REXROTH EFC3600 Series User manual

Operating Instructions
Electric Drives
and Controls Pneumatics Service
Linear Motion and
Assembly Technologies
Hydraulics
Rexroth Frequency Converter
EFC 3600
R912003768
Edition 03

Bosch Rexroth AG EFC 3600
Record of Revision
Edition Release Date Notes
DOK-RCON03-EFC-3600***-IT01-EN-P 2013/01 First edition
DOK-RCON03-EFC-3600***-IT02-EN-P 2013/04 Firmware update
DOK-RCON03-EFC-3600***-IT03-EN-P 2014/01
Added CE, UL and
RCM certification in-
formation; added ac-
cessories information
Reference
For documentation available in other type or language, please consult your local
sales partner or check www.boschrexroth.com/EFC3600.
Copyright
© Bosch Rexroth (Xi'an) Electric Drives and Controls Co., Ltd. 2014
This document, as well as the data, specifications and other information set
forth in it, are the exclusive property of Bosch Rexroth (Xi'an) Electric Drives
and Controls Co., Ltd. It may not be reproduced or given to third parties with-
out its consent.
Liability
The specified data is intended for product description purposes only and shall
not be deemed to be a guaranteed characteristic unless expressly stipulated in
the contract. All rights are reserved with respect to the content of this docu-
mentation and the availability of the product.
RS-9fc09331c365acb30a6846a000d53c8a-3-en-US-12

English
Do not attempt to install or put these products into operation until you have
completely read, understood and observed the documents supplied with the
product.
If no documents in your language were supplied, please consult your Bosch
Rexroth sales partner.
Deutsch
Nehmen Sie die Produkte erst dann in Betrieb, nachdem Sie die mit dem
Produkt gelieferten Unterlagen und Sicherheitshinweise vollständig
durchgelesen, verstanden und beachtet haben.
Sollten Ihnen keine Unterlagen in Ihrer Landessprache vorliegen, wenden Sie
sich an Ihren zuständigen Bosch Rexroth Vertriebspartner.
Français
Ne mettez les produits en service qu'après avoir lu complètement et après avoir
compris et respecté les documents et les consignes de sécurité fournis avec le
produit.
Si vous ne disposez pas de la documentation dans votre langue, merci de
consulter votre partenaire Bosch Rexroth.
Italiano
Mettere in funzione i prodotti solo dopo aver letto, compreso e osservato per
intero la documentazione e le indicazioni di sicurezza fornite con il prodotto.
Se non dovesse essere presente la documentazione nella vostra lingua, siete
pregati di rivolgervi al rivenditore Bosch Rexroth competente.
Español
Los productos no se pueden poner en servicio hasta después de haber leído por
completo, comprendido y tenido en cuenta la documentación y las advertencias
de seguridad que se incluyen en la entrega.
Si no dispusiera de documentación en el idioma de su país, diríjase a su
distribuidor competente de Bosch Rexroth.
Português (Brasil)
Utilize apenas os produtos depois de ter lido, compreendido e tomado em
consideração a documentação e as instruções de segurança fornecidas
juntamente com o produto.
Se não tiver disponível a documentação na sua língua dirija-se ao seu parceiro
de venda responsável da Bosch Rexroth.
EFC 3600 Bosch Rexroth AG
DOK-RCON03-EFC-3600***-IT03-EN-P I

