Renishaw RMI-QE User manual

Quick-start guide
H-6551-8520-RTA
RMI-QE

Issued: xx.xxxx
EN Publications for this product are available
by scanning the barcode or visiting
www.renishaw.com/rmi-qe.
DE Für dieses Produkt stehen weitere Informationen zur
Verfügung. Scannen Sie dazu den Barcode oder besuchen Sie
www.renishaw.de/rmi-qe.
ES Para acceder a las publicaciones sobre este producto
escanee el código de barras o visite
www.renishaw.es/rmi-qe.
FR Les documentations pour ce produit sont disponibles en
scannant le code barres ou en visitant
www.renishaw.fr/rmi-qe.
IT Le pubblicazioni relative a questo prodotto sono disponibili
scansionando il codice a lato oppure visitando il sito:
www.renishaw.it/rmi-qe.
日本語 本製品に関する資料については、バーコードをスキャンするか
www.renishaw.jp/rmi-qe
をご覧ください。

PL Dostęp do dokumentacji tego produktu można uzyskać,
skanując kod kreskowy lub odwiedzając witrynę
www.renishaw.pl/rmi-qe.
CS Publikace pro tento produkt jsou k dispozici po naskenování
QR kódu nebo na stránce
www.renishaw.cz/rmi-qe.
RU Если вас интересует информация об этом продукте,
отсканируйте штрих-код или посетите сайт
www.renishaw.ru/rmi-qe.
中文
(繁體)
可透過下列方式獲得此產品的出版物
透過掃描條碼，或造訪
www.renishaw.com.tw/rmi-qe。
中文
(简体)
可通过以下方式获得此产品的相关文档：
扫描二维码，或访问
www.renishaw.com.cn/rmi-qe。
한국어 본 제품에 대한 간행물은
바코드를 스캔하거나 다음을 방문하여 확인하실 수있습니다
www.renishaw.co.kr/rmi-qe.

Safety
Information to the machine supplier/installer
It is the machine supplier’s responsibility to ensure that the user is made aware of any hazards involved during operation, including those
mentioned in Renishaw product literature, and to ensure that adequate guards and safety interlocks are provided.
If the probe fails, the probe signal may falsely indicate a probe seated condition. Do not rely on probe signals to halt the movement of the
machine.
Information to the equipment installer
All Renishaw equipment is designed to comply with the relevant EU and FCC regulatory requirements. It is the responsibility of the
equipment installer to ensure that the following guidelines are adhered to, in order for the product to function in accordance with these
regulations:
• Any interface MUST be installed in a position away from any potential sources of electrical noise (for example, power transformers,
servo drives).
• All 0V/ground connections should be connected to the machine “star point” (the “star point” is a single point return for all equipment
ground and screen cables).This is very important and failure to adhere to this can cause a potential difference between grounds.
• All screens must be connected as outlined in the user instructions.
• Cables must not be routed alongside high current sources (for example, motor power supply cables), or be near high-speed data
lines.
• Cable lengths should always be kept to a minimum.
Equipment operation
If this equipment is used in a manner not specied by the manufacturer, the protection provided by the equipment may be impaired.

5
Abbreviations are as follows:
• NO = Normally open
• NC = Normally closed
• NH = Normally high
• NL = Normally low
Factory settings shown are for:
• A-6551-0049
• A-6551-0050
SW1 SW2
ON
PROBE LOW ERROR PROBE MACHINE
STATUS 1 BATTERY STATUS 2a/2b START
Pulsed NO NO NO Pulsed NH Level Dedicated Seated ‘Fast’
start start on turn on
Level NC NC NC Level NL Pulsed Common Seated ‘Standard’
start start off turn on
Switch SW1 output configuration Switch SW2 output configuration
CAUTION: Exercise caution when using error or probe SSR in NO mode as a wiring fault could cause loss of error
condition and therefore could result in a non-failsafe condition.
Switch settings SW1 and SW2

6
CAUTION: The power supply 0 V should be terminated at the machine ground (“star point”). A negative supply can be used, when wired
appropriately.
RMI-QE
5 V
Driver
Driver
12 V to 30 V
0 V
Screen
Probe status 1 (SSR)
Low battery (SSR)
Error (SSR)
Machine start input [P1]
Machine start input [P2] (see note)
Machine start input [P3] (see note)
Machine start input [P4] (see note)
Machine start return
Probe status 2a
(5 V isolated driven skip)
Probe status 2b
Power supply (12 V to 30 V)
Machine ground (“star point”)
Signal
Return
Turquoise
Turquoise/black
Violet
Violet/black
Green
Green/black
White
Pink
White/red
White/blue
Brown
Yellow
Grey
Orange
Red (see note)
Black
Green/yellow
Wiring diagram (with output groupings shown)
NOTE: A switch can be tted between the machine power supply and the red wire, to aid powering up the RMI-QE when partnering.

7
SIGNAL LED
Off No probes
operating
Good
communications
Poor
communications
Overload error
KEY TO THE SYMBOLS
Continuously on
Flashing
ERROR LED
Off No error
Error
System error
See installation
guide
Overload error
LOW BATTERY/START LED
Off Battery is okay
and no M-code
start/stop in
progress
Battery low
M-code start/
stop in progress
Battery low and
M-code start/
stop in progress
Overload error
PROBE STATUS LED
Probe triggered
Probe seated
System error
See installation
guide
Overload error
P1, P2, P3, P4 SYSTEM STATUS LEDs
Off Probe number empty
Probe number full, in standby
Probe number full, operating
System error
See installation guide
Selection error
Partnering/clearing pending, probe full
Partnering pending, probe empty
Partnering complete, probe full
Probe authentication error
Clearing complete, probe empty
RMI-QE visual diagnostics
