RICOH Americas Corporation Content ID# rfg030901
Ver.1.9 Page 1 of 38 1/1 /2009
Subject to change without notice
Product Support Guide
D014 / D015
Introduction
Model Type Color MFP
Launch Date 1/15/200
S/N Configuration M79/M 0
Product Code D014/D015
Brand/Model Name
Product Code Gestetner Lanier Ricoh Savin
D014 / D015 MP C6000/MP C7500 LD260c / LD275c MP C6000 / MP C7500 C6055 / C7570
Product Concept
The Model D014/D015 is based on the engine platform of the B132/B200. Some enhanced specifications
include, shorter warm up time, new scan-to-functions, new security features, wider paper handling
capabilities and copy quality refinements.

Product Support Guide
D014 / D015
Ver.1.9 Page 2 of 38 1/1 /2009
Subject to change without notice
Order Number
Main Frame
Item Model Name EDP Code Lanier ID Notes
Copier
Lanier LD2 0c
Ricoh MP C 000
Savin C 055
Gestetner MP C 000
413959 21 -1244 -
Copier
Lanier LC275c
Ricoh MP C7500
Savin C7570
Gestetner MP C7500
4139 0 21 -1245 -
Options
Item Description EDP Code Lanier ID Product
Code
Common
/ Unique
Finisher SR4010 - 50 sheet document stapler 413974 21 -124 D374 U
Finisher SR4020 Saddle stitch finisher 41397 21 -1247 D373 U
Finisher
Adapter
Finisher Adapter Type C
(for SR5000 finisher) 413973 21 -7190 D375 U
Printer/Scanner Ricoh Printer/Scanner Bundle 003187MIU - - U
Printer/Scanner Savin Printer/Scanner Bundle 003188MIU - - U
Printer/Scanner Gestetner (RLA) Printer/Scanner Bundle 003189MIU - - U
Printer/Scanner Lanier Printer/Scanner Bundle 003190MIU - - U
PostScript PostScript 3 Unit Type C7500 414000 21 -7192 D378 U
LCT RT4000 A3/12 x 18 LCT 4139 5 21 -7193 D350 U
Fax Option Fax Option Type C7500 4139 8 21 -7194 D35 U
G3 Interface Fax Option Type C7500 413971 21 -7195 D357 U
File Format
Converter File Format Converter Type E 414007 21 -719 D377 U
Wireless IEEE 802.11a/g Type J 414008 21 -7197 D377-01 U
Copy Data
Security Copy Data Security Unit Type F 413985 21 -7198 B829-07 C (D009)
DOSS Disk Overwrite Security System Type H 414002 21 7-199 D377-0 U
Browser Web Browser Type D 414173 21 -7200 D377-17 U
Java VM Java VM Card Type F 414004 21 -7201 D377-12 U
HDD
Encryption HDD Encryption Type A 414021 21 -7202 D377-1 C (D009)
Tab Sheet Tab Sheet Holder Type 32 0 412203 21 -7112 B499-04 C (B132)

