In accordance with IEC 60417, this machine uses the following symbols for the main power switch:
ameans POWER ON.
cmeans STAND BY.
Introduction
This manual contains detailed instructions and notes on the operation and use of this machine. For your
safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy
place for quick reference.
Important
Contents of this manual are subject to change without prior notice. In no event will the company be li-
able for direct, indirect, special, incidental, or consequential damages as a result of handling or oper-
ating the machine.
Notes:
Some illustrations in this manual might be slightly different from the machine.
Certain options might not be available in some countries. For details, please contact your local dealer.
Laser Safety:
This machine is considered a class 1 laser device, safe for office/EDP use. The machine contains a 5-
milliwatt, 760-800 nanometer wavelength, GaAIAs laser diode. Direct (or indirect reflected ) eye contact
with the laser beam might cause serious eye damage. Safety precautions and interlock mechanisms
have been designed to prevent any possible laser beam exposure to the operator.
The following label is attached on the back side of the machine.
Caution:
Use of controls or adjustments or performance of procedures other than those specified in this manual
might result in hazardous radiation exposure.
Notes:
Certain types might not be available in some countries. For details, please contact your local dealer.
Two kinds of size notation are employed in this manual. With this machine refer to the metric version.
For good copy quality, the supplier recommends that you use genuine toner from the supplier.
The supplier shall not be responsible for any damage or expense that might result from the use of parts
other than genuine parts from the supplier with your office products.
Power Source
220 - 240 V, 50/60 Hz, 4 A or more
Please be sure to connect the power cord to a power source as above. For details about power source,
see “Power Connection” in the Copy Reference.
Copyright © 2006

i
Manuals for This Machine
The following manuals describe the operational procedures of this machine. For
particular functions, see the relevant parts of the manual.
Note
❒Manuals provided are specific to machine type.
❒Adobe Acrobat Reader is necessary to view the manuals as a PDF file.
❖General Settings Guide (this manual)
Provides an overview of the machine and describes System Settings (paper
trays, Key Operator Tools, etc.), and troubleshooting.
❖Network Guide
Describes procedures for configuring the machine and computers in a net-
work environment.
❖Copy Reference
Describes operations, functions, and troubleshooting for the machine's copier
function.
❖Printer/Scanner Reference
Describes system settings, functions, troubleshooting and operations for the
machine's printer and scanner function.
❖Other Manuals
•QuickReferenceCopyGuide
• Quick Reference Printer / Scanner Guide
StellaC3L_GSG_F-AE_FM_forPaper.book Page i Monday, September 11, 2006 4:00 PM

ii
TABLE OF CONTENTS
Manuals for This Machine ......................................................................................i
Copyrights and Trademarks .................................................................................1
Trademarks ................................................................................................................1
Information about Installed Software..........................................................................1
How to Read This Manual ..................................................................................... 8
ENERGY STAR Program .......................................................................................9
1. Getting Started
Guide to Components ......................................................................................... 11
Options .................................................................................................................13
External Options.......................................................................................................13
Control Panel........................................................................................................ 14
Display .....................................................................................................................15
Reading the Display and Using Keys....................................................................... 16
2. Combined Function Operations
Changing Modes .................................................................................................. 17
Multi-Access.........................................................................................................18
3. User Tools ( System Settings )
User Tools Menu ( System Settings ).................................................................19
Accessing User Tools ( System Settings ) ........................................................21
Changing Default Settings .......................................................................................21
Quitting User Tools ..................................................................................................22
Settings You Can Change with User Tools .......................................................23
General Features ....................................................................................................23
Tray Paper Settings .................................................................................................24
Timer Settings ..........................................................................................................25
Key Operator Code ..................................................................................................26
User Code ............................................................................................................. 30
Registering a New User Code..................................................................................30
Changing a User Code.............................................................................................31
Deleting a User Code...............................................................................................31
Displaying the Counter for Each User Code ............................................................32
Printing the Counter for Each User Code.................................................................33
Clearing the Counter ................................................................................................33
4. Troubleshooting
If Your Machine Does Not Operate As You Want..............................................35
xClearing Misfeeds ...........................................................................................37
Changing the Paper Size..................................................................................... 39
Changing the Paper Size of the Paper Tray (Tray 1)...............................................39
Changing the Paper Size in the Paper Tray Unit (Tray 2)........................................40
Selecting the Paper Size with User Tools ................................................................42
StellaC3L_GSG_F-AE_FM_forPaper.book Page ii Monday, September 11, 2006 4:00 PM

