RGBlink VENUS X1 PRO-E User manual

Article No: RGB-RD-UM-X1PRO-E E001
Revision No: V1.1
VENUS X1PRO-E
USER MANUAL

VENUS X1PRO-E User Manual
1
CONTENTS
CONTENTS........................................................................................................................................................ 1
Declarations.....................................................................................................................................................3
FCC/Warranty.......................................................................................................................................... 3
Operators Safety Summary......................................................................................................................4
Installation Safety Summary.................................................................................................................... 4
Chapter 1 Your Product.................................................................................................................................... 6
1.1 In the Box........................................................................................................................................... 6
1.2 Product Overview.............................................................................................................................. 7
1.2.1 Rear Panel............................................................................................................................... 8
1.2.2 Front Panel............................................................................................................................10
1.2.3 Dimension.............................................................................................................................12
Chapter 2 Installing Your Product.................................................................................................................. 13
2.1 Plugging in Signals............................................................................................................................13
2.2 Plugging in Main Power................................................................................................................... 13
2.3 Turning on Your Product..................................................................................................................13
Chapter 3 Using Your Product........................................................................................................................ 15
3.1 Using the MENU Button...................................................................................................................15
3.2 Understanding the MENU Structure............................................................................................... 16
3.3 Using the Menu................................................................................................................................17
3.3.1 Understanding the Display................................................................................................... 17
3.3.2 Understanding the Main Menu............................................................................................ 18
3.3.3 Mode Menu.......................................................................................................................... 18
3.3.4 Advanced Menu....................................................................................................................19
3.3.5 Language Menu.................................................................................................................... 22
3.3.6 Factory Reset Menu..............................................................................................................22
3.4 Standard Mode................................................................................................................................ 23
3.4.1 Single Image Switching......................................................................................................... 23
3.4.2 Set the Output Resolution....................................................................................................23
3.4.3 Set the Image Select............................................................................................................. 25
3.5 Split Mode........................................................................................................................................28
3.5.1 Split Mode.............................................................................................................................28
3.5.2 Multi- Split............................................................................................................................ 32
3.6 Preview Mode.................................................................................................................................. 35
3.7 Standard Alone Mode......................................................................................................................39
3.8 Output Brightness............................................................................................................................40
3.9 Logo Setting..................................................................................................................................... 41
3.10 Using Black Out..............................................................................................................................42
3.11 Saving Views...................................................................................................................................43
3.12 Recall Saved Settings......................................................................................................................44
Chapter 4 Ordering Codes..............................................................................................................................45
4.1 Product.............................................................................................................................................45
4.2 Options.............................................................................................................................................45

VENUS X1PRO-E User Manual
2
4.2.1 Input Options........................................................................................................................ 45
4.2.2 Output Options.....................................................................................................................45
Chapter 5 Support ........................................................................................................................................ 46
5.1 Questions and Troubleshooting.......................................................................................................46
5.2 Contact Us........................................................................................................................................48
Chapter 6 Appendix........................................................................................................................................49
6.1 Specification.....................................................................................................................................49
6.2 Software Upgrade............................................................................................................................ 55
6.2.1Use XTOOL to upgrade the software.....................................................................................55
6.2.2 Upgrade the software by USB disk.......................................................................................62
6.3 Terms & Definitions......................................................................................................................... 63
6.4 Revision History............................................................................................................................... 68

VENUS X1PRO-E User Manual
3
Thank you for choosing our product!
This User Manual is designed to show you how to use this video processor quickly and make use of all
the features. Please read all directions and instructions carefully before using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area may cause harmful interference, in which case the user will be
responsible for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally stipulated
terms of guarantee. On receipt, the purchaser must immediately inspect all delivered goods for
damage incurred during transport, as well as for material and manufacturing faults. RGBlink must be
informed immediately in writing of any complains.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and
software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of
justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion
within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can
demand a reduction in the purchase price or cancellation of the contract. All other claims, in particular
those relating to compensation for direct or indirect damage, and also damage attributed to the
operation of software as well as to other service provided by RGBlink, being a component of the system
or independent service, will be deemed invalid provided the damage is not proven to be attributed to
the absence of properties guaranteed in writing or due to the intent or gross negligence or part of
RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if
the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if,
after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all
guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are
system failures which are attributed to programs or special electronic circuitry provided by the purchaser,
e.g. interfaces. Normal wear as well as normal maintenance are not subject to the guarantee provided by
RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in this

VENUS X1PRO-E User Manual
4
manual must be complied with by the customer.
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous
voltages. To avoid personal injury, do not remove the top cover. Do not operate the unit without the
cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts rms
between the supply conductors or between both supply conductor and ground. A protective ground
connection by way of grounding conductor in the power cord is essential for safe operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical shock,
plug the power cord into a properly wired receptacle before connecting to the product input or output
terminals. A protective-ground connection by way of the grounding conductor in the power cord is
essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is in good
condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating
characteristics. Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
Installation Safety Summary
Safety Precautions
For all VENUS X1PRO-E processor installation procedures, please observe the following important safety
and handling rules to avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire
provided in the AC power Cord.