Product Support Guide
D014 / D015
Ver.1.9 Page 3 of 38 1/1 /2009
Subject to change without notice
Item Description EDP Code Lanier ID Product
Code
Common
/ Unique
Holder
1 bin Tray Copy Tray 2075 412190 21 -7113 B75 C (B132)
LCT RT43 LCT 411182 481-0534 B473 C (B132)
LCT Adapter LCT Adapter Type B 412204 21 -7114 B 99 C (132)
LG Kit for RT43 Legal Unit for RT 43 Type 1075 411187 481-0534 B474 C (B132)
DLT Tray Kit A3/11 x 17 Tray Type 2105 411398 481-0 78 B331 C (B132)
Punch Unit Punch Unit Type 32 0 412209 21 -711 B702 C (B132)
Jogger Unit Jogger Unit Type 32 0 412212 21 -7117 B703 C (B132)
Finisher SR5000 100 Sheet Finisher 412981 479-1712 B830-17 C (B132)
Punch Punch Unit Type 5000 412983 481-7052 B831 C (B234)
Cover
Interposer Cover Interposer Type 32 0 412213 21 -7118 B704 C (B132)
Dual Source
Interposer
CI5000
2 Source Cover Interposer 41297 4817051 B835 C (B234)
9-bin Mailbox CS391 Mailbox 412191 21 -1229 B7 2 C (B234)
Z Fold Unit Z Folding Unit ZF4000 412805 479-1714 B 0 C (B234)
Bluetooth Bluetooth Type 3245 4128 21 -7092 B82 C (B132)
Copy Connect Copy Connector Type 32 0 412415 21 -7127 B328 C (B132)
Ethernet Gigabit Ethernet Type B 414204 21 -7203 D377-21 U
FAX Memory FAX Memory (SAF) 001342MIU 481-0174 G578 C (B209)
Key Counter
Interface Key Counter I/F Unit 20pin (Type A) 413012 21 718 B870 C (B222)
Key Counter
Bracket Key Counter Bracket Type 1027 412537 481-0478 B452 C (B132)
Key Card
Bracket Key Card Bracket Type B 412279 21 -7122 B498 C (B132)
IEEE 1284 IEEE 1284 Type A 411 99 481-078 B 79-17 C (B132)
BK5010 Plockmatic Bookletmaker 413101 479-1720 - -
CF5010 Plockmatic Cover Feeder 413102 481-7078 - -
TR5010 Plockmatic Trimmer 413103 481-707 - -
BF5010 Plockmatic Book Folder
(requires trimmer) 413104 481-7077 - -
BK5010 Rail
Unit Plockmatic Rail Unit 413105 481-7079 - -

Product Support Guide
D014 / D015
Ver.1.9 Page 4 of 38 1/1 /2009
Subject to change without notice
Item Description EDP Code Lanier ID Product
Code
Common
/ Unique
BK5010
Staples Staples 41147 11 -7119 - -
GBC GBC StreamPunch III 414387 479-1745 - -
GBC Die Set
3 Hole
(Ring Binder)
Die Set 001450MIU
481-073 - -
GBC Die Set
11 Hole
(Velobind)
Die Set 001451MIU
481-0737 - -
GBC Die Set
19 Hole
(Cerlox)
Die Set 001452MIU
481-0738 - -
GBC Die Set
21 Hole
(Twin Loop
Wire 2:1)
Die Set 001453MIU 481-0739 - -
GBC Die Set
32 Hole
(Twin Loop
Wire 3:1)
Die Set 001454MIU 481-0740 - -
GBC Die Set
44 Hole
(Color Coil)
Die Set 001455MIU
481-0741 - -
GBC Die Set
32 Hole
(Pro Click)
Die Set 002493MIU
481-70 - -
Note:
Additional information about the BK5010 can be found in the BK5010 Product Support Guide. (rfg02291 )

Product Support Guide
D014 / D015
Ver.1.9 Page 5 of 38 1/1 /2009
Subject to change without notice
Supplies/Yields
Name/Description
Ricoh
Product
Code
Savin
Product
Code
Lanier
Product
Code
Memo for RLA
only Gestetner
Product Code
Yield
(CTN)
Toner MP C7500 (Black) *² 841084 841092 4800459 841088 43,200*
Toner MP C7500 (Cyan) *² 841085 841093 48004 0 841089 21, 00*
Toner MP C7500 (Magenta) *² 84108 841094 48004 1 841090 21, 00*
Toner MP C7500 (Yellow) *² 841087 841095 48004 2 841091 21, 00*
Developer (Black) D0149 40 D0149 40 D0149 40 D0149 40 450K*
Developer (Cyan) D0149 0 D0149 0 D0149 0 D0149 0 450K*
Developer (Magenta) D0149 70 D0149 70 D0149 70 D0149 70 450K*
Developer (Yellow) D0149 80 D0149 80 D0149 80 D0149 80 450K*
Drum D0149510 D0149510 D0149510 D0149510 450K
Staple Type K for SR4010/4020 410801 9858 410801 - 5,000
Staple Refill Type K for SR4010/4020 410802 9859 410802 - 15,000
Staple CSC7 0A for SR4010/4020 - - - 89858 5,000
Staple Refill CSC7 0B for
SR4010/4020 - - - 89859 15,000
Staple Type L for SR4020
(Saddle Stitch) 411240 9885 480091 - 2,000
Staple Refill Type L for SR4020
(Saddle Stitch) 411241 988 480092 - 8,000
Staple CSC8 0A for SR4020
(Saddle Stitch) - - - 89885 2,000
Staple Refill CSC8 0B for SR4020
(Saddle Stitch) - - - 8988 8,000
Staple Type M for SR5000 413013 9908 4800383 89908 5,000
Staple Refill Type M for SR5000 41302 9909 480383 89909 25,000
Note:
* A4, 5% chart is used to measure the above yield. Storage period for toner is max. 1 year.
*² Newly developed 10% developer mixture. Not compatible with the B132 Series. See the ‘Differences Between
the D014/D015 & B132/B200’ section of the Service Manual for complete details.