iii
5. Other Functions
Other Functions ...................................................................................................43
Displaying the Total Counter....................................................................................43
Changing the Language...........................................................................................43
6. Specifications
Main Unit...............................................................................................................45
Options .................................................................................................................48
Exposure Glass Cover .............................................................................................48
Auto Document Feeder capable of scanning both sides of a sheet (ARDF)............48
Paper Tray Unit (Tray 2) ..........................................................................................49
Copy Paper ........................................................................................................... 50
Recommended Paper Sizes and Types...................................................................50
Unusable Paper .......................................................................................................52
Paper Storage ..........................................................................................................52
INDEX......................................................................................................... 53
StellaC3L_GSG_F-AE_FM_forPaper.book Page iii Monday, September 11, 2006 4:00 PM

iv
StellaC3L_GSG_F-AE_FM_forPaper.book Page iv Monday, September 11, 2006 4:00 PM

1
Copyrights and Trademarks
Trademarks
Microsoft®, Windows®and Windows NT®are registered trademarks of Micro-
soft Corporation in the United States and/or other countries.
Acrobat®is a registered trademark of Adobe Systems Incorporated.
Bluetooth™ is a trademark of the Bluetooth SIG, Inc. (Special Interest Group)
and is used by RICOH Company Limited under license.
Copyright ©2001 Bluetooth SIG, Inc.
The Bluetooth Trademarks are owned by Bluetooth SIG, Inc. USA.
Other product names used herein are for identification purposes only and might
be trademarks of their respective companies. We disclaim any and all rights to
those marks.
The proper names of the Windows operating systems are as follows:
• The product name of Windows®95 is Microsoft®Windows®95
• The product name of Windows®98 is Microsoft®Windows®98
• The product name of Windows®Me is Microsoft® Windows® Millennium
Edition (Windows Me)
• The product names of Windows®2000 are as follows:
Microsoft®Windows®2000 Professional
Microsoft®Windows®2000 Server
Microsoft®Windows®2000 Advanced Server
• The product names of Windows®XP are as follows:
Microsoft®Windows®XP Home Edition
Microsoft®Windows®XP Professional
• The product names of Windows ServerTM 2003 are as follows:
Microsoft®Windows ServerTM 2003 Standard Edition
Microsoft®Windows ServerTM 2003 Enterprise Edition
Microsoft®Windows ServerTM 2003 Web Edition
• The product names of Windows NT®4.0 are as follows:
Microsoft®Windows NT®Workstation 4.0
Microsoft®Windows NT®Server 4.0
Information about Installed Software
expat
• The software including controller, etc. (hereinafter “software”) installed on
this product uses the expat Version 1.95.2 (hereinafter “expat”) under the con-
ditions mentioned below.
• The product manufacturer provides warranty and support to the software of
the product including the expat, and the product manufacturer makes the in-
itial developer and copyright holder of the expat, free from these obligations.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 1 Monday, September 11, 2006 4:00 PM

