Rice Lake Performance Series User manual

882D
Belt Scale Integrator
Technical Manual
PN 184260 Rev GSeptember 19, 2023

© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Revision History
© Rice Lake Weighing Systems ● All Rights Reserved 3
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
Revision History
This section tracks and describes manual revisions for awareness of major updates.
Revision Date Description
F December 27, 2022 Established revision history; Revolution software and FCC statement update; UKCA declaration of conformity
added; firmware version 2.04
G September 19, 2023 Added power cord changes
Table i. Revision Letter History

882D Belt Scale Integrator
4 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.4 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.4.1 Available Option Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.1 Product Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 Mounting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3 Backplate Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4.1 Load Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4.2 Cable Shield Grounding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4.3 Power Cable Grounding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4.4 Power Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.4.5 Speed Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.4.6 Digital I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4.7 Serial Communications – Port 1 (COM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4.8 USB Device Communications – Port 2 (USBCOM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.5 USB Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6 Ethernet Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.7 CPU Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.8 Audit Trail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.9 Backplate Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.9.1 Sealing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.10 Parts Kits Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.11 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1 Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.2 Weigh Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.3 Audit Trail Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.4 Totalizers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.4.1 Totalizer 1 and 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.4.2 Master Totalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.0 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 Setup Switch Configuration Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 User Menu Configuration Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.3 General Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.4 User Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.5 Audit Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.6 Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.6.1 Setup – Scale Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.6.2 Setup – Features Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.6.3 Setup – Ports Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Contents

Contents
© Rice Lake Weighing Systems ● All Rights Reserved 5
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
4.6.4 Setup – Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.6.5 Setup – Setpoints Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.6.6 Setup – Digital I/O Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.6.7 Setup – Analog Output Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.6.8 Setup – Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.7 Test Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.8 Time & Date Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1 Speed Sensor Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.1 Calculated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.2 Revolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.3 Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.2 Weigh Frame Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.2.1 Static Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.2.2 Dynamic Span . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.2.3 Dynamic Zero. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5.2.4 Linearization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.0 Using Revolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.1 Connecting to the 882D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.2 Saving and Restoring Configuration Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.2.1 Uploading Configuration to Revolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.2.2 Downloading to the 882D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.3 Updating the 882D CPU Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.0 EDP Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.1 Reporting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.1.1 AUDITJUMPER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.1.2 BUILD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.1.3 DIN#s - Digital Input State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.1.4 DISPLAYBUILD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.1.5 DUMPAUDIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.1.6 FBTEST1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.1.7 HARDWARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.1.8 OPTVERSION#s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.1.9 P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.1.10 Pn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.2 Weigh Mode Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.2.1 DISPLAYMODE Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.2.2 Totalizer Value Reporting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.2.3 Load Value Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.2.4 Speed Value Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.2.5 Rate Value Reporting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.2.6 XE and XEH Error Code Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.3 Key Press Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.4 Batching Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.5 Calibration Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.5.1 Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.5.2 Weigh Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.6 RESETCONFIGURATION Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

