Rice Lake RL101 User manual

RL101
Below-the-Hook Scale
Operation Manual
PN 220243 Rev AOctober 13, 2023

© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Revision History
© Rice Lake Weighing Systems ● All Rights Reserved 3
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
Revision History
This section tracks and describes manual revisions for awareness of major updates.
Revision Date Description
AOctober 13, 2023 Initial manual release with product launch
Table i. Revision Letter History

Contents
RL101 Below-the-Hook Crane Scale
4 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1.1 Adhere to Laws and Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1.2 Operator Obligations and Prohibitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1.3 Safety Measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1.4 RL101 Scale Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1.5 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1.6 Risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1.7 Personal Protective Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.2 Identification labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.3.1 Permitted Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.0 Hardware Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Main components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 PACKAGING AND HANDLING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2.1 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Annunciators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.4 Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.5 Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.6 Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.6.1 RL101 Scale Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.6.2 Remote Control Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1 RL101 Scale Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1.1 Checks Before Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.2 Load Lifting and Weight Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3 Basic Scale Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3.1 Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3.2 Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3.3 Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.3.4 Display Brightness Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.3.5 Automatic Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3.6 Tare Deletion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3.7 Set Preset Tare Value (PT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.4 Advanced Scale Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.4.1 Access the Function Menu and Set the Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.4.2 Activate Weight Hold Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.4.3 Disable the Weight Hold Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.4.4 Change between Net and Gross Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.4.5 Weight Peak Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.4.6 Disable Weight Peak Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.4.7 Total Function (Weight Summation). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.4.8 Convert Measurement Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.4.9 How to Convert Measurement Units with Unit Conversion Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.5 Set PEAK Sampling Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.0 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Contents
© Rice Lake Weighing Systems ● All Rights Reserved 5
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
4.1 Daily Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2 Regular maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.3 Maintenance Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.4 Maintenance Registry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.1 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2 Error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

RL101 Below-the-Hook Crane Scale
6 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 7
1.0 Introduction
This manual is intended for operators using and managing the RL101 scale. It provides information about the hardware,
machinery use, safety information, maintenance and troubleshooting.
Manuals are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
Warranty information is available at www.ricelake.com/warranties
1.1 Safety
Safety Definitions:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT: Indicates information about procedures that, if not observed, could result in damage to equipment or
corruption to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
WARNING
Failure to heed could result in serious injury or death.
Read this manual carefully before carrying out any handling operations or lifting any loads.
Only use lifting equipment with a capacity suitable for the weight to be lifted.
Keep hands, feet and loose clothing away from moving parts.
Before using the RL101 scale, ensure it is in proper working order.
Apply the load to the hook only when the load is resting on the ground.
To achieve a correct weighing result, the load must be raised by at least 2 to 5 in from the ground.
Use the RL101 scale in non-condensing environments with moderate temperature and humidity levels.
Use the RL101 scale where there are no vibrations.
Never exceed the rated load limit of the unit.
Never use the scale in environments where there is the danger of fire or explosion.
Never make alterations or modifications to the unit.
Never use the RL101 scale when it no longer fulfills the safety criteria.
Never clean the RL101 scale with solvents, aggressive substances or flammable products.
Never wash the RL101 scale with direct water jets.
Never pour liquids on the indicator.
Never expose the RL101 scale to atmospheric agents (sun, rain, etc.).
Never allow minors (children) or inexperienced persons to operate this unit.
Never use for purposes other than weight measurement.
Never place fingers into slots or possible pinch points.
Never use any load-bearing component that is worn beyond 5% of the original dimension.
Never use this product if any components are cracked.
Never remove or obscure warning labels.
Never remove or replace supplied shackles and hooks.
Never move the sample (load) with scale inline. The RL101 scale is a lift and weigh device designed to capture static weighments.
i

