Ricoh MP C3003 User manual

STEP 1:
Select the Copier icon. Note: If you are not already
on the home screen, Select the Home button on
the Control Panel.
STEP 2:
• Enter the number of Booklets you want to
create. (For demonstration purposes, the
number 25 has already been added.)
• You will now choose the Paper Size. Select
11 x 17.
STEP 3:
Select Dup./Combine/Series.
TRAINING EXERCISE
CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING
STAPLED BOOKLETS
SELECT
SELECT
SELECT
Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.
All other trademarks are property of their respective owners. ©2013 Ricoh Americas Corp.
Color Multifunction
MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.
All other trademarks are property of their respective owners. ©2013 Ricoh Americas Corp. Page 2
CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS
Color Multifunction
MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series
STEP 4:
Select Book.
STEP 5:
Select Magazine.
STEP 6:
Select the Staple icon.
SELECT
SELECT
SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.
All other trademarks are property of their respective owners. ©2013 Ricoh Americas Corp. Page 3
CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS
Color Multifunction
MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series
STEP 7:
Select the Program button on the Control Panel.
STEP 8:
Select Program.
STEP 9:
You will now begin the process of naming your
short cut icon. Select a “Not Programmed” button.
SELECT
SELECT
SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.
All other trademarks are property of their respective owners. ©2013 Ricoh Americas Corp. Page 4
CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS
Color Multifunction
MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series
STEP 10:
Type the name of your icon. Select OK. For
demonstration purposes, Booklets 11x17 has
already been entered.
STEP 11:
The name of your short cut icon now appears in the
program list. Select Program to Home.
STEP 12:
A screen appears asking if you are sure you want
to register the program to the Home screen. Select
Yes.
SELECT
SELECT
SELECT

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355. Ricoh® and the Ricoh logo are registered trademarks of Ricoh Co, Ltd.
All other trademarks are property of their respective owners. ©2013 Ricoh Americas Corp. Page 5
CUSTOMIZING HOME SCREEN WITH SHORT CUT ICON: CREATING STAPLED BOOKLETS
Color Multifunction
MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 Series
STEP 13:
Notice that the Home icon appears next to the
Booklets 11x17 program. Select Exit to return to
the Copier main screen.
Note: To see the short cut icon you created, Select
the Home button on the Control Panel.
STEP 14:
You have now completed customizing your home
screen.
JOB TASK COMPLETE.
SELECT