882D Belt Scale Integrator
6 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
7.7 Parameter Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.7.1 Scale Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.7.2 Time and Date Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.7.3 Passwords Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.7.4 Features Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.7.5 Ports – COM Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.7.6 Ports – USBCOM Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.7.7 Ports – Ethernet Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.7.8 Ports – Fieldbus Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.7.9 Keypad Lock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.7.10 Setpoints Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.7.11 Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.7.12 Digital I/O Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.7.13 Database Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7.7.14 Analog Output Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
7.7.15 Digital Output Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.0 Print Formatting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.1 Print Formatting Tokens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.2 Default Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8.3 Customizing Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8.3.1 Using the EDP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8.3.2 Using the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
9.0 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
9.1 Ethernet Server/Client Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
9.1.1 Direct Connection from a PC to the 882D Ethernet Server without a network (Ad-Hoc) . . . . . . . . . . . . . . . . . . . . . . 80
9.1.2 PC Connection to the 882D Ethernet Server Through a Network Switch or Router . . . . . . . . . . . . . . . . . . . . . . . . . 81
9.1.3 Connection to a Remote Server - Demand Print to an Ethernet Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
9.1.4 Connecting to a Remote Server - Stream weight data to an Ethernet Remote Display. . . . . . . . . . . . . . . . . . . . . . . 82
9.1.5 Connecting to a Remote Server, Stream/Demand Data to Remote Ethernet-to-RS-232 Device Server. . . . . . . . . . 83
10.0 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
10.1 Batch and Continuous Setpoints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
10.2 Batch Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
10.3 Batching Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
11.0 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
11.1 Maintenance Checkpoints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
11.2 Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
11.3 Troubleshooting Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
11.4 Battery Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
11.5 Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
11.6 CPU Board Excitation Fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
11.6.1 Fuse Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
11.6.2 Fuse Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
11.7 882D Permanent Field Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
12.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
12.1 Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
12.1.1 Displayed Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
12.2 Using the HARDWARE Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Contents
© Rice Lake Weighing Systems ● All Rights Reserved 7
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
12.3 ASCII Character Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
12.4 Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
12.4.1 Stream Serial Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
12.4.2 Stream Tokens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
12.4.3 Print Output Serial Data Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
12.4.4 RS-485 Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
12.5 Analog Output Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
12.6 Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
12.7 CPU Board Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
13.0 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
14.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

882D Belt Scale Integrator
8 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 9
1.0 Introduction
This manual is intended for use by service technicians responsible for installing and servicing the 882D Belt Scale Integrator.
Manuals are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
Warranty information is available at www.ricelake.com/warranties
1.1 Overview
A belt conveyor scale continuously measures bulk material as it is moved along a conveyor. The system requires two general
parameters to operate:
• Weight of the material being moved along the conveyor belt
• Speed at which the material is moved along the conveyor belt
The weight of the material on the belt is determined by weighing a section of the conveyor belt loaded with material and
subtracting the average weight of the unloaded belt. The speed at which the material is moving is determined by measuring the
speed of an idler or wheel in contact with the conveyor belt. The weight and speed are combined by the 882D to give a running
total and a rate of flow for the material. Optimum operation of the scale system requires the components to be installed
correctly, periodically calibrated and properly maintained.
1.2 Safety
Safety Definitions:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT: Indicates information about procedures that, if not observed, could result in damage to equipment or
corruption to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
WARNING
Failure to heed could result in serious injury or death.
Some procedures described in this manual require work inside the enclosure. These procedures are to be performed by qualified
service personnel only.
Ensure the power cord is disconnected from the power source before opening the unit.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without enclosure completely assembled.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not exceed the rated load limit of the unit.
Do not make alterations or modifications to the unit.
Do not use for any purpose other than as a belt scale integrator.
Do not remove or obscure warning labels.
Do not submerge.
i

882D Belt Scale Integrator
10 Visit our website www.RiceLake.com
1.3 FCC Compliance
United States
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la Class A prescites dans le Règlement sur le brouillage radioélectrique edicté par le ministère des
Communications du Canada.
1.4 Options
There are two option card slots, connectors J8 and J9, that can support Rice Lake option cards. Each option card kit includes
instructions for installing and set up.
1.4.1 Available Option Cards
Single Analog Output – supports a single analog output
4-Channel Relay – supports 4 relay outputs
8-Channel Digital I/O (24V DC) – supports 8 digital inputs/outputs
24-Channel Digital I/O (TTL level) – supports 24 digital inputs/outputs
Fieldbus Carrier Board – only supported on slot 1 and supports the following modules:
• Ethernet/IP™
• PROFINET®
• DeviceNet®
• PROFIBUS®
• Modbus TCP/IP®
• EtherCAT®
NOTE: Refer to the Interface Option Cards Installation and Programming Manual (PN 190906) for Fieldbus command
specifications.
Option Card Power Limitations
Only two of the following can be used simultaneously due to power limitations:
• Single Analog Output option card
• 24-Channel Digital I/O option card
• Pulse encoder that draws > 50 mA
• 5V on the Digital I/O connector > 100 mA