Nederlands
Stel de producten pas in bedrijf nadat u de met het product geleverde
documenten en de veiligheidsinformatie volledig gelezen, begrepen en in acht
genomen heeft.
Mocht u niet beschikken over documenten in uw landstaal, kunt u contact
opnemen met uw plaatselijke Bosch Rexroth distributiepartner.
Svenska
Använd inte produkterna innan du har läst och förstått den dokumentation och
de säkerhetsanvisningar som medföljer produkten, och följ alla anvisningar.
Kontakta din Bosch Rexroth återförsäljare om dokumentationen inte medföljer
på ditt språk.
Suomi
Ota tuote käyttöön vasta sen jälkeen, kun olet lukenut läpi tuotteen mukana
toimitetut asiakirjat ja turvallisuusohjeet, ymmärtänyt ne ja ottanut ne
huomioon.
Jos asiakirjoja ei ole saatavana omalla äidinkielelläsi, ota yhteys asianomaiseen
Bosch Rexroth myyntiedustajaan.
Český
Před uvedením výrobkůdo provozu si přečtěte kompletní dokumentaci a
bezpečnostní pokyny dodávané s výrobkem, pochopte je a dodržujte.
Nemáte-li k dispozici podklady ve svém jazyce, obraťte se na příslušného
obchodního partnera Bosch Rexroth.
Magyar
Üzembe helyezés előtt olvassa el, értelmezze, és vegye figyelembe a csomagban
található dokumentumban foglaltakat és a biztonsági útmutatásokat.
Amennyiben a csomagban nem talál az Ön nyelvén írt dokumentumokat, vegye
fel a kapcsolatot az illetékes Bosch Rexroth-képviselővel.
Polski
Produkty wolno uruchamiaćdopiero po przeczytaniu wszystkich dokumentów
dostarczonych wraz z produktem oraz wskazówek dotyczących bezpieczeństwa i
ich pełnym zrozumieniu. Wszystkich wskazówek tam zawartych należy
przestrzegać.
Jeżeli brak jest dokumentów w Państwa języku, proszęsięskontaktowaćz
lokalnym partnerem handlowym Bosch Rexroth.
Πо русски
Вводить изделие вэксплуатацию разрешается только после того, как Вы
полностью прочли, поняли иучли информацию, содержащуюся в
поставленных вместе сизделием документах, атакже указания по технике
безопасности.
Bosch Rexroth AG EFC 3600
II DOK-RCON03-EFC-3600***-IT03-EN-P

Если Вы не получили документацию на соответствующем национальном
языке, обращайтесь кполномочному представителю фирмы Bosch Rexroth.
Română
Punerea în funcţiune a produselor trebuie efectuatădupăcitirea, înţelegerea şi
respectarea documentelor şi instrucţiunilor de siguranţă, care sunt livrate
împreunăcu produsele.
În cazul în care documentele nu sunt în limba dumneavoastrămaternă,
contactaţi furnizorul dumneavoastrăcompetent pentru Bosch Rexroth.
Türkçe
Ürünleri beraberinde teslim edilen evraklarıve güvenlik talimatlarınıtamamen
okuduktan, anladıktan ve dikkate aldıktan sonrak i‚leme koyun.
Şayet size ulusal dilinizde evraklar teslim edilmemişise, sizinle ilgili olan Bosch
Rexroth dağıtım ortağınla irtibata geçin.
中文
请在完全通读、理解和遵守随同产品提供的资料和安全提示后才使用这些产品。
若产品资料还未翻译成您本国语言，请联系 Bosch Rexroth 相应的销售伙伴。
日本語
本製品をお使いになる前に、必ず同封の文書および安全注意事項を全部お読みになり
理解した上で指示に従って本製品を使用していただきますようお願いいたします。
同封の文書がお客様の言語で書かれていない場合は、どうぞ Bosch Rexroth 製品の販
売契約店までお問い合わせください。
한국어
먼저 회사의 제품을 받으신 다음 제품과 함께 배송된 안내서 및안전에 관한 지침서를
충분히 숙지하여 이를 준수하여 주십시오.
귀하의 모국어로 된안내서가 배송되지 않았다면 Bosch Rexroth 대리점에 알려주시기
바랍니다.
EFC 3600 Bosch Rexroth AG
DOK-RCON03-EFC-3600***-IT03-EN-P III

