Rice Lake DC-190 ULTRA COUNT User manual

73352
DC-190
OO
OOpp ppee eerr rraa aatt ttiiii oo oonn nn MM MMaa aann nnuu uuaa aallll
When Accuracy Counts
CC
CCoo oouu uunn nntt ttiiii nn nngg gg SS SScc ccaa aallll ee ee

CONTENT
1. General Specification 1
2. Overall Dimension
2.1 DC 190 Indicator 2
2.2 S-X Platform 2
2.3 Pole Type 3
2.4 Bench Type 4
3. Keysheet And Display Layout 5
4. Initial Set Up
4.1 Set Up
4.1.1. DC 190 Bench Type Set Up 7
4.1.2. DC 190 Pole Type Set Up 8
4.2 Location of Span Switch and Connector 9
4.3 Default SPEC 9
4.4 Customer Specification Setting 10
4.5 Weigh & Measure Specification Setting 10
4.6 Internal Count and A / D Count 11
4.7 Calibration 11
5. Specification List
5.1 Software Version 12
5.2 Customer Specification 13
5.3 Weight & Measure Specification 15
5.4 Multi-drop Host Communication Specification 19
6. PC Connection
6.1 General Specification 20
6.2DC 190 to PC Output Data Format 20
6.2.1 With Header 20
6.2.2 Without Header 25
6.3 Data 26
6.4 Wire Configuration 30
7. Printer Connection
7.1 Connection to TVP/ELTRON Printer 31
7.2 Connection to SE250 / EPSON Printer 31
7.3 RS232 Related SPEC List 32
7.4 Wire Configuration 34
8. Set Point Connection
8.1 Pin Configuration 35
8.2 Set Point SPEC Setting 35
8.3 Set Point Set Up 36

9. Barcode Scanner Connection
9.1 General Specification 37
9.2 Default Spec for Barcode Scanner 37
9.3 Pin Configuration 37
9.4 Input Data 38
9.4.1 3 Line Barcode 38
9.4.2 Barcode Scanning Mode 38
9.5 Header Code 39
9.6 Z Command Code 39
9.7 RS232 Related SPEC List 40
9.8 Barcode Sample 40
10. Force Balance Connection
10.1 General Specification 41
10.2 Calibration of Scale 41
10.3 Force Balance SPEC Setting 42
10.4 Wire Configuration 44
11. Circuit Diagram
11.1Block Diagram 45
11.1.1 With Main Board TWB-01900 45
11.1.2 With Main Board TWB-01901 46
11.2 DC 190 Main Board TWB-01900-347
11.3 DC 190 Main Board TWB-01901-050
11.4 DC 190 A / D Board TWB-01930-154
11.5 DC 190 Filter Board TWB-01940-055
11.6 DC 190 A / D Connector Board TWB-01950-156
11.7 DC 190 Connector Board TWB-01921-157
11.8 DC 190 RS232 / 4 Line Interface Board TWB-01970-058
11.9 DC 190 Key Board TPB-1672-360
11.10 DC 190 Power Board TWB-01911-161
12 APPENDIX A 62

