Pifco P28044 Mounting instructions

MODEL P28044
www.pifco.co
Cordless Air-Pro
Lightweight
Vacuum Cleaner
YOUR SAFETY & INSTRUCTION MANUAL
PLEASE READ CAREFULLY
Need help?
For advice, spares & returns.
Call: [phone]
8:30am to 6:00pm Monday - Friday
Visit: www.pifco.co

2
Customer support team: [phone]
Technical data
Description: Cordless Air-Pro Upright Vacuum Cleaner
Model: P28044
Vacuum: DC22V 2150mAh
Motorized Cleaning Head: DC21.6V 20W
Battery: 3.7V 2150mAh
Adaptor:
Input: 100-240V ~50/60Hz 0.35A
Output: 27.0V 0.5A
Documentation
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
Warranty
This product is guaranteed for 12 months from the date of original purchase. If any defect arises
due to faulty materials of workmanship, the faulty products must be returned to the place of
purchase. Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.pifco.co
WARNING:
Do not aempt to open any part of the power adaptor or plug.
WIRING SAFETY FOR UK USE ONLY
(Power adapters only)
Never open the power adapter, you risk getting an electric shock.
Only use the power adapter that is supplied with your product.
You must always connect the power adapter to the product before connecting to the mains power
supply.
The power adapter must be used indoors only, and must not be subjected to damp conditions.
The power adapter does not have any user serviceable parts.
If in doubt, consult a qualified electrician who will be pleased to do this for you.
If you need to remove the plug – disconnect it from the mains – and then cut it off of the mains
lead and immediately dispose of it in a safe manner. Never attempt to reuse the plug or insert it
into a socket outlet as there is a danger of an electric shock.

4
Customer support team: [phone]
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer,
its service agent or a similarly
qualified person.
• DO NOT let the cord hang over
the edge of a table or counter
or let it come into contact with
any hot surfaces.
• DO NOT carry the appliance by
the power cord.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer apart from those
supplied with this product. DO
NOT use extension cords with
the appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• Switch off and unplug before
fitting or removing tools/
attachments, after use and
before cleaning.
• Close supervision is necessary
when any appliance is used by
or near children.
• Children should not play with
the appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Cleaning and user maintenance
should not be undertaken by
children without supervision.
• Take care when any appliance is
used near pets.
• Not suitable for carpets with
long fibres as the bristles will
damage the fibres.
• Keep the vacuum cleaner
moving over the carpet surface
at all times to avoid damaging
the carpet fibres.
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:

5
www.pifco.co
• DO NOT use this product for
anything other than its intended
use.
• DO NOT immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• This appliance is for household
use only.
• DO NOT use the appliance
outdoors.
• Keep hair, loose clothing,
fingers and all body parts away
from moving parts.
• DO NOT use to pick up
flammable liquids such as
gasoline or use in an area where
they might be present.
• DO NOT use the appliance
without the dust container filter
in place.
• DO NOT pick up anything that
is burning or smoking such
as cigarettes, matches or hot
ashes.
• Use extra care when cleaning
on stairs.
• Use only manufacturer’s
recommended accessories.
• DO NOT pull cord, use cord as
a handle, close a door on cord,
or pull cord around sharp edges
or corners.
• DO NOT run vacuum cleaner
over the cord. Keep cord away
from heated surfaces.
• This product is fitted with a
thermal cut-out, which will
activate if the motor overheats
due to blocked air inlets. If the
appliance cuts out, allow it to
cool for 1 hour, then empty the
dust container and clean all of
the filters.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.
HIGH VOLTAGE ROTATING PARTS

6
Customer support team: [phone]
What’s in the box & details:
Instruction Manual
Adapter
1. Power Switch
2. Handle
3. Power LED
4. Charging Socket
5. Dust Bin
6. Dust Bin Handle
7. Exhaust Filter Housing
8. Brushroll Release Button
9. Brushroll
Before your first use:
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and counted all the parts and the contents
against the parts list.
4. Charge the rechargeable battery
Dispose of the packaging in a responsible manner.
3
5
6
1
2
4
7
8
5
9

7
www.pifco.co
Assembly and of your vacuum:
1. Carefully unpack the Vacuum Sweeper.
Ensure that all parts are included before
discarding packaging.
2. Insert the upper part of the handle into
the lower portion.
3. Push the two parts together until you
hear them click in place.
4. To detach the handle: Just push the
button on the back and pull out the
upper part.
Charging your vacuum:
A full charge takes approximately 5 hours.
1. The vacuum will not be charged when
unpacked and so must be charged before
first use. Before charging, ensure that the
appliance is switched off.
2. Connect the charger mains plug to a
suitable mains outlet and the other
adapter into the charging port on the
vacuum.
3. After charging, stand the vacuum
sweeper upright, step on the filter
housing area and pull the handle back,
ready to begin sweeping.
Using your appliance:
Use the power switch on the handle to
turn the device on. If the item fails during
operation, please switch the device off
immediately by using the power switch and
determine the cause using the troubleshooting
guide.
Note:
This vacuum sweeper works best on
smooth surfaces such as wood, ceramic,
tiles and marble. It will also perform well
on hard, short-haired carpet. It should
NOT be used on long-haired carpets as
the fibres will damage the system.
Note:
Keep the brushes free of fibres, hairs, and
other objects that could impede proper
functioning. Always remove them when
it occurs.
Note:
Do not use the device to clean carpet
fringe or frayed carpets.
Push
Push

