INSTALLATION INSTRUCTIONS: RV-SERIES WASTE CONTAINERS AND HAMPERS
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
RV-SERIES WASTE CONTAINERS AND HAMPERS
I-RV-CK-HURV-0519
#2
TOOLS REQUIRED:
15 MIN
ESTIMATED ASSEMBLY TIME:
CARE AND MAINTENANCE:
Clean with a damp cloth and wipe
parts dry.
* Depending on unit purchased
Door Mounting Kit Sold Separately
Part# RV DM KIT
HURV-1512 RV-9PB RV-18PB-2
RV-18PB-1 RV-1216-CK HPRV-1520
PARTS LIST
No. Description Qty.
A Base Unit 1
B Waste Containers/Hamper 1 or 2*
C #8 x 3/4” Truss Head Screws 4
AB C
WATCH VIDEO TUTORIALS OF
PRODUCT INSTALLATIONS
WWW.REV-A-SHELF.COM/VIDEOS
2Customer Service: 800-626-1126 | rev-a-shelf.com
FIG. C-1 FIG. C-2
#2#2#2
#2#2#2
Note: Your RV series has
been shipped fully assembled
for ease of installation.
First remove the container(s)
from the wire frame. Place the
frame inside of your cabinet.
Look to make sure that there
is plenty of clearance to shut
the door and for the waste
containers (See Figure A).
STEP 1
If there is sufcient clearance,
install (2) rear screws (See
Figure C-1).
Note: If framework prevents
access to rear screws,
remove framework by pulling
out and lifting frame from
slides.
If your product features full
extension slides remove
frame by disengaging release
triggers (See Figure C-2).
Press one side up and the
other side down.
Finally, replace the frame
onto the slides then place
your waste containers in the
wire frame and the installation
is complete.
STEP 2
With the frame in a closed
position, insert the front two
screws, making sure that the
framework is square to the
front of the cabinet
(See Figure B).
STEP 3
FIG. A
FIG. B
No. Descripción / Description Qty.
AUnidad de base / Unité du bas 1
BContenedores de residuos/Cesto de basura
Contenants à déchets/panier
1 or 2*
CTornillos de cabeza de cruz #8 x 3/4”
Vis à tête bombée # 8 x ¾ po
4
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
CONTENEDORES Y CESTAS DE BASURA RV-SERIES
RV-GAMME DE CONTENANTS À DÉCHETS ET PANIERS
I-RV-CK-HURV-0519
#2
15 MIN
* Depending on unit purchased
Equipo de montaje para puerta ven-
dido por separado Part# RV DM KIT
Ensemble d’installation sur porte ven-
du séparément. No de pièces pour
ensembles RV DM KIT
HURV-1512 RV-9PB RV-18PB-2
RV-18PB-1 RV-1216-CK HPRV-1520
Lista de partes / Liste des pièces
AB C
INSTRUCCIONES DE INSTALACIÓN / INSTRUCTIONS D’INSTALLATION
INSTRUCCIONES DE INSTALACIÓN: CONTENEDORES Y CESTAS DE BASURA RV-SERIES
INSTRUCTIONS D’INSTALLATION: SYSTÈME DE TIROIRS À DEUX NIVEAUX
Herramientas requeridas:
Outils Requis:
Tiempo estimado de ensamblado:
Durée de l’installation:
Limpie con un paño húmedo y
seque las partes.
Nettoyer avec un chiffon
humide et essuyer pour sécher
complètement.
CUIDADO/ ENTRETIEN:
4Customer Service: 800-626-1126 | rev-a-shelf.com
FIG. C-1 FIG. C-2
Nota: Su RV-Series ha sido enviada
completamente ensamblada para facilitar su
instalación.
Primero quite los contenedores del bastidor
de metal. Coloque el marco dentro de su
gabinete. Asegúrese de que haya suciente
espacio para cerrar la puerta y para los
contenedores de desechos (Ver gura A).
Note : Votre gamme RV a été expédiée
complètement assemblée pour permettre une
installation facile.
D’abord, enlever le(s) contenants du cadre
métallique. Placez le cadre à l’intérieur de votre
armoire. Assurez-vous qu’il y ait sufsamment
d’espace libre pour fermer la porte et pour le(s)
contenant(s) à déchets (voir gure A).
PASO 1 / ÉTAPE 1
Si hay suciente espacio libre, instale (2)
tornillos traseros (Ver gura C-1).
Nota: Si la estructura impide el acceso a los
tornillos traseros, retírela tirando de ella y
levantándola de las correderas.
Si su producto tiene correderas de extensión
completa, retire el bastidor soltando los
dispositivos de bloqueo (Vea gura C-2).
Presione un lado hacia arriba y el otro hacia
abajo.
Finalmente, reemplace el bastidor en las
correderas, luego coloque los contenedores
de desechos en el bastidor metálico y la habrá
nalizado la instalación.
S’il y a sufsamment d’espace libre, installez les
(2) vis arrière (voir gure C-1).
Note : Si le cadre empêche d’accéder aux vis
arrière, enlevez-le en le tirant et en le levant des
côtés.
Si votre produit comporte des glissières pleine
extension, enlevez le cadre en désengageant les
gâchettes (voir gure C-2). Appuyez sur un côté
vers le haut et sur l’autre côté ver le bas.
Puis, replacez le cadre dans les glissières et
placez le(s) contenant(s) à déchet dans le cadre
métallique. L’installation est terminée.
PASO 2 / ÉTAPE 2
Con el marco en posición cerrada, inserte
los dos tornillos frontales, asegurándose de
que el bastidor esté a escuadra con la parte
delantera del gabinete (Ver gura B).
Le cadre en position fermée, insérez les deux
vis du devant en vous assurant que le cadre
soit à égalité avec le devant de l’armoire (voir
gure B).
PASO 3 / ÉTAPE 3
FIG. A
FIG. B
