iDimension® PWD
Static Dimensioning System
Managers Guide
PN 198680 Rev AJuly 16, 2020

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2.0 QubeVu Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Edit/Cancel/Save Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 System Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3.1 System Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3.2 Restart Device Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 QubeVu Inspector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4.1 Device Information Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4.2 Change Log Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4.3 Long Term Storage Log Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.0 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Touch Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.1 Customer Display Icon – Out of Bounds Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Operator Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 Customer Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.4 Demo Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.0 Operator Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Extract Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.0 Admin Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.0 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.1 General Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.1.1 General Settings Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.1.2 Data Extraction Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.1.3 Date/Time Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1.4 External Cameras Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.2 Measurement Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.1 Measurement Settings Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.2 Remote Sensors Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.3 Certification Settings Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.3 Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4 User. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5.1 Network Settings Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5.2 Network Security Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.1 IFM Sensor Alignment and Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.2 Setup Work Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.0 Capture Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
9.0 Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9.1 Firmware Upgrade Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

iDimension PWD Managers Guide
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
9.1.1 USB Drive or Network Share . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.1.2 Local File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9.2 Custom Logo Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10.0 Backup and Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
10.1 Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
10.2 Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
11.0 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
11.1 Component Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
11.1.1 Scale Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11.2 System Log Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
11.3 Debug Info. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
12.0 License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
13.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
13.1 QubeVu Engineering Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
13.2 Configuring Axis IP Camera Using IP Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
13.3 Installation Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
13.4 Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
13.4.1 Extended Status Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
13.4.2 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
13.5 Appendix C: Sample XSL File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
13.6 Data Extraction Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
13.6.1 Data Collection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
13.6.2 Data Extraction Definition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
13.7 TCP Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
13.7.1 TCP Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
13.7.2 TCP Interface Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
13.8 QubeVu Protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
13.8.1 Sample Requests and Responses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
13.8.2 Serial Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
QubeVu® Manager is the program provided to set up and configure the iDimension PWD and is recommended for use by
technical system administrators.
When interfacing this device to a third party program, please reference the software manufacturer’s documentation for setup
and configuration parameters as necessary.
Manuals and additional resources are available from the Rice Lake Weighing Systems website at www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 Additional Resources
For additional resources, see the following information:
iDimension PWD Assembly Instructions
The iDimension PWD Assembly Instructions (PN 198812) provides an overview on how to assemble the iDimension PWD.
iDimension PWD Operation Manual
The iDimension PWD Operation Manual (PN 198811) provides an overview on how to operate the iDimension PWD.
iDimension PWD Setup Manual
The iDimension PWD Setup Manual (PN 199543) provides an overview on how to setup QubeVu Manager for the iDimension PWD.
880 Performance™ Series Controller and Indicator Technical Manual
The 880 Performance Series Controller and Indicator Technical Manual (PN 158387) provides a detailed overview of the 880
indicator installation, configuration and operation procedures.
SUMMIT® 3000 Installation Manual
The SUMMIT 3000 Installation Manual (PN 76012) provides a detailed overview of the SUMMIT 3000 installation procedure.
1.2 Regulatory Information
This product is a Class 1 Laser Product according to IEC 60825-1:2007 Ed. 2.0 and complies with 21 CFR 1040.1 pursuant to
Laser Notice No. 50. A laser source with a diffraction optical element is embedded in the product, which produces a maximum
output power of 1.1 mW at the aperture with a maximum wavelength of 825 nm.
FCC
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their own expense. Changes or modifications not expressly approved by Postea, Inc. could void the user’s FCC
granted authority to operate the equipment.

iDimension PWD Managers Guide
2 Visit our website www.RiceLake.com
2.0 QubeVu Manager
This section provides an overview of QubeVu Manager information.
QubeVu Manager is the program installed on the iDimension PWD which provides more advanced configuration or features,
system diagnostics and calibration not accessible from the touch screen operator display.
To access QubeVu Manager, connect the iDimension PWD via ethernet to a computer then open a web browser and enter:
http://192.168.0.2.
Figure 2-1. QubeVu Manager Home Page
Parameter Description
Displays Display information (Section 3.0 on page 10)
Operator Tools Operator tools information (Section 4.0 on page 14)
Admin Tools Admin tools instructions (Section 5.0 on page 16)
License License information (Section 12.0 on page 62)
Table 2-1. QubeVu Manager Home Page Navigation