Bosch Rexroth AG EFC 3600
IV DOK-RCON03-EFC-3600***-IT03-EN-P

Table of Contents Page
1 Introduction to the Documentation....................................................... 1
2 Safety Instructions for Electric Drives and Controls.............................. 2
2.1 Definitions of Terms.............................................................................. 2
2.2 Explanation of Signal Words and the Safety Alert Symbol.................... 3
2.3 General Information............................................................................... 4
2.3.1 Using the Safety Instructions and Passing Them on to Others.............. 4
2.3.2 Requirements for Safe Use.................................................................... 4
2.3.3 Hazards by Improper Use....................................................................... 6
2.4 Instructions with Regard to Specific Dangers....................................... 6
2.4.1 Protection Against Contact With Electrical Parts and Housings............ 6
2.4.2 Protective Extra-Low Voltage as Protection Against Electric Shock ..... 8
2.4.3 Protection Against Dangerous Movements............................................ 8
2.4.4 Protection Against Magnetic and Electromagnetic Fields During Op-
eration and Mounting........................................................................... 10
2.4.5 Protection Against Contact with Hot Parts.......................................... 10
2.4.6 Protection During Handling and Mounting.......................................... 11
3 Important Directions for Use............................................................... 12
3.1 Appropriate Use................................................................................... 12
3.2 Inappropriate Use................................................................................ 12
4 Delivery and Storage............................................................................ 13
4.1 Product Identification.......................................................................... 13
4.1.1 Checking Information on Packing Nameplate...................................... 13
4.1.2 Checking Information on Frequency Converter Nameplate................. 14
4.1.3 Visual Inspection of the Frequency Converter..................................... 14
4.2 The Scope of Supply............................................................................ 15
4.3 Transport of the Components............................................................. 16
4.4 Storage of the Components................................................................. 16
5 Mounting and Installation.................................................................... 17
5.1 EFC 3600 Dimensions Figure............................................................... 17
5.2 EFC 3600 Dimensions.......................................................................... 19
5.3 EFC 3600 Mounting............................................................................. 20
5.4 Block Diagram...................................................................................... 23
5.5 Notes on Main Circuit Wiring............................................................... 24
EFC 3600 Bosch Rexroth AG
Table of Contents
DOK-RCON03-EFC-3600***-IT03-EN-P V

Page
5.6 Main Circuit Wiring Diagram................................................................ 26
5.7 Main Circuit Terminals......................................................................... 27
5.8 Main Circuit Terminals Description..................................................... 27
5.9 Cable and Fuse Dimensions................................................................. 28
5.9.1 Selection Standards............................................................................ 28
5.9.2 Recommendation on Cable Dimensioning........................................... 29
5.9.3 Recommendation for Design of the Fuses........................................... 30
5.10 Main Circuit Wiring Steps.................................................................... 30
5.11 Grounding Screw Removal of Internal EMC Filter............................... 31
5.12 Notes on Control Circuit Wiring........................................................... 32
5.13 Control Circuit Terminals..................................................................... 32
5.14 Control Circuit Terminals Description................................................. 33
5.15 NPN / PNP Switch SW for the Digital Inputs....................................... 34
5.16 NPN and PNP Modes........................................................................... 35
5.17 Analog Input Terminals (+10 V, Vr1, GND,+I)....................................... 36
5.18 Recommendations on Control Circuit Wiring...................................... 36
5.19 Control Circuit Wiring Steps................................................................ 37
6 Operating Panel................................................................................... 38
6.1 Figure and Description........................................................................ 38
6.2 Seven-segment Display........................................................................ 38
6.3 LED Indicator....................................................................................... 39
6.4 Menu Structure.................................................................................... 40
6.5 Operating Mode................................................................................... 41
6.6 Operating Example.............................................................................. 41
7 Commissioning.................................................................................... 42
7.1 Checking and Preparation before Commissioning............................... 42
7.2 Commissioning Process....................................................................... 43
7.3 EFC 3600 Basic Parameters Fast Settings........................................... 44
7.4 Restore Parameters to Factory Defaults.............................................. 45
7.5 Solutions for Simple Errors during Commissioning............................. 45
8 Parameter Settings.............................................................................. 46
8.1 Group b0: System Parameters............................................................. 46
8.1.1 Password and Access Control............................................................. 46
8.1.2 System Configuration.......................................................................... 48
8.1.3 Frequency Converter Configuration..................................................... 49
8.1.4 Monitoring Display............................................................................... 50
Bosch Rexroth AG
Table of Contents EFC 3600
VI DOK-RCON03-EFC-3600***-IT03-EN-P

