Rev-A-Shelf CRC-36CR User manual

2409 Plantside Drive
Jeffersontown, KY 40299
502-499-5835 • 502-491-2215 FAX
800-626-1126
www.rev-a-shelf.com
We hope you enjoy your new closet accessories from
Rev-A-Shelf. We pride ourselves in providing the best
quality,service, and innovation in the industry. If you
have any questions about our products, feel free to call
our Customer Service Specialist at 800-626-1126.
I-CLOSET
Installation
Instructions

Part # CRC-36CR
1
2
2 pcs
1 pc
1
3
No. Quantity Description
36" Chrome Closed Rod
Rod Holder
1. Mount the rod holder to the side of the
 cabinet.
2. Put the rod into the rod holder. 3. Your installation is complete.
Rod
Installation
3
4 pcs
Wood screws
2
Notes:
1. Avoid using acid or corrosive
cleaner to wipe the product.
7/8" (22 mm)
3/8" (10 mm)
Hole Diameter:
5/32" (4 mm)
NOTE: If distance is less than 36", measure opening
and cut rod to desired length.

Part # TRC-14CR
1
2
3
1 set
3 pcs
1 set
3
No. Quantity Description
Tie Rack Installation
Notes:
1. Pay attention to the direction of
slide member to avoid the mistake
of assembly.

2. The minimum required depth of the
cabinet is 14" (356 mm).

3.Avoid using acid or corrosive cleaner
to wipe the product.
Slides
1. According to the dimension, mount
the slide memeber to the side of cabinet.
2. Connect Tie Rack with the slide. 3. Your installation is complete.
Tie Rack
Wood screws

2
1
11-3/4" (300 mm)
7-1/2" (192 mm)
2-3/4" (70 mm)

Part # SRC-20CR
1
2
3
1 set
6 pcs
1 set
3
15-1/2" (395 mm)
10-1/2" (267 mm)
2-15/16" (75 mm)
45-1/2" (1155 mm)
No. Quantity Description
Shoe/Basket Rack Installation
Slides
1. According to the dimension, mount the
slides to the left or right side of the cabinet.
2. Connect frame with the slides. 3. Note there are two ways to put the 
basket on the frame.
Frame and 4 baskets
Wood screws
Notes:
1. Pay attention to the direction of slide
member to avoid the mistake of assembly.
2. The minimum required depth of the
cabinet is 19-3/4" (502 mm).
3.Avoid using acid or corrosive cleaner
to wipe the product.
2
1

Part # CWB Series
1
2
3
1 set
8 pcs
1 set
No. Quantity Description
Chrome Basket Installation
Slides
1. According to the dimension, mount the
slides to the side of cabinet.
Basket
Wood screws
Notes:
1. Pay attention to the direction of slide
member to avoid the mistake of assembly.

2. The minimum required depth of the
cabinet is 14" (356 mm) for CWB-**14**** 
and 20" (508 mm) for CWB-**20**CR.

3.Avoid using acid or corrosive cleaner
to wipe the product.
3
2. Attach basket to slides by press fitting the top
rail into the four pivoting polymer width adjustment
pieces.
3. Your installation
is complete.
18" (457 mm) or 24" (610 mm)
2
1
15/32" (12 mm)
1-1/4" (32 mm)
7-9/16" (192 mm)
1-1/4" (32 mm)
15/32"
(12 mm)
1-1/4" (32 mm)
7-9/16" (192 mm)
Note:
Width
adjustment

Part # TBC-14TCR
1
2
3
4
1 set
3 pcs
1 set
1 pc
2
1
No. Quantity Description
Tie Belt Combo Rack Installation
Notes:
1. Pay attention to the direction of
slide member to avoid the mistake
of assembly.

2. The minimum required depth of the
cabinet is 14" (356 mm).

3.Avoid using acid or corrosive cleaner
to wipe the product.
Slides
1. According to the dimension, mount the
slides to the side of cabinet.
2. Connect Tie Belt Combo Rack with
the slide then place the Top Tray on
the
frame.
3. Your installation is complete.
Tie Belt Combo Rack
Top Tray
Wood screws
3
4
11-3/4" (300 mm)
7-1/2" (192 mm)
2-3/4" (70 mm)

Part # PSC Series
1
2
3
1 set
6 pcs
1 set
No. Quantity Description
Pull-out Pants Rack Installation
Slides
1. According to the dimension, mount the
slides to the side of cabinet.
2. Connect Pants Rack with the slides.
3. Press fit pivoting fingers.
Adjust level by slightly bending.
4. Your installation
is complete.
Pants Rack
Wood screws
Notes:
1. Pay attention to the direction of slide
member to avoid the mistake of assembly.

2. The minimum required depth of the
cabinet is 18" (457 mm).

3.Avoid using acid or corrosive cleaner
to wipe the product.
Width adjustment screws
Width adjustment screws
2
1
17-5/16" (440 mm)
12-1/4" (312 mm)
4-3/4" (120 mm)
23-5/8" (600 mm) to 24-3/8" (620 mm)
3
17-5/8" (447 mm) to 18-3/8" (467 mm)
or
Note: PSC-24CR contains
13 pivoting fingers
PSC-18CR contains 9.

Part # PRC-18CR
1
2
3
1 set
6 pcs
1 set
2
1
No. Quantity Description
Pull-out Pants Rack Installation
Slides
1. According to the dimension, mount the
slide members to the side of cabinet.
2. Connect pants rack to the slides. 3. Your installation is complete.
Trouser holders
Wood screws
Notes:
1. Pay attention to the direction of
slide members to avoid the mistake
of assembly.

2. The minimum required depth of the
cabinet is 18" (457 mm).

3.Avoid using acid or corrosive
cleaner to wipe the product.
3
17-1/4" (440 mm)
12-1/4" (312 mm)
4-3/4" (120 mm)
2" (50 mm)
NOTE: Lift rack to lock in
extended position.
NOTE: Pants rack folds
down in stored position.