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 11
2.0 Installation
This section describes procedures for connecting power, load cells, speed sensor, digital I/O and data communications cables
to the 882D. An assembly drawing and parts list are included for the service technician.
Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to state and
local regulations.
Risque d’explosion si la batterie est remplacée par un type incorrect. Mattre au rebus les batteries usagées
selon les règlements d'état et locaux.
• Use anti-static protection for grounding and to protect components from electrostatic discharge (ESD) when working inside the
882D enclosure.
• Procedures requiring work inside the 882D must be performed by qualified service personnel only.
• The power supply cord serves as the power disconnect for the 882D. The power receptacle to the 882D must be easily
accessible.
2.1 Unpacking
Immediately after unpacking, visually inspect the 882D to ensure all components are included and undamaged. The 882D
enclosure comes assembled to the universal mount. The shipping carton should also contain the parts kit (Section 2.10 on
page 20) and the manuals. If any parts were damaged in shipment, notify Rice Lake Weighing Systems and the shipper
immediately.
2.1.1 Product Dimensions
Figure 2-1. Product Dimensions
Risk of electrical shock.
Risque de choc.
Disconnect power before servicing.
Débranchez l’alimentation avant l’entretien.
WARNING
AVERTISSEMENT
CAUTION
ATTENTION
9.93
8.10
.63
.68
8.94
6.50
4.14
4.31
4.00
6.25 1.06
2.50
.73
.27
1.934.50
.28
Top View Bottom View
Front View Back ViewSide View

882D Belt Scale Integrator
12 Visit our website www.RiceLake.com
2.2 Mounting Instructions
The 882D includes a universal mount. The universal mount can be mounted on a wall, tabletop or any flat surface.
NOTE:The universal mount comes attached to the 882D. Rice Lake Weighing Systems recommends removing the 882D
from the universal mount prior to mounting.
Figure 2-2. Mounting the 882D
1. Using the mount as a template, mark the screw locations.
2. Drill holes for the screws.
3. Secure the universal mount using the appropriate length 1/4'' or M6 hardware (not included).
4. Reattach the 882D to the universal mount.
2.3 Backplate Removal
Remove the backplate of the 882D to connect cables for installed option cards and to gain access to the display board, CPU
board and power supply board.
WARNING: The 882D has no on/off switch. Before removing the backplate and opening the unit, ensure the power cord is
disconnected from the power receptacle.
1. Place the 882D face-down on an anti-static work mat.
2. Remove the M4 nuts holding the backplate to the enclosure with a 7 mm socket or wrench.
3. Lift the backplate away from the enclosure. Disconnect the ground wire from the backplate by removing the M4 nut
with a 7mm socket or wrench and set it aside.
Figure 2-3. Removing the Backplate
NOTE:882D ships with only four nuts securing the backplate. The remaining backplate nuts are included in the parts kit.
For reassembly torque backplate nuts to 15 in-lb (1.7 N-m).