DC 190 GENERAL SPECIFICATION
1
1GENERAL SPECIFICATION
Model :DI 190 ( Indicator)
DC 190 (Pole / Bench)
Dimension :Indicator -142 (L) X 310 (W) X 88 (H)
Pole -415 (L) X 420 (W) X 455 (H)
Bench -415 (L) X 435 (W) X 120 (H)
Capacity :Single Loadcell (Pole / Bench -SX Platform)
500g, 1 Kg, 2.5 Kg, 5 Kg, 10 Kg, 25 Kg, 50 Kg
1Lb, 2.5 Lb, 5 Lb, 10 Lb, 25 Lb, 50 Lb, 100 Lb
Dual Loadcell (Pole / Bench-SX Platform)
500g & 2.5 Kg, 500g & 5 Kg, 1 Kg & 5 Kg, 1kg & 10 Kg
Number Of Loadcells :2 Internal, 1 External, 1 Force Balance (RS232C)
Loadcell Connectivity :0.4 ~ 2.46 mV/V
Type Of Display :VFD
Weight Display -6 Digits
Unit Weight Display -5 Digits
Quantity -7 Digits
Display Resolution :1 / 10,000 ; 1 / 5,000 ; 1 / 2,500
Counting Resolution :1 / 500,000 ; 1 / 1,000,000
Keyboard :Mechanical key switch
Printing Items :Time; ID code; Lot No; Net Weight; Gross Weight;
Unit Weight; Tare Weight; Parts Name; Parts No; Quantity
Memory Item :200 items
Set Point Output :6 Set Points (Open Collector type)
Option :RS232C -PC;
Barcode Scanner (TTL or RS232C type);
Printer SE 250, LP 2622 and LP2722;
Force Balance (Ohaus Explorer )
Power Source :DI 190 -AC/DC Adapter Only
DC 190 -AC/DC Adapter, Rechargeable Battery or AC power.
i) AC/ DC 12 V / 1.4A Adapter (Class II Type)
ii) Rechargeable Battery -Panasonic LC-R123R4PTI
(AC voltage to charge; must charge > 6 hrs;
usage approx. 7 hrs.)
iii) AC 115 / 220 V

DC 190 OVERALL DIMENSION
2
2OVERALL DIMENSION
2.1 DC 190 INDICATOR
2.2 S-X PLATFORM

DC 190 OVERALL DIMENSION
3
2.3 POLE TYPE
POLE TYPE WITH 1 SCALE
POLE TYPE WITH 2 SCALES

DC 190 OVERALL DIMENSION
4
2.4 BENCH TYPE
BENCH TYPE WITH 1 SCALE
BENCH TYPE WITH 2 SCALES

DC 190 KEYSHEET AND DISPLAY LAYOUT
5
3KEYSHEET AND DISPLAY LAYOUT
KEY FUNCTION
Numeric No.
To change between Gross and Net; use as inventory key
To callout PLU data; to program commodity name inprogramming mode
To print data when printer is connected; store SPEC data
To subtract; to decrease SPEC no; to program parts no., date and time
To accumulate; to increase SPEC no; to program set point
To enter unit weight usingnumeric key board
To switch between different scales
To compute unit weight by sampling
To set and clear the tare weight
To clear the data of entries and unit weight.
To reset the zero point of the scale.
Change the maintenance and weighing mode
Turn on and off the machine.
Decimal Point

DC 190 KEYSHEET AND DISPLAY LAYOUT
6
INDICATOR LAMPS
ZERO When the gross weight is zero
NET When tare weight is set
GROSS When [Gross/Net] is pressed
INSUFF When net weight is below a specific percentage of capacity weight
RECOM When unit weight re-computing is possible
MEMORY When quantity is being accumulated or when memory overflows
MODE When in the programming mode
BATT When battery power level is low
SCALE 1 When built in platform 1 is used
SCALE 2 When built in platform 2 is used
SCALE 3 When external platform is used
SCALE 4 When force balance is used
IN Inventory in
OUT Inventory out

DC 190 INITIAL SETUP
7
4INITIAL SETUP
4.1 SET UP
BOTTOM OF S-X PLATFORM
4.1.1 DC 190 BENCH TYPE SET UP
Part need : DC 190 Indicator
S-X Platform
Bracket AG
4 x
DC 190
S-X Platform
Remove this load cell
stopper screw and nut
before proceed.
Bracket AG

DC 190 INITIAL SETUP
8
4.1.2 DC 190 POLE TYPE SET UP
S-X Platform
Pipe AA
DC 190 Indicator
Case BC
Case BA
Leg (A) -2
Bracket BA
Grommet AH
Case BB
Bracket BG
Assy
AA
2 x screws
2 x screws
2 x screws
2 x
2 x screws
4 x
screws
4 x screws
4 x screws
Hex nut M6
Parts need : DC 190 Indicator
S-X Platform
Assy AA
Bracket BA
Bracket BG
Case BA
Case BB
Case BC
Grommet AH
Leg (A)-2
Pipe AA
4 x screws

