Explanations to symbols
...Important
Note #3
...Allen key #3
#25
...Hexalobular T25
...Useful
Tip ...Manually
1. PREFACE
Dimensions
H
B
T
R-S
R-H
F-H
RO-T1
RO-H
RO-T2
RO-T3
RO-S
FB-TFB-S
R-
F-
Dimensions
Height [mm] 1161
Width [mm] 480
Corpus depth [mm] 719
Weight
Weight [kg] ~185
Flue pipe connection
R - Ø Flue pipe outlet [mm] 130
RO - H original angle pipe connection height [cm] 126
RO - T1 original angle pipe total depth [cm] 72
RO - T2 original angle pipe distance to rear wall [cm] 7
RO - T3 Deapth from rear wall to middle of flue
pipe [cm] 22
RO - S original angle pipe side distance [cm] 24
R - H Rear connection height [cm] 97
R - S Rear connection side distance [cm] 24
Fresh air connection
F - Ø Diameter [mm] 125
F - H Connection height [cm] 9
F - S Side distance [cm] variabel
FB - S Floor connection side distance [cm] 15
FB - T Floor connection depth [cm] 43
Amount of fuel
Nominal load Part load
Amount of fuel ~2,2kg* ~1,1kg*
*Practical values may vary depending on fuel quality.
Technical data
Technical data
Heating power range [kW] 4 - 8
Room heating capacity (depending on house
insulation) [m³] 90-210
Fuel consumption [kg/h] up to 2,2
Efficiency [%] 83,5
CO2 [%] 10,7
CO-emission on 13% OO [mg/mN
3] 627,5
Dust emission [mg/mN
3] 18
Exhaust [g/s] 6,4
Exhaust temperature [°C] 241,1
Chimney draft requirement [Pa] 12
The owner of small firing systems or the person authorised for the small
firing system is to keep the technical documentation and is to submit it to the
authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as local
regulations concerning the installation and operation of firing installations!
Packaging
Your first impression is important to us!
The packaging of your new stove provides excellent protection against damage.
However damage to the stove and accessories may still occur during transport.
Note
Therefore please check your stove on receipt for damage and completeness!
Report any deficiencies to your dealer immediately! Pay particular attention
during unpacking that the stone panels remain intact. Scratches to the
material can easily occur. Stone panels are excluded from the warrant.
The packaging of your new stove is environmentally neutral to a great extent.
Tip
The wood used in the packaging has not been surface treated and may
therefore be burnt in your woodburning stove (not in a pelletstove!). The
cardboard and film (PE) can be depolluted via the municipal waste collection
for recycling.

4
Spare part overview - exploded diagram
33
34
35
36
24
14
17
8
22
12
13
23
1
2
3
4
19
20
39
38
21
15
16
16
14
14
10
13
5
5
11
12
10
6
9
7
7
18
31
28
29
28
32
30
25
27
26
37
49
50
46
47
48
44
43
43
42
45
40
41

|5
EN
4
71
55
56
60
56
63
63
66
66
72
67
68
58
51
52
64
57
70
65
69
54
53
59
62
61
59
62
89
90
91
78
84
86
82
74
81
74
73
83
87
88
85
76
77
75
85
97
96
95
94
98
79
92
93
80