RL101 Below-the-Hook Crane Scale
8 Visit our website www.RiceLake.com
1.1.1 Adhere to Laws and Regulations
Follow all local laws and regulations when using the RL101 scale.
1.1.2 Operator Obligations and Prohibitions
Operators must:
• Always perform maintenance operations with the RL101 scale powered off.
• Tie up long hair to prevent it from getting caught.
• Use personal protective equipment and devices in an appropriate manner.
• Report safety concerns immediately.
Operators must never:
• Use the RL101 scale improperly.
• Perform actions that may compromise safety.
• Remove or modify safety/warning devices.
• Wear bracelets, rings or chains that can dangle and can be caught by moving parts.
• Use the RL101 scale if it has not been installed according to regulations and laws.
• Use the RL101 scale outside of the permitted environmental conditions.
WARNING: Rice Lake Weighing Systems is not liable for damage to property or people if the RL101 scale has been used in
a non-permitted environment.
1.1.3 Safety Measures
• Adhere to safety warnings established by Rice Lake Weighing Systems, the manufacturer of the lifting equipment,
regulations and laws.
• Entrust the use of the RL101 scale to expert/trained personnel.
• Ensure only trained personnel install, put into service, maintain and repair the RL101 scale.
• Ensure that the Operator manual is always available where the RL101 scale is used.
• The nominal capacity of the scale must be equal to or greater than the crane.
• Only use Rice lake Weighing Systems replacement parts.
• The RL101 scale must be submitted to regular maintenance and repair.
• When faults or irregularities are observed, immediately stop all operations and do not reuse the RL101 scale until it has
been evaluated by trained/authorized personnel.
1.1.4 RL101 Scale Warnings
Warning Description
The RL101 scale is considered a lift and weigh device, therefore, use must be limited only to weighing
needs. The RL101 scale is not designed for cargo handling and transportation.
Once load handling is done, move away, and ensure that the load is well balanced by lifting it up only a
few inches from the ground and then lower the load down to the ground. Remove the RL101 scale at the
end of the weighing operations.
Use the scale exclusively for the lifting and the weighing of suspended loads and for tension
measurements. Suspended loads may cause applied torsion stresses and should be hung with flexible
or swiveling bindings.
Table 1-1. RL101 Scale Warning Symbols

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 9
Monitor load lifting. While lifting, observe the movement of the load. The RL101 scale is a lift and weigh
device and not designed for cargo handling and transportation.
Lift the load at low speeds to mitigate load swiveling, knocking or tilting.
Use fasteners that allow correct alignment of the scale.
Perform maintenance, repairs or cleaning with the RL101 scale powered off.
Use PPE assigned by the manufacturer of the lifting system and listed in this manual.
The nominal capacity of the RL101 scale must not be lower than the maximum capacity of the lifting
equipment.
Never stand or pass under a suspended load.
Never exceed the nominal capacity of the RL101 scale. The illustration refers to the 3000 lb model.
Refer to the maximum capacity of the purchased RL101 scale.
Warning Description
Table 1-1. RL101 Scale Warning Symbols (Continued)
If max 3t
Min 3t
MAX
3000 lb

RL101 Below-the-Hook Crane Scale
10 Visit our website www.RiceLake.com
Do not allow the RL101 scale to come into contact with liquid. Adhere to IP rating of the RL101 scale.
Do not use solvents or industrial chemicals for cleaning the RL101 scale.
Only use the RL101 scale with the included shackles.
Never move the load diagonally or rotate the load.
Do not swing the load by pushing it or putting it beyond the operating area of the lifting equipment.
Never exceed the weight capacity of any lifting equipment.
Never use multiple attachment points.
Never make any mechanical changes to the scale.
Warning Description
Table 1-1. RL101 Scale Warning Symbols (Continued)
IP54
AUTHORIZED

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 11
1.1.5 Environmental Conditions
1.1.6 Risks
Safety has been integrated into the design and construction of the RL101 scale as much as possible; however, risks remain that
operators must be protected against.
For each risk, a description of the risk and of the zone or part of the RL101 scale subject to the risk is provided (unless it is a risk
valid for the entire RL101 scale). Procedural information on how to avoid the risk and on the correct use of the personal
protection devices is provided.
Symbol Description
Never install the RL101 scale in an environment at risk of explosions.
Never expose the RL101 scale to sources of heat of direct sunlight.
Never expose the RL101 scale to strong magnetic or electrical fields.
Never use the device to weigh radioactive materials or melted masses.
Never install the RL101 scale in an environment at risk of corrosion.
Never use the device beyond the temperature range of -14°F to 104°F (10°C to +40°C).
Table 1-2. Environmental Condition Warnings
Risk Description
Risk of crushing The risk of crushing lower limbs under the load during its descent remains.
Risk of load
falling
The risk of the load falling and crushing during lifting operations remains.
Table 1-3. Risks

