INSTALLATION INSTRUCTIONS: DOOR MOUNT SPICE RACK
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
DOOR MOUNT SPICE RACK
TOOLS REQUIRED:
10 MIN
ESTIMATED ASSEMBLY TIME:
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
I-5365-1118
#2#2#2
WATCH TUTORIALS OF OUR
PRODUCTS BEING INSTALLED
WWW.REV-A-SHELF.COM/VIDEOS
PARTS LIST
No. Description Qty.
A Spice Rack Unit 1
B #6 x 1/2” Flat Head Screws 4
AB
Customer Service: 800-626-1126 | rev-a-shelf.com
2
Measure and mark the center
of the cabinet door
(See Figure A).
STEP 1
Using the mark from Step 1,
center the product and adjust
the mounting brackets to the
desired height and tighten.
Note: Make sure to install to
the thick portion of the door.
STEP 2
Mark hole locations and fasten
to the door taking care not to
drill through.
STEP 3
FIG. A
#2#2#2
*5365 requires 2-1/2” of clearance
behind door.
*Existing shelves may need
to be modied to allow space
for these bins and items stored within.
*Wall Cabinet Adjustable Shelves need
to be positioned prior to installation to
verify that units clears them.
Door
2-1/2”
INSTRUCCIONES DE INSTALACIÓN: ESPECIERO PARA MONTAR EN PUERTA LES INSTRUCTIONS D’INSTALLATION: ÉTAGÈRE À ÉPICES MURALE
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
ESPECIERO PARA MONTAR EN PUERTA / ÉTAGÈRE À ÉPICES MURALE
I-5365-1118
#2#2#2
Lista de Parts/Liste des Pièces
No. Descripcion/Description Qty.
AEspeciero / Étagère à épices 1
B#6 tornillos de cabeza plana de 1/2”
Vis à tête plate no 6 de ½ po
4
AB
INSTRUCCIONES DE INSTALACIÓN / LES INSTRUCTIONS D’INSTALLATION
HERRAMIENTAS REQUERIDAS
OUTILS REQUIS
TIEMPO ESTIMADO DE
ENSAMBLADO:
DURÉE DE L’INSTALLATION:
VER VIDEOS DE
INSTALACIONES DE PRODUCTOS
REGARDER DES VIDÉOS
D’INSTALLATIONS DE PRODUITS
WWW.REV-A-SHELF.COM/VIDEOS
CUIDADO:
ENTRETIEN:
Limpie con un paño húmedo y
seque las partes.
Nettoyer avec un chiffon
humide et essuyer pour sécher
complètement.
10 MIN
Customer Service: 800-626-1126 | rev-a-shelf.com
4
Medir y marcar el centro de la
puerta de la alacena
(Ver gura A).
Mesurez et marquez le centre
de la porte du placard
(Voir l’image A).
PASO 1 / ÉTAPE 1
Usando la marca del paso 1,
centrar el producto y ajustar
los soportes del montaje a la
altura deseada, y apretar.
Nota: Asegúrese de instalar
en la parte gruesa de la
puerta.
À l’aide de la marque que
vous avez faite à l’étape 1,
centrez le produit et réglez
les supports de xation à la
hauteur désirée, puis serrez.
Remarque : assurez-vous
d’installer l’étagère dans la
partie épaisse de la porte.
PASO 2 / ÉTAPE 2
Marcar la ubicación de los
agujeros y sujetar a la puerta
teniendo cuidado de no
perforarla.
Marquez les emplacements
des trous et xez l’étagère à la
porte, en prenant soin de ne
pas la percer.
PASO 3 / ÉTAPE 3
FIG. A
#2#2#2
5365 necesita 2-1/2” de
espacio detrás de la puerta.
*Los estantes existentes
pueden necesitar
ser modicados para liberar
espacio
para estos recipientes y
los elementos guardados
dentro.
*Los estantes ajustables
de la alacena necesitan ser
posicionados antes de la
instalación para vericar
que el especiero no choque
contra ellos.
*5365 requiert 2-1/2 po
(6,35 cm) d’espace libre
derrière la porte.
*Les tablettes existantes
peuvent devoir être
modiées an de donner
l’espace requis aux
contenants et aux articles
qui y sont entreposés.
*Les tablettes réglables de
l’étagère murale peuvent
devoir être positionnées
avant l’installation de
celle-ci an de s’assurer
que les articles entreposés
disposent de sufsamment
d’espace.
2-1/2”
Puerta
Porte