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 13
2.4 Cable Connections
The 882D has seven cord grips at the bottom of the enclosure, one is used for the power supply. The backplate must be
removed to make connections to the load cells, speed sensor, communications, digital inputs and digital outputs. Plugs must
remain in all unused cord grips to prevent moisture and dust from entering the enclosure. For recommended wire gauge and
cord grip specifications refer to Table 12-6 and Table 12-7 on page 97. Torque cord grip nuts to 33 in-lb (3.7 N-m).
IMPORTANT: Do not have open/bare wires outside of the enclosure. Make sure no stripped portion of cable is on the
outside of the cord grips.
WARNING: Power must be disconnected before servicing or installation. Failure to do so could result in electrical shock
and damage to the CPU board.
2.4.1 Load Cells
To attach the cable from a load cell or junction box, route cable to the J1 connector ( Figure 2-9 on page 18 ). Connector for the
cable is included in the parts kit. Wire the load cell cable from the load cell or junction box to connector as shown in Table 2-1 . If
using a 6-wire load cell cable (with sense wires), remove jumpers JP5 and JP6 (Figure 2-9 on page 18).
NOTE: For a 4-wire installation leave jumpers JP5 and JP6 in place and leave pins 3 and 4 empty on the connector.
2.4.2 Cable Shield Grounding
Except for the power cord, all cables routed through the cord grips must be shield grounded against the enclosure.
• Use hardware provided in the parts kit to install shielding clamps on the grounding studs at the bottom of the enclosure
• Install only the necessary amount of shielding clamps for the cord grips to be used; finger tighten nuts at this time
• Route cables through the cord grips and shielding clamps to determine the cable lengths required to reach the
appropriate cable connectors
• Mark the cables to remove the insulated jackets and shielding as described in the next two sections
Foil Shielded Cable
Figure 2-4. Foil Shielded Cable
1. Strip the insulated jacket and foil 1/2'' (15 mm) past the shielding clamp.
2. Strip another 1/2'' of the insulated jacket, leaving the foil shielding exposed.
3. Fold the foil shielding back on the cable where the cable passes through the clamp.
4. Ensure the silver (conductive) side of the foil is turned outward.
5. Wrap the shield wire around the cable so it contacts the foil where the cable passes through the clamp.
6. Torque the shielding clamp nut to 10 in-lb (1.13 N-m) so the clamp is around the cable and contacting the shield wire.
Connector Pin Function
J1 1 +SIG
2 –SIG
3 +SENSE
4 –SENSE
5 +EXC
6 –EXC
For 6-wire load cell connections, remove
jumpers JP5 and JP6.
Table 2-1. J1 Pin Assignments
Silver
side out
Shield wire
Cut insulated jacket here
for foil shielded cables
Length of foil before
folding back on
cable insulation

882D Belt Scale Integrator
14 Visit our website www.RiceLake.com
Braid Shielded Cable
Figure 2-5. Braid Shielded Cable
1. Strip the insulated jacket and braided shielding from a point just past the shielding clamp.
2. Strip another 1/2'' (15 mm) of the insulated jacket, leaving the braid exposed where the cable passes through the clamp.
3. Tighten the shielding clamp nut.
2.4.3 Power Cable Grounding
AC versions of the 882D are shipped with the AC power cable already installed and grounded to the enclosure. For DC
versions of the 882D, use the following steps to ground and connect the DC power cable.
1. Run DC power cable (not included) up through the cord grip (Figure 2-6).
NOTE: For the recommended wire gauge refer to Table 12-6 on page 97.
2. One wire will be terminated (grounded) at a stud near the cord grip using the proper grounding stack. The backplate
ground is already attached to a stud. Remove it so that the power cord ground can be on the bottom of the stack as
represented in Figure 2-6. Torque nuts to 10 in-lb (1.13 N-m).
3. Run the other two wires toward the back of the enclosure and connect them to the three pin plug (included in the parts
bag) that connects into the power supply board as shown in Figure 2-6 and Table 2-2.
A ferrite from the parts kit must be applied to
the DC power cable within 1'' of the cord grip.
Figure 2-6. Connect DC Wiring
Pin AC DC
1 N +
2 Chassis
GND
Chassis
GND
3 L –
Table 2-2. Power Connection Pin Assignments
Braid
Cut insulated jacket here
Power
Supply
Power Cord Ground
Backplate
Ground
Grounding
Stud
M4 Nut
Lock
Washer

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 15
2.4.4 Power Cables
AC versions of the 882D are shipped with the AC power cable already installed.
Figure 2-7. AC Power Cable
NOTE: The AC power cable is grounded to the threaded grounding hole on the back panel of the enclosure between the
cord grip and the power supply connections rather than using Pin 3. This is a UL requirement.
NOTE: Colors may vary depending on manufacturer of AC power cable. Utilize testing procedures to ensure proper
installation.
2.4.5 Speed Sensor
A belt conveyor scale must be equipped with an encoder (speed sensor) that accurately senses the belt speed and travel
distance when the belt is empty or loaded. The J13 connector provides the pulse input from the speed sensor to the 882D. To
attach the cable from the encoder, route the cable to the J13 connector (Figure 2-9 on page 18). The connector for the cable is
included in the parts kit. Wire the cable to connector as shown in Figure 2-4. Pins 4, 5 and 6 are the top level of the connector
and make up the primary pulse input channel (Input 1). Pins 1, 2 and 3 are the bottom level of the connector and make up the
secondary pulse input channel (Input 2).
Table 2-4. J13 Pin Assignments (Speed Sensor)
Pin Description Wire Color Cable Part No.
1 120 VAC (Line In) Brown or Black 180842
2 AC Neutral Blue or White
3 Ground N/C or Green/Yellow –
4 DC Out (-V) Black 199514
5 DC Out (+V) Red
Table 2-3. AC Power Supply Pin Assignments
Connector Pin Signal
J13 1 +12V, 100 mA max
2 Ground
3 Pulse Input #2
4 +12V, 100 mA max
5 Ground
6 Pulse Input #1