DC 190 INITIAL SETUP
9
4.2 LOCATION OF SPAN SWITCH AND CONNECTOR.
** A sealing screw is screw onto the span switch hole.
Please remove the screw to access to the span switch.
Back view of DC 190
Top view of DC 190
4.3 DEFAULT SPEC
To default to the country specification
KEY T0 DISPLAY 12345
PRESS WEIGHT UNIT WEIGHT QUANTITY
0.0000 00xxAt weighting mode
[REZERO]
+ [1][2][4] DFT SPC 01 Go to Default SPEC mode.
[0] DFT SPC 01 0Enter 00 –Japan
01 –USA
02 –Europe / SI
[*] PROG C00 To execute country
default specification
INDICATOR : 1 = ZERO; 2 = INSUFFICIENT; 3 = PROG; 4 = KG; 5 = SCALE 1

DC 190 INITIAL SETUP
10
4.4 CUSTOMER SPECIFICATION SETTING
To change or view the Customer SPEC Data.
KEY T0 DISPLAY 12345
PRESS WEIGHT UNIT WEIGHT QUANTITY
0.0000 00xxAt maintenance mode
[REZERO]
+ [1][4][1] SPC00 0 0 0 0 At Customer Specification Mode
[+] SPC01 0 0 0 0 To increase Spec no.
and save spec before.
[1][0][1][1] SPC01 1 0 1 1 0 0 0 0 Enter data to change eg.
0000 to 1011
[+] SPC02 0 1 0 0 Save data and increase
spec no.
[1][0][1][1] SPC02 1 0 1 1 0 1 0 0
[C] SPC02 0 1 0 0 Clear data enter
[-] SPC01 1 0 1 1 Decrease the SPEC no.
[*] PROG C 0 0 Save SPEC data and exit
to programming mode.
[MODE] 0.0000 00xxxx
INDICATOR : 1 = ZERO; 2 = INSUFFICIENT; 3 = PROG; 4 = KG; 5 = SCALE 1
4.5 WEIGHT & MEASURE SPECIFICATION SETTING
To check or change the Weight & Measure SPEC.
Please turn on the Span Switch when using this mode.
KEY T0 DISPLAY 12345
PRESS WEIGHT UNIT WEIGHT QUANTITY
0.0000 00xxAt maintenance mode
[REZERO]+
[1][4][2] SPC20 0 0 0 0 At Weight & Measure Specification Mode
[+] SPC21 0 0 1 1 To increase Spec no. and
save spec before.
[1][0][1][0] SPC21 1 0 1 0 0 0 1 1 Enter data to change eg.
0000 to 1011
[+] SPC22 0 0 1 0 Save data and increase
spec no.
[1][0][1][1] SPC22 1 0 1 0 0 0 1 0
[C] SPC22 0 0 1 0 Clear data enter
[-] SPC21 1 0 1 0 Decrease the SPEC no.
[*] PROG C 0 0 Save SPEC data and exit
to programming mode.
[MODE] 0.0000 00xxxx
INDICATOR : 1 = ZERO;2 = INSUFFICIENT; 3 = PROG; 4 = KG; 5 = SCALE 1

