resi-linx digi-MOD RL-DM1000 User manual

F
G
LCD Display
IR LED
Scroll up / down
Enter Button (OK)
LED Indicator Input
A
B
C
D
H
Face Plate
Connections
IR
RL-DM1000
®
®
ABCD
IN
Video Audio L Audio R
OFF ON (REMOTE) PWR
IR REPEATER
REMOTE SET UP
ASI IN
DC 12V
ANT IN RF OUT
Video and Audio Input
ASI Input
IR Repeater
Remote Power Switch
Screw Holes for Mounting brackets
12V DC Power Input
Not Active
RF Output
Antenna Input
LED Indicator Input
AB C D
E
I
E
WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
Vcomm Pty Ltd
ABN: 99 091 281 524
N15275
Connections
Face Plate
Hardware Connection
1. Connect the RCA cable from the video source (eg.
CABLE / PAY TV, DVD, VCR, CAMERA) to the yellow
RCA video ‘INPUT’ jack (Video) on the rear of the
RL-DM1000 Modulator.
2. Connect the RCA cable from the audio source to the red/
white ‘INPUT’ audio jacks (AudioR, AudioL) on the
rear of the RL-DM1000 Modulator. Use red and white
jacks for dual input, or either one for single input.
3. For ASI connect the cable from the Source to the ASI
Input B on the rear of the RL-DM1000 Modulator.
4. Connect the RF output H from the RL-DM1000
to the modulator input on the RF Distribution Module
Alternatively, connect the RF output H to an existing
distribution system or directly to a television set.
5. Slide the Remote Power switch D to ‘ON’ if connecting
the Modulator to a RL-RF380 Video Hub.
6. Connect IR emitters RL-IR700/800 to the outputs C
on the rear of the RL-DM1000 Modulator. Place the
other end within 25mm of the IR receiver on the AV
source (depending on environmental conditions).
7. Connect the supplied 12V DC Switch Mode power pack
to the power input F .
A
A
A
B
C
D
E
F
G
H
I
INPUT
Video Input
Video Input Level
Video Mode
Audio Input
Audio Input Level
Input Connectors
Input Impedance
OUTPUT
Output Level
Output Impedance
Channel Bandwidth
Output Level Adjustment
MER
Connector Type
MODULATION
Video Resolution
Video Compression
Audio Compression
GENERAL
Power Supply
Consumption
Dimensions
Weight
CVBS / ASI
0.7-1.4 V (pp)
PAL
Stereo
0.4 - 4.8 V (pp)
Video (RCA) - Audio (RCA)
75
Ʊ
85 dB V
75
7 MHz
20 dB typ.
30 dB typ.
“F” female
PAL 720x576 @ 25fps
MPEG2 MP@ML
MPEG1 Layer ll
12 VDC 3-AMP
1100 MA
300mm x 200mm x 47mm
1.660kg
Technical Specications
OK
digi-MOD INSTALLATION MANUAL
Ʊ
www.resi-linx.com
RL-DM1000
Radio Frequency Range
DVB-T Single Input Digital IR Modulator
complete with 12V DC 3A Power Supply
®

www.resi-linx.com
WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
Vcomm Pty Ltd
ABN: 99 091 281 524
N15275
RL-DM1000
Radio Frequency Range
DVB-T Single Input Digital IR Modulator
complete with 12V DC 3A Power Supply
12V DC 3A
RL-RF210
InputOutput 4 Output 1
Output 2Output 3
RL-RF300
RL-RF210
ON
OFF
ANT IN 1 2 3 4
5 6 7 8
INPUT
TV OUTPUTS
AUX MOD RF IN
MOD RF IN
(PWR/IR PASS)
IR
IR LED
PWR LED 12V DC
GAIN
FM TRAP
®
N15275
PATENTED
RL-DM1000
IN
Video Audio L Audio R
OFF ON (REMOTE) PWR
IR REPEATER
REMOTE SET UP
ASI IN
DC 12V
ANT IN RF OUT
RL-RF380
digi-MOD WIRING DIAGRAM
To AV SourceAV SOURCE x 1
digi-MOD
®

WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
Vcomm Pty Ltd
ABN: 99 091 281 524
N15275
Output Channel 21
Attenuation 0
Constellation QAM64
FEC 3/4
Guard Interval 1/16
Channel Region Australia
Network Name RL-NETWORK
Channel Name CHANNEL - 1
Video Input CVBS
Video Standard PAL
The resi-linx “digi-MOD” range of Digital Modulators comes available in the following three options
RL-DM1000 – Single Channel
RL-DM2000 – Dual Channel
RL-DM4000 – Quad Channel
The “digi-MOD” DVB-T Digital RF Modulation system will allow you to distribute any AV devices (Foxtel, Austar, DVD, CCTV Camera
etc) around the home or business with ease.
The resi-linx “digi-MOD” comes with the following factory pre-sets
digi-MOD INFORMATION SHEET
Before you start installing the digi-MOD, you should perform a “Factory Default”
In order to do this, please follow the below steps -:
• Power Up the digi-MOD, wait until the booting process is complete
• Oncecomplete,usetheScrollup/downKeytoreach“DefaultCong”inthemenu.Once“DefaultCong”islocated–press
the “OK” button
• Then power down the digi-MOD by removing the power lead
• Wait 5 seconds and the re-connect the power supply
Once the unit has completed its booting process, enter the menu by selecting the “OK” button
• The LCD screen will now display “Advanced Menu Output Channel” - select the “OK” button
• The LCD screen will now display “Output Channel 21” with the frequency in MHz. In some TV sets Channel 21 in not available, so
it is recommended to change this to appropriate available output channel to suit your installation (40, 50, 60 etc.)
• Once you have scrolled and selected a channel number, Select “OK” to lock in the change
• Then use the UP scroll button until the LCD display reads “Advanced Menu EXIT”
• Select “OK”, the LCD will now read “EXIT, EXIT Menu”. Select “OK”
• The LCD display will now show “Running”
• The digi-MOD unit is now ready to have sources connected.
• Auto Scan for Channels on the TV set with the digi-MOD connected and powered
• Sources for selected digi-MOD Channel selection, (e.g. channel 40), are found on TV channels 101 (changeable via menu – see
below).
• Ifthedigi-MODispowereddown,thereisnoneedtorecongure.Allsettingswillremainunlessafactorydefaultisdone.
• IfyouareconnectingviaASI,simplygotothe‘VideoInput’optioninthedesiredinputandchangefromCVBStoASI.Allowupto
70secondsfortheModulatortodetecttheASIInputandlockitin.
www.resi-linx.com
RL-DM1000
Radio Frequency Range
DVB-T Single Input Digital IR Modulator
complete with 12V DC 3A Power Supply
®

WARRANTY
Vcomm Pty Ltd states that the warrant that the customer can rely on is that
provided by the manufacturer. In the event of any warranty claim please
contact us and we will forward it to the manufacturer. The manufacturer will
then determine the extent of their liability. This expressly negates, to the
extent possible by Australian law, any warranty reliance on Vcomm Pty Ltd.
Vcomm Pty Ltd
ABN: 99 091 281 524
N15275
digi-MOD INFORMATION SHEET
CHANNEL NAME. Channels can be named by using the Scroll UP key until you reach “CHANNEL NAME”
UsetheUP/DOWNscrollkeystochangeeachletter.ClickOKtoconrmchannelnamechange.
LCN (Logic Channel Number) can be moved from its default position (101, 102, 103 and 104) to a different channel number (e.g. 4, 5,
6, 8) by scrolling up/down in the LCN option for each channel. Once selected, press the “OK” button to lock your channel change.
Changing the Channel name/s and LCN
Channel Output – 21 UHF (6-69)
FEC (forward error correction) - ¾ (1/2, 2/3, ¾, 5/6, 7/8)
Guard Int - 1/16 (1/2, ¼, 1/8, 1/16, 1/32)
Attenuator - 0 (0 – 20dB adjustable)
Constellation - 64QAM (16QAM)
OFDM Mode - 8K (2K)
Video Input - CVBS (ASI)
Brightness – 128 (adjustable)
Contrast – 128 (adjustable)
Saturation – 128 (adjustable)
Sharpness – 64 (adjustable)
HUE – 128 (adjustable)
CELL ID – 0
STREAM ID – 1000
NETWORK ID – 100
ORG NET ID – 10
NETWORK NAME – RL-NETWORK (changeable via menu)
PROGRAM NUMBER – 1000/2000/3000/4000 (changeable via menu)
CHANNEL NAME – CHANNEL-1 (changeable via menu)
LCN – 101 (changeable via menu)
Setting options – (default rst)
Safety Precautions
• Do not apply power to the DVB-T Single Input Digital IR Modulator until all components have been installed and all wiring has been properly
terminated. Failure to do so may result in damage to the product and void manufacturer’s warranty
• Do notattempttoterminate,changeorun-installanywiringwithoutrstunpluggingPowerAdapterfromtheDVB-T Single Input Digital IR
Modulator
• Do not expose any component to moisture. Doing so can create electrical hazards or render the component unusable. Exposure to moisture will
also void the warranty on the system.
• This modulator is powered with a voltage of 12 VDC. The power supply voltage must not exceed this, otherwise this modulator could suffer
irreparable damage and subsequent invalidation of the warranty.
Note:
- Do not replace the power supply with a voltage greater than 12 VDC.
- Do not connect the modulator to the power if the power cord is damaged.
- Do not plug the modulator into the mains supply until all cables have been connected correctly.
- Do not cut the cord.
• Avoid placing the modulator next to central heating components and in areas of high humidity.
• Do not cover any modulator elements that could obstruct the ventilation slots and cause overheating.
• If the modulator has been kept in cold conditions for a long time, keep it in a warm room no less than 2 hours before plugging it into the mains.
