Repotec GEL2P-ESW26G User manual

GEL2P-ESW26G
Gigabit Managed Switch
Installation and Getting Started Guide

INSTALLATION and GETTING STARTE GUIDE
GEL2P-ESW26G Gigabit Managed Switch
Installation and Getting Started Guide
Revision A1
i

ABOUT THIS GUIDE
PURPOSE This guide gives specific information on how to operate and
use the management functions of the switch.
AUDIENCE The guide is intended for use by network administrators who
are responsible for operating and maintaining network
equipment; consequently, it assumes a basic working
knowledge of general switch functions, the Internet Protocol
(IP), and Simple Network Management Protocol (SNMP).
CONVENTIONS The following conventions are used throughout this guide to
show information:
NOTE:Emphasizes important information or calls your
attention to related features or instructions.
W ARNING : Alerts you to a potential hazard that could cause
personal injury.
C AUTION : Alerts you to a potential hazard that could cause loss
of data, or damage the system or equipment.
WARRANTY See the Customer Support/ Warranty booklet included with
the product.
A copy of the specific warranty terms applicable to your
Manufacture products and replacement parts can be obtained
from your Manufacture Sales and Service Office pr authorized
dealer.
Revision A1
ii

COMPLIANCES AND
SAFETY STATEMENTS
FCC-CLASS A This equipment has been tested and found to comply with the
limits for a Class A computing device pursuant to Subpart J of
part 15 of FCC Rules, which are designed to provide reasonable
protection against such interference when operated in a
commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his
own expense.
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void
your authority to operate the equipment.
You may use unshielded twisted-pair (UTP) for RJ-45
connections – Category 3 or better for 10 Mbps connections,
Category 5 or better for 100 Mbps connections, Category 5, 5e,
or 6 for 1000 Mbps connections. For fiber optic connections, you
may use 50/125 or 62.5/125 micron multimode fiber or 9/125
micron single-mode fiber.
CE MARK
DECLARATION
OF CONFORMANCE
FOR EMI AND
SAFETY (EEC)
This equipment has been tested and found to comply with the
protection requirements of European Emission Standard
EN55022/EN61000-3 and the Generic European Immunity
Standard EN55024.
Revision A1
iii

EMC:
EN55022(2006)+A1:2007/CISPR
22:2006+A1:2006
Class A
4K V CD, 8KV, AD
IEC61000-4-2 (2001) 3V/m
IEC61000-4-3( 2002) 1KV – (power line), 0.5KV – (signal line)
IEC61000-4-4(2004) Line to Line: 1KV, Line to Earth: 2KV
IEC61000-4-5 (2001) 130dBuV(3V) Level 2
IEC61000-4-6 (2003) 1A/m
IEC61000-4-8 (2001) Voltage dips:
>95%, 0.5period, 30%, 25periods
IEC61000-4-11(2001) Voltage interruptions:
>95%, 250periods
C AUTION : Circuit devices are sensitive to static electricity, which
can damage their delicate electronics. Dry weather conditions
or walking across a carpeted floor may cause you to acquire a
static electrical charge.
To protect your device, always:
•Touch the metal chassis of your computer to ground the static
electrical charge before you pick up the circuit device.
•Pick up the device by holding it on the left and right edges only.
•If you need using outdoor device connect to this device with
cable then you need to addition an arrester on the cable
between outdoor device and this device.
Fig. Addition an arrester between outdoor device and this switch
•The switch supports the SFP Vendor includes: Manufacture,
Agilent, Avago and Finisar
Revision A1
iv

NOTE:The switch is indoor device; if it will be used in outdoor
environment or connects with some outdoor device, then it must
use a lightning arrester to protect the switch
W ARNING :
Self-demolition on Product is strictly prohibited. Damage
caused by self-demolition will be charged for repairing fees.
Do not place product at outdoor or sandstorm.
Before installation, please make sure input power supply and
product specifications are compatible to each other.
To reduce the risk of electric shock. Disconnect all AC or DC
power cord and RPS cables to completely remove power
from the unit.
Before importing / exporting configuration please make sure
the firmware version is always the same.
After firmware upgrade, the switch will remove the
configuration automatically to latest firmware version.
RELATED
PUBLICATIONS
The following publication gives specific information on how to
operate and use the management functions of the switch:
The User’s Manual
REVISION
HISTORY This section summarizes the changes in each revision of this
guide.
Release
Date
Revision
6.38 01/06/2016 A1
Revision A1
v

