RIKA induo II User manual

INDUO II
Operating manual

2
TABLE OF CONTENTS
1. PREFACE 3
Explanations to symbols.................................................................................................................................................................................................. 3
Spare part overview exploded diagram............................................................................................................................................................4
Spare part overview article numbers...................................................................................................................................................................6
Dimensions ................................................................................................................................................................................................................................... 8
Amount of fuel ........................................................................................................................................................................................................................... 8
Electrical connection........................................................................................................................................................................................................... 8
Technical data........................................................................................................................................................................................................................... 8
Packaging...................................................................................................................................................................................................................................... 8
2. IMPORTANT INFORMATION 9
General warning and safety information .........................................................................................................................................................9
First heating.................................................................................................................................................................................................................................9
Safety distances ......................................................................................................................................................................................................................9
Prior to set up...........................................................................................................................................................................................................................10
Convection air conduction ..........................................................................................................................................................................................10
3. INSTALLING THE STOVE 11
Connection to the chimney ...........................................................................................................................................................................................11
Connecting to a steel chimney ..................................................................................................................................................................................11
Combustion air.........................................................................................................................................................................................................................11
Feeding in external combustion air.......................................................................................................................................................................11
4. BRIEF INFORMATION ON FUEL  PELLETS 12
What are pellets?....................................................................................................................................................................................................................12
Wood pellet specification according to ENplus – A1 .............................................................................................................................12
Pellet container refilling during operation......................................................................................................................................................12
Pellet storage.............................................................................................................................................................................................................................12
5. BRIEF INFORMATION ON COMBUSTIBLE  LOGS 13
Suitable fuels and fuel amounts ............................................................................................................................................................................. 13
Wood types................................................................................................................................................................................................................................. 13
Output controlling................................................................................................................................................................................................................ 13
Clean combustion................................................................................................................................................................................................................ 13
6. TECHNOLOGY AND SAFETY FUNCTIONS 14
Operating comfort............................................................................................................................................................................................................... 14
Top efficiency - lowest emissions........................................................................................................................................................................... 14
Burnback and flue gas flaps ...................................................................................................................................................................................... 14
Overheating............................................................................................................................................................................................................................... 14
Low-temperature shutdown ....................................................................................................................................................................................... 14
Electrical excess current protection ................................................................................................................................................................... 14
Automatic cleaning cycle.............................................................................................................................................................................................. 14
Component monitoring .................................................................................................................................................................................................. 14
Auger motor monitoring................................................................................................................................................................................................. 14
7. ASSEMBLYDISMANTLING STONE AND OPTIONS 15
Dismantling stone .................................................................................................................................................................................................................15
Conversion to flue pipe connection rear......................................................................................................................................................... 16
8. BURNBACK AND FLUE GAS FLAP 17
Start of operation ..................................................................................................................................................................................................................17
Refilling logs - opening flue gas flap....................................................................................................................................................................17

|3
2
EN
9. FLOW DIAGRAM PELLET  LOG OPERATION 18
10. COMFORT OPTIONS 19
Room sensor, Radio room sensor........................................................................................................................................................................... 19
Interface for various options...................................................................................................................................................................................... 19
External room thermostat ............................................................................................................................................................................................ 19
External connection cable bridge......................................................................................................................................................................... 19
Option firenet ........................................................................................................................................................................................................................... 19
RIKA VOICE ................................................................................................................................................................................................................................. 19
11. MAINTENANCE 20
Cleaning the fire trough ................................................................................................................................................................................................ 20
Checking the door contact.........................................................................................................................................................................................20
Empty the ash drawer..................................................................................................................................................................................................... 20
Cleaning the door glass.................................................................................................................................................................................................20
Cleaning painted surfaces..........................................................................................................................................................................................20
12. CLEANING 21
Cleaning the convection air openings...............................................................................................................................................................21
Combustion air - intake...................................................................................................................................................................................................21
Cleaning the pellet container.....................................................................................................................................................................................21
Bearings .........................................................................................................................................................................................................................................21
Checking door seal..............................................................................................................................................................................................................21
Cleaning flue pipes ..............................................................................................................................................................................................................21
Cleaning flue gas deflector section.....................................................................................................................................................................22
Cleaning the flue pipes ...................................................................................................................................................................................................22
13. PROBLEMS  POSSIBLE SOLUTIONS 23
Problem 1...................................................................................................................................................................................................................................... 23
Problem 2..................................................................................................................................................................................................................................... 23
Problem 3 .................................................................................................................................................................................................................................... 23
14. INSTRUCTIONS FOR COMMISSIONING PROTOCOL 24
Operator instruction ......................................................................................................................................................................................................... 24
15. GUARANTEE CONDITIONS 26
16. WARRANTY CONDITIONS 26
1. PREFACE
Explanations to symbols
...Important
note #8
...Hex #8
#6
...Allen key #6 ...Scrawl with
Metaflux
...Useful
tip #10
...Hex #10 ...Manually ...Hacksaw

