Renishaw TP8 User manual

TP8 user's guide
Documentation part number: H-1000-5118-04-B
TP8 user's guide
www.renishaw.com
Issued 10 2019
1

General information
© 2006 ‐ 2019 Renishaw plc. All rights reserved.
This document may not be copied or reproduced in whole or in part, or transferred to any other media or language, by any means, without
the prior written permission of Renishaw.
The publication of material within this document does not imply freedom from the patent rights of Renishaw plc.
Disclaimer
RENISHAW HAS MADE CONSIDERABLE EFFORTS TO ENSURE THE CONTENT OF THIS DOCUMENT IS CORRECT AT THE DATE OF
PUBLICATION BUT MAKES NO WARRANTIES OR REPRESENTATIONS REGARDING THE CONTENT. RENISHAW EXCLUDES LIABILITY,
HOWSOEVER ARISING, FOR ANY INACCURACIES IN THIS DOCUMENT.
Trademarks
RENISHAW, the probe symbol used in the RENISHAW logo and REVO are registered trademarks of Renishaw plc in the United Kingdom and
other countries. apply innovation and names and designations of other Renishaw products and technologies are trademarks of Renishaw
plc or its subsidiaries.
All brand names and product names used in this document are trade names, service marks, trademarks, or registered trademarks of their
respective owners.
All trademarks and trade names are acknowledged.
WEEE
The use of this symbol on Renishaw products and/or accompanying documentation indicates that the product should not be mixed with the
general household waste upon disposal. It is the responsibility of the end user to dispose of this product at a designated collection point for
waste electrical and electronic equipment (WEEE) to enable reuse or recycling. Correct disposal of this product will help save valuable
resources and prevent potential negative effects on the environment. For more information, please contact your local waste disposal service
or Renishaw distributor.
Warranty
Renishaw plc warrants its equipment for a limited period (as set out in our Standard Terms and Conditions of Sale) provided that it is installed
exactly as defined in associated Renishaw documentation.
Prior consent must be obtained from Renishaw if non-Renishaw equipment (e.g. interfaces and/or cabling) is to be used or substituted. Failure
to comply with this will invalidate the Renishaw warranty.
Claims under warranty must be made from authorised service centres only, which may be advised by the supplier or distributor.
TP8 user's guide
www.renishaw.com
Issued 10 2019
2

Care of equipment
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with
care.
Changes to Renishaw products
Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to
Renishaw equipment previously sold.
Packaging
To aid end user recycling and disposal the materials used in the different components of the packaging are stated here:
Packaging component Material 94/62/EC code 94/62/EC number
Outer box Corrugated fibreboard PAP 20
Packing foam Polyurethane foam PUR 113
Plastic bags Low density Polyethylene LDPE 4
TP8 user's guide
www.renishaw.com
Issued 10 2019
3

Product compliance
EU declaration of conformity
Contact Renishaw plc or visit www.renishaw.com/EU for the full EU declaration.
EMC conformity
This equipment must be installed and used in accordance with this installation guide. This product is intended for industrial use only and
should not be used in a residential area or connected to a low voltage power supply network which supplies buildings used for residential
purposes.
REACH regulation
Information required by Article 33﴾1﴿ of Regulation ﴾EC﴿ No. 1907/2006 ﴾“REACH”﴿ relating to products containing substances of very high
concern (SVHCs) is available at:
www.renishaw.com/REACH
China RoHS
Contact Renishaw plc or visit www.renishaw.com/ChinaRoHS for the full China RoHS tabulation.
TP8 user's guide
www.renishaw.com
Issued 10 2019
4

Probe trigger force adjustment
NOTE: Only increase the stylus trigger force if you encounter unexpected probe triggers.
The probe trigger force can be adjusted using a 2.5 mm hexagonal wrench. A clockwise rotation increases the trigger force from 0.1 N to 0.3
N approximately. Before leaving the factory, this force is set to 0.12 N based on a 21 mm long stylus fitted with a 4 mm diameter ball tip.
TP8 user's guide
www.renishaw.com
Issued 10 2019
5

Dimensions
TP8 user's guide
www.renishaw.com
Issued 10 2019
6

Specification
Principal application Robust universal DCC and manual CMMs.
Sense directions 5‐axis: ±X, ±Y, +Z
Unidirectional repeatability maximum ﴾2σ μm﴿ ﴾at stylus tip﴿ 0.5 μm ﴾0.00002 in﴿
Pre‐travel variation 360° ﴾XY plane﴿ ±1 μm ﴾±0.00004 in﴿
Weight (without shank) 95 g (3.36 oz)
Stylus range M3
Stylus force range (adjustable) 0.11 N - 0.3 N
Stylus force (set by Renishaw) 0.11 N - 0.13 N
Stylus overtravel (typical) XY plane:
±22°
+Z axis:
5.5 mm (0.22 in) @ 0.11 N
2 mm (0.08 in) @ 0.3 N
Mounting method Shank
Suitable interface PI 7-3, PI 200-3, UCC
Above data applies to test conditions as follows:
Stylus length 21 mm (0.83 in)
Stylus velocity 480 mm/min (1.57 ft/min)
Stylus force 0.11 N to 0.13 N
Ø4 mm ball