QubeVu Manager
© Rice Lake Weighing Systems ● All Rights Reserved 3
2.1 Navigation
A navigation menu is located in the upper left section of all pages. This allows users to keep track of their current location and
provides links back to each preceding page.
Example: The user is in the Calibration Settings screen and can select Admin Tools to return to the Admin Tools
menu or Qubevu Manager to return to the home page.
Figure 2-2. Menu Navigation

iDimension PWD Managers Guide
4 Visit our website www.RiceLake.com
2.2 Edit/Cancel/Save Keys
Within various menus, there are three active keys: , and .
Figure 2-3. Edit, Cancel and Save Keys
Edit
Press to enable settings within the general setting mode and calibration menu settings to be changed.
After changing the settings, press to continue.
Cancel
Press to cancel all edits made to all tabs, unless saved.
Save
Press to save all changes made during the edit process within the page and a sub menu tab. Upon save, the unit may
restart and return to the home screen.

QubeVu Manager
© Rice Lake Weighing Systems ● All Rights Reserved 5
2.3 System Status
The system status of the connected device is displayed in the upper right corner of all pages.
Example:
User: Logged into the device under the Admin mode. Press to return to the standard user mode.
Device: The default setting is the serial number of the iDimension device. This can be renamed within the Network
Settings while in the Admin mode.
Running: The current status of the unit.
Address: 10.10.1.2: The Current IP address of the unit.
Figure 2-4. Status Display
If edit has been selected while in a screen, the unit may stay in the Configuring status and a restart is required to return to the
Running mode.
2.3.1 System Status Messages
The device status messages which may be displayed are described below.
Item No. Description
1 User
2 Device and System Status (Section 2.3.1)
3 IP Address
4 Log Out (Log In is located here if not signed in)
5 Restart (Section 2.3.2 on page 6)
6 QubeVu Inspector (Section 2.4 on page 6)
Table 2-2. Status Indicators
Status Description
STARTING The system is starting up
STARTED The device has been power cycled or rebooted; Wait for the status to change to RUNNING before performing a dimension;
If the device remains in STARTING mode, use the demo display or USB display Help button to view and clear dimensions
ERROR The web browser is unable to determine the status; ERROR may display during a system reboot
STOPPING The system is transitioning into STOPPED state
STOPPED The service has stopped; STOPPED displays during a restart or reboot of the system; If the unit continues to display STOPPED,
perform a restart or power cycle the unit from the AC Outlet or power switch on the kiosk
RESTARTING The device has been power cycled, reset or rebooted and the system is restarting services; Wait for the status to change to
RUNNING before performing a dimension
CONFIGURING While in Admin mode, and Edit condition has been activated to change configuring settings; If the settings are saved, the device
should return to the RUNNING mode; If a save function has not been performed properly and the device is in the configuring mode,
perform a restart
RUNNING System is in operational state
Table 2-3. Status Messages
2
1
4 5 6
3

iDimension PWD Managers Guide
6 Visit our website www.RiceLake.com
2.3.2 Restart Device Information
To restart or reboot the system, select one of the following buttons:
• Press to restart the service currently running on the device
• Press to reboot the operating system. Rebooting the unit takes several minutes and power cycles the unit
• Press to go to the previous menu
Figure 2-5. Restart/Reboot Prompt
2.4 QubeVu Inspector
QubeVu Inspector allows users to view information regarding the device, changes made to settings and long term storage
data. It is not necessary to log in to view the information available on the QubeVu Inspector tab.
Use the following steps to access QubeVu Inspector tab:
1. Press to access device information. The Device Information tab displays specific information about the device.
Figure 2-6. QubeVu Information Window
2. Select . The QubeVu Inspector menu displays (Section 2.4.1 on page 7).