DC 190 INITIAL SETUP
11
4.6 INTERNAL COUNT AND A/D COUNT
To check the internal count of the A / D.
KEY TO DISPLAY 12345
PRESS WEIGHT UNIT WEIGHT QUANTITY
PROG C 0 0 xxAt maintenance mode
[REZERO] +
[*][*][+] 050000 xxUnit weight display the internal count while the
Quantity display the A/D
count
[MODE] PROG C 0 0 xxEscape to maintenance
mode
[MODE] 0.0000 00xxxxReturn to weighing mode
INDICATOR : 1 = ZERO; 2 = INSUFFICIENT; 3 = PROG; 4 = KG; 5 = SCALE 1/2/3/4
4.7 CALIBRATION
Calibrate the scale to it specific weight. Please turn on the Span switch when using this mode. Select
the scale to calibrate before proceeds.
KEY T0 DISPLAY 1234
PRESS WEIGHT UNIT WEIGHT QUANTITY
S-ON At S-ON display.
[REZERO] +
[8][7][1][5] 1.2364 15641 Go to the calibration mode. Display shows zero count.
If display shows–
PRESS CODE LO-ERR or
PRESS CODE HI-ERR -
press [#] to auto compute the
zero point.
The zero count should be at
100,000 ± 20,000 range.
If after auto compute, the zero
count is not in range, press [+]
key to increase or [-] to
decrease the zero count until it
is in range.
[REZERO] 0.0000 93234 Set to zero weight.
5.2715 093234 Place weight on the platter e.g.
5 kg
[5][.][0][0][0]
[0] 5.2715 5.0000 580397 Key in the weight on the platter e.g. 5 kg
[*] ------------------Compute the span calibration.
1
00000 5500000 Weigh and Unit weight show
the span count of the weight
while the Quantity shows the
count of zero + span.
[MODE] S-ON At S-ON display.
0.0000 00xxxxPush the span switch to return
to normal
INDICATOR : 1 = ZERO; 2 = INSUFFICIENT; 3 = KG; 4 = SCALE 1/2/3/4

DC 190 SPECIFICATION LIST
12
5SPECIFICATION LIST (BASED ON VERSION 6.87)
5.1 SOFTWARE VERSION
REVISION
NUMBER MODIFICATION DETAIL SOFTWARE VERSION
0.00 FIRST RELEASE OF NEW SPEC LIST Ver1.04, Ver1.06 &
Ver2.11
0.01 Removed DP122 spec and replace by LP2622
Add SPEC39 bit 0 Ver2.15 and above
0.02 Battery 1&2 Spec (SPEC32 bit 2, SPEC39 bit 1) Ver 3.18 and above
0.03 Added tare Spec on SPEC0 Ver 2.20 and above
0.04 Change load Cell Sensitivities Table Ver 2.22 and above
0.05 Changed to 16 bit CPU, added new mode (Job Schedule
mode) and enable PC to multi-scale communication. Ver 3.43 and above
0.06 Changed RS232 and Force Balance baud rate setting
(1200 to 19200 and 2400 to 38400); Added SPEC43 bit 2 &
3 to set data receive waiting time.
Ver 3.45 and above
0.07 SPEC03 XX01 (12 DigitsTeraoka Code) and SPEC03
00XX (12 Digits Numeric Number) are not used. Ver 3.51 and above
0.08 Added notes 8) and 9). Ver 3.54 and above
0.09 Added SPEC12 bit 1 if set to 0 to download label format
for Eltron printer. Set to 1 for non-downloading. Ver 3.70 and above
0.10 Added SPEC46 to select types of In and Out Inventory
combination.
Added SPEC39 to control AD Timing
Ver 3.72 and above
0.11 Added SPEC45 bit 0 and bit 1 to control Zero Tracking
Speed. Ver 3.78 and above
0.12 Added note 15.
Added SPEC45 bit 3 to select TWB-01970 option board
and TWB-01921 option board.
Added SPEC45 bit 2 to select DP-122 printer or other
printers.
Ver 3.79 and above
0.13 Changed Spec:
The previous usage of SPEC19 bit 0 is changed to
SPEC47 bit 0. Changed selectionof Japan Force Balance
using SPEC19 bit 1 only to selection using SPEC19 bit 0
& 1.
Added New Spec:
Added SPEC47 bit 1 to select webserver (6.84) and
SPEC47 bit 2 for qty scanning (6.84).
Added SPEC47 bit 3 to select label or receipt printing and
SPEC47 bit 1 to enable Siteplayer/Ethernet (6.85).
Added Spec48 bit 0 to select Epson printer (6.86).
Ver 3.80 and above;
Ver 6.80 and above