Contents
ABOUT THIS GUIDE........................................................................................................ii
COMPLIANCES AND SAFETY STATEMENTS......................................................iii
INTRODUCTION................................................................................................................1
OVERVIEW.................................................................................................................................... 1
DESCRIPTION OF HARDWARE.................................................................................3
NETWORK PLANNING ...................................................................................................5
INTRODUCTION TO SWITCHING..................................................................................... 5
APPLICATION EXAMPLES.................................................................................................... 5
INSTALLING THE SWITCH..........................................................................................6
SELECTING A SITE................................................................................................................... 6
ETHERNET CABLING ............................................................................................................... 6
EQUIPMENT CHECKLIST....................................................................................................... 7
PACKAGE CONTENTS.............................................................................................................. 7
MOUNTING................................................................................................................................... 7
INSTALLING AN OPTIONAL SFP TRANSCEIVER................................................... 10
CONNECTING TO A POWER SOURCE........................................................................... 14
CONNECTING TO THE CONSOLE PORT....................................................................... 14
Operation of Web-based Management.............................................................16
MAKING NETWORK CONNECTIONS....................................................................17
CONNECTING NETWORK DEVICES............................................................................... 17
TWISTED-PAIR DEVICES................................................................................................... 17
FIBER OPTIC SFP DEVICES............................................................................................... 18
CABLE LABELING AND CONNECTION RECORDS.......................................21
TROUBLESHOOTING ....................................................................................................22
Basic Troubleshooting Tips.............................................................................................. 22
POWER AND COOLING PROBLEMS......................................................................24
Installation ................................................................................................................................ 24
Revision A1
vi

IN-BAND ACCESS.................................................................................................................... 24
SPECIFICATIONS...........................................................................................................25
PHYSICAL CHARACTERISTICS........................................................................................ 25
SWITCH FEATURES................................................................................................................ 25
MANAGEMENT FEATURES.................................................................................................. 26
STANDARDS............................................................................................................................... 26
COMPLIANCES.......................................................................................................................... 26
Revision A1
vii

INTRODUCTION
OVERVIEW GEL2P-ESW26G L2+ Managed Switch is a next-generation
Ethernet Switch offering full suite of L2 features, including
advanced L3 features such as Static Route that delivers better
cost performance and lower total cost of ownership in
Enterprise networks via fiber or copper connections.
GEL2P-ESW26G delivers 24 (10M/100M/1G) RJ45 ports, 2
Combo GbE RJ45/SFP ports and RJ45 Console port.
GEL2P-ESW26G provides high HW performance and
environment flexibility for SMBs and Enterprises.
GEL2P-ESW26G is ideal to deliver management simplicity,
optimum user experience, and lower cost. The embedded
Device Managed System is designed to be extremely
easy-to-use/manage/install IP Phone, IP Cam, or Wifi-AP for
Enterprise Applications.
Front of the Switches
Back of the Switches
AC Power Socket
Revision A1
1

SWITCH
ARCHITECTURE
The switch performs a wire-speed, non-blocking switching fabric.
This allows wire-speed transport of multiple packets at low
latency on all ports simultaneously. The switch also features
full-duplex capability on all ports, which effectively doubles the
bandwidth of each connection.
This switch uses store-and-forward technology to ensure
maximum data integrity. With this technology, the entire packet
must be received into a buffer and checked for validity before
being forwarded. This prevents errors from being propagated
throughout the network.
NETWORK
MANAGEMENT
OPTIONS
The switch can also be managed over the network with a web
browser or Telnet application. The switch includes a built-in
network management agent that allows it to be managed
in-band using SNMP or RMON (Groups 1, 2, 3, 9) protocols. It
also has an RJ45 console port connector on the front panel for
out-of-band management. A PC may be connected to this port
for configuration and monitoring out-of-band via a null-modem
serial cable.
NOTE:For a detailed description of the management features,
refer to the User’s manual.
Revision A1
2

DESCRIPTION OF
HARDWARE
1000BASE-T
PORTS
The switch contains 26 1000BASE-T RJ-45 ports. All RJ-45 ports
support automatic MDI/MDI-X operation, auto-negotiation and
IEEE 802.3x auto-negotiation of flow control, so the optimum
data rate and transmission can be selected automatically.
SFP
TRANSCEIVER
SLOTS
GEL2P-ESW26G supports the Small Form Factor Pluggable (SFP)
transceiver slots are shared with RJ-45 port 25 to 26. In the
default configuration, if an SFP transceiver (purchased
separately) is installed in a slot and has a valid link on the port,
the associated RJ-45 port is disabled.
The following table shows a list of transceiver types which have
been tested with the switch. For an updated list of vendors
supplying these transceivers, contact your local dealer. For
information on the recommended standards for fiber optic
cabling, see “1000 Mbps Gigabit Ethernet Collision Domain”.
Supported SFP Transceivers
Media Standard
Fiber Diameter
(microns)
Wavelength (nm)
Maximum Distance*
1000BASE-SX 50/125
62.5/125
850
850
550 m
275 m
1000BASE-LX/
LHX/ XD/ZX 9/125
9/125
9/125
1310
1550
1300
10 km
30.50 km
10 km
1000BASE-LX
Single Fiber N/A TX-1310/RX-1550
Tx-1550/RX-1310
20 km
20 km
1000BASE-T
N/A
N/A
100 m
100-FX 50/125
62.5/125
850
1550
2 km
15km
NOTE:* Maximum distance may vary for different SFP vendors
Revision A1
3