882D Belt Scale Integrator
16 Visit our website www.RiceLake.com
2.4.6 Digital I/O
The Digital I/O Port, J2 connector (Figure 2-9 on page 18) is intended to be connected to both digital inputs and outputs.
Digital inputs can be set to provide many functions, including most keypad functions except MENU. Digital inputs are active low
(0 VDC) and inactive high (5 VDC). Use the Digital I/O menu to configure the digital inputs.
Digital outputs are used to control relays that drive other equipment. Outputs are designed to sink, rather than source, switching
current. Each output is an open collector circuit, capable of sinking 20 mA when active. Digital outputs are active when low or at
0 VDC, with reference to the 5 VDC supply.
Use the Digital I/O menu to set the function of the Digital I/O pins to OUTPUT and then use the Setpoints menu to configure the
digital outputs. Table 2-5 shows the pin assignments for the J2 connector.
2.4.7 Serial Communications – Port 1 (COM)
The J3 connector (Figure 2-9 on page 18) is intended to provide a connection point for the RS-232 or the two-wire
RS-485/RS-422 serial communications. Table 2-6 shows the pin assignments for the J3 connector.
NOTE: For RS-232, all four switches on SW3 (Figure 2-9 on page 18) must be in the OFF position.
For RS-485/RS-422, all four switches on SW3 must be in the ON position.
2.4.8 USB Device Communications – Port 2 (USBCOM)
The USB Device Port, J4 micro USB connector (Figure 2-9 on page 18), is intended to be connected to a PC only. It appears as
a Virtual COM Port and is assigned a “COMx” designation. Applications communicate through the port like a standard RS-232
communications port.
A ferrite from the parts kit must be applied to the USB cable within 1'' of the cord grip.
The cable must be sent through the ferrite twice.
The driver must be installed on the PC before the USB Device Port can be used. With the PC and 882D powered on, connect a
USB cable from the PC to the micro USB connector (J4) on the 882D. The PC will recognize that a device has been connected,
and attempt to install the driver needed to make it work. The driver can also be downloaded from the Rice Lake website.
NOTE: If using Windows 7 or later and the PC is connected to the Internet, the operating system may be able to install the
drivers without any interaction.
When the individual drivers are installed, a new COM Port designation is assigned for each physical USB port the 882D is
connected to on the PC.
Connector Pin Signal
J2 1 5VDC, 500 mA max
2 GND
3 DIO1
4 DIO2
5 DIO3
6 DIO4
Table 2-5. J2 Pin Assignments (Digital I/O)
Pin RS-232 RS-485/RS-422
1 GND GND
2 RX B
3 TX A
Table 2-6. J3 Pin Assignments (Port 1 Serial Communications)