2
• Information relating to the expat is available at:
http://expat.sourceforge.net/
Copyright (c) 1998, 1999, 2000 Thai Open Source Software Centre, Ltd. and Clark
Cooper.
Permission is hereby granted, free of charge, to any person obtaining a copy of
this software and associated documentation files (the “Software”), to deal in the
Software without restriction, including without limitation the rights to use,
copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the
Software, and to permit persons to whom the Software is furnished to do so, sub-
ject to the following conditions:
The above copyright notice and this permission notice shall be included in all
copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY
KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AU-
THORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAG-
ES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT,
TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION
WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFT-
WARE.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 2 Monday, September 11, 2006 4:00 PM

3
NetBSD
1. Copyright Notice of NetBSD
For all users to use this product:
This product contains NetBSD operating system:
For the most part, the software constituting the NetBSD operating system is not
in the public domain; its authors retain their copyright.
The following text shows the copyright notice used for many of the NetBSD
source code. For exact copyright notice applicable for each of the files/binaries,
the source code tree must be consulted.
A full source code can be found at http://www.netbsd.org/.
Copyright © 1999, 2000 The NetBSD Foundation, Inc.
All rights reserved.
Redistribution and use in source and binary forms, with or without modifica-
tion, are permitted provided that the following conditions are met:
ARedistributions of source code must retain the above copyright notice, this list
of conditions and the following disclaimer.
BRedistributions in binary form must reproduce the above copyright notice,
this list of conditions and the following disclaimer in the documentation
and/or other materials provided with the distribution.
CAll advertising materials mentioning features or use of this software must
display the following acknowledgment:
This product includes software developed by The NetBSD Foundation, Inc.
and its contributors.
DNeither the name of The NetBSD Foundation nor the names of its contribu-
tors may be used to endorse or promote products derived from this software
without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE NETBSD FOUNDATION, INC. AND
CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DIS-
CLAIMED. IN NO EVENT SHALL THE FOUNDATION OR CONTRIBUTORS
BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEM-
PLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMIT-
ED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF
USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CON-
TRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTH-
ERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 3 Monday, September 11, 2006 4:00 PM

4
2. Authors Name List
All product names mentioned herein are trademarks of their respective owners.
The following notices are required to satisfy the license terms of the software
that we have mentioned in this document:
• This product includes software developed by the University of California,
Berkeley and its contributors.
• This product includes software developed by Jonathan R. Stone for the NetB-
SD Project.
• This product includes software developed by the NetBSD Foundation, Inc.
and its contributors.
• This product includes software developed by Manuel Bouyer.
• This product includes software developed by Charles Hannum.
• This product includes software developed by Charles M. Hannum.
• This product includes software developed by Christopher G. Demetriou.
• This product includes software developed by TooLs GmbH.
• This product includes software developed by Terrence R. Lambert.
• This product includes software developed by Adam Glass and Charles Han-
num.
• This product includes software developed by Theo de Raadt.
• This product includes software developed by Jonathan Stone and Jason R.
Thorpe for the NetBSD Project.
• This product includes software developed by the University of California,
Lawrence Berkeley Laboratory and its contributors.
• This product includes software developed by Christos Zoulas.
• This product includes software developed by Christopher G. Demetriou for
the NetBSD Project.
• This product includes software developed by Paul Kranenburg.
• This product includes software developed by Adam Glass.
• This product includes software developed by Jonathan Stone.
• This product includes software developed by Jonathan Stone for the NetBSD
Project.
• This product includes software developed by Winning Strategies, Inc.
• This product includes software developed by Frank van der Linden for the
NetBSD Project.
• This product includes software developed for the NetBSD Project by Frank
van der Linden.
• This product includes software developed for the NetBSD Project by Jason R.
Thorpe.
• The software was developed by the University of California, Berkeley.
• This product includes software developed by Chris Provenzano, the Univer-
sity of California, Berkeley, and contributors.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 4 Monday, September 11, 2006 4:00 PM