Page
8.1.5 System Information............................................................................. 52
8.2 Group b1: Basic Parameters................................................................ 53
8.2.1 Basic Running Control......................................................................... 53
8.2.2 Acceleration/deceleration Control....................................................... 59
8.2.3 Starting configuration.......................................................................... 62
8.2.4 Stopping Configuration........................................................................ 64
8.3 Group S0: V/F Control......................................................................... 68
8.3.1 V/F Curve............................................................................................. 68
8.3.2 Enhanced V/F Control.......................................................................... 72
8.3.3 No-trip Control..................................................................................... 76
8.4 Group S2: Motor Parameters............................................................... 78
8.4.1 Motor Nameplate Parameters.............................................................. 78
8.4.2 Motor Physical Data............................................................................. 79
8.4.3 Motor Thermal Protection.................................................................... 80
8.5 Group S3: Running Parameters........................................................... 82
8.5.1 Jogging Parameters............................................................................. 82
8.5.2 Skip Frequency.................................................................................... 83
8.5.3 Restarting after Power Fault................................................................ 84
8.5.4 Brake Chopper Control........................................................................ 85
8.5.5 Additional Running Control.................................................................. 86
8.6 Group E0: Input Terminal Parameters................................................. 88
8.6.1 Multi-function Digital Input Terminals................................................. 88
8.6.2 Analog Input Channel Gain.................................................................. 94
8.6.3 Analog Input Filtering Time.................................................................. 95
8.6.4 Analog Input Curve Configuration........................................................ 95
8.7 Group E1: Output Terminal Parameters.............................................. 98
8.7.1 Multi-function Output Terminals.......................................................... 98
8.7.2 Frequency Detection.......................................................................... 101
8.7.3 Overload Pre-warning........................................................................ 103
8.7.4 External Signal Counter..................................................................... 104
8.7.5 Analog Output Terminal..................................................................... 105
8.8 Group E2: Multi-speed and Simple PLC............................................ 106
8.8.1 Acceleration/deceleration time 2, 3 and 4......................................... 106
8.8.2 Multi-speed Frequency...................................................................... 106
8.8.3 Simple PLC Basic Control.................................................................. 108
8.8.4 PLC Stage Control............................................................................. 108
8.9 Group E3: PID Control....................................................................... 111
8.9.1 PID Basic Configuration..................................................................... 111
EFC 3600 Bosch Rexroth AG
Table of Contents
DOK-RCON03-EFC-3600***-IT03-EN-P VII

Page
8.9.2 PID Control........................................................................................ 112
8.10 E4: Error and Protection.................................................................... 115
8.10.1 Protection Configuration................................................................... 115
8.10.2 Error Reset......................................................................................... 120
8.10.3 Error Code Memory........................................................................... 120
8.10.4 System Status at the Latest Error..................................................... 121
8.11 Group H0: Communication................................................................ 122
9 Diagnosis........................................................................................... 124
9.1 Diagnosis Messages when Booting the Device.................................. 124
9.2 Diagnosis on Parameter Backup ....................................................... 124
9.3 Diagnosis for Power Down/Drop....................................................... 124
9.3.1 In Stop State...................................................................................... 124
9.3.2 In Run State....................................................................................... 125
9.4 Diagnosis on Warnings....................................................................... 125
9.5 Diagnosis on Errors............................................................................ 126
9.5.1 Error Description and Solution.......................................................... 126
9.5.2 Error Reactions of the Frequency Converter..................................... 136
9.5.3 Clearing an Error Message................................................................. 136
9.5.4 Error Memory..................................................................................... 136
9.5.5 Automatic Error Reset....................................................................... 136
10 Technical Data................................................................................... 137
10.1 General Technical Data...................................................................... 137
10.2 Electrical Data.................................................................................... 139
10.3 Derating of Electrical Data................................................................. 139
10.3.1 Derating and Ambient Temperature................................................... 139
10.3.2 Derating and Mains Voltage............................................................... 140
10.3.3 Derating and Output Current............................................................. 140
11 Electromagnetic Compatibility (EMC)............................................... 141
11.1 EMC Requirements............................................................................ 141
11.1.1 General Information........................................................................... 141
11.1.2 Noise Immunity in the Drive System.................................................. 141
11.1.3 Noise Emission of the Drive System.................................................. 144
11.2 Ensuring the EMC Requirements....................................................... 148
11.3 EMC Measures for Design and Installation........................................ 149
11.3.1 Rules for Design of Installations with Drive Controllers in Compli-
ance with EMC................................................................................... 149
Bosch Rexroth AG
Table of Contents EFC 3600
VIII DOK-RCON03-EFC-3600***-IT03-EN-P