RL101 Below-the-Hook Crane Scale
12 Visit our website www.RiceLake.com
1.1.7 Personal Protective Equipment
When working near the RL101 scale, both for assembly operations and for maintenance/adjustment, it is required to comply
with the general accident-prevention regulations. It is important to use personal protective equipment (PPE) required for each
operation. PPE for those operating or maintaining the equipment must comply with local laws and regulations.
A list of personal PPE that may be required is provided below:
Symbol Description
Indicates a requirement for personnel to use safety or insulating gloves.
Indicates a requirement for personnel to use safety goggles.
Indicates a requirement for personnel to use safety footwear.
Indicates a requirement for personnel to use ear protection (earplugs or earmuffs).
Indicates a requirement for personnel to wear the specific safety clothing.
Table 1-4. Personal Protection Equipment Warnings

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 13
1.2 Identification labels
The RL101 scale is equipped with a identification labels positioned on the right side.
Figure 1-1. Identification Labels
WARNING: Do not remove identification labels.
Mod.
Sn
RL101
9876543210
Rice Lake Weighing Systems - Rice Lake, WI, USA - www.ricelake.com
6 V DC
Max
Min
e =
R1 R2 R3
600 lb 1500 lb 3000 lb
4 lb 10 lb 20 lb
0.2 lb 0.5 lb 1 lb
P/N 219144

RL101 Below-the-Hook Crane Scale
14 Visit our website www.RiceLake.com
1.3 Specifications
1.3.1 Permitted Environmental Conditions
The facility where the RL101 scale must be used is an indoor environment protected from weather such as rain, hail, snow, fog,
dust, combustible dust and aggressive agents (such as corrosive vapor or excessive heat sources).
The RL101 scale has been designed and built to operate safely in the following environmental conditions:
WARNING: Environmental conditions other than those specified may cause serious damage to the RL101 scale and void
the warranty.
IMPORTANT: The work surface must be sufficiently illuminated. In the event of dark areas in the workplace, it is the user's
responsibility to provide suitable lighting devices.
Specification Description
Material Painted ABS and steel
Case dimensions 6.89 x 18.9 x 15.35 in (175 x 480 x 390 mm)
Weight
Max capacity
Power supply Four AA Batteries
Operating life 40 hours
Keyboard Five Keys
Remote control Infrared with 19 buttons
IR Rating IP54
Table 1-5. RL101 Specifications
Environmental Condition Description
Room temperature 14°F to 104°F (-10°C to 40°C)
Maximum relative humidity 85% non-condensing
Room lighting minimum of 50 lux - non-glare light
Table 1-6. Environmental Conditions
Model Without Packaging With Packaging
RL101-3k 17.64 lb (8 kg) 24.25 lb (11 kg)
RL101-6k 22.05 lb (10 kg) 30.87 lb (14 kg)
RL101-12k 24.25 lb (11 kg) 33.07 lb (15 kg)
Model Capacity
RL101-3k 3306 lb (1500 kg)
RL101-6k 6613 lb (3000 kg)
RL101-12k 13227 lb (6000 kg)

Hardware Components
© Rice Lake Weighing Systems ● All Rights Reserved 15
2.0 Hardware Components
2.1 Main components
The RL101 scale is made up of the following main components:
Figure 2-1. Main Components
Item Component
1 Load cell body
2 Shackle connecting the load cell to the lifting equipment
3 Shackle connecting the load cell to a load
4 Electronic equipment that provides a display, system controls/adjustments and converts signals from load cells into a unit of measure
5 RJ11 connector for RS-232 serial connection to external devices
Table 2-1. RL101 Scale Main Components
2
4
1
5
3

RL101 Below-the-Hook Crane Scale
16 Visit our website www.RiceLake.com
2.2 Packaging and Handling
2.2.1 Packaging
Use the included case to transport the RL101 scale. It is designed to protect the RL101 scale from potential impacts or falls
during transport. The case must not be compressed from above or from the sides by external forces. It is important the case
and RL101 scale are stored in enclosed places that adhere to the environmental conditions (Section 1.1.5 on page 11 and
Section 1.3.1 on page 14).
Upon receiving the RL101 scale, the customer must verify there is no damage caused by transportion. Immediately after
unpacking, visually inspect the RL101 scale to ensure all included components are undamaged. If parts were damaged in
shipment, notify Rice Lake Weighing Systems and the shipper immediately.
Figure 2-2. RL101 Scale in Transport Case
MODEL Without Packaging With Packaging
RL101-3k 17.64 lb (8 kg) 24.25 lb (11 kg)
RL101-6k 22.05 lb (10 kg) 30.87 lb (14 kg)
RL101-12k 24.25 lb (11 kg) 33.07 lb (15 kg)
Table 2-2. Packaging Weights