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 17
For example, if the PC has two physical RS-232 COM Ports, they most likely are designated COM1 and COM2. When
connecting the 882D to a USB port on the PC, it is assigned the next available port designation, or in this case, COM3. When
plugging into the same physical USB port on the PC, the port designation is again COM3. If plugging into another physical USB
port on the PC, it is assigned the next available designation, in this case COM4.
After the drivers are installed, use Windows Device Manager to determine the COM Port designation that was assigned to the
USB port. Or open the application that is to be used with the 882D, such as Revolution®, to see which ports are available.
Configuration of the USB Device Port is done in the USBCOM sub-menu under PORTS in configuration mode.
The port can be configured as either a demand port for EDP commands and printing, or as a data streaming port. Other settings
include the termination character(s), echoes, responses, the end-of-line delay and whether or not the 882D displays a 'print'
message when a print format sends data out the port.
NOTE: If a computer application has an open communications connection through the USB Device Port and the physical
cable connection is interrupted, a soft reset must be performed on the 882D or the power must be cycled to the 882D; the
connection in the computer application must be disconnected and then reconnected before it will continue to communicate
with the 882D.
For the USB Device Port, it does not matter what the settings are for Baud, Data Bits, Parity and Stop Bits in the computer
software. The port communicates in the same way regardless of these settings.
This port is not a host port and is not intended to be connected to other devices such as keyboards, memory sticks or
printers.
2.5 USB Host
The 882D will be capable of hosting a USB device through the J5, Type A USB connection, in a future release.
2.6 Ethernet Communications
The 882D features Ethernet TCP/IP 10Base-T/100Base-TX communication using a standard RJ45 connector, J6 (Figure 2-9
on page 18). It can support two simultaneous connections, one as a server, the other as a client.
Through an Ethernet network, software applications can communicate with the 882D using the EDP command set (Section 7.0
on page 57), or data can be streamed continuously from the 882D, or printed on demand.
The Ethernet port supports both DHCP and manual configuration of settings such as the IP and netmask. In addition, the TCP
Port number, Primary and Secondary DNS, and the Default Gateway can be configured using the Ethernet sub-menu of the
Ports setup menu. For more information on configuring the Ethernet port see Section 4.6.3.2 on page 38.
Physical connection to the 882D Ethernet port can be made directly from a PC to the 882D (AdHoc Network), or through a
network router or switch. The port supports auto-sensing MDI/MDIX cable configuration, so either straight-through or crossover
cables can be used.
The RJ45 Ethernet jack on the 882D CPU board houses two LEDs to
indicate the status and speed of the connection.
Yellow LED (left) indicates the status of the connection:
• Off for no link
• On for a link
• Blinking if there is activity
Green LED (right) is:
• Off for a 10Base-T connection
• On for a 100Base-TX connection
IMPORTANT: The Ethernet port is not intended for use on Telecom Networks Circuits that are subject to lightning or power
faults. For information on using the Ethernet port see Section 9.1 on page 80.
Figure 2-8. RJ45 Ethernet Jack
Yellow LED Green LED