Page
11.3.2 EMC-optimal Installation in Facility and Control Cabinet.................. 151
11.3.3 Control Cabinet Mounting according to Interference Areas – Exem-
plary Arrangements............................................................................ 153
11.3.4 Design and Installation in Area A – Interference-free Area of Control
Cabinet.............................................................................................. 154
11.3.5 Design and Installation in Area B – Interference-susceptible Area of
Control Cabinet................................................................................. 156
11.3.6 Design and Installation in Area C – Strongly Interference-susceptible
Area of Control Cabinet..................................................................... 156
11.3.7 Ground Connections.......................................................................... 157
11.3.8 Installing Signal Lines and Signal Cables........................................... 158
11.3.9 General Measures of Radio Interference Suppression for Relays,
Contactors, Switches, Chokes and Inductive Loads.......................... 159
12 Accessories........................................................................................ 160
12.1 Mains Choke...................................................................................... 160
12.1.1 Mains Choke Selection...................................................................... 160
12.1.2 Dimensions........................................................................................ 160
12.1.3 Electrical data.................................................................................... 164
12.2 EMC Filter.......................................................................................... 165
12.2.1 The Function of EMC Filter................................................................ 165
12.2.2 External EMC Filter Type................................................................... 165
12.2.3 Technical Data................................................................................... 165
12.3 Brake Resistor.................................................................................... 171
12.3.1 Brief Introduction.............................................................................. 171
12.3.2 Brake Resistor Selection.................................................................... 171
12.3.3 Brake Resistor in Aluminum Housing................................................. 174
12.4 Motor Choke...................................................................................... 176
12.4.1 Motor Choke Selection...................................................................... 176
12.4.2 Dimensions........................................................................................ 177
12.4.3 Electrical data.................................................................................... 179
12.5 Communication Interface.................................................................. 179
12.5.1 RS485/RS232 Adapter....................................................................... 179
12.5.2 Cable for RS485/RS232 Adapter....................................................... 179
12.6 Operating Panel Cable for Control Cabinet Mounting....................... 179
12.6.1 Control Cabinet Mounting Plate........................................................ 179
12.6.2 Operating Panel Cable for Control Cabinet Mounting....................... 182
12.7 Accessories for Shielded Cable Connection...................................... 182
13 Communication Protocols................................................................. 184
EFC 3600 Bosch Rexroth AG
Table of Contents
DOK-RCON03-EFC-3600***-IT03-EN-P IX

Page
13.1 Brief Introduction.............................................................................. 184
13.2 ModBus Protocol............................................................................... 184
13.2.1 Protocol Description.......................................................................... 184
13.2.2 ModBus Interface............................................................................... 186
13.2.3 ModBus Function and Message Format............................................. 187
13.2.4 Communication Mapping Register Address Distribution................... 195
13.2.5 ModBus Communication Example..................................................... 198
13.2.6 Special Notes..................................................................................... 199
13.2.7 Communication Networking.............................................................. 199
13.3 PROFIBUS Protocol........................................................................... 201
13.3.1 Protocol Description.......................................................................... 201
13.3.2 PROFIBUS Function........................................................................... 201
13.3.3 PROFIBUS Interface........................................................................... 202
13.3.4 Requirements for PROFIBUS Link..................................................... 202
13.3.5 Relationship between Communication Rate and Cables................... 203
13.3.6 EMC Measures................................................................................... 203
13.3.7 Periodical Data Communication........................................................ 203
14 Maintenance...................................................................................... 211
14.1 Safety Instructions............................................................................. 211
14.2 Daily Inspection................................................................................. 211
14.3 Periodic Inspection............................................................................ 212
14.4 Operating Panel Removal and Mounting............................................ 213
14.5 Fan Removal and Mounting................................................................ 215
15 Service and Support.......................................................................... 217
16 Environmental Protection and Disposal ............................................ 218
16.1 Environmental Protection.................................................................. 218
16.2 Disposal............................................................................................. 218
17 Appendix............................................................................................ 220
17.1 Appendix 1: Abbreviations................................................................. 220
17.2 Appendix 2: Parameter List............................................................... 220
17.2.1 Description of Attribute Symbols in Parameter Tables...................... 220
17.2.2 Group b0: System Parameters........................................................... 221
17.2.3 Group b1: Basic Parameters.............................................................. 223
17.2.4 Group S0: V/F control........................................................................ 226
17.2.5 Group S2: Motor Parameters............................................................. 227
Bosch Rexroth AG
Table of Contents EFC 3600
XDOK-RCON03-EFC-3600***-IT03-EN-P