8
Customer support team: [phone]
Cleaning and care:
Caution! Never vacuum clean without a filter
or with a damaged filter. Dust that is sucked
into the unit could force its way into the
device and damage the motor.
Emptying dust bin:
1. Remove the dust bin from the Vacuum
sweeper by holding the dust bin handle
and pulling upward until it separates from
the body.
2. Hold the Dust Bin over a suitable
receptacle such as a bin and press
the dust release button to empty the
container.
Cleaning the filter:
When the filter is blocked push the button
located on the dust bin to release the dust cap.
1. Take out the Sponge filter from the Dust
bin
2. Take out the filter housing from the Dust
bin by pulling the filter handle.
3. Holding the Dust bin over a garbage bag
or other receptacle, then pour out the
dirt particles.
4. Remove the filter from the filter housing
by rotating the filter handle anticlockwise
and lifting it off.
5. Shake off the sponge until the majority
of the dust has been removed. Wash the
dust bin, filter housing, filter and sponge
under clean, warm water and allow it to
dry thoroughly.
Important: Allow all filters to dry completely
before replacing in the vacuum sweeper
6. Once all parts have dried fully, put the
filter into the filter housing and rotate the
filter handle clockwise to fix it into place.
7. Insert the filter housing into the dust bin.
Put the sponge into the Dust cap, and
then close the dust cap until it locks back
into position.
8. Place the Dust bin into Vacuum sweeper
pressing it down until you hear it click
into place
Note:
When the Dust Bin is full or the filter is
blocked, they should be cleaned before
further use.
Note:
Do not clean the sponge using detergent.
Push

9
www.pifco.co
Cleaning the brush roller:
1. Before cleaning the brushroller make sure
the unit is switched off and the power
cord is unplugged.
2. Turn the vacuum sweeper upside down.
Turn the brush button screw to its unlock
position.
3. Open the brush housing, lift the tab on
the brush roller up to remove it from the
vacuum sweeper.
4. Remove any string, carpet fibres, or hair
wrapped around the brush roller. The
groove on the brush roller allows a pair
of scissors to cut the debris without
damaging the bristles.
5. The brush roller can be removed and
rinsed under running water. Let the brush
roller air-dry completely before replacing
into the vacuum sweeper.
To re-assemble, hold the brush roller by the
tab and align the other end with the gear. Then
with the tab facing up, place the brush roller in
the vacuum sweeper.
Put the brush fixing device into position and
screw the release button to lock position.
Cleaning the exhaust filter:
1. To remove the exhaust filter for cleaning,
press down the clip on the back of the
exhaust filter housing and lift the cover
away.
2. Remove the exhaust filter from the
exhaust filter housing.
3. Shake off the exhaust filter until the
majority of the dust has been removed,
then wash the exhaust filter under
clean, warm water and allow it to dry
thoroughly.
4. Once the exhaust filter has dried fully,
slot it back into the exhaust filter housing
and replace the exhaust filter housing
cover.
Cleaning the external of the
vacuum:
1. Use a dry cloth to clean the unit including
the dust bin and remove hair and fibres
from the bristles.
2. 2. Do Not use abrasive material to clean
the device and do not submerge it in
water under any circumstance.
Storage:
• When the appliance is not in use, store in
a safe, dry place, out of reach of children.
• DO NOT store the vacuum in direct
sunlight.
Note:
Do not clean the exhaust filter using
detergent.
Do not use external heat sources, such as
a radiator to dry the exhaust filter.

10
Customer support team: [phone]
WARNING:
DO NOT immerse any electrical part of the appliance in water such as motor units or plugs.
Please see cleaning secon for further instrucons.
Troubleshoong:
Problem Possible Soluon
Vacuum will not work. The vacuum may have run out of charge.
Charge fully.
This vacuum cleaner is equipped with a motor
protective thermostat. If for some reason
your vacuum overheats, the thermostat will
automatically turn the suction motor off.
Should this occur, allow it to cool for 1 hour,
then empty the dust container and clean all of
the filters.
Vacuum will not pick-up or suction power is
weak.
The dust container may be full, or the filters
may require cleaning.
Empty the dust container and clean the filters.
Check to make sure the Brush roller was
replaced correctly if it had been removed.
Make sure that the Brush roller was reinserted
correctly with the pull tab facing up.
Dust is escaping from the vacuum. The filter may not be installed correctly, or
the dust container may be full. Empty the dust
container and reassemble the filter system
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are
required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk
for access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of electrical items
purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled,
rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.

11
www.pifco.co
Notes

0618.V1
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantasc products,
we are oering you an extra 1 year peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by vising:
www.pifco.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
