iDimension® Plus
Static Dimensioning System
Assembly Instructions
PN 197164November 4, 2019

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 iDimension Plus Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.0 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1.1 Pole Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1.2 Attach Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1.3 Attach Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1.4 Attach Scanning Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

iDimension Plus
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
This manual provides an overview of the iDimension Plus assembly instructions.
When interfacing this device to a third parties software program, please reference the software manufacturer’s documentation
for setup and configuration parameters as necessary.
Manuals and additional resources are available from the Rice Lake Weighing Systems website at www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
iDimension Plus QubeVu Manager Guide
The iDimension Plus QubeVu Manager Guide (PN 195441) provides a detailed overview of the QubeVu Manager, the
embedded firmware of the iDimension Plus. The QubeVu Manager is a set of tools provided to set up and configure the
iDimension Plus in any environment. These tools are recommended for use by a technical systems administrator.
iDimension Plus Operation Manual
The iDimension Plus Operation Manual (PN 195439) provides a detailed overview of the installation requirements, operation of
the iDimension Plus and configuration parameters to change in the QubeVu Manager to alter the performance of the unit.
The iDimension Plus Operation Manual is provided with each unit.
Prior to powering on the unit, see the iDimension Plus Operation Manual (PN 195439). The iDimension Plus Operation
Manual contains the following information for common installation and operation requirements:
1. Place system into the location intended for use.
2. Setup Wizard.
•Upon initial power up, the setup wizard steps through configuring time and date, zeroing the height of the
system with or without a scale, creating your scan zone and defining the system for use in displaying
dimensions in imperial or metric mode
3. Connect to network via DHCP or directly to network connection on local PC for configuring system using
embedded software, QubeVu Manager, from a Google Chrome web browse. Contact your network
administrator, if static IP address is required.
•Scale parameters
•Flat detection, objects under 1.2'' in height
•Static IP address
•Adjusting scan area and zone of interest for measuring flats
•Configuring certification settings
•Calibration, if necessary
Note

iDimension Plus
2 Visit our website www.RiceLake.com
1.1 Safety
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
Indicates information about procedures that, if not observed, could result in damage to equipment or corruption
to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Failure to heed could result in serious injury or death.
Electric shock hazard!
There are no user serviceable parts. Refer to qualified service personnel for service.
The unit has no power switch, to completely remove power from the unit, disconnect the power source at the AC outlet.
For pluggable equipment the socket outlet must be installed near the equipment and must be easily accessible.
When cycling power, use the in-line power cord at a power outlet, do not power at the base.
Always disconnect from main power before performing any work on the device.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without all shields and guards in place.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not use near water, avoid contact with excessive moisture.
Keep the unit dry.
Retain packaging. When transporting the unit, always disassemble and pack it in its original packaging.
Use only supplied power adapter. Never short-circuit the power adapter or the device.
Operate between 41–104º F (5–40º C).
Never remove the iDimension Plus head cover or the electrical connection panels at the base of the pole assembly.
Never modify or attempt to repair the unit. Service must be performed by Rice Lake Weighing Systems only.
Handle cables and cable connectors with care. Never use damaged power cords or plugs or loose electrical sockets. Never touch
the power cord with wet hands.
Ensure that the base plate, pole assembly and head unit are all securely attached before attempting to move the unit.
Never lift the unit by grasping only the pole assembly; always ensure that both sections of the pole assembly and the base plate
are supported.
Never drop or allow an impact to the head.
Mount on a flat surface.
Never use product for anything other than its intended purpose.
DANGER
WARNING
CAUTION
IMPORTANT
WARNING

Overview
© Rice Lake Weighing Systems ● All Rights Reserved 3
2.0 Overview
This section provides an overview of the parts featured within the packaging for the iDimension Plus.
2.1 iDimension Plus Parts
The iDimension Plus is packaged with the following parts:
Figure 2-1. iDimension Plus Parts
Keep calibration object for future use.
Immediately after unpacking the iDimension Plus, visually inspect the contents to ensure all components are included and
undamaged. If any parts were damaged in shipment, notify Rice Lake Weighing Systems and the shipper immediately.
Item No. Part No. Description Qty.
1 197224 Upper Pole Assembly 1
2 Lower Pole Assembly 1
3 195516 Display Pole Mounting Bracket 1
4 195517 Base Plate 1
5 188101 Calibration Object 1
6 195504 Scanning Head 1
7 195510 USB Display and Bracket 1
8 – Ethernet Cable 1
9 195509 AC Power Cable 1
10 Power Supply 1
Table 2-1. iDimension Plus Parts List
1
2
4
3
10
9
8
7
6
5
2
Note

iDimension Plus
4 Visit our website www.RiceLake.com
3.0 Assembly
This section provides an overview of iDimension Plus assembly instructions.
3.1 Unit Assembly
To assemble the iDimension Plus, follow the procedure below.
3.1.1 Pole Assembly
1. Locate the two hex screws and two Phillips screws pre-installed at the pole joint of the upper pole assembly.
Using a 3 mm hex key and #1 Phillips screw driver, remove the screws and set them aside for installation in Step 3.
Figure 3-1. Upper Pole Assembly Joint
2. Ensure the holes align.
Figure 3-2. Connecting Pole Joint
3. Reinstall the four screws removed in Step 1.
Figure 3-3. Secured Pole Joint
Phillips Screws
Hex Screws
Phillips Screws
Hex Screws