Page
17.2.6 Group S3: Running Parameters......................................................... 228
17.2.7 Group E0: Input Terminals................................................................. 230
17.2.8 Group E1: Output Terminals.............................................................. 232
17.2.9 Group E2: Multi-speed and Simple PLC............................................ 234
17.2.10Group E3: PID Control....................................................................... 236
17.2.11Group E4: Error and Protection......................................................... 237
17.2.12Group H0: Communication................................................................ 240
17.2.13Group d: Monitoring Parameters....................................................... 241
17.3 Appendix 3: Type Coding................................................................... 242
17.3.1 EFC 3600 Type Coding...................................................................... 242
17.3.2 Type Coding of EFC 3600 Function Modules..................................... 243
17.3.3 Type Coding of EFC 3600 Accessories.............................................. 244
17.4 Appendix 4: Certification................................................................... 251
17.4.1 CE...................................................................................................... 251
17.4.2 UL...................................................................................................... 252
17.4.3 RCM................................................................................................... 253
Index.................................................................................................. 255
EFC 3600 Bosch Rexroth AG
Table of Contents
DOK-RCON03-EFC-3600***-IT03-EN-P XI

Bosch Rexroth AG EFC 3600
XII DOK-RCON03-EFC-3600***-IT03-EN-P

1 Introduction to the Documentation
Personal injury and property damage caused by
incorrect operations of applications, machines
and installations!
WARNING
Do not attempt to install or put these products into operation until you have
completely read, understood and observed the documents supplied with the
product.
If no documents in your language were supplied, please consult your
Bosch Rexroth sales partner.
Chapters and Contents
Chapter Title Description
1 IntroductiontotheDocumentation Overview
2 SafetyInstructionsforElectricDrivesandControls Safetycautions
3 ImportantDirectionsforUse
4 DeliveryandStorage Productinformation
5 MountingandInstallation
6 OperatingPanel
Actualapplications
(foroperatorsandrepairers)
7 Commissioning
8 ParameterSettings
9 Diagnosis
10 TechnicalData
11 ElectromagneticCompatibility(EMC)
12 Accessories
13 CommunicationProtocols
14 Maintenance Maintenanceinformation
15 ServiceandSupport Serviceinformation
16 EnvironmentalProtectionandDisposal Environmentalinformation
17 Appendix Additionalinformation
– Index Indexinformation
Tab. 1-1: Chapters and contents
Feedback
Your experience is important for us to improve products and this Operating In-
structions. We will be pleased to receive your feedback on any mistake or re-
quest for variation.
Please send your feedback via email to: [email protected]
EFC 3600 Bosch Rexroth AG
Introduction to the Documentation
DOK-RCON03-EFC-3600***-IT03-EN-P 1/259

