RI IVF Thermometer User manual

User Manual
Document 7-90-000UM, Issue 1, MRF 1618, 12th March 2015
Research Instruments Ltd
Bickland Industrial Park, Falmouth, Cornwall TR11 4TA, UK
t: [phone] | f: [phone] |e: [e-mail]
www.research-instruments.com
0120
IVF Thermometer

User Manual Research Instruments Ltd
IVF Thermometer
CONTENTS
Introducon 1
Intended Use 1
Warranty 1
Disposal 1
Screws 2
Baeries 2
Probe 4
Using the IVF Thermometer 4
Media Measurement 5
Incubator Measurement 5
Probe in holder 5
Surface Measurement 6
Care and Maintenance 7
Troubleshoong 7
Calibraon 7
Specicaon&ApplicablePartNumbers 8
RI Returns System 9
Contact Details 9

User Manual
1
Research Instruments Ltd
IVF Thermometer
Introducon
The IVF Thermometer has been specially designed for IVF laboratories,
as an independent temperature control monitor. Laboratories use the
IVF Thermometer to verify that any temperature-controlled equipment
is performing as desired. The unit is waterproof and is calibrated for use
with refrigerators, incubators and heated stages.
Intended Use
To measure the temperature of temperature-controlled equipment
typically used in a IVF laboratory.
Contraindicaon: It is not intended that this device come into direct
contactwithanyssuesamplesbeingtreatedinaclinicalseng,orwith
media which is in direct contact with such samples.
Warranty
This instrument has been carefully assembled and tested, and is
warranted against faulty workmanship and materials for two years from
the date of purchase.
Duringthewarrantyperiodanydefecveinstrumentwillberepairedor
replacedatthediscreonofthemanufacturer.Thiswarrantydoesnot
coverdamageorfailureresulngfrommisuseoraccident.
Modicaon,adjustmentoranyalteraonwiththeinternalarrangement
of the instrument shall absolve the manufacturer from any liability in
respect of the instrument.
Disposal
When the IVF Thermometer has reached the end of its life, it
must not be disposed of with normal waste. Return it to RI to be
destroyed in an environmentally safe way, or use a local facility for
the disposal of waste electronic equipment.

User Manual
2
Research Instruments Ltd
IVF Thermometer
Baeries
The IVF Thermometer is powered by two AA baeries.
Non-rechargeable or rechargeable baeries may be used. We
recommend either alkaline or low-self-discharge Nickel Metal Hydride
(NiMH)types.Replacethebaerieswhenthelowbaeryindicator
appears on the display.
1. Remove the baery cover by undoing the two screws using a
at-bladedscrewdriver.
Research Instruments Ltd
Tel: [phone]
www.research-instruments.com
Made in England
AA
Read Instructions Before Use
Type T
Thermocouple Thermometer
Range: -250°C to +400°C/-418°F to +752°F
Screws

User Manual
3
Research Instruments Ltd
IVF Thermometer
Research Instruments Ltd
Tel: [phone]
www.research-instruments.com
Read Instructions Before Use
Type T
Thermocouple Thermometer
Range: -250°C to +400°C/-418°F to +752°F
Research Instruments Ltd
Tel: [phone]
www.research-instruments.com
Made in England
AA
Read Instructions Before Use
Type T
Thermocouple Thermometer
Range: -250°C to +400°C/-418°F to +752°F
2. Fitthebaeriesasshown.Theorientaonofthebaeriesmustbe
asshownonthediagramonthebaerycover.
If the meter is not going to be used for an extended period then remove
thebaeries.Thiswillpreventanypossibledamagefrombaeryleakage.

User Manual
4
Research Instruments Ltd
IVF Thermometer
Probe
The IVF Thermometer is supplied with a miniature thermocouple which
is ideally suited for temperature measurement in small volumes of liquid.
AlsoavailablefromRI is a robustprobesuitableforlarger volumesof
liquid,andacryo-probeopmisedforcryopreservaontemperatures.
Connecttheprobetothesocketatthetopofthemeterandghtenthe
screwcollar.Removethewhiteplascsleevefromtheprobepbefore
use, but keep the sleeve to protect the probe when it is not being used.
Note:Thepoftheprobeismadewithverythinwires.Alwayshandle
the probe gently to minimise the risk of breakage.
Using the IVF Thermometer
Turn the meter on by pressing the ONbuonforabouthalfasecond.
Themodelnumber“2110”willashinthedisplaybrieyandthemeter
will begin measuring.
Press the HOLDbuontofreezethecurrentlymeasuredvalue.Thiscan
beusefulwhenwringdowntemperatures.Thesymbolwillshow
on the display. Press the HOLDbuonagaintoreturntothelivedisplay.
Toswitchthemetero,pressandholdtheOFFbuon.Themeterwill
alsoautomacallyswitchoaeraboutveminutesifnobuonshave
beenpressed.Itwillnotautomacallyswitchoifthe HOLDisacve.
Pleasenotetheosetvaluestatedonthecurrentcalibraon
cercateandadjustyourreadingaccordingly.