PORT AND
SYSTEM STATUS
LEDS
The GEL2P-ESW26G switch includes a display panel for system
and port indications that simplify installation and network
troubleshooting. The LEDs, which are located on left hand side of
the front panel for easy viewing. Details are shown below and
described in the following tables.
Port Status LEDs
LED Condition Status
TP SPEED Green/Yellow Lit Green when TP link on 1000Mbps
Yellow when TP link on 10/100Mbps
PoE (Link/ACT) Green
Lit Green when PoE link with PD and supply
power to PD
SFP SPEED Green/Yellow Lit Green when SFP link on 1000Mbps
Yellow when SFP link on 100Mbps
Mode Status LEDs
LED Condition Status
Link/ACT/Speed Green
Lit Green indicates all LED of each port are in
Link/ACT/Speed mode.
System Status LED
SYSTEM LED Condition Status
Power Green
OFF
Lit green when power is coming up
Off when Power is turn off
POWER SUPPLY
SOCKET
There are a power sockets on the rear panel of the switch. For
normal power supply, the GEL2P-ESW26G Switch has standard
power socket for AC power cord.
Revision A1
4

NETWORK PLANNING
INTRODUCTION
TO SWITCHING A network switch allows simultaneous transmission of multiple
packets; it can partition a network more efficiently than bridges
or routers. Therefore the switch has been recognized as one of
the most important devices for today’s networking technology.
When performance bottlenecks are caused by congestion at the
network access point such as file server, the device can be
connected directly to a switched port. And, by using full-duplex
mode, the bandwidth of the dedicated segment can be doubled
to maximize throughput.
When networks are based on repeater (hub) technology, the
distance between end stations is limited by a maximum hop
count. However, a switch can subdividing the network into
smaller and more manageable segments, and linking them to
the larger network than it turns the hop count back to zero and
removes the limitation.
A switch can be easily configured in any Ethernet, Fast Ethernet,
or Gigabit Ethernet network to significantly increase bandwidth
while using conventional cabling and network cards.
APPLICATION
EXAMPLES The GEL2P-ESW26G Switch implements 24 Gigabit Ethernet TP
ports with auto MDIX and 2 slots for the removable SFP module
(GEL2P-ESW26G port 25/26) which supports comprehensive
types of fiber connection, such as LC and BiDi-LC modules. It is
not only designed to segment your network, but also to provide
a wide range of options in setting up network connections. Some
typical applications are described below.
The switch is suitable for the following applications.
 Remote site application is used in Enterprise or SMB
 Peer-to-peer application is used in two remote offices
 Office network
 High Performance Requirement environment
 Advance Security for network safety application
 Suitable for data/ voice and video conference application
Revision A1
5

INSTALLING THE
SWITCH
SELECTING A
SITE The Switch can be mounted in a standard 19-inch equipment
rack (Via Optional Rack mount Kit) or on a flat surface. Be
sure to follow the guidelines below when choosing a location.
◆ The site should:
 Be at the center of all the devices you want to link and
near a power outlet.
 Be able to maintain its temperature within 0 to 45°C
(32 to 113 °F) and its humidity within 10% to 90%,
non-condensing.
 Be accessible for installing, cabling and maintaining
the devices.
 Allow the status LEDs to be clearly visible.
◆ Make sure the twisted-pair Ethernet cable is always routed
away from power lines, radios, transmitters or any other
electrical interference.
◆ Make sure that GEL2P-ESW26G 26Port Series Switch is
connected to a separate grounded power outlet that
provides 100 to 240 VAC, 50 to 60 Hz.
ETHERNET
CABLING To ensure proper operation when installing the switch into a
network, make sure that the current cables are suitable for
100BASE-TX or 1000BASE-T operation. Check the following
criteria against the current installation of your network:
◆ Cable type: Unshielded twisted pair (UTP) or shielded
twisted pair (STP) cable with RJ-45 connectors; Category 5
or Category 5e with maximum length of 100 meters is
recommend 100BASE-TX, and Category 5e or 6 with
maximum length of 100 meters is recommend for
1000BASE-T.
◆ Protection from radio frequency interference emissions.
◆ Electrical surge suppression.
◆ Separation of electrical wires and data based network wiring.
◆ Safe connections with no damaged cables, connectors or
shields.
Revision A1
6

