Ricoh Antares-PJ1 Series Manual

1
Antares-PJ1Training
Slide 1
Y020/Y021/Y022
Service Training
Antares-PJ1
Version 1.0
This training course provides service technician training for the Antares-PJ1
series.

2
Antares-PJ1Training
Slide 2
Y020/Y021/Y022
Service Training
Product Overview
This section provides an overview of the machine, and the options that can be
installed.

3
Antares-PJ1Training
Slide 3
What Models are there in the Series?
Antares-PJ1 cw (Y020): PJ WX2130
2500 lumens, WXGA resolution
Antares-PJ1 cx (Y021): PJ X2130
2500 lumens, XGA resolution
Antares-PJ1 cs (Y022): PJ S2130
2500 lumens, SVGA resolution
These are compact entry-level models with
standard features.
The models in this series cannot be used as
network projectors.
These models do not work with 'Network Utility‘,
‘Projector Management Utility’, or @Remote.
No additional notes

4
Antares-PJ1Training
Slide 4
Main Specifications
For SVGA/XGA: F# 2.41 ~ 2.55, f=21.79 ~ 23.99 mm,
1.1X Mechanical Zoom Lens
For WXGA: F# 2.50 ~ 2.67, f=21.86 mm ~ 24 mm,
1.1X Mechanical Zoom Lens
Projection lens
200W OSRAM E20.8Lamp type 2500lmBrightness 6 segmentsColor wheel type
Antares-PJ1 cw Antares-PJ1 cx Antares-PJ1 cs
Type DLP
Resolution WXGA XGA SVGA
Dimensions (W×D×H) 286.3 ×192 ×88
Weight 2.5 kg (5.5 lbs)
Power 280W
Keystone Vertical (Manual)
Speaker 2W x 1
Wireless LAN No
Wired LAN No
USB Service Use Only
HDMI Yes
No additional notes

5
Antares-PJ1Training
Slide 5
Features
This product can be installed by users, except
when mounted on a ceiling.
This product is designed for user maintenance.
Regular on-site maintenance is not needed.
There is no display panel, but LEDs show the
symptoms for troubleshooting (blinking/lit,
number of times the LEDs blink, etc).
A service mode is available.
No additional notes

6
Antares-PJ1Training
Slide 6
Low Energy Consumption
4,000 hour lamp life and lower power
consumption in Eco mode
0.5W power consumption in standby mode
Note that in the service mode menu, Eco Mode is referred to as ‘Low Mode’.

7
Antares-PJ1Training
Slide 7
Consumables and Options
Replacement lamp (Y207)
200W mercury lamp
Life: 3000 hours (normal mode), 4000 hours (Eco
mode)
» There may be a 50% decrease in brightness at the end
of the lamp’s life.
3D glasses (Y107)
Will also be usable with other DLP-type projector
models to be released in the near future.
No additional notes

8
Antares-PJ1Training
Slide 8
Reliability Information
Average monthly projection time: 44.0 hrs/month
2.00 hrs/day x 22 working days/month
Failure Rate
1st year: 0.0025 cases/unit/month
2nd year: 0.0029 cases/unit/month
3rd year: 0.0037 cases/unit/month
The failure rate of a projector increases with its
total power-up time. This is due in part to the
failure characteristics of optical engines in
projectors.
Lamp Life
Normal Mode: 3,000 hrs
Eco Mode: 4,000 hrs
No additional notes

9
Antares-PJ1Training
Slide 9
Lamp Near-end/End Alerts
There is no near-end alert.
The lamp end alert occurs when the machine
calculates that the life time has expired.
If used in Normal Mode only, the alert appears
after 3,000 hrs projection time
If used in Eco Mode only, the alert appears after
4,000 hrs projection time
If the user switches between modes, the machine
calculates when to display the alert based on
how long the lamp was used in each mode.
No additional notes

10
Antares-PJ1Training
Slide 10
Disposal of Broken Lamps
Projector lamps normally contain mercury
vapour.
These lamps can rupture due to impact or being
used longer than their life expectancy.
The time that the breakage will occur differs
widely for each lamp and its circumstances of
use.
These lamps must be disposed of in accordance
with local environmental regulations.
No additional notes

11
Antares-PJ1Training
11
Slide 11 11
Overview External View
1. Operation panel
2. Zoom
3. Ventilation (inlet)
4. Speaker
5. Focus ring
6. Ventilation (outlet)
7. IR receiver
8. Lens
9. Lens cap
10.Connection ports
11.Adjustable feet
Slide 11 11
Overview External View
1. Operation panel
2. Zoom
3. Ventilation (inlet)
4. Speaker
5. Focus ring
6. Ventilation (outlet)
7. IR receiver
8. Lens
9. Lens cap
10.Connection ports
11.Adjustable feet
No additional notes

12
Antares-PJ1Training
Slide 12
Operation Panel
The three LEDs are used
to show symptoms for
troubleshooting.
Remote
Controller
No additional notes