882D Belt Scale Integrator
18 Visit our website www.RiceLake.com
2.7 CPU Board
Figure 2-9. 882D CPU Board
Connectors
The COMM 1 port supports RS-232 or two-wire RS-485/RS-422 communications; selectable with switch SW3. The port is
configured using the COM menu under Ports. See Section 4.6.3.1 on page 37.
2.8 Audit Trail
The 882D supports a Type 3 Audit Trail. The Audit Trail records all of the changes to Legal for Trade parameters.
During installation, determine if access will be allowed to the configuration and calibration functions through the front panel. The
position of the 3-pin Audit Trail jumper (JP4) on the CPU board controls if access is allowed or not.
• If the jumper is set to ON, the Setup Menu will be visible, making calibration and configuration accessible through the
front keypad.
• If set to OFF, the Setup Menu will not be visible, making calibration and configuration accessible only by pressing the
setup switch.
The audit trail event logger operates in either position of the audit jumper.
R
6
1
R
8
0
R
8
9
R
4
5
C
7
3
R
1
2
R
22
0
S
G
A
P
2
T
T
PX
2
U
1
3
C
3
8
U
1
6
L
9
R
1
1
9
9
JP4
C
5
2
C
3
3
R
4
3
T
P
T
5
7
R
8
2
R
8
C
6
R
3
5
T
P
T
7
3
R
3
1
U
1
5
U
1
8
R
9
2
R
5
4
R
4
4
R
22
1
R
7
8
LED1
LED8
R
9
3
LED10
T
P
S
1
3
3
C
6
8
S
G
AP
1
R
6
4
R
9
4
C
4
1
JP3
U
3
R
22
7
C
5
5
L
7
R
8
3
L
8
U
1
7
C
4
3
S
G
A
P
5
V
R
1
R
3
4
C
5
8
R
9
6
T
P
T
5
4
4
4
T
P
T
5
6
C
3
9
M
H
1
R
1
7
8
8
R
7
9
C
4
0
R
8
6
C
4
9
T
P
T
5
5
C
6
5
S
G
AP
4
R
8
1
U
1
9
C
7
R
5
7
C
6
0
C
4
2
JP6
R
6
2
T
P
T
7
2
LED6
RN
1
C
7
2
C
1
4
4
T
P
T
7
0
R
5
6
L
3
L
4
L
1
R
6
0
R
8
4
O
N
SW2
C
6
9
R
5
8
O
N
SW4
LED7
L
6
L1
1
R
7
R
5
9
C
8
C
4
4
C
7
4
C
3
1
C
7
9
R
5
0
R
0
1
C
7
6
R
I
C
E
L
A
K
E
C
2
9
C
3
7
X
1
R
1
0
S
G
AP
3
R
8
5
R
9
T
P
T
6
9
T
PS
1
5
R
7
7
R
1
3
9
R
16
1
C
5
3
C
2
4
TP34
R
7
2
C
1
6
T
P
T
7
1
C
1
8
8
R
8
7
R
4
0
C
7
5
R
9
1
M
H
2
C
2
3
T
P
T
5
9
R
4
7
T
P
S
1
2
2
C
2
6
C
4
7
C
7
7
R
6
3
C
8
0
R
7
4
4
C
3
6
C
2
8
C
2
7
C
5
1
1
JP2
R
1
1
C
6
3
T
P
T
6
7
T
P
T
7
4
SW1
C
6
2
JP5
C
4
8
T
P
T
5
8
R
3
7
JP1
CTS
1 2 3 4
ON
SW3
1
1
7
7
U
1
2
2
V
R
2
C
8
4
C
7
0
U
4
C
4
5
C
6
4
T
PS
1
8
8
U
11
R
12
5
5
R
12
2
2
R
9
5
R
1
1
5
5
R
1
1
1
C
6
1
C
5
0
R
1
2
3
3
R
12
4
T
P
S
1
1
1
R
7
5
5
R
30
0
R
1
3
C
1
2
C
3
U
7
C9
2
C
1
9
R
5
L
2
R
4
R
7
1
R
1
8
R
0
2
LED4
LED2
R
3
3
C
2
0
C
6
7
R
2
7
R
2
8
L
5
C
5
T
P
T
6
6
R
2
6
C
9
6
R
1
6
R
0
3
C
1
7
U
1
0
0
LED9
R
3
2
R
2
3
C
1
5
R
4
8
C
2
5
R
10
0
R
1
6
5
5
C
5
7
R
2
0
R
10
1
C
8
5
R
2
2
R
7
3
3
R
2
3
8
R
14
6
6
4
4
R
1
4
R
9
9
C
7
8
T
P
T
6
0
D
1
7
7
7
7
7
7
7
R
5
1
R
1
4
8
8
C
5
9
U
1
4
M
H
9
TP4
C
1
0
0
D
1
5
LED5
T
P
T
6
1
C
8
6
R
2
3
5
T
PS
1
6
T
PS
1
7
R
1
7
6
T
PS
1
4
R
1
7
R
2
1
R
16
8
8
TP45
R
1
9
C
2
1
TP43
U
2
2
C
1
0
4
W
6
C
9
0
U
2
6
C
1
0
3
C
7
1
TP42
T
PS
6
D
4
T
P
T
7
5
R
16
4
R
2
9
W
5
R
16
9
9
U
2
R
5
5
F
1
R
1
7
5
R
3
0
C
2
2
C
1
3
W
4
R
1
7
7
C
1
08
C
10
5
TP44
R
9
0
R
6
6
C
3
2
D
9
D
7
A
S
S
Y
P
N
/
R
e
v
R
18
0
D
1
1
D
8
S
G
AP
6
R
16
2
D
3
R
6
5
D
2
R
3
8
R
17
9
W
2
C
3
5
R
4
6
R
17
1
C
3
4
X
3
D
6
D
5
T
T
P
S
5
P
P
b
b
C
4
6
U
1
U
2
2
0
X
2
R
4
9
R
8
8
M
H
1
0
C
3
0
R
5
2
C
6
6
D
1
R
17
2
C
5
6
R
16
6
6
U
9
R
6
U
5
U
U
6
X
4
R
5
3
D
1
0
T
V
S
2
T
V
S
1
C
5
4
R
16
3
R
17
0
0
R
16
7
M
H
3
M
H
4
M
H
5
M
H
6
M
H
7
M
H
8
ON (AUDIT) OFF
Watch
Dog
C
ou
p
on
LB3
J2
J6
J3
4 6
3
J13
J4
J8
B1
J1
J5
J7
U8
J9
Setup Switch
Header (JP3)
Audit Jumper (JP4)
Remote Sense
Jumpers (JP5, JP6)
RS-232/RS-485/
RS-422 (SW3)
• Load Cell (J1)
• DIO (J2)
• COMM 1 (J3)
• USB Micro Device (J4)
• USB Host (J5)
• Ethernet TCP/IP (J6)
• Power Board (J7)
• OPT#1 (J8) and OPT#2 (J9)
• Pulse Input (J13)