Hardware Components
© Rice Lake Weighing Systems ● All Rights Reserved 17
2.3 Annunciators
Figure 2-3.
Item Icon Description
1 Indicates the scale is unloaded and at zero (gross).
2 Indicates the weight is unstable.
3NET The net weight is displayed.
Note: When this annunciator displays, there is a saved tare.
4 / 5 G B The gross weight is displayed.
6 Indicates the battery level:
7Max= MIN= e= Metrics are displayed.
8LT A locked tare is enabled.
9PT A manual tare is enabled.
10 W1 W2 W3 Indicates the range of active weighing.
11 lb ... g Indicates the units of measurement: pounds (lb), tonnes (t), kilograms (kg) or grams (g).
12 *Indicates a key is pressed. In some operating modes, it means that a specific function is enabled.
Table 2-3. Annunciator Descriptions
l
b
G B
1
2
3
4 and 5
6
11
12
7 8 9 10

RL101 Below-the-Hook Crane Scale
18 Visit our website www.RiceLake.com
2.4 Keyboard
Figure 2-4. Keyboard Keys
Table 2-4. RL101 Button Descriptions
Key Description
Short Press: Resets the weight on the scale.
Long Press: Press for 2 seconds to adjust the screen brightness.
Parameter/Menu: Navigates up in menus, parameters or parameter values.
Short Press: Tares the scale.
Long Press: Press for 2 seconds to enter a preset tare.
Parameter/Menu: Navigates down in menus, parameters or parameter values.
Short Press: Retrieves the specific function of the operating mode.
Long Press: Press for 5 seconds to change operating mode.
Parameter/Menu: Navigates right in menus.
Short Press: Activates print function (typically not applicable).
Long Press: Press for 5 seconds to enter the configuration menu.
Parameter/Menu: Confirms the selected menu/parameter.
Short Press: Clears tare
Long Press:
• If pressed for 2 seconds, the RL101 powers off or on.
• If pressed for 5 seconds, metrological information displays.
Parameter/Menu:
• Returns to previous menu without saving.
• At save prompt, cancels without saving.
RL101

Hardware Components
© Rice Lake Weighing Systems ● All Rights Reserved 19
2.5 Remote control
Figure 2-5. Remote Control
Button Description
Selects the desired function.
If held down, the brightness of the display changes.
Short Press: Clears tare.
Long Press:
• If pressed for 2 seconds, the RL101 powers off.
Parameter/Menu:
• Returns to previous menu without saving.
• At save prompt, cancels without saving.
NOTE: This button does not power the RL101 scale on.
Enters the corresponding digit
Short Press: Tares the scale.
Long Press: Press for 2 seconds to enter a preset tare.
Parameter/Menu: Navigates down in menus, parameters or parameter values.
Short Press: Resets the weight on the scale.
Long Press: Press for 2 seconds to adjust the screen brightness.
Parameter/Menu: Navigates up in menus, parameters or parameter values.
Short Press: Retrieves the specific function of the operating mode.
Long Press: Press for 5 seconds to change operating mode.
Parameter/Menu: Navigates right in menus.
Short Press: Activates print function (typically not applicable).
Long Press: Press for 5 seconds to enter the configuration menu.
Parameter/Menu: Confirms the selected menu/parameter.
Not used.
Table 2-5. Remote Control Button Descriptions

RL101 Below-the-Hook Crane Scale
20 Visit our website www.RiceLake.com
2.6 Batteries
2.6.1 RL101 Scale Batteries
The RL101 scale requires four AA batteries to operate. Batteries are installed in a detachable tray located in the back of the
scale.
WARNING: Before replacing the RL101 scale batteries, ensure loads are removed and it is lowered to floor height.
To replace batteries:
1. Hold C to until the RL101 scale powers off.
2. Remove the battery tray by pressing in the two retention tabs while pulling the tray away from the RL101 scale.
3. Replace batteries while adhering to polarity illustrated in battery tray.
4. Reinsert battery tray into scale ensuring it securely locks into place.
Figure 2-6. Battery Tray