13
Antares-PJ1Training
13
Slide 13 13
9Interface
Overview Connection Ports
1. HDMI
2. COMPUTER IN/COMPONENT IN
3. S-VIDEO IN
4. VIDEO IN
5. Service port
6. MONITOR OUT
7. AUDIO IN
8. Power in
9. Anti-theft lock
1. HDMI Connector: Input for digital signals from a HDMI (High-Definition
Multimedia Interface) compatible digital source.
2. COMPUTER IN/COMPONENT IN Connector: Input for analog RGB signals
from a computer or a component video signal (Y/PB/PR) from video equipment.
3. S-VIDEO IN Connector: Input for S video signals from video equipment.
4. VIDEO IN Connector: Input for video signals from video equipment.
5. SERVICE Port: Use this port to update the firmware.
6. MONITOR OUT Connector: Output for analog RGB signals or component
video signal (Y/PB/PR) to another device.
7. AUDIO IN Jack: Input for audio signals from a computer or video equipment.
8. AC IN: Connect the supplied power cord.
9. Kensington TM Lock

14
Antares-PJ1Training
Slide 14
Optical Components
The DMD chip is the central part of this type of projector.
A DMD chip consists of many small pixel-sized mirrors laid out on a semi-
conductor chip. Light shone on the DMD chip is reflected by all these tiny
mirrors. (For a chip with 1024 x 768 resolution, there are 786,432 small
mirrors.)
Light is shone onto the chip through a fast-spinning color wheel (CW in
the diagram) that has a red sector, a green sector, and a blue sector.
This light is reflected off the chip and out through a lens onto a screen.
Lamp: Light source
UV-IR Filter: Lets visible light through (wavelengths between 380~780nm) and
prevents UV and IR damage to other optical parts.
CW (Color wheel): The wheel has a red segment, a green segment, and a blue
segment. The wheel rotates to provide red, green, and blue light (the color of the
output beam changes from red, to green to blue)
Integrating Rod: Gives the light a uniform luminous flux.
L3: Condensing lens. Condenses divergent light.
L2: Condensing lens. Works with L3 to condense divergent light.
M1: Mirror 1. Changes the light direction.
M2: Mirror 2. Changes the light direction.
Relay L1: Condenses and magnifies divergent light before it goes to the DMD.
DMD Chip: Contains micro mirrors to generate the image
Projection Lens (WT41 in the diagram): Projects the image onto the screen.

15
Antares-PJ1Training
Slide 15
DMD Chip
R, G, and B signals from the image generating device are sent to
the DMD chip, and timed so that the red signal arrives at the same
time that the red part of the wheel is in the beam path, and
similarly for the green and blue signals.
The DMD chip generates the R, G, and B images by re-positioning
the micromirrors using micromachined hinges to make different
pixelated images for each colour (meaning that each micromirror
has an ON and an OFF position).
For SVGA resolution, the mirrors are 16-micrometer squares, with
a gap of about 0.8 micrometers between each mirror.
No additional notes

16
Antares-PJ1Training
16
Slide 16 16
System Block Diagram
Lamp
Fan Speaker
DMD board
Signal Main board
Screen
Lens
Color
wheel
Power LVPS
Lamp driver
380VDC
Signal input Board to board Wire Light path
Optical Engine
DMD Chip
Keypad
board
Photosensor
(CW index)
Rod
This diagram shows how signals flow between boards.
It also shows the light path from the lamp through to the lens.
The light changes between red, green, and blue as the color wheel turns.
The red dotted lines indicate the components of the optical engine.
Slide 16 16
System Block Diagram
Lamp
Fan Speaker
DMD board
Signal Main board
Screen
Lens
Color
wheel
Power LVPS
Lamp driver
380VDC
Signal input Board to board Wire Light path
Optical Engine
DMD Chip
Keypad
board
Photosensor
(CW index)
Rod

17
Antares-PJ1Training
Slide 17
Boards
Main board (MB): Power/signal control and
processing
DMD board (DMD BD): Image signal processing
and DMD control
LVPS (DC-DC): Power supply, passes signals
between boards
LVPS means Low Voltage Power Supply
Lamp driver (Ballast): Starts the lamp
When the lamp is being lit, the voltage is over
10,000V.
No additional notes

18
Antares-PJ1Training
18
Slide 18 18
Main Board
SPK
J12 2P
IR
J17 3P CW
J7 4P
MB to KB
J22 24P
Blower
J6 3P FAN
J5 3P
LAMP
J8 5P
MBtoLVPS
J1 8P
DMD BD to Main
board
HDMI
19P Computer in
15P S-VIDEO
4P VIDEO AUDIO
IN
DMD Board
LVPS
Lamp Driver
Lamp
5P
5P
2P
2P
2P
2P
8P
8P
Power Inlet
Thermal Switch (2P) Interlock Switch (2P)
Computer Out
15P
Mini USB
J9 3P
Keypad board
Board Layout
This diagram shows how to connect the cables to the main board and other
parts.

19
Antares-PJ1Training
Slide 19
Main Board Block Diagram
Lamp
driver
DDP
2000
LVPS AC in
DC
3.3V,
5V, 12V
Source in
Fans
Speaker Audio AMP
TAP0172
Video
Decoder
TVP5147
ADC
AD9983
DAD
1000
CW index
DMD
BD
DMD
CHIP CW
Photo sensor BD
CW Motor
driver
Lamp
Projection
Lens
Main
Board
No additional notes

20
Antares-PJ1Training
Slide 20
Y020/Y021/Y022
Service Training
Basic Points about Service
This section explains the basic points about servicing the machine.