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 19
2.9 Backplate Attachment
Once cabling is complete, reattach the backplate ground wire to the backplate. Position the backplate over the enclosure and
install the eight backplate nuts. Use the torque pattern shown in Figure 2-10 to prevent distorting the backplate gasket.
Torque nuts to 15 in-lb (1.7 N-m).
Figure 2-10. Torque Pattern
2.9.1 Sealing
In certain applications, it may be necessary to seal the 882D to restrict access from the setup switch.
882D Sealing
1. Remove the lower left and lower center nuts securing the backplate. Replace with two drilled hex standoffs found in
the parts kit.
2. Place the sealing wire through the drilled hex standoffs on the backplate, then through the fillister head screw at the
bottom of the enclosure, as shown in Figure 2-11.
3. Seal the wire to secure.
Figure 2-11. Sealing the 882D
12
86
57
3
4

882D Belt Scale Integrator
20 Visit our website www.RiceLake.com
2.10 Parts Kits Components
Parts Kit, AC Power (PN 180851) Parts Kit, DC Power (PN 187498)
Part No Description Qty Part No Description Qty
153873 Connector, 3 Pos Screw Terminal 1 153873 Connector, 3 Pos Screw Terminal 1
153883 Connector, 6 Pos Screw Terminal 3 153883 Connector, 6 Pos Screw Terminal 3
15631 Cable Tie, 3in Nylon 6 15631 Cable Tie, 3in Nylon 6
16159 Bag, Plastic 3 x 5 1 15694 Connector, Eye Crimp No 8 1
180826 Nut, M4 x 0.7 x 10mm 10 15888 Terminal Block, 3 Position 1
180852 Standoff, M4 x 0.7 x 10mm 2 16159 Bag, Plastic 3 x 5 1
181694 Connector, 3 x 2 Pos Spring Term 1 180826 Nut, M4 x 0.7 x 10mm 10
184278 Ferrite Core, Snap On 1 180852 Standoff, M4 x 0.7 x 10mm 2
186198 Label, Capacity Belt Scale 1 181694 Connector, 3 x 2 Pos Spring Term 1
19538 Post Plug, Slotted Black 1 184278 Ferrite Core, Snap On 2
42149 Bumper, Rubber Grommet 4 186198 Label, Capacity Belt Scale 1
53075 Clamp, Ground Cable Shield 4 19538 Post Plug, Slotted Black 1
67550 Clamp, Ground Cable Shield 2 42149 Bumper, Rubber Grommet 4
53075 Clamp, Ground Cable Shield 4
67550 Clamp, Ground Cable Shield 2
Table 2-7. Parts Kits Components
