Resol DeltaSol BS/4 V2 User manual

DeltaSol
®
BS/4 V2
www.solarhotwaterparts.com.au

DeltaSol
®
BS/4 V2
2
System-monitoring-display
Up to 4 Pt1000 temperature sensors
2 semiconductor relays for pump speed control
3 basic system layouts to choose from
Heat quantity measurement
RESOL VBus
®
Function control
Thermostat function (time-controlled)
Control of the system by RESOL ServiceCenter software possible
User-friendly operation
Housing with outstanding design
Extra-low power consumption

DeltaSol
®
BS/4 V2
3
hanging
fixation
display
pushbutton
can fuse 4A
cable conduits with strain relief
cover

DeltaSol
®
BS/4 V2
4
1
3
2
OK
back (-) forward (+)
System monitoring display
Tool bar to show actual status
of the system
Channel indication
upper line text display
lower line temperature or
temperature difference display
Relay activity
Maximum store temperature exceeded
Antifreeze function active
Sensor fault
Manual mode

DeltaSol
®
BS/4 V2
5
Commissioning menu
All vital adjustments for an easy commissioning

DeltaSol
®
BS/4 V2
6
Heat quantity
Display: measured values (depending on the selected system layout)
Collector temperatures
Store temperatures
Other temperatures
Pump speed
COL: collector temperature
TST: store temperatut
TSTB: store temperature base
TSTT: store temperature top
TDIS: thermal disinfection temperaure
TR: temperature return
[if heat quantity measurement is active]
n %: current pump speed
Operation hours
h P: operation hours
h P1: operation hours relay 1
h P2: operation hours relay 2
Heat quantity
kWh: heat quantity in kWh
[if heat quantity measurement is active]
MWh: heat quantity in MWh
[if heat quantity measurement is active]

DeltaSol
®
BS/4 V2
7
1
3
2
OK
back (-) forward (+)
Operation
Scroll through the display channels by pressing
buttons 1 and 2
Accessing the adjustment channels:
Scroll down in the display menu and press
button 1 for approx. two seconds after you have
reached the last display item
When an adjustment value is shown on the
display, SET is indicated to the right of the
channel name
Press button 3 in order to access the adjustment
mode SET starts flashing
Adjust the value using buttons 1 and 2
Briefly press button 3, SET permanently appears,
the adjusted value will be saved

DeltaSol
®
BS/4 V2
8
Overview of system layouts:
Arr 1 : standard solar system layout
Arr 2 : solar system layout with afterheating
Arr 3 : standard solar system layout with heat dump

DeltaSol
®
BS/4 V2
9
System 1

DeltaSol
®
BS/4 V2
10
System 2

DeltaSol
®
BS/4 V2
11
System 3

DeltaSol
®
BS/4 V2
12
DT O
DT1O
DT2O
DT3O
Switch-off temperature difference
Switch-on temperature difference
DT F
DT1F
DT2F
DT3F
Nominal temperature difference
Maximum store temperature
S MX
S1MX
S2MX
Rise
RIS
RIS1
RIS2
RIS3
DT S
DT1S
DT2S
DT3S
Please note: The controller is equipped with a
security switch-off of the store, which avoids a further
loading of the store if 95 °C is reached at the store.

DeltaSol
®
BS/4 V2
13
Temperature limitation and antifreeze function
Collector minimum limitation
Collector emergency temp.
Collector minimum temp.
Antifreeze function
Antifreeze temperature

DeltaSol
®
BS/4 V2
14
System cooling Collector coolingblocked
Cooling function
Arr = 3 no cooling functions, but
CMX = switching condition for
heat dump function
Store cooling Holiday cooling
S MX = switch-on condition
More extensive cooling during times
without DHW consumption
additional

DeltaSol
®
BS/4 V2
15
Drainback option
Drainback option activation
Initialisation
• Switch-on cond. must be
continuously fulfilled
Filling time
• Pump at 100 %
• Booster active
Stabilisation
• Switch-off conditions ignored
while medium heats up
Booster option

DeltaSol
®
BS/4 V2
16
Tube collector function
Start + end of
time frame
Pump runtime for
measuring purpose
Standstill interval between
pump runtimes
In a drainback system, the filling and
stabilising procedure will take place for
each OTC pump runtime. Evaluate if
OTC activation is necessary!

DeltaSol
®
BS/4 V2
17
Thermal disinfection
Disinfection temperature
Starting delay time
Disinfection period
Monitoring
period

DeltaSol
®
BS/4 V2
18
Arr 2 thermostat function
AH O < AH F
thermostat function for afterheating
AH O > AH F
thermostat function for using surplus energy
Use of surplus energy
Afterheating
Thermostat switch-
on temperature
Thermostat switch-
off temperature

DeltaSol
®
BS/4 V2
19
Option heat quantity
measurement
Maximum flow in l/min
at 100 % pump speed
Concentration of
antifreeze in VOL %
Type of antifreeze:
0: water
1: propylene glycol
2: ethylne glycol
3: Tyfocor
®
LS/G-LS

DeltaSol
®
BS/4 V2
20
Difference or deltaT collector – store [K]
Pump speed [%]
First the controller works as a standard differential controller. If the switch-on difference (DT O) is reached, the pump is activated at
full speed for 10 seconds. The speed is then reduced to the minimum pump speed value (nMN = 30 %). If the temperature difference
reaches the adjusted set value (DT S), the pump speed increases by one step (10 %). If the difference increases by 2 K (RIS), the pump
speed increases by 10 % respectively until the maximum pump speed of 100 % is reached. The response of the controller can be
adapted via the parameter „Rise“. If the temperature difference falls below the adjusted switchoff temperature difference (DT F), the
controller switches off.
