CADE DOUBLE BATH SCONCE
PARTS ENCLOSED:
(A) Glass Shade (2)
(B) Socket Cover (1)
(C) Backplate Screws (4)
(D) Backplate (1)
(E) Mounting Screw (1)
(F) Mounting Plate (1)
(G) Adapter Plate (1)
(H) Wire Nuts (3)
(I) Mounting Screw (1)
(J) Wire Hole (1)
(K) Wire Hole (1)
(A)
(C)
(C)
(B)
(D)
(J)
(E)
(I)
"J BOX"
(F)
(G)
(H)
(A)
(H)
FIG. A
VERTICAL
MOUNT
(K)
FIG. B
HORIZONTAL
MOUNT
(J)
(E) (I)
"J BOX"
(F)
(G)
(H)
(K)
(H)
1 of 3
CADE DOUBLE BATH SCONCE
All wires are connected. When unpacking, be careful not to pull wires,
as a bad connection may result. Do not connect electricity until your
xture is fully assembled. To reduce the risk of re, electrical shock
or personal injury, always turn o xture and allow it to cool prior to
replacing the lightbulb. Do not touch bulb when xture is turned on
or look directly at lit bulb. Keep ammable materials away from the lit
bulb.
This lighting fixture contains lead, a chemical known to the State of
California to cause cancer, birth defects and other reproductive harm.
Wash hands after installing, handling, cleaning or otherwise touching
this light fixture.
When using a dimmer device with this xture, a specic electronic low
voltage (ELV) dimmer must be used to avoid potential damage to the
transformer.
WARNING: This product can expose you to lead, which is
known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information, go to
www.P65Warnings.ca.gov.
IMPORTANT PLEASE READ
WE RECOMMEND INSTALLATION BY A
LICENSED ELECTRICIAN.
SAFETY INSTRUCTIONS:
VERTICAL MOUNTING: FIG. A
WARNINGS:
These instructions are provided for your safety. It is very important
that they are read completely before beginning the installation of your
xture.
This xture ships with two non-replaceable solid-state LEDs installed.
If any special control devices are used with this xture, follow the
instructions carefully to assure full compliance with N.E.C.
requirements. If there are any questions, contact a qualied electrical
contractor.
1. Remove all parts carefully from the box and remove all plastic
coverings.
2. Remove glass shades (A) by unscrewing from threaded socket
cover (B).
3. Remove backplate screws (C) from backplate (D).
4. Carefully position adapter plate (G) behind mounting plate (F). Guide
wires from xture through hole (J) on mounting plate (F) and hole (K),
located on adapter plate (G).
5. Make proper electrical connection with wiring exiting hole of adapter
plate (G).
6. Connect ground wire (green) from the xture to the ground wire in
outlet box. Connect the black wires of the xture (or smooth side of
the wire) to the black wire in the outlet box using wire nuts (H).
Connect the white wires of the xture (or rough side of the wire) to
the white wire in the outlet box using wire nuts (H).
7. Ax mounting plate (F) and adapter plate (G) to“J BOX” by inserting
mounting plate screw (I) into slotted hole on bottom of mounting
plate (F) and slotted hole on bottom of adapter plate (G). Thread
screw (I) into bottom hole of“J BOX.”
8. After mounting plate and adapter plate are moved into desired
position, insert mounting plate screw (E) into slotted hole in top of
mounting plate (F) and slotted hole in top of adapter plate (G) and
thread screw (E) into drywall above“J BOX”. Make sure to use
threaded plastic sleeve (included) with mounting plate screw (E)
when attaching xture to drywall.
9. Align holes in top and bottom of backplate (D) with screw holes in
top and bottom of mounting plate (F).
10. Place backplate (D) over mounting plate (F). Thread backplate
screws (C) into backplate (D) to secure xture to mounting plate (F).
11. Align threaded section of glass shades (A) with threaded openings
of socket cover (B). Thread glass shades (A) onto threaded socket
cover (B) until tight.
THIS PRODUCT IS NOT A TOY AND THE PRODUCT HAS
NO PLAY VALUE.
WARNING: STRANGULATION HAZARD
Keep cord at least 3 feet away from cribs, bassinets, and toddler beds.
Keep out of reach of children under 3 years of age.
ASSEMBLY & INSTALLATION
Wipe clean with a soft, dry cloth or static duster. Always avoid the use of
harsh chemicals or abrasive cleaners, as they may cause damage to the
xture’s nish.
CARE INSTRUCTIONS:
2 of 3
SHUT OFF MAIN ELECTRICAL SUPPLY FROM THE MAIN BREAKER.
CADE DOUBLE BATH SCONCE
Wipe clean with a soft, dry cloth or static duster. Always avoid the use of
harsh chemicals or abrasive cleaners, as they may cause damage to the
xture’s nish.
ASSEMBLY INSTRUCTIONS CONT.
HORIZONTAL MOUNTING: FIG. B
CARE INSTRUCTIONS:
1. Remove all parts carefully from the box and remove all plastic
coverings.
2. Remove glass shades (A) by unscrewing from threaded socket
cover (B).
3. Remove backplate screws (C) from backplate (D).
4. Carefully position adapter plate (G) behind mounting plate (F) and
guide wires from xture through hole (M) located in the middle of
mounting plate (F) and hole (K), located in the middle of adapter plate
(G).
5. Make proper electrical connection with wiring exiting hole of adapter
plate (G).
6. Connect ground wire (green) from the xture to the ground wire in
outlet box. Connect the black wires of the xture (or smooth side of
the wire) to the black wire in the outlet box using wire nuts (H).
Connect the white wires of the xture (or rough side of the wire) to
the white wire in the outlet box using wire nuts (H).
7. Ax mounting plate (F) and adapter plate (G) to“J BOX” by inserting
mounting plate screw (I) into slotted hole on bottom of mounting
plate (F) and slotted hole on bottom of adapter plate (G). Thread
screw (I) into bottom hole of“J BOX.”
8. Position mounting plate (F) and adapter plate (G) horizontally over
“J BOX”. Ax mounting plate (F) and adapter plate (G) to drywall on
right and left sides of “J BOX” by inserting mounting plate screws (E)
and (I) into slotted holes on right and left side of mounting plate
(F) and adapter plate (G). Make sure to use threaded plastic sleeve
(included) with mounting plate screws (E) and (I) when attaching
xture to drywall.
9. Align holes in top and bottom of backplate (D) with screw holes in
top and bottom of mounting plate (F).
10. Place backplate (D) over mounting plate (F). Thread backplate
screws (C) into backplate (D) to secure xture to mounting plate (F).
11. Align threaded section of glass shades (A) with threaded openings
of socket cover (B). Thread glass shades (A) onto threaded socket
cover (B) until tight.
3 of 3