DC 190 SPECIFICATION LIST
13
5.2 CUSTOMER SPECIFICATION ([REZERO]+[1][4][1])
SPEC NO BIT 3 BIT 2 BIT 1 BIT 0
0Tare when Scale
Change
0:Old Tare (*2)
1:New Tare
Digital Tare
Accumulation
0:No (*2)
1:Yes
0 : Not Used 0:Not Used
1Power Auto Off Function
0 0 0 0 : Auto power off Disable when Net Weight = 0
0 0 0 1 ~ 1 1 1 1 : Duration to activate Power Off (in Minute)
2Scale Specification (*3)
0 0 : Gram 0 1 : Kg
1 0 : Lb 1 1 : Not Used
Kg / Lb Lamp
Inhibit
0 : No (*2)
1 : Yes (*3)
Inventory Display by
Gross Key
0 : Gross Display (*7)
1 : No of Inventory
3ID Code (Only for V2.xx) (*4)
0 0 : Not Used (*5)
0 1 : 16 Digits Teraoka Code
1 0 : Not Used (*5)
1 1 : 16 Digits Numeric Number
Entry Part No (*4)
0 0 : 12 Digits Numeric Number
0 1 : Not Used (*5)
1 0 : Not Used (*5)
1 1 : 16 Digits Teraoka Code (V2.xx)
4Set New Item Code
during Normal Mode
0 : Yes
1 : No
Extent of Insufficient Samples
0 0 : 0.1 %
0 1 : 0.2 %
1 0 : 0.0 %
1 1 : Not Used
Negative Counting
0 : No
1 : Yes
5Sampling Time for
Unit Wt Calculation
0 : 10 times
1 : 5 times
Unit Weight Auto
Recomputing
0 : No
1 : Yes
Date Order
0 0 : Year/Month/Day
0 1 : Day/Month/Year
1 0 : Not Used
1 1 : Month/Day/Year
6Display Accuracy of
Unit Weight
0 : No
1 : Yes
Clear all Input Key in
One Touch (V2.xx)
0 : Yes
1 : No
RS232 Continue
Sending Rate to PC
(V2.xx)
0 : High
1 : Low
Auto Shift to Next
Position (Teraoka
Code Entry)
0 : No
1 : Yes
7Set Point Buzzer
0 : Yes
1 : No
Set Points Latching
(V2.xx)
0 : Latch
1 : No Latch
Set Point Type
0 0 : % Quantity 1 0 : Quantity
0 1 : % Weight 1 1 : Weight
8RS232C Connection
(Force Balance)
0 : No
1 : Yes
RS232C Data Length
(PC/Force Balance)
(Optional)
0 : 7 bits
1 : 8 bits
RS232C Baud Rate
(PC/Force Balance)
(Optional)
0 0 : 19200 1 0 : 4800
0 1 : 38400 1 1 : 9600
9RS232C Stop Bit
(PC/Force Balance)
(Optional)
0 : 1 bits
1 : 2 bits
Force Balance Type
0 : Japan
1 : Export
RS232C Parity Bit
(PC/Force Balance)
(Optional)
0 0 : No 1 0 : Not Used
0 1 : Odd 1 1 : Even
10 RS232C Connection
(PC/Printer)
0 : No
1 : Yes
RS232C Data Length
(PC/Printer)
(Optional)
0 : 7 bits
1 : 8 bits
RS232C Baud Rate
(PC/Printer)
(Optional)
0 0 : 19200 1 0 : 4800
0 1 : 38400 1 1 : 9600