5
Sablotron
Sablotron (Version 0.82) Copyright (c) 2000 Ginger Alliance Ltd. All Rights Re-
serve
a) The application software installed on this product includes the Sablotron soft-
ware Version 0.82 (hereinafter, “Sablotron 0.82”), with modifications made by
the product manufacturer. The original code of the Sablotron 0.82 is provided by
Ginger Alliance Ltd., the initial developer, and the modified code of the Sablo-
tron 0.82 has been derived from such original code provided by Ginger Alliance
Ltd.
b) The product manufacturer provides warranty and support to the application
software of this product including the Sablotron 0.82 as modified, and the prod-
uct manufacturer makes Ginger Alliance Ltd., the initial developer of the Sablo-
tron 0.82, free from these obligations.
c) The Sablotron 0.82 and the modifications thereof are made available under the
terms of Mozilla Public License Version 1.1 (hereinafter, “MPL 1.1”), and the ap-
plication software of this product constitutes the “Larger Work” as defined in
MPL 1.1. The application software of this product except for the Sablotron 0.82
as modified is licensed by the product manufacturer under separate agree-
ment(s).
d) The source code of the modified code of the Sablotron 0.82 is available at: ht-
tp://support-download.com/services/device/sablot/notice082.html.
e) The source code of the Sablotron software is available at: http://www.ginger-
all.com.
f) MPL 1.1 is available at: http://www.mozilla.org/MPL/MPL-1.1.html.
JPEG LIBRARY
• The software installed on this product is based in part on the work of the In-
dependent JPEG Group.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 5 Monday, September 11, 2006 4:00 PM

6
SASL
CMU libsasl
Tim Martin
Rob Earhart
Rob Siemborski
Copyright (c) 2001 Carnegie Mellon University. All rights reserved.
Redistribution and use in source and binary forms, with or without modifica-
tion, are permitted provided that the following conditions are met:
ARedistributions of source code must retain the above copyright notice, this list
of conditions and the following disclaimer.
BRedistributions in binary form must reproduce the above copyright notice,
this list of conditions and the following disclaimer in the documentation
and/or other materials provided with the distribution.
CThe name “Carnegie Mellon University” must not be used to endorse or pro-
mote products derived from this software without prior written permission.
For permission or any other legal details, please contact:
Office of Technology Transfer
Carnegie Mellon University
5000 Forbes Avenue
Pittsburgh, PA 15213-3890
[phone], fax: [phone]
[e-mail]
DRedistributions of any form whatsoever must retain the following acknowl-
edgment:
“This product includes software developed by Computing Services at Carn-
egie Mellon University (http://www.cmu.edu/computing/).”
CARNEGIE MELLON UNIVERSITY DISCLAIMS ALL WARRANTIES WITH
REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS, IN NO EVENT SHALL CARNEGIE
MELLON UNIVERSITY BE LIABLE FOR ANY SPECIAL, INDIRECT OR CON-
SEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING
FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF
CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT
OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS
SOFTWARE.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 6 Monday, September 11, 2006 4:00 PM

7
MD4
Copyright (C) 1990-2, RSA Data Security, Inc. All rights reserved.
License to copy and use this software is granted provided that it is identified as
the “RSA Data Security, Inc. MD4 Message-Digest Algorithm” in all material
mentioning or referencing this software or this function.
License is also granted to make and use derivative works provided that such
works are identified as “derived from the RSA Data Security, Inc. MD4 Message-
Digest Algorithm” in all material mentioning or referencing the derived work.
RSA Data Security, Inc. makes no representations concerning either the mer-
chantability of this software or the suitability of this software for any particular
purpose. It is provided “as is” without express or implied warranty of any kind.
These notices must be retained in any copies of any part of this documentation
and/or software.
MD5
Copyright (C) 1991-2, RSA Data Security, Inc. Created 1991. All rights reserved.
License to copy and use this software is granted provided that it is identified as
the “RSA Data Security, Inc. MD5 Message-Digest Algorithm” in all material
mentioning or referencing this software or this function.
License is also granted to make and use derivative works provided that such
works are identified as “derived from the RSA Data Security, Inc. MD5 Message-
Digest Algorithm” in all material mentioning or referencing the derived work.
RSA Data Security, Inc. makes no representations concerning either the mer-
chantability of this software or the suitability of this software for any particular
purpose. It is provided “as is” without express or implied warranty of any kind.
These notices must be retained in any copies of any part of this documentation
and/or software.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 7 Monday, September 11, 2006 4:00 PM

