Introduction
The PH6M is a shank mounted, fixed orientation, probe head incorporating the Renishaw autojoint probe connector.
The PH6M is compatible with the AM1 adjustment module to allow precise autojoint alignment with machine axes, enabling trouble-free
autochange operation.
Probe reach may be extended using the PEM range of extension bars for multiwired probes or the PAA series for adapting to M8 connected
probes.
Electrical connection is made via a 15‐pin micro ‘D' type connector. A range of mating cables is available with the remote end either
terminated or unterminated according to installation requirements.
An integral LED indicates the status of touch-trigger probes.
PH6M user's guide
www.renishaw.com
Issued 06 2022
6

Installation and connection
The PH6M is fitted with an integral 15‐pin micro ‘D' socket. If required, this socket can be adapted by using a suitable cable to which a 5‐pin
DIN socket has been fitted.
Locking and unlocking the autojoint is performed either manually using the S10 joint key (supplied) or automatically using the Renishaw
autochange system. This allows probes to be changed without the need to requalify.
PH6M user's guide
www.renishaw.com
Issued 06 2022
7

Dimensions
PH6M user's guide
www.renishaw.com
Issued 06 2022
8

Operation
The autojoint is a highly repeatable coupling mechanism which will minimise the need for tip re-qualification after the exchange of probes or
extension bars. The locking mechanism is operated by rotating an actuator contained in the mating half of the coupling, which is located on
the probe or extension bar. The actuator has a drive slot which may be operated using an S10 joint key for manual probe or extension bar
changing applications. Automatic probe or extension bar changing is possible using the Renishaw ACR1 or ACR3 autochange systems.
The status of the probe is indicated by the probe status LED. This is normally lit when the probe is ready for use and extinguishes as the probe
triggers.
Key Description
1Allen key 2.5 A/F
2M3 × 8 socket head screws ﴾3 off﴿
3Shank
4Multiwire probe cable
5Probe status LED
6Autojoint adaptor
7S10 joint key
PH6M user's guide
www.renishaw.com
Issued 06 2022
9

System connection
PH6M user's guide
www.renishaw.com
Issued 06 2022
10

Interconnecting cables
There is a choice of standard cables to connect from PH6M to probe interfaces PI 7-2, PI 200, OPI6, the AC2 card for SP600M or the ACR3
card for SP25M.
Connectors shown in brackets are supplied in kit form. The cable is supplied with the micro ‘D' connector fitted and the remote end prepared,
but unterminated, to facilitate assembly into machine looms.
Termination Length Ident Part number Notes
﴾15‐way high density ‘D'﴿ 25 m PL38 A-1016-7625 Supplied unterminated
﴾15‐way high density ‘D'﴿ 15 m PL42 A-1016-7624 Supplied unterminated
Unterminated 12 m PL56 A-1016-7626 No connector supplied
﴾15‐way high density ‘D'﴿ 8 m PL44 A-1016-7627 Supplied unterminated
﴾15‐way high density ‘D'﴿ 3.7 m PL46 A-1016-7628 Supplied unterminated
﴾15‐way high density ‘D'﴿ 1.9 m PL45 A-1016-7629 Supplied unterminated
Please contact Renishaw for details of cables for PI 200.
PH6M user's guide
www.renishaw.com
Issued 06 2022
11

Specification
Repeatability 1 µm ﴾2σ﴿ at stylus tip 50 mm ﴾1.97 in﴿ from connector face
Probe compatibility Direct fitting of SP25M, TP7M, OTP6M, SP600M and TP6A
PAA series adaptor/extension required for M8 connector probes
TP200, TP20 and TP2
Dimensions Length: 40 mm ﴾1.57 in﴿ – without shank
Diameter: 60 mm (2.36 in)
Weight 160 g (0.36 lb)
Probe mount Multiwired autojoint
Number of sockets One
Style of probe joint Multiwired autojoint
Probe status indication One LED
Cable connection 15‐way micro ‘D' connector
PH6M user's guide
www.renishaw.com
Issued 06 2022
12

Probe compatibility
PH6M user's guide
www.renishaw.com
Issued 06 2022
13

Accessories and parts lists
Accessories
Part Description Part number
AM1 Adjustment module for precise alignment of
the head axes with the CMM or autochange
rack
A-1026-0320
S10 Autojoint key A-1051-0040
Parts list
Please quote the part number when ordering.
Type Part number
PH6M + MS1 shank A-1074-0031
PH6M + MS2 shank A-1074-0032
PH6M + MS3 shank A-1074-0033
PH6M + MS9 shank A-1074-0039
PH6M + MS13 shank A-1074-0043
PH6M + MS15 shank A-1074-0045
PH6M user's guide
www.renishaw.com
Issued 06 2022
14