RJ-45 Connections SFP Transceiver
EQUIPMENT
CHECKLIST After unpacking this switch, please check the contents to be sure
you have received all the components. Then, before beginning
the installation, be sure you have all other necessary installation
equipment.
PACKAGE
CONTENTS
GEL2P-ESW26G 26 Port Series GbE Management Switch
Four adhesive rubber feet
Mounting Accessory (for 19” Rack Shelf, Optional)
This Installation Guide
User’s Manual CD
AC Power Cord
RJ-45 Console Cable
NOTE:Please notify your sales representative immediately if
any of the aforementioned items is missing or damaged.
W ARNING : The mini-GBICs are Class 1 laser devices. Avoid direct
eye exposure to the beam coming from the transmit port.
MOUNTING The switch can be mounted in a standard 19-inch equipment
rack or on a desktop or shelf. Mounting instructions for each
type of site as follow.
RACK MOUNTING Before rack mounting the switch, please pay attention to the
following factors:
Temperature: Since the temperature within a rack assembly
may be higher than the ambient room temperature, check
that the rack-environment temperature is within the
specified operating temperature range (0 to 45 °C).
Mechanical Loading: Do not place any equipment on top of a
rack-mounted unit.
Revision A1
7

Circuit Overloading: Be sure that the supply circuit to the
rack assembly is not overloaded.
Grounding: Rack-mounted equipment should be properly
grounded.
TO Rack-mount Devices:
Step1. Attach the brackets to the device using the screws provided in the Mounting
Accessory.
Attaching the Brackets
Step2. Mount the device in the rack (Via Optional Rack-Mount kit), using four
rack-mounting screws (not provided). Be sure to secure the lower
rack-mounting screws first to prevent the brackets being bent by the weight of
the switch.
Installing the switch in a Rack
Revision A1
8

Step3. If installing a single switch only, turn to “Connection to a Power Source” at the
end of this chapter.
Step4. If installing multiple switches, mount them in the rack, one below the other, in
any order.
Revision A1
9

DESKTOP OR SHELF MOUNTING:
Step1. Attach the four adhesive rubber feet to the bottom of the first switch.
Attaching the Adhesive Rubber Feet
Step2. Set the device on a flat surface near an AC power source, making sure there are
at least two inches of space on all sides for proper air flow.
Step3. If installing a single switch only, go to “Connecting to a Power Source” at the end
of this Chapter.
Step4. If installing multiple switches, attach four adhesive feet to each one. Place each
device squarely on top of the one below, in any order.
INSTALLING AN
OPTIONAL SFP
TRANSCEIVER
You can install or remove a mini-GBIC SFP from a mini-GBIC slot
without having to power off the switch. Use only Manufacture
mini-GBIC.
NOTE:
The mini-
GBIC slots are shared with the two 10/ 100/
1000Base-T RJ-45 ports. If a mini-GBIC is installed in a
slot, the associated RJ-45 port is disabled and cannot be
used.
Revision A1
10

The mini-GBIC ports operate only at full duplex. Half
duplex operation is not supported.

Ensure the network cable is NOT connected when you
install or remove a mini-GBIC.
C AUTION : Use only supported genuine Manufacture mini-GBICs
with your switch. Non-Manufacture mini-GBIC might have
compatible issue, and their use may result in product malfunction.
Revision A1
11

Inserting an SFP Transceiver into a Slot
The SFP slots support the following optional SFP transceivers:
Description
1000Base-SX GE SFP Fiber Module, LC Multi-Mode 850nm
1000Base-SX GE SFP Fiber Module, LC Multi-Mode 1310nm 2km
1000Base-LX GE SFP Fiber Module, LC Single-Mode 10km
1000Base-LX GE SFP Fiber Module, LC Single-Mode 30km
1000Base-LX GE SFP Fiber Module, LC Single-Mode 50km
1000Base-LX GE SFP Fiber Module, LC Single-Mode 50km
1000Base-LX GE SFP Fiber Module, Bidi LC Single-Mode 10km,
1310nm
1000Base-LX GE SFP Fiber Module, Bidi LC Single-Mode 10km,
1550nm
1000Base-LX GE SFP Fiber Module, Bidi LC Single-Mode 20km,
1550nm
1000Base-LX GE SFP Fiber Module, Bidi LC Single-Mode 20km,
1310nm
100Base-FX FE SFP Fiber Module, LC Multi-Mode
100Base-FX FE SFP Fiber Module, LC Single-Mode 20km
C AUTION :We recommend the SFP Transceiver from the
following vendors:
Manufacture Corporation
Agilient Technologies
AVAGO Technologies
Finisar Corporation
TO Install a SFP transceiver, do the following:
Step1. Consider network and cabling requirements to select an appropriate SFP
transceiver type.
Step2. Insert the transceiver with the optical connector facing outward and the slot
connector facing down. Note that SFP transceivers are keyed so they can only
Revision A1
12