QubeVu Manager
© Rice Lake Weighing Systems ● All Rights Reserved 7
2.4.1 Device Information Tab
The Device Information tab provides access to view the serial number and firmware version number.
Figure 2-7. Device Information Tab

iDimension PWD Managers Guide
8 Visit our website www.RiceLake.com
2.4.2 Change Log Tab
The Change Log tab is a list of changes made to the settings. This menu is used by the local weights and measures inspector
and factory service personnel.
• To view using a date range – enter a Start and End date then press
Figure 2-8. Change Log Tab
• To view all previous logs, press without entering a date range
Figure 2-9. Change Log Tab (Continued)
• Use the arrow keys on the PC keyboard to scroll through the results
• Press to export the log to a .csv file

QubeVu Manager
© Rice Lake Weighing Systems ● All Rights Reserved 9
2.4.3 Long Term Storage Log Tab
The Long Term Storage tab is necessary to satisfy particular Legal-for-Trade requirements in certain jurisdictions.
The measurement data stored in the Long Term Storage Log contains all relevant information necessary to reconstruct an
earlier measurement. The stored data is protected against accidental, unintentional and intentional changes and can be
authentically traced back to the measurement which generated them.
Enable Long Term Storage
Long term storage is enabled from the General Settings menu (Section 6.1.2 on page 22).
View Long Term Storage Data
Long term storage data is viewed from the Long Term Storage Log. The log is queried by specifying a Start and End scan ID.
The total number of entries is displayed along with the first and last scan IDs.
This information is highlighted within Figure 2-10.
• Enter a scan ID range and press to search for a specific log
Figure 2-10. Long Term Storage Log Tab
• Use the arrow keys on the PC keyboard to scroll through the results
• Press to export the log to a .cvs file
Note

iDimension PWD Managers Guide
10 Visit our website www.RiceLake.com
3.0 Display
This section provides an overview of iDimension PWD Display Pages menu instructions.
QubeVu Manager provides three displays that can be used in case the application does not have access to the USB
touchscreen operator display.
To enter the Display Pages menu use the following procedure:
• Press from the QubeVu Manager menu (Figure 2-1 on page 2) to enter the Display Pages menu
Figure 3-1. Displays Menu
Parameter Description
Operator Display Operator display information (Section 3.2 on page 12)
Customer Display Customer display information (Section 3.3 on page 12)
Demo Display Demo display information (Section 3.4 on page 13)
Table 3-1. QubeVu Manager Home Page Navigation

Display
© Rice Lake Weighing Systems ● All Rights Reserved 11
3.1 Touch Screen Display
The touch-screen display is used to navigate QubeVu. The Power button for the USB display is located on the back of the unit.
The USB operator display can be configured in QubeVu Manager.
Figure 3-2. Touchscreen Display
Function keys allow the iDimension PWD to be managed via the touchscreen display.
3.1.1 Customer Display Icon – Out of Bounds Indications
Out of bounds indication provide a visual indication if the placement of the pallet or box is within a 72''x 72'' work area.
Figure 3-3 indicates the pallet is out of bounds on the left edge, when facing the scale:
Figure 3-3. Out of Bounds Indication – Left
The following out of bounds flags found in the engineering app:
{IPaddress/tools/engapp.php}, the “IPaddress/status” or “IPaddress/statusex” web pages:
Left – OOB = 1
Front – OOB = 8
Right – OOB = 2
Rear – OOB = 4
Out of bounds flags are used in combination with “Ref” designation during configuration for the Remote Sensors.
If the OOB indications do not reflect accurately, please review the IP camera reference settings.
Item No. Function Function
1 Out of Bounds Indication For out of bounds indications, see Section 3.1.1
2 Displayed Dimensions Displayed Dimensions
3 Weight Display The weight display is used to indicate to weight of the item at the time of the item at the time of the dimensions were
captured; Use the 880 Indicator weight display to view live weight data, including negative weight
4 Information Button Provides access to configuration menu to set-up of time and date, display configured IP address and firmware
updates via USB thumb drive
5 Zero Height Key Not applicable to this application
6 Scan Button Trigger the iDimension PWD to dimension
7 Help Key Displays the Issue Review menu; Provides real time feedback to the operator of the unit; Provides step by step instructions
on how to clear conditions such as started, stopped, wait or remove condition with no object in the scan area
8 Live Image The weigh area provides a real-time view of the scanning area from the scanning head onto the USB display
Table 3-2. Key Functions
5
2
1
4
3
6 7
8
Note