4
Spare part overview exploded diagram
7
8
9
16
15
11
11
11
12
12
13
13
5
5
18
4
4
20
19
17
10
14
14
6
1
1
2
2
3
3
21
66
28
27
29
33
25
34
24
35
32
26
30
31
39
42
37
36
38
22
23
48
47
45
46
50
53
51
52
54
57
67
68
69
55
56
49
64
65
52
51
58
43
44
40
41
62
61
63
59
60
60

|5
4
EN
70
71
73
72
75
74
76
77
81
84
89
82
79
85
83
78
88
80
87
86
119
113
120
118
117
116
115
113
98
112
107
105
104
103
99
92
94
97
95
110
109
96
108
114
111
93
90
91
102
101
100
106
132
139
141
142
143
135
136
137
135
144
137
145
138
126
127
146
134
133
150
147
123
121
122
128
130
155
154
129
153
152
151
149
148
129
131
128
130
129
129
140
124
125
160
128
130
165
156
157
158
164
163
162
161
159

6
Spare part overview article numbers
Nr. Art.Nr. Description
1 L02007 Guide stone
2 N111965 Washer M05
3 N111866 Hexagonal screw
4 N111856 Hexagonal countersunk screw M04x12
5 L01957 Closure plate
6 L02010 Door lock
7 B16564 Door metallic assy
B16972 Door compleet, black
8 N103693 Flat seal black 8x2
9 Z34303 Door glass (ceramic glass)
10 N112551 Round sealing strip grey D11 (1m)
11 Z34472 Hinge plate
12 N112175 Washer
13 N103964 Hexagonal screw
14 Z34457 Hinge
15 N112075 Allen screw
16 L02574 Glass holder
17 N112551 Round sealing strip grey D11 (1m)
18 N111637 Setscrew door opener
19 N111798 Cylindrical pin door opener
20 B16565 Door opener assy
21 N112065 Cylinder screw
22 Z34554 Wood retainer metallic
Z36928 Wood retainer black
23 N111947 Self-tapping screw M05x16
24 Z34412 Firebrick lining front left
25 Z34411 Firebrick lining rear left
26 Z34553 Air scoop metallic
Z36252 Air scoop black
27 Z35555 Angle bracket and allen screw
28 B18224 Heat exchanger cover metallic
B16679 Heat exchanger cover black
29 N111320 Sealing cord grey D14
30 B16682 Flue gas chute lid
31 N103066 Round sealing strip black D06
32 Z36658 Baffle plate
33 Z34409 Firebrick lining rear
34 Z34410 Firebrick lining rear right
35 Z34413 Firebrick lining front right
36 N103560 Hexagonal screw
37 L02008 Fire trough tray
38 N111846 Hexagon socket 06x12
39 Z36643 Fire trough
40 Z34468 Sealing
41 Z36935 Seal
42 Z34244 Turning grid
43 L02044 Turning grid support
44 N112148 Hexagonal screw
45 L01875 Driving plate turning grid
46 N112470 Spring clip
47 N108131 Pressure spring
48 Z33924 Intermediate shaft turning grid
Nr. Art.Nr. Description
49 N107521 Hexagonal screw M05x12
50 Z34824 Bearing clamping plate metallic
Z34965 Bearing clamping plate black
51 N104718 Circlips D08
52 N108310 Sinter bearing ID10
53 Z34757 Bearing plate top metallic
Z34966 Bearing plate top black
54 B16553 Sprocket top
55 N100172 Washer
56 N110928 Screw
57 Z34557 Chain turning grid
58 B16559 Actuating cam turning grid
59 N111825 Contact switch
60 Z34461 Bearing plate bottom metallic
Z34964 Bearing plate bottom black
61 N111631 Round sealing cord grey D06
62 B16680 Cleaning cover
63 N112093 Milled nut (cleaning cover)
64 B16957 Sprocket bottom
65 Z34555 Sinter bearing ID 10,2 sprocket out
66 L02952 Ash drawer
67 Z35158 Spacer chain guide / clamping plate
68 Z35302 Chain guide
69 Z35303 Clamping plate
70 B16675 Flap lever flue gas flap
71 N112283 Hexagonal screw
72 N112499 Setscrew with pin
73 Z36535 Shaft of fluegas flap
74 N103560 Hexagonal screw
75 Z36925 Bearing
76 Z36926 Shaft of fluegas flap
77 B18135 Lever fluegas flap
78 Z18997 Rubber buffer
79 N112321 Pressure spring
80 Z34471 Tension spring flue gas flap
81 B18087 Hinge shaft
82 N112120 O-ring
83 L02954 Holder plate
84 N111732 Magnetic switch top part
85 N111733 Magnetic switch bottom part
86 N112409 Hexagon socket screw
87 B17925 Flap handle
88 N112315 Cylindrical pin
89 B17340 Fluegas flap assy
90 Z34565 Soapstone option, lateral
91 B18082 Stone retainer
92 B16576 Convection cover metallic assy
B16965 Convection cover assy, black
93 E15143 Convection cover AH metallic
E15356 Convection cover AH black
94 B16577 Flue pipe cover metallic
B16966 Flue pipe cover black
Note: Please consider the powdercoated parts can differ slightly in colour and colour effects though they are elaborated in high quality.

