RIDGID STEALTH User manual

2017-2018 FORD®SUPER DUTY®
STEALTH GRILLE MOUNT
(Excludes PLATINUM Edition)
INSTALLATION INSTRUCTIONS
*THIS MOUNT FITS THE FOLLOWING LIGHTS:
(2) 6” SR-Series®
PRODUCT INCLUDES:
(1) Stealth Grille Mount
* LIGHTS SOLD SEPARATELY
IMPORTANT
THANK YOU FOR PURCHASING RIGID INDUSTRIES’ PRODUCTS FOR YOUR VEHICLE.
Please read through all of these Instructions and tips before proceeding with the installation.
We do our best to provide a simple installation process for all applications however
a professional installation is always recommended.
Always disconnect any power sources connected to your vehicle
before servicing fuses or electrical systems.

FIGURE 1
FIGURE 1.1
FIGURE 2
FIGURE 2.1
STEP 1
Open hood and remove the plastic
push pins that attach the plastic
radiator shield. Use push pin pliers,
non-marring prybar or equivalent.
See Figures 1, 1.1
STEP 2
Reove the (8) 10mm bolts towards
the front of the truck and set aside to
install later.
See Figures 2, 2.1

FIGURE 4
FIGURE 4.1
STEP 4
Lay grille at on the front and set
the RIGID bracket into place as
shown (marked D and P for drivers/
passenger). Using a 1/16” drill bit, drill
each hole through the rst layer of
plastic.
BE SURE NOT TO DRILL THROUGH
THE FRONT OF THE GRILLE!
See Figures 4, 4.1
FIGURE 3
FIGURE 3.1
STEP 3
Remove grille by pulling away from
the truck on the top and using a pick
or a at head screw driver, push pins
down on the bottom of the grille and
pull the grille out.
NOTE - BE SURE NOT TO DROP
ANY CLIPS WHEN REMOVING THE
GRILLE
See Figures 3, 3.1