8
How to Read This Manual
Symbols
The following set of symbols is used in this manual.
R
WARNING:
This symbol indicates a potentially hazardous situation that might result in
death or serious injury when you misuse the machine without following the in-
structions under this symbol. Be sure to read the instructions, all of which are de-
scribed in the Safety Information section.
R
CAUTION:
This symbol indicates a potentially hazardous situation that might result in mi-
nor or moderate injury or property damage that does not involve personal injury
when you misuse the machine without following the instructions under this
symbol. Be sure to read the instructions, all of which are described in the Safety
Information section.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates information or preparations required prior to operating.
Note
This symbol indicates precautions for operation, or actions to take after abnor-
mal operation.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
[]
Keys that appear on the machine's display panel.
{}
Keys built into the machine's control panel.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 8 Monday, September 11, 2006 4:00 PM

9
ENERGY STAR Program
•LowPowermode
This product automatically lowers its power consumption 1 minute after fin-
ishing the last copy or print job. Printing is still possible in Low Power mode,
but to make copies, you have to press the operation switch first.
For details about how to change the interval between last job and Low Power
mode, see p.25 “Energy Saver Timer”.
• Off mode (Copier only)
To conserve energy, this product automatically turns off 1 minute after finish-
ing the last copy or print job. In this manual, the Off mode is called the Auto
Off mode.
For details about how to change the interval between last job and Auto Off
mode, see p.25 “Auto Off Timer”.
• Sleep mode (Printer, or scanner installed)
If there is a printer, or scanner unit installed, this product automatically low-
ers its power consumption even further 1 minute after finishing the last copy
or print job. Printing is still possible in Sleep mode, but to make copies, you
have to press the operation switch first.
For details about how to change the interval between last job and Sleep mode,
see p.25 “Auto Off Timer”.
Note
❒If you want to operate this product while it is in either of these modes, do
one of the following:
• Turn on the operation switch.
• Place originals in the ARDF.
• Lift the exposure glass cover or ARDF.
ENERGY STAR®Program
The ENERGY STAR®Program encourages energy conservation by promoting energy efficient
computersand other officeequipment.
The programbacks the development anddissemination of productsthatfeature energysaving
functions.
It is an open program in which manufacturers participate voluntarily.
Targeted products are computers, monitors, printers, facsimiles, copiers, scanners, and multi-
function devices. Energy Star standards and logos are internationally uniform.
StellaC3L_GSG_F-AE_FM_forPaper.book Page 9 Monday, September 11, 2006 4:00 PM

10
•DuplexPriority
To conserve paper, the Duplex function (1-Sided →2-Sided) can be selected
preferentially when you turn on the operation switch or the main power
switch, press the {Clear Modes}key, or the machine resets itself automatically.
To change Duplex Mode Priority, see Copy Reference.
Specifications
Recycled Paper
We recommend use of recycled paper which is environmentally friendly. Please
contact your sales representative for recommended paper.
Copier only Printer, or scanner installed
Low Power
mode
Power con-
sumption
25 W 30 W
Default interval 1 minute 1 minute
Recovery time Less than 10 seconds Less than 10 seconds
Sleep mode Power con-
sumption
- Less than 10 W
Default interval -1minute
Recovery time - Less than 10 seconds
Off mode Power con-
sumption
less than 1 W -
Default interval 1 minute -
Recovery time Less than 10 seconds -
Duplex Priority 1 Sided →1 Sided
StellaC3L_GSG_F-AE_FM_forPaper.book Page 10 Monday, September 11, 2006 4:00 PM