User Manual
5
Research Instruments Ltd
IVF Thermometer
Media Measurement
To check the temperature of media in a culture dish we recommend
preparing a test dish in your normal manner but with water drops instead
ofculturemedia.Theprobepiswaterproofsothepcanbeimmersed
directlyinthewaterdrop.Allowthereadingtoselebeforerecordingor
adjusngthetemperature.Theprobecanbeheldbyhandorplacedinthe
holder supplied.
Incubator Measurement
If the incubator has a dedicated access port for temperature measurement
then pass the probe through this port and ensure it is correctly sealed.
Otherwise, the probe cable is thin enough to pass through the door seal.
Refertotheincubatorinstruconsforfurtherdetails.
Contraindicaon:Itisnotintendedthatthisdevicecomeinto
directcontactwithanyssuesamplesbeingtreatedinaclinical
seng, or with media which is in direct contact with such
samples.
Probe in holder

User Manual
6
Research Instruments Ltd
IVF Thermometer
Surface Measurement
AkitcontainingheattransferpasteandsuitabletapeisavailablefromRI.

1. Squeezeasmallamountof
heat transfer paste onto the
surface to be measured.
2. Insertthepoftheprobeinto
the paste.
3. Cut a short piece of the adhesive tape provided and secure the probe
to the surface by placing the tape lengthways as shown. If the tape is
placed across the probe it can fall out easily.

User Manual
7
Research Instruments Ltd
IVF Thermometer
Care and Maintenance
Immersioninmediasoluonswillacceleratecorrosionoftheprobep
due to the salt content of the media. Similarly, long-term exposure to
humidiedairinsideanincubatormayacceleratecorrosion.Toprolong
the life of the probe, we suggest using plain water drops instead of culture
mediawhencheckingthetemperatureinaPetridish(seepage5).
Aer each use, rinse the probe p in plain water, blot dry gently and
allowtoairdry.Thenreplacetheplasccapbeforestoring.
Troubleshoong
Displayshows“O-C”(opencircuit);thismeanstheprobehasfailed.The
mostcommoncauseoffailureisabrokenwireatthep.Failedprobes
cannot be repaired and must be replaced.
Calibraon
WerecommendcalibrangtheIVFThermometerannually.Thiscanbe
done by RI, but it may be more convenient for most users to use a local
testcompany.Werecommendcalibraonbeconductedbyatesthouse
accreditedtonaonalstandards.Themetershouldbecalibratedtothe
specicaonsshownonpage8.
Calibraondoesnotinvolveadjusngthemeter,rathercomparisonto
a traceable standard oset. For example, if the calibraon cercate
shows a reading of 37.3°C at an actual 37.0°C then the meter will do this
consistently.Thisosetcanbeallowedforwhenmakingmeasurements.
Replacing a probe always requires a new calibraon. Similarly, the
meter can be used with more than one probe, but each probe should be
calibrated separately with the meter, and care should be taken to apply
thecorrectosetforeachprobe.
Thecryo-probedoesnotrequirecalibraonastheinherentaccuracyis
sucientforthepurpose.See thespecicaontableonthefollowing
page.

User Manual
8
Research Instruments Ltd
IVF Thermometer
Specicaon & Applicable Part Numbers
Probe Type Standard microdrop probe
Accuracy UKAS-ceredoset.Measurementatcalibraon
points repeatable to ±0.2°C
Sensor T-type thermocouple
Calibraon points 5°C, 37°C, 45°C
Units Celsius(°C)
Operaon me on baery Approx.500hours,dependingonbaerycapacity
Dimensions 15.5cm x 6.7cm x 4cm
Weight of units 250g
Probe Type Oponal cryo-probe
Tempertaure range 0 to -200°C
Accuracy ±1.5% of reading or 1°C, whichever is greater
Probe length 150mm
Probe diameter 1.5mm
Probe sheath Stainless steel
Calibraon Notrequired
Probe Type Oponal robust probe
Temperature range 0 to +100°C
Accuracy (calibrated) ±0.2°C(±0.4°F)overtherange-20°Cto+70°C
(-4°Fto+158°F)
0.1%ofreading/±0.2°C(±0.4°F)elsewhere(whichever
isgreater).
Accuracy (uncalibrated) ±0.5°C(±0.9°F)overtherange-20°Cto+70°C
(-4°Fto+158°F)
0.1%ofreading/±0.2°C(±0.4°F)elsewhere(whichever
isgreater).
Calibraon Oponal
Part Number Descripon
7-90-001 Standard microdrop probe replacement
7-90-011 Oponalcryo-probe
7-90-013 Oponalrobustprobe
7-90-003 Spare probe and holder
7-90-006 Spare probe holder

User Manual
9
Research Instruments Ltd
IVF Thermometer
Contact Details
Research Instruments Ltd, Bickland Industrial Park,
Falmouth, Cornwall, TR11 4TA, UK
Tel:+44(0)1326372753Fax:+44(0)1326378783
E-mail:[e-mail]
Website:www.research-instruments.com
For all queries or service issues please contact your authorised distributor
orRI’sserviceteamon[e-mail]
RI Returns System
1. ContactRItoobtainaReturnedMaterialsAuthorisaon(RMA)number.
Note: Goods will not be replaced or refunded without prior agreement
andclearlystangtheRMAnumber.
2. Pack the item carefully in its original packaging. RI will not accept
responsibility for damage due to incorrect packaging. Replacement
itemsoraddionalrepairswillbeinvoiced.
3. Clearly label the package with the RMA number. Mark the package
“Urgent - Returned Items For Repair” and ship to the address overleaf.
Goods should be insured for their full value during shipping.
Feedback
Thank you for purchasing an RI product. To help RI develop the best tools
forART,werelyoncustomerfeedback.Ifyouhaveanysuggesonsforhow
wecanimproveourproductsortheinformaonweprovidewiththem,
pleasesendthemto[e-mail].Yourfeedback
willhelp usdeveloptheproductandsupporngmaterialstomeetyour
future needs.