DC 190 SPECIFICATION LIST
14
SPEC NO Bit 3 Bit 2 Bit 1 Bit 0
11 RS232C Stop Bit
(PC/Printer)
(Optional)
0 : 1 bit
1 : 2 bits
Printer Type
(V2.xx)
0 : TVP Printer/
Eltron LP2622 or
LP2722
1 : SE250/
EPSON Printer (*6)
RS232C Parity Bit
(PC/Printer)
(Optional)
0 0 : No 1 0 : Not Used
0 1 : Odd 1 1 : Even
12 RS232C Output
(PC/Printer)
(Optional)
0 0 : Not Available
0 1 : When Counting Condition (PC)
1 0 : By * Key (PC + Printer)
1 1 : In Both Case
ELTRON/TVP
Printer Download
Label Format
0 : Enable
1 : Disable
RS232C with Header
(PC)
0 : Yes
1 : No
13 RS232C Header Send
(PC) (V2.xx)
0 : Code
1 : Title
RS232C Connector
D-Sub DIN
0 0 0:Printer Force Balance
0 0 1 : Force Balance Printer
0 1 0 : Printer PC (*1) (V2.xx)
0 1 1 : PC Printer (*1) (V2.xx)
1 0 0 : PC Force Balance (V2.xx)
1 0 1 : Force Balance PC (V2.xx)
1 1 0-1 1 1 : Not Used
14 RS232C Connection
(Barcode Scanner)
0 : No
1 : Yes
RS232C Data Length
(Barcode Scanner)
(Optional)
0 : 7 bits
1 : 8 bits
RS232 Baud Rate
(Barcode Scanner)
(Optional)
0 0 : 1200 1 0 : 4800
0 1 : 2400 1 1 : 9600
15 RS232C Stop Bit
(Barcode Scanner)
(Optional)
0 : 1 bits
1 : 2 bits
RS232C with Header
(Barcode Scanner)
0 : Yes
1 : No
RS232C Parity Bit
(Barcode Scanner)
(Optional)
0 0 : No 1 0 : Not Used
0 1 : Odd 1 1 : Even
16 Scale 1 (LED):
0 0 : Internal Scale 1
0 1 : Internal Scale 2
1 0 : External Scale
1 1 : Force Balance
Scale 2 (LED) :
0 0 : Internal Scale 1
0 1 : Internal Scale 2
1 0 : External Scale
1 1 : Force Balance
17 Scale 3 (LED):
0 0 : Internal Scale 1
0 1 : Internal Scale 2
1 0 : External Scale
1 1 : Force Balance
Scale 4 (LED) :
0 0 : Internal Scale 1
0 1 : Internal Scale 2
1 0 : External Scale
1 1 : Force Balance
18 Set Point TTL Output
0 : Active Low
1 : Active High
Number of Set Points
0 0 0 : 2 Set Points
0 0 1 : 3 Set Points
0 1 0 : 4 Set Points (Not Used for RS485 Network Card)
0 1 1 : 5 Set Points (Not Used for RS485 Network Card)
1 0 0 : 6 Set Points (Not Used for RS485 Network Card)
19 Display “Not F”
message for item that
is not stored in
memory before
(V2.xx)
0 : Yes
1 : No
Link to IMS
(For US Version in
V2.xx)
0 : No
1 : Yes
Type of Force Balance
(Japan Version Only)
0 0: SHG-300
0 1:HR-200
1 0:HR-60
1 1: Not Used