11
1. Getting Started
Guide to Components
1. Exposure glass cover (optional) or
ARDF (optional).
See p.13 “External Options”
2. Exposure glass
Place originals here face down.
3. Internal tray
Copied or printed paper is delivered
here.
4. Ventilation holes
Prevents overheating. Do not obstruct
the ventilation holes by placing objects
near them or leaning things against them.
If the machine overheats, a fault might
occur.
5. Main power switch
If the machine does not operate after
turning on the operation switch, check
the main power switch is turned on. If it
is off, turn it on.
ARK043S
StellaC3L_GSG_F-AE_FM_forPaper.book Page 11 Monday, September 11, 2006 4:00 PM

Getting Started
12
1
6. Main power indicator
Lights when the main power switch is
turned on, and goes off when the switch
is turned off.
7. Operation switch (On indicator)
Press to turn the power on (the On indi-
cator lights). To turn the power off, press
again (the On indicator goes off).
8. Control panel
See p.14 “Control Panel”.
9. Front cover
Open to access the inside of the machine.
10. Paper tray (Tray 1)
Load paper here.
11. Paper tray unit (optional)
See p.13 “External Options”.
12. Internal tray guide
Open out to support large paper and
raise the end fence.
1. Bypass tray
Use to copy onto OHP transparencies,
adhesive labels, translucent paper, enve-
lopes, and custom size paper.
2. Right cover
Open this cover to remove jammed paper
fed from the paper tray.
3. Lower right cover
Open this cover to remove jammed paper
from the optional paper tray unit.
ARK024S
StellaC3L_GSG_F-AE_FM_forPaper.book Page 12 Monday, September 11, 2006 4:00 PM

Options
13
1
Options
External Options
1. Exposure glass cover
Lower this cover over originals.
2. ARDF
Place stacks of originals here.
They will feed in automatically. This doc-
ument feeder can be used for two-sided
originals.
3. Paper tray unit (Tray 2)
Holds 500 sheets.
12
3
ARK025S
StellaC3L_GSG_F-AE_FM_forPaper.book Page 13 Monday, September 11, 2006 4:00 PM

Getting Started
14
1
Control Panel
This illustration shows the control panel of the machine with options fully in-
stalled.
1. {Copy}key
Press to activate the copy function.
2. {Scanner}key
Press to activate the scanner function.
3. {Printer}key
Press to activate the printer function.
4. Indicators
Display errors and machine status.
h: Error indicator. See Network Guide
and see p.37 “xClearing Misfeeds”.
B: Load Paper indicator. See Copy Refer-
ence.
D: Add Toner indicator. See Copy Refer-
ence.
5. Display
Displays operation status and messages.
6. Selection keys
Correspond to items on the display. Press
to select the corresponding item.
7. Scroll keys
Press to select an item.
{U} : scroll upward
{T} : scroll downward
{V} : scroll right
{W} : scroll left
8. {User Tools/Counter}key
•UserTools
Press to change default or operation
parameters according to requirement.
See p.21 “Accessing User Tools ( Sys-
tem Settings )”.
•Counter
Press to check or print the counter val-
ue. See p.43 “Other Functions”.
9. {Clear Modes}key
Press to clear the current settings.
10. {Clear/Stop}key
•Clear:
Clears an entered numeric value.
•Stop:
Stops a job in progress, such as scan-
ning, or printing.
11. Main power indicator
The main power indicator lights when
the main power switch is turned on.
Important
❒Do not turn off the main power
switch while the On indicator is lit
or blinking. Doing so may damage
the memory.
12. Operation switch (On indicator)
Press to turn the power on. The On indi-
cator lights. To turn the power off, press
again.
178101291134 652
13 14 16 201915 18 21 ARK032S17
StellaC3L_GSG_F-AE_FM_forPaper.book Page 14 Monday, September 11, 2006 4:00 PM