Product Support Guide
D014 / D015
Ver.1.9 Page of 38 1/1 /2009
Subject to change without notice
Paper
Recommended Plain Paper
Not available at this time
Recommended Special Paper
Special Paper
Type Brand Product Name Media Type Size Weight
IP Hammermill HML Color Copy Gloss Coated gloss DLT 32lb
IP Hammermill Ultra Premium Photo Laser Coated gloss LT 8pt/180gsm
IP Hammermill Color Copy Gloss Coated gloss LT 80lb.cover
Domter Microprint Coated Laser Coated gloss DLT 32lb
Domter Microprint Coated Laser Coated gloss LT 32lb
Domter Microprint Coated Laser Coated gloss DLT 80lb.cover *1
Mohawk Color Copy Gloss Coated gloss DLT 32lb
Mohawk Color Copy Gloss Coated gloss LT 32lb
Mohawk Color Copy Gloss Coated gloss DLT 90lb
Xerox Color Elite Gloss Coated gloss LT 100lb.Text
Xerox Color Elite Gloss Coated gloss 12x18 100lb.Text
Special Paper
IP Carolina C2S Digital Thick paper DLT 10pt/ 2 0gsm
Notes:
• The "Feeding quality using the DLT LCT" was tested with air assist. To activate the air assist
function, select "Thick Paper 2" or "Thick Paper 3" mode. For lighter weighted paper, select
"Special Paper 2" mode.
• If a misfeed occurs when using either the mainframe paper bank or LT LCT, please fan the paper.
If the problem continues, try using the bypass tray setting a sheet at a time.
*1 Poor fusing may occur, use “Thick Paper 3”.

Product Support Guide
D014 / D015
Ver.1.9 Page 7 of 38 1/1 /2009
Subject to change without notice
Option Compatibility
Hardware Options 1 2 3 4 5 7 8 9 10 11 12 13 14 15 1 17 18
1 11”x17” / A3 Tray
2 Tab Sheet Unit
3 A3/DLT LCT X
4 A4/LT LCT X M
5 A4/LT LCT Adapter M
LG Unit for LCT M M
7 Copy Tray X X X X X X X
8 50 Staple Finisher X X X X X
9 Saddle Stitch Finisher X X X X X
10 100 Staple Finisher X X X M X X
11 SR5000 M X
12 PU for 50 staple 1 1 X X X X
13 PU for SR5000 X X M X X
14 Jogger Unit 50 staple 1 1
15 9-bin Mailbox X 1 1 X X X X X
1 Cover Interposer X 1 1 X X X X
17 2 Source Interposer X X X X X
18 Z folding unit X X 1 1
(X) Cannot be installed together
(M) Must be installed together
(1) Must be select one of these options & installed together
Software Option 19 20 21 22 23 24 25 2 27 28 29 30 31 32 33
19 Printer/Scanner Unit
20 PostScript 3 M
21 IEEE1284 Centro M X X X
22 Wireless LAN M X X X
23 Bluetooth Unit M X X X
24 Gigabit Ethernet M X X X
25 HDD Overwrite Unit
2 Copy Data Security
27 HDD Encryption Unit
28 FAX Option
29 G3 Interface Unit M
30 Copy Connector
31 Java VM Card
32 File Format Converter
33 Browser Unit