DC 190 SPECIFICATION LIST
15
5.3 WEIGHT & MEASURE SPECIFICATION ([REZERO]+[1][4][2])
Please turn ON the span switch before proceed.
SPEC NO BIT 3 BIT 2 BIT 1 BIT 0
20 Minimum Display (Scale 1)
0 0 : 2 1 0 : 5
0 1 : 1 1 1 : 10
Minimum Display (Scale 2)
0 0 : 21 0 : 5
0 1 : 11 1 : 10
21
0 : Not Used
Weight Decimal Point Position (Scale 1)
0 0 0 : 00000 0 1 1 : 00.000
0 0 1 : 0000.0 1 0 0 : 0.0000
0 1 0 : 000.00 1 0 1: 0.00000 (*8)
22
0 : Not Used
Weight Decimal Point Position (Scale 2)
0 0 0 : 00000 0 1 1 : 00.000
0 0 1 : 0000.0 1 0 0 : 0.0000
0 1 0 : 000.00 1 0 1 : 0.00000 (*8)
23 Display Resolution
0 0 : 1/10,000 1 0 : 1/2,500
0 1 :1/5,000 1 1 : Not Used
Zero Setting Range
0 0 : + Unlimited 1 0 : ± 10 % FS
-10 % FS
0 1 : ± 2 % FS 1 1 : Not Available
24 Masked Display at
Minus Weight
0 : Gross
1 : Net
Display at Minus
Weight
0 : Minus Display
1 : Masked
Zero Lamp
Lighting Method
0 : Gross
1 : Net
When no AC, Display
Mask when Battery Low
or No Battery
0 : Yes
1 : No
25 Scale Starting Method
0 : Automatic
1 : Manual
IR Mode protected by
Span Switch
0 : No
1 : Yes
Scale Type
0 : Single Scale
1 : Double Scale
Gross Mode Available
0 : Yes
1 : No (*7)
26 Zero Tracking when
Tare
0 : Yes
1 : No
Weight Reset when
Tare
0 : Yes
1 : No
Initial Start Range
0 0 : + Unlimited 1 0 : ± 10 % FS
-10 % FS
0 1 : ± 2 % FS 1 1 : Not Available
27 Comma Display
0 : No
1 : Yes
Digital Tare Setting
0 : No
1 : Yes
Tare Range
0 0 : 100% FS 1 0 : 5% FS
0 1 : 50% FS 1 1 : Not Available
28 Auto Tare Clear when
Rezero
0 : No
1 : Yes
Automatic Unit Weight Clear Condition
0 0 : Over Net 5d and Gross 21d and
Weight Stable
0 1 : >= Net 1d and Weight Stable
1 0 : >= Net 1d and Quantity > 0 and
Weight Stable
Automatic Unit Weight
Clear
0 : No
1 : Yes
29 Digital Tare Rounding
0 : Tare Exactly
1 : Round to Nearest
Increment
Tare Value Exchange
0 : Yes
1 : No
Tare Addition
0 : Yes
1 : No
Tare Subtraction
0 : Yes
1 : No

DC 190 SPECIFICATION LIST
16
SPEC NO BIT 3 BIT 2 BIT 1 BIT 0
30 Loadcell Sensitivities Selection (mV/V) (Scale 1)
0 0 0 0 4.00
0 0 0 1 3.76
0 0 1 0 3.52
0 0 1 1 3.28
0 1 0 0 3.04
0 1 0 1 2.80
0 1 1 0 2.56
0 1 1 1 2.32
1 0 0 0 2.08
1 0 0 1 1.84
1 0 1 0 1.60
1 0 1 1 1.36
1 1 0 0 1.12
1 1 0 1 0.88
1 1 1 0 0.64
1 1 1 1 0.40
31 Loadcell Sensitivities Selection (mV/V) (Scale 2)
0 0 0 0 4.00
0 0 0 1 3.76
0 0 1 0 3.52
0 0 1 1 3.28
0 1 0 0 3.04
0 1 0 1 2.80
0 1 1 0 2.56
0 1 1 1 2.32
1 0 0 0 2.08
1 0 0 1 1.84
1 0 1 0 1.60
1 0 1 1 1.36
1 1 0 0 1.12
1 1 0 1 0.88
1 1 1 0 0.64
1 1 1 1 0.40
32 Calibration /
Default SPEC /
SPEC 142 Mode
Protected by Span
Switch
0 : Yes
1 : No
Platform Battery
Low Lamp
0 : Yes
1 : No
Auto Exit from Add
Mode
0 : No
1 : Yes
External Loadcell
(Scale 3)
0 : No
1 : Yes
33 Over Weight Mask at
0 : +1d
1 : +9d
Weight Decimal Point Position (Scale 3)
0 0 0 : 00000 0 1 1 : 00.000
0 0 1 : 0000.0 1 0 0 : 0.0000
0 1 0 : 000.00
34
0 : Not Used
Loadcell Type
(Scale 1)
0 : For Standard or
Normal Loadcell
1 : For Abnormal
Loadcell with too
Large Offset
A/D Board (Scale 1)
0 0 : Normal
0 1 : Prevent from Small Vibration /
Fast Change in Display
1 0 : Prevent from Medium Vibration
1 1 : Prevent from Large Slow Change
in Display