VENUS X1PRO-E User Manual
5
The AC Socket-outlet should be installed near the equipment and be easily accessible.
Unpacking and Inspection
Before opening VENUS X1PRO-E processor shipping box, inspect it for damage. If you find any damage,
notify the shipping carrier immediately for all claims adjustments. As you open the box, compare its
contents against the packing slip. If you find any shortages, contact your sales representative.
Once you have removed all the components from their packaging and checked that all the listed
components are present, visually inspect the system to ensure there was no damage during shipping. If
there is damage, notify the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your VENUS X1PRO-E should be clean, properly lit, free from static,
and have adequate power, ventilation, and space for all components.

Chapter 1: Your Product
VENUS X1PRO-E User Manual
6
Chapter 1 Your Product
1.1 In the Box
Note:
AC Power Cable supplied as standard according to destination market.
Screw driver color is random.
AC Power Cord
DVI Cable
Screw Driver
Antistatic Bag
DB9 to RJ11
Cable

Chapter 1: Your Product
VENUS X1PRO-E User Manual
7
1.2 Product Overview
Professional 4K scaling and switching.
VENUS X1PRO-E enables 4K switching, scaling and signal distribution to 2k display devices. It
supports up to 4K input signals with Dual Link DVI, HDMI and Display Port. With independent
scaling for each output, support Matrix for input and output, up to 8K1K or 4K2K pixel-to- pixel
output.
VENUS X1PRO-E with features like LOGO capture and standard test pattern built in, EDID
management. Seamless switching between the inputs. Support remotely configured and control
by XPOSE and XPOSE mobile.
Modular design is based on replaceable input optional modules structure, provide 3 slots for
input option modules, you can reach more possibility and application range.

Chapter 1: Your Product
VENUS X1PRO-E User Manual
8
1.2.1 Rear Panel
Input Connectors
13
DVI-I DVI
Standard DVI signals can be input, compatible HDMI1.3
11
4K DVI2 IN(HDMI)
Standard DVI and 4K DVI signals can be input, compatible HDMI1.4 & 4K HDMI
signals.
10
4K DP IN
Standard DisplayPort and 4K DisplayPort signals can be input.
Input Option Slots
1.2.3
Input Optional Slots
Range of inputs are available for user fitting.
DVI\SDI\HDMI\VGA\USB\CVBS\DP
Output Connectors
5
DVI1-DVI4 Output Backup
4 x DVI output, connect to the monitor.
8
DVI-I – DVI
4 x DVI output, connect to the monitor or LED display which has DVI interface.
9
DP Loop Output
Connect to the DP input of the next VENUS X1PRO-E or the device with DP input.
12
DVI Loop Output
Connect to the DVI input of the next VENUS X1PRO-E or the device with DVI or
HDMI input.
Control Connectors
4
RS232 Interface
Use for system upgrade or remote control by windows software.

Chapter 1: Your Product
VENUS X1PRO-E User Manual
9
Power Connection
6
Power Switch
Illuminated power switch.
7
IEC – Power Input
Main power input AC 85-264V Max 65W.

Chapter 1: Your Product
VENUS X1PRO-E User Manual
10
1.2.2 Front Panel
Display
1
OLED Display: Displays current status of the product, and for feature selections
provides interactive choices in conjunction with buttons on the front panel.
Multi-Function Buttons
2
Rotary Button: This button used for menu selections and confirmation.
Illuminated Buttons
3
MENU Button
Menu and back button.
Push the button again will return to the last level menu or exit the menu.
Push the button twice to enter the effect switch function menu.
Push the button for 3 seconds will lock the front panel, and push the button for 5
seconds to unlock.
Push the MENU and TAKE button for 3 seconds will switch the language.
4
SCALE Button
This button used for size and position adjusting.
It reused as the stop and play button for the USB signal.
5
SAVE Button
Save all current settings with the VENUS X1PRO-E to 1 of the 36 available slots.
Additionally, this button is used for direct numeric entry for numbers 1.
6
Dedicated Signal Buttons
For each of inputs on the back panel a dedicated back-lit buttons are provided. When lit,
the signal is selected for use, when red light is flashing, signal is in preview or the signal
is not available.
Additionally, each button is numbered and can be used as direct number entry when

Chapter 1: Your Product
VENUS X1PRO-E User Manual
11
values such as resolution and size.
7
LOGO Button
LOGO load &LOGO Capture shortcut button.
8
OUT BRIGHT
Shortcut button for output Setting, output Brightness Setting, and 4K Input Signal
switch.
9
SPLIT Button
Split function button.
10
LOAD Button
Restores/Loads all current settings with the VENUS X1PRO-E from 1 of the 24
available slots.
Additionally, this button is used for direct numeric entry for numbers 6.
11
MODULE Buttons
If optional input module is fitted, then these three buttons operate as per Dedicated
Signal Buttons above.
Additionally, these buttons are used for direct numeric entry for numbers 7/8/9.
12
BLACK Button
Black button.
Additionally, this button is used for direct numeric entry for number 0.
13
TAKE Button
To preview the selected signal and take it to output.
14
USB Connector
For system upgrade.