iDimension PWD Managers Guide
12 Visit our website www.RiceLake.com
3.2 Operator Display
The Operator Display menu simulates the configuration of the Touch Screen USB display. The Operator Display menu can
be configured using the Admin/Setup Menu/Displays administrative function.
• Press from the Display Pages menu (Figure 3-1 on page 10) to enter the Operator Display menu.
Figure 3-4. Operator Display
See Section 3.1 on page 11 for function descriptions.
3.3 Customer Display
The Customer Display menu can be used for applications when a visible display is required for dimensioning.
The Customer Display menu does not provide access to any operator controls. The Customer Display menu can be
configured using the Admin/Setup Menu/Displays administrative function.
• Press from the Display Pages menu (Figure 3-1 on page 10) to enter the Customer Display menu
Figure 3-5. Customer Display
Note

Display
© Rice Lake Weighing Systems ● All Rights Reserved 13
3.4 Demo Display
The Demo Display menu is intended for use during demonstrations and testing the effects of configuration changes.
The Demo Display menu can be used to help the Rice Lake Weighing Systems technical support team in troubleshooting.
• Press from the Display Pages menu (Figure 3-1 on page 10) to enter the Demo Display menu
Press to manually trigger a dimension.
Figure 3-6. Demo Display
Status messages are displayed within display screen menus. Messages displayed on screen are not error messages.
See Section 13.4 on page 70 for displayed status, extended status and error status messages.
Note

iDimension PWD Managers Guide
14 Visit our website www.RiceLake.com
4.0 Operator Tools
This section provides an overview of iDimension PWD Operator Tools menu instructions.
To enter the Operator Tools menu use the following procedure:
• Press from the QubeVu Manager menu (Figure 2-1 on page 2) to enter the Operator Tools menu
Figure 4-1. Operator Tools Menu

Operator Tools
© Rice Lake Weighing Systems ● All Rights Reserved 15
4.1 Extract Data
Extract Data allows the user to view the status of the scheduled scan data extract and perform a manual export of scan data.
See Section 6.1.2 on page 22 for detailed information on configuring a scan data extract.
1. Press from the Operator Tools menu (Figure 4-1 on page 14) to enter the Extract Data menu.
• The Extract Data menu displays the status of both the scheduled extract and the manual extract
2. Press to perform a manual extract.
Figure 4-2. Extract Data

iDimension PWD Managers Guide
16 Visit our website www.RiceLake.com
5.0 Admin Tools
This section provides an overview of iDimension PWD Admin Tools menu instructions.
The Admin Tools menu is used for configuring, calibrating, defining, upgrading, backing up and running diagnostics on the system.
To enter the Admin Tools menu use the following procedure:
1. Press from the QubeVu Manager menu (Figure 2-1 on page 2) to enter the Admin Tools menu.
2. The QubeVu Manager login screen displays. The default username and password are admin and password.
Figure 5-1. Admin Tools Menu
Parameter Description
Setup General (optional and scale), time and date, data extraction and long term storage, measurement, network settings ( Section 7.0 on page 38 )
Calibration Calibration settings, define work area and calibrate cameras (Section 7.0 on page 38)
Capture Definitions Capture definitions for QubeVu (Section 8.0 on page 48)
Firmware Upgrade Update firmware (Section 9.0 on page 50)
Backup Backup and restore settings (Section 10.0 on page 53)
Diagnostics Diagnostics settings (Section 11.0 on page 55)
Table 5-1. Admin Tools Navigation
