RH Z-BAR User manual

Z-BAR LED GRAND FLOOR LAMP
F
G
H
I
PARTS ENCLOSED
(A) Upper Lamp Body (1)
(B) Head (1)
(C) Lower Lamp Body (1)
(D) Base (1)
(E) Retaining Screw (1)
(F) Base Pin (1)
(G) Wrench (1)
(H) Special Screwdriver (1)
(I) Power Adaptor

Z-BAR LED GRAND FLOOR LAMP
ASSEMBLY & INSTALLATION
1. Screw the base pin (F) onto the base (D).
Using the provided wrench (G), tighten the connection
between the two.
2. Insert the lower lamp body (C) onto the base (D).
3. Insert the upper lamp body (A) onto the lower lamp body
(C).

Z-BAR LED GRAND FLOOR LAMP
5
4. After inserting the upper body (A) into the
lower body (B), slide the upper body laterally
towards the back side of the lamp until the
upper body is flush with the lower body.
5. Using the provided special screwdriver (H),
tighten the retaining screw (E) into the lower
body (B) to secure the connection.

Z-BAR LED GRAND FLOOR LAMP
6
7
8
6. Insert the LED head (B) onto the upper lamp
body (A).
7. Connect the power cord from the lamp’s body
(B) to the power adaptor (I), then plug it into an
outlet.
8. Press the on/off button to turn on and off. Hold
this button to dim/brighten the light.

Z-BAR LED GRAND FLOOR LAMP
IMPORTANT SAFETY INSTRUCTIONS
All wires are connected. When unpacking, be careful not to
pull wires, as a bad connection may result. Do not connect
electricity until your fixture is fully assembled.
WARNING: This product can expose you to lead, which is
known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information, go to
www.P65Warnings.ca.gov
THIS PRODUCT IS NOT A TOY AND HAS NO PLAY VALUE.
WARNING: STRANGULATION HAZARD
Keep cord at least 3 feet away from cribs, bassinets, and toddler
beds. Keep out of reach of children under 3 years of age.
CARE INSTRUCTIONS
Do not use polishes or cleaners on the fixture. Wipe clean with a soft,
dry cloth.
