the clock has been switched:
CLOCK_OSCILLATING (0x01)
Remarks None
[Function Name] R_CGC_Get_XT1_Status
Synopsis Gets XT1 oscillation clock status.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration uint8_t R_CGC_Get_XT1_Status(void)
Explanation Gets the XT1 oscillation clock status.
Arguments None
Return value When the clock has not been switched:
CLOCK_NOT_OSCILLATING (0x00)
When the clock has been switched:
CLOCK_OSCILLATING (0x01)
Remarks None
[Function Name] R_CGC_Get_HOCO_Status
Synopsis Gets HOCO clock status.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration uint8_t R_CGC_Get_HOCO_Status(void)
Explanation Gets the HOCO clock status.
Arguments None
Return value When the clock has not been switched:
CLOCK_NOT_OSCILLATING (0x00)
When the clock has been switched:
CLOCK_OSCILLATING (0x01)
Remarks None

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 18 of 51
May 28, 2015
[Function Name] R_TAU0_Channel0_GetParameter
Synopsis Gets parameters of channel 0 of TAU0.
Header #include "r_cg_macrodriver.h"
#include "r_cg_timer.h"
#include "r_cg_userdefine.h"
Declaration void R_TAU0_Channel0_GetParameter(uint8_t status, uint8_t *p_clkdiv, uint16_t *p_count)
Explanation Gets and stores the parameters associated with the clock status specified in an argument in
p_clkdiv, p_count.
p_clkdiv Loaded with the frequency division ratio of the operation clock for channel 0 of
TAU0.
p_count Loaded with the count value of channel 0 of TAU0.
Arguments First argument: status : Clock status (1 to 3)
Specify one of the following constants:
X1_STATUS
Gets parameters for X1 oscillation clock.
XT1_STATUS
Gets parameters for XT1 oscillation clock.
HOCO_STATUS
Gets parameters for HOCO clock.
Second argument: *p_clkdiv : Loaded with the frequency division ratio of the
operation clock for channel 0 of TAU0.
Third argument: *p_count : Loaded with the count value of channel 0 of
TAU0.
Return value None
Remarks p_clkdiv and p_count are the first and second arguments of R_TAU0_Channel0_Restart,
respectively.
[ Function Name ] R_CGC_StopClock
Synopsis Stops clock.
Header #include "r_cg_macrodriver.h"
#include "r_cg_cgc.h"
#include "r_cg_userdefine.h"
Declaration void R_CGC_StopClock(uint8_t status)
Explanation Stops the clock specified in the argument.
Arguments First argument: status : Clock to stop (1 to 3)
Specify one of the following constants:
X1_STATUS
XT1_STATUS
Stops HOCO.
HOCO_STATUS
Does nothing (because the old XT1 oscillation
clock always oscillates.)
Return value None
Remarks None

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 19 of 51
May 28, 2015
[Function Name] R_TAU0_Channel0_Restart
Synopsis Restarts channel 0 of TAU0.
Header #include "r_cg_macrodriver.h"
#include "r_cg_timer.h"
#include "r_cg_userdefine.h"
Declaration void R_TAU0_Channel0_Restart(uint8_t clkdiv, uint16_t count)
Explanation Stops the interval timer for channel 0 of TAU0 temporarily.
Call R_TAU0_Channel0_ChangeInterval specified in the argument to change the interval of
channel 0 of TAU0.
Restarts the interval timer for channel 0 of TAU0.
Arguments First argument: clkdiv : Frequency division ratio of the operation clock
for channel 0 of TAU0
Return value Second argument: count : Count value of channel 0 of TAU0
Remarks None
Synopsis None
[Function Name] R_TAU0_Channel0_ChangeInterval
Synopsis Changes interval of channel 0 of TAU0.
Header #include "r_cg_macrodriver.h"
#include "r_cg_timer.h"
#include "r_cg_userdefine.h"
Declaration void R_TAU0_Channel0_ChangeInterval(uint8_t clkdiv, uint16_t count)
Explanation Changes the frequency division ratio of the operation clock for channel 0 of TAU0 to clkdiv.
Changes the count value of channel 0 of TAU0 to count.
Arguments First argument: clkdiv : Frequency division ratio of operation clock (0 to
15)
0: fCLK / 20
15: fCLK / 215
fCLK :
Frequency of CPU/peripheral hardware clock
Return value Second argument: count : Count value (0 to 65535)
Remarks None
Synopsis 15 is assumed if clkdiv in the first argument is greater than 15.
[Function Name] R_TAU0_Channel0_Stop
Synopsis Sets stop of channel 0 of TAU0.
Header #include "r_cg_macrodriver.h"
#include "r_cg_timer.h"
#include "r_cg_userdefine.h"
Declaration void R_TAU0_Channel0_Stop(void)
Explanation Masks the interrupts of channel 0 of TAU0 to stop counting.
Arguments None
Return value None
Remarks None

RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 20 of 51
May 28, 2015
[Function Name] r_tau0_channel0_interrupt
Synopsis Processes an interval timer interrupt of channel 0 of TAU0.
Header #include "r_cg_macrodriver.h"
#include "r_cg_timer.h"
#include "r_cg_userdefine.h"
Declaration static void __near r_tau0_channel0_interrupt(void)
Explanation Inverts the LED output (P62) at transition to this interrupt processing.
Arguments None
Return value None
Remarks None
[Function Name] r_intc0_interrupt
Synopsis Processes an INTP0 external interrupt.
Header #include "r_cg_macrodriver.h"
#include “r_cg_intc.h
#include "r_cg_userdefine.h"
Declaration static void __near r_intc0_interrupt(void)
Explanation Updating the switch status.
This function checks the switch status twice. It waits (for 10 ms) to deal with chattering
between the first and second switch checking operations.
The function sets g_SwitchStatus to SWITCH_OFF (0x00) if it fails to detect two switch
presses in succession.
The function sets g_SwitchStatus to SWITCH_ON (0x01) if it detects two switch presses in
succession.
Updating the clock status
This function sets g_ClockStatus to one of the following constants according to the number
of switch presses:
HOCO_NEXT_STATUS_X1
X1_NEXT_STATUS_XT1
XT1_NEXT_STATUS_HOCO
Arguments None
Return value None
Remarks None
[Function Name] R_IT_Wait_ms
Synopsis Waits in units of 1 ms.
Header #include "r_cg_macrodriver.h"
#include "r_cg_it.h"
#include "r_cg_userdefine.h"
Declaration void R_IT_Wait_ms(uint16_t wait_count)
Explanation Waits for a period of wait_count * 1 ms using a 12-bit interval timer.
Arguments First argument: wait_count : Wait count
Return value None
Remarks This function does not use the vector interrupt function of the 12-bit interval timer.
It waits for the period specified in the argument while polling the interrupt request flag after
the 12-bit interval timer is started.
The function does not wait if the first argument wait_count is set to 0.