Product Support Guide
D014 / D015
Ver.1.9 Page 8 of 38 1/1 /2009
Subject to change without notice
Branding Information
Branding is required as the machines are shipped as a generic version.
Ricoh version machines: You must attach the model label (provided) to the front cover.
Savin/Lanier: You must attach the model label (provided) to the front cover and set the Plug and Play name
with SP 5-907.
Configuration
Main Frame Configuration
Peripherals2
Peripherals4 Base Unit
+
Adapter
+
Adapter
Jogger unit
for 50 staple
finisher
Copy Tray
2 sources
Cover Interposer
*Can be connected only
with 100 staple Finisher
Cover Interposer
*Can be connected only with
50 staple
Finishers
9 - bins mail box
*
Can be connected only
with 50 staple Finisher
Z folding unit
Peripherals1 Peripherals3
+ +
A4/LT LCT
+ +
A3+/DLT LCT
Adapter
Adapter
Peripherals5
Jogger unit
for 100
staple
finisher
(standard)
100 staple 3000 sheet
Finisher
50 staple 3000 sheet
Finisher
50 staple 2000 sheet
Saddle Stitch Finisher
Base Unit
-
: New option for D014/D015

Product Support Guide
D014 / D015
Ver.1.9 Page 9 of 38 1/1 /2009
Subject to change without notice
MFP Options
MFP Option Board Slot / SD Card Assignments
Hardware Option
Controller Option
Punch Unit for SR5000 NA 2/3 Printer/Scanner Unit (Inc. PictBridge)
Punch Unit for SR5000 EU 2/4 PostScript 3
Punch Unit for SR5000 SD 4
Punch Unit for 50 staple Finisher NA 2/3 Network Option
Punch Unit for 50 staple Finisher EU 2/4 IEEE802.11a/b/g
Punch Unit for 50 staple Finisher SD 4 IEEE1284
LG Unit for LT/A4 LCT Blootooth interface unit
A3/DLT tray kit
Copy connecter Others
Tab Sheet Unit Browser Unit
File Format Converter JAVA VM Card
FAX Unit
Security Option G3 Interface unit
HDD Overwrite Security Kit NRS
Unauthorized copy Gard Unit Key Counter Bracket
HDD Encriptoion Unit Key Card Bracket
Key card I/F Option
New option
Common to other models
Common to B132/B200

Product Support Guide
D014 / D015
Ver.1.9 Page 10 of 38 1/1 /2009
Subject to change without notice
# Slot Option Name
1 A Copy Connector (B328) only
2 B • IEEE1284 (B 79) • File Format Converter (D377) • IEEE802.11a/g (D377)
• Bluetooth (B82 )
3 C Gigabit Ethernet (D377). The EFI (Fiery) controller is connected through
Gigabit Ethernet.
4 Upper • Browser Unit (D377) • Data Overwrite Security (D377) • HDD Encryption Unit (D377)
• PostScript3 (D378) • Printer/Scanner Unit (D37 )
5 Lower
• VM Card (D377)
Also used as the Service Slot for firmware updates, moving applications to another SD card
with SP5873 (Apli Move).
USB 2.0 Built-in for connection of USB devices.
7 100BaseT Standard LAN connection point.
8
9
USB Ch1
USB Ch 2
For future use (PictaBridge, other application devices).
Note: These connection points are covered with a plate. Remove the
screw, rotate the plate and reattach it with the screw so that the slots
are exposed, and then attach the connector.
10 TEL Jack for telephone connection
11 Line 1 Jack for main telephone line from the outside for connection to Fax
Option (D35 ).
12 ISDN Jack for ISDN connection Japan Only
13 Line 2 Jack for a 2nd line connection to Fax Interface Unit (D357) (G3) when
this option is installed.
14 Line 3 Not used. (G4 is not available for installation outside Japan at this time.)
Important Notes
• Only two SD Card slots are available for applications.
• The VM card must be inserted in the lower slot.
• Other applications must be inserted in the upper slot.
• If more than one application is required in the upper slot, the applications must be
moved to the same SD card with SP5873-1.
• The PostScript3 application cannot be moved to another card. However, other
applications can be moved to the PostScript3 SD card.
• The VM Card must be inserted in the lower slot. This is because it requires about 22 MB
of disk space, and cannot be merged onto the SD card in the upper slot if that card
already contains all the other applications.
• If the customer needs more than one application in the upper slot, the applications must
be moved to one SD card. (See "Moving Applications to One SD Card" in this section)