2 Safety Instructions for Electric Drives and Controls
2.1 Definitions of Terms
Documentation
A documentation comprises the entire documentation used to inform the user of
the product about the use and safety-relevant features for configuring, integrat-
ing, mounting, installing, commissioning, operating, maintaining, repairing and
decommissioning the product. The following terms are also used for this kind of
documentation: Operating Instructions, Instruction Manual, Commissioning
Manual, Application Description, Assembly Instructions, Project Planning Man-
ual, Safety Notes, Product Insert, etc.
Component
A component is a combination of elements with a specified function, which are
part of a piece of equipment, device or system. Components of the electric drive
and control system are, for example, supply units, drive controllers, mains
choke, mains filter, motors, cables, etc.
Control System
A control system comprises several interconnected control components placed
on the market as a single functional unit.
Device
A device is a finished product with a defined function, intended for users and
placed on the market as an individual piece of merchandise.
Electrical Equipment
Electrical equipment encompasses all devices used to generate, convert, trans-
mit, distribute or apply electrical energy, such as electric motors, transformers,
switching devices, cables, lines, power-consuming devices, circuit board assem-
blies, plug-in units, control cabinets, etc.
Electric Drive System
An electric drive system comprises all components from mains supply to motor
shaft; this includes, for example, electric motor(s), motor encoder(s), supply
units and drive controllers, as well as auxiliary and additional components, such
as mains filter, mains choke and the corresponding lines and cables.
Installation
An installation consists of several devices or systems interconnected for a de-
fined purpose and on a defined site which, however, are not intended to be
placed on the market as a single functional unit.
Machine
A machine is the entirety of interconnected parts or units at least one of which
is movable. Thus, a machine consists of the appropriate machine drive ele-
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls EFC 3600
2/259 DOK-RCON03-EFC-3600***-IT03-EN-P

ments, as well as control and power circuits, which have been assembled for a
specific application. A machine is, for example, intended for processing, treat-
ment, movement or packaging of a material. The term "machine" also covers a
combination of machines which are arranged and controlled in such a way that
they function as a unified whole.
Manufacturer
The manufacturer is an individual or legal entity bearing responsibility for the
design and manufacture of a product which is placed on the market in the indi-
vidual's or legal entity's name. The manufacturer can use finished products, fin-
ished parts or finished elements, or contract out work to subcontractors. How-
ever, the manufacturer must always have overall control and possess the re-
quired authority to take responsibility for the product.
Product
Examples of a product: Device, component, part, system, software, firmware,
among other things.
Qualified Persons
In terms of this application documentation, qualified persons are those persons
who are familiar with the installation, mounting, commissioning and operation of
the components of the electric drive and control system, as well as with the haz-
ards this implies, and who possess the qualifications their work requires. To
comply with these qualifications, it is necessary, among other things,
1) to be trained, instructed or authorized to switch electric circuits and devices
safely on and off, to ground them and to mark them
2) to be trained or instructed to maintain and use adequate safety equipment
3) to attend a course of instruction in first aid
User
A user is a person installing, commissioning or using a product which has been
placed on the market.
2.2 Explanation of Signal Words and the Safety Alert Symbol
The Safety Instructions in the available application documentation contain spe-
cific signal words (DANGER, WARNING, CAUTION or NOTICE) and, where re-
quired, a safety alert symbol (in accordance with ANSI Z535.6-2011).
The signal word is meant to draw the reader's attention to the safety instruction
and identifies the hazard severity.
The safety alert symbol (a triangle with an exclamation point), which precedes
the signal words DANGER, WARNING and CAUTION, is used to alert the reader
to personal injury hazards.
EFC 3600 Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON03-EFC-3600***-IT03-EN-P 3/259

DANGER
In case of non-compliance with this safety instruction, death or serious injury
will occur.
WARNING
In case of non-compliance with this safety instruction, death or serious injury
could occur.
CAUTION
In case of non-compliance with this safety instruction, minor or moderate injury
could occur.
NOTICE
In case of non-compliance with this safety instruction, property damage could
occur.
2.3 General Information
2.3.1 Using the Safety Instructions and Passing Them on to Others
Do not attempt to install and operate the components of the electric drive and
control system without first reading all documentation provided with the prod-
uct. Read and understand these safety instructions and all user documentation
prior to working with these components. If you do not have the user documenta-
tion for the components, contact your responsible Bosch Rexroth sales partner.
Ask for these documents to be sent immediately to the person or persons re-
sponsible for the safe operation of the components.
If the component is resold, rented and/or passed on to others in any other form,
these safety instructions must be delivered with the component in the official
language of the user's country.
Improper use of these components, failure to follow the safety instructions in
this document or tampering with the product, including disabling of safety devi-
ces, could result in property damage, injury, electric shock or even death.
2.3.2 Requirements for Safe Use
Read the following instructions before initial commissioning of the components
of the electric drive and control system in order to eliminate the risk of injury
and/or property damage. You must follow these safety instructions.
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls EFC 3600
4/259 DOK-RCON03-EFC-3600***-IT03-EN-P