Assembly
© Rice Lake Weighing Systems ● All Rights Reserved 5
3.1.2 Attach Base
1. Lay the pole assembly on a table or flat surface. Ensure the base block is hanging over an edge.
2. Use a 3 mm hex key to remove the four screws installed in the base block. Set screws aside for installation in Step 5.
Figure 3-4. Base Black
3. Locate the alignment slot (center left) and alignment hole (center right).
4. Locate guide pins in base plate.
Figure 3-5. Base Plate Top view
5. Install the base plate by inserting the guide pins into the alignment slot and alignment hole from Figure 3-4, using the
four screws removed in Step 2 with the 3 mm hex wrench.
Figure 3-6. Base Plate Bottom view
Alignment Hole
Hex Screw
Alignment Slot
Guide Pin Guide Pin
Hex Screws Hex Screws

iDimension Plus
6 Visit our website www.RiceLake.com
3.1.3 Attach Display
1. Using a 3 mm hex key, remove the pre-installed hex screw from the pole assembly display bracket.
Figure 3-7. Pole Assembly Display Bracket
2. Secure the display mount to the pole assembly display bracket using the previously removed screw.
Figure 3-8. Secure Display Mount
3. Remove the display cover plate from the back of the display.
4. Plug the USB display cable into the mini USB port.
Figure 3-9. USB Display Cable
Hex Screw
Hex Screw
Display Cover Location
USB Display Cable

Assembly
© Rice Lake Weighing Systems ● All Rights Reserved 7
5. Route the USB display cable into the cable slot and replace the display cover.
Figure 3-10. Display Cover
3.1.4 Attach Scanning Head
1. Locate the cables extending from the upper pole opening. Cables include power, Ethernet, USB 1 and USB 2.
Figure 3-11. Pole Assembly Kit Cables
Cables should extend approximately 6''. If cables require adjustment, carefully pull cable through the upper arm.
Extra cable length is available.
2. Remove the rear cover from the scanning head by loosening and removing the three small Phillips screws of the
cover. See Step 9 on page 10 for instructions on how to reinstall the Phillips screws.
Figure 3-12. Scanning Head Parts
USB Display Cover
Note
Cable Slot
Rear Cover
Phillip Screws (3)
Spacer Block with
Mounting Screws
Scanning Head

iDimension Plus
8 Visit our website www.RiceLake.com
3. Loosen the three mounting screws so the screws are .25'' from the spacer plate.
Figure 3-13. Mounting Screws and Key Holes
4. Insert the cables from the upper pole assembly through the cable slot on the rear enclosure.
Figure 3-14. Feed Cables Through Head
5. Line up the mounting screws with the keyholes in the pole assembly. Insert the screws through the pole wall and seat
them all the way down into the keyholes.
Figure 3-15. Upper Pole Keyhole Access
Mounting Screws Keyholes
Mounting Screws

Assembly
© Rice Lake Weighing Systems ● All Rights Reserved 9
6. Ensure that the heads of the mounting screws are seated properly in keyholes. The plastic spacer block top surface
should be parallel with the top surface of the pole.
Figure 3-16. Assembly Parallel
7. Use the 3 mm hex key and tighten the screws. Ensure the scanning head remains parallel with the pole while
tightening.
8. Secure cable connections from the pole assembly to the scanning head (Table 3-1):
Figure 3-17. Scanning Head
Figure 3-18. Scanning Head Connections
Item No. Description
1 Power (DC in) - 24 V1
2 Ethernet Port
3 Open USB Port
4 SD Card (Not Supported)
5 HDMI Port (Not Supported)
6 Display Connection
7 USB Port at Electrical Base
Table 3-1. Scanning Head Connection List

iDimension Plus
10 Visit our website www.RiceLake.com
9. Reinstall the scanning head rear cover using the three small Phillips screws removed within Step 7 on page 9.
Figure 3-19. Scanning Head with Rear Cover Secured
Figure 3-20. Scanning Head with Rear Cover Secured Continued
Phillips Screw
Phillips Screw
Phillips Screw

Assembly
© Rice Lake Weighing Systems ● All Rights Reserved 11
10. Connect cables to the back of the electrical base (Table 3-2).
Figure 3-21. Electrical Base
Prior to powering on the iDimension Plus, see the iDimension Plus Operation Manual (PN 195439) for system setup
and configuration
11. Attach the power cable connector to the port labeled Input 24 V, prior to plugging the power cable connector into an
AC outlet.
Figure 3-22. AC Power Connection
Item No. Description
1 Standard USB Port (type A, for use with scale, barcode scanner or USB hub)
2 Ethernet Port (used to connect to network in order to interface compatible software)
3 Power (DC in) - 24 V1
Table 3-2. Electrical Base connections
1
2
3
Note

iDimension Plus
12 Visit our website www.RiceLake.com
12. The fully assembled iDimension Plus should resemble Figure 3-23.
Figure 3-23. Assembled iDimension Plus

230 W. Coleman St. • Rice Lake, WI 54868 • USA
U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe [phone]
Rice Lake Weighing Systems is an ISO 9001 registered company.
© Rice Lake Weighing Systems Specifications subject to change without notice.
www.ricelake.com
PN 197164November 4, 2019