Chapter 1: Your Product
VENUS X1PRO-E User Manual
12
1.2.3 Dimension
Following is the dimension of VENUS X1PRO-E for your reference:

VENUS X1PRO-E User Manual
13
Chapter 2 Installing Your Product
2.1 Plugging in Signals
Connect signals to the product (ensure all devices are powered off first). Tighten connector
screws/locks where provided.
For connector protection and for additional cable support this product is fitted with protection
frames on either side of the device. For cable support use cable ties to attached to the protection
frames to avoid stress on signal connectors.
2.2 Plugging in Main Power
Connect IEC cable to device and plug into wall socket. Turn on power at wall socket.
2.3 Turning on Your Product
Turn the power switch on the rear of the product to the ON position.
OLED display will show as below, completing initialization before loading last settings and
input/output configuration.

Chapter 2: Installing Your Product
VENUS X1PRO-E User Manual
14
VENUS X1PRO-E
Init Device Finished!
Input 1 DVI1:NO INPUT
SV: 0.99 SN:1397
System Mode :Standard
Output Resolution :720x480x60

VENUS X1PRO-E User Manual
15
Chapter 3 Using Your Product
3.1 Using the MENU Button
Push the [MENU] button to enter the menu display.
Turn the rotary knob to navigate to the menu item required. The symbol shows the current
item. Push the knob to select and enter into the menu item.
As shown in the figure below:

Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
16
3.2 Understanding the MENU Structure
The MENU structure is shown in the figure below:
+

Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
17
3.3 Using the Menu
Use the menu system for convenient and intuitive operation. VENUS X1PRO-E OLED display
shows the menu items. The OLED display will show the default state when the menu is not in use,
or the operation has timed out. Using the MENU button and rotary knob in the front panel, the
OLED display will show the corresponding menus according to user selections.
3.3.1 Understanding the Display
Turn the power switch to the ON position, the OLED display will show the start-up interface and
show the default menu after completing initialization as below:
Introduce for the above information:
1
Input Signal
Shows the current Input signal that is selected. The related dedicated signal button
will be lit red.
2
Input Resolution
Show the current input resolution from the selected Input source. To configure input
resolutions, use the EDID Management features. A wide range of input resolutions are
supported depending the input – refer to Specification.
If a # symbol is show after the resolution, then a custom resolution is being used.
3
Software version
Shows the software version of the product.
When not displayed here, the serial number can be found via the TECH SUPPORT
menu.
4
Serial Number
Shows the serial of the product.
When not displayed here, the serial number can be found via the TECH SUPPORT

Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
18
->Standard >>
Split >>
Preview >>
Stand Alone Mode >>
->Advanced >>
语言/Language English
Factory Reset >>
->Standard >>
Split >>
Preview >>
Stand Alone Mode >>
menu.
5
System Mode
Show the default system mode.
6
Output Resolution
Show the current output resolution. To configure output resolutions, use the OUTPUT
menu. A wide range of resolutions are supported – refer to Specification.
If a # symbol is show after the resolution, then a custom resolution is being used.
3.3.2 Understanding the Main Menu
Push the MENU button in the default state and turn the rotary knob, the OLED display will show
the main menus as below:
There are 7 menu items in the main menu, and display in 2 pages. Turn the rotary knob, and
select any menu above, push the rotary knob to confirm, the OLED display will show the
submenu. If push the MENU button, the OLED display will return to the last level menu.
3.3.3 Mode Menu
Standard Mode
Select standard resolution or custom the resolution.
Thirteen Image Select Modes for selection.
For details, please refer to Standard Mode.
Split Mode
Select standard resolution or custom the resolution.
Twelve Split Mode and Multi-Split Mode for selection.
For details, please refer to Split Mode.

Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
19
-> Output Brightness >>
Hot Backup >>
Input Adjust >>
Output Adjust >>
-> LOGO Setting >>
Test Pattern >>
Save Setting >>
System Setting >>
Preview Mode
Select standard resolution or custom the resolution.
Four Presentation Modes for selection.
For details, please refer to Preview Mode.
Stand Alone
Mode
Setting four DVI Alone output and EDID setting.
For details, please refer to Stand Alone Mode.
3.3.4 Advanced Menu
Output Brightness
Adjust four DVI output Brightness alone or together, adjustment
Brightness range within 0-128.
Hot Backup
Hot Backup
Enable or Disable function
Hot Backup input
Input signal backup.
Hot backup total 1 to 3.
Input Adjust
Input Details
Display the input source and resolution.
Image Quality
Adjust Image Brightness, Contrast, Saturation, Sharpness, Color
Red/Green/Blue, Reset Parameters. Only adapt to DVI2 and DP input.
Zoom
Zoom Up
Image to up zoom.
Zoom Down
Image to down zoom.
Zoom Up & Down
Image to up and down zoom.
Zoom Left
Image to left zoom.
Zoom Right
Image to right zoom.
Zoom Left & Right