●Bosch Rexroth is not liable for damages resulting from failure to observe the
safety instructions.
●Read the operating, maintenance and safety instructions in your language be-
fore commissioning. If you find that you cannot completely understand the
application documentation in the available language, please ask your supplier
to clarify.
●Proper and correct transport, storage, mounting and installation, as well as
care in operation and maintenance, are prerequisites for optimal and safe op-
eration of the component.
●Only qualified persons may work with components of the electric drive and
control system or within its proximity.
●Only use accessories and spare parts approved by Bosch Rexroth.
●Follow the safety regulations and requirements of the country in which the
components of the electric drive and control system are operated.
●Only use the components of the electric drive and control system in the man-
ner that is defined as appropriate. See chapter "Appropriate Use".
●The ambient and operating conditions given in the available application docu-
mentation must be observed.
●Applications for functional safety are only allowed if clearly and explicitly
specified in the application documentation "Integrated Safety Technology". If
this is not the case, they are excluded. Functional safety is a safety concept in
which measures of risk reduction for personal safety depend on electrical,
electronic or programmable control systems.
●The information given in the application documentation with regard to the
use of the delivered components contains only examples of applications and
suggestions.
The machine and installation manufacturers must
–make sure that the delivered components are suited for their individual ap-
plication and check the information given in this application documenta-
tion with regard to the use of the components,
–make sure that their individual application complies with the applicable
safety regulations and standards and carry out the required measures,
modifications and complements.
●Commissioning of the delivered components is only allowed once it is sure
that the machine or installation in which the components are installed com-
plies with the national regulations, safety specifications and standards of the
application.
●Operation is only allowed if the national EMC regulations for the application
are met.
●The instructions for installation in accordance with EMC requirements can be
found in the section on EMC in the respective application documentation.
The machine or installation manufacturer is responsible for compliance with
the limit values as prescribed in the national regulations.
EFC 3600 Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls
DOK-RCON03-EFC-3600***-IT03-EN-P 5/259

●The technical data, connection and installation conditions of the components
are specified in the respective application documentations and must be fol-
lowed at all times.
National regulations which the user must take into account
●European countries: In accordance with European EN standards
●United States of America (USA):
– National Electrical Code (NEC)
–National Electrical Manufacturers Association (NEMA), as well as local engi-
neering regulations
– Regulations of the National Fire Protection Association (NFPA)
●Canada: Canadian Standards Association (CSA)
●Other countries:
– International Organization for Standardization (ISO)
– International Electrotechnical Commission (IEC)
2.3.3 Hazards by Improper Use
●High electrical voltage and high working current! Danger to life or serious in-
jury by electric shock!
●High electrical voltage by incorrect connection! Danger to life or injury by
electric shock!
●Dangerous movements! Danger to life, serious injury or property damage by
unintended motor movements!
●Health hazard for persons with heart pacemakers, metal implants and hearing
aids in proximity to electric drive systems!
●Risk of burns by hot housing surfaces!
●Risk of injury by improper handling! Injury by crushing, shearing, cutting, hit-
ting!
●Risk of injury by improper handling of batteries!
●Risk of injury by improper handling of pressurized lines!
2.4 Instructions with Regard to Specific Dangers
2.4.1 Protection Against Contact With Electrical Parts and Housings
This section concerns components of the electric drive and control
system with voltages higher than 50 volts.
Bosch Rexroth AG
Safety Instructions for Electric Drives and Controls EFC 3600
6/259 DOK-RCON03-EFC-3600***-IT03-EN-P