|7
6
EN
Nr. Art.Nr. Description
95 N111631 Round sealing cord grey D06
96 Z21690 Blind cover metallic
97 Z30137 Flue pipe attachments (without seal)
metallic grey D150
Z20556 Flue pipe connection black D150
98 B17100 Stone retainer
99 N112143 Hexagonal nut M03
100 N111842 Hexagon socket M03x10
101 N111733 Magnetic switch bottom part
102 L01445 Switch spacer
103 N112144 Washer M03
104 N111732 Magnetic switch top part
105 N110461 Double ball catch
106 N111731 Container seal
107 B16578 Container lid metallic grey assy
B16971 Container lid black assy
108 Z34994 Cleaning opening metallic
Z34995 Cleaning opening black
109 Z36659 Rear wall right metallic grey
Z36661 Rear panel right, black
110 Z34486 Rear wall left metallic grey
Z34971 Rear panel left black
111 B17925 Flap handle
112 B16574 Touch-display plug-in
113 N111730 Grommet
114 N112490 Levelling screw black
115 B17924 Right side panel metallic
B17931 Right side panel black
116 Z34483 Soapstone front
Z35078 Sandstone front
Z36340 Quartz front anthracite grey
Z36545 Frontstone white
117 B16570 Cover panel, bottom metallic
B16960 Casing panel bottom black
118 Z34479 Cable cover metallic grey
Z34967 Cable cover black
119 B16566 Side panels steel metallic grey left
B16964 Side casing panel, left black
120 B16568 Front top metallic
B16961 Front top black
121 B17923 Ceramic ignition
122 Z36293 Seal for ignition
123 Z34464 Insertion screw
124 B15248 Sensor tube
125 B16676 Flame temperatur sensor
126 L01954 Pressure bracket
127 N111862 Screw motor, stepless
128 Z11915 Lock ring conveyer screw
129 Z35182 Friction bearing Di16
130 N112499 Setscrew with pin
131 Z34463 Discharge auger
132 B16798 Handle burnback flap
Nr. Art.Nr. Description
133 B16030 Additional motherboard for motor, incl.
cable
134 Z34790 Electromagnet
135 L01445 Switch spacer
136 N111732 Magnetic switch top part
137 L02310 Guard plate
138 N111942 Self-locking nut
139 Z34885 Activator security flap
140 Z34529 Torsion spring
141 Z35524 Spacer
142 N104195 Washer
143 N112299 Hexagonal screw
144 N111733 Magnetic switch bottom part
145 N112044 Hexagon socket screw
146 L02012 Magnet plate
147 B16561 Mainboard USB11
148 B16672 Additional board
149 B16671 Additional board
150 N111862 Screw motor, stepless
151 L02250 Bearing holding plate
152 L02605 Bearing collar plate
153 L02604 Motor plate
154 N111967 Allen screw M06x10
155 Z35752 Bearing retaining ring
156 B16547 Air regulator assy
157 B18088 Extension of actuator
158 N112220 Circlips
159 N111817 Air regulator motor
160 N111880 Turning grid motor
161 Z34467 Coupling turning grid motor
162 N111825 Contact switch
163 N112309 Pressure spring door contact
164 Z35156 Stop bar
165 N111581 Induced draft fan motor
N111604 Fuse 2,5 A
Z34841 Cable for additional motherboard
E15745 Sealing kit
Note: Please consider the powdercoated parts can differ slightly in colour and colour effects though they are elaborated in high quality.

8
Dimensions
939
208 395
450
1141
882
515
1700
714
229
198
175
125
150
Dimensions
Height [mm] 
Width [mm] 
Corpus depth [mm] 
Weight
Weight without shell [kg] 
Weight with shell [kg] 
Weight with soap stone sideways
(optional) [kg] 
Flue Pipe Connection
Flue pipe outlet [mm] 
Original angle pipe connection height [mm] 
Original angle pipe total depth [mm] 
Original angle pipe distance to rear wall [mm] 
Deapth from rear wall to middle of flue
pipe [mm] 
Original angle pipe side distance [mm] 
Rear connection height [mm] 
Rear connection side distance [mm] 
Fresh Air Connection
Diameter [mm] 
Connection height [mm] 
Side distance [mm] 
Amount of fuel
Nominal Load Part Load
Log operation 2,8 kg 1,4 kg
Pellet operation ~, kg/h* ~, kg/h*
Burn time at full
pellet hopper ~ h* ~ h*
*Practical values may vary depending on pellet quality.
Note
Pellet consumption depends on the size of the pellets. The larger
the pellet, the slower the feed and vice versa.
Electrical connection
The stove is supplied with an approx. 2m long connecting cable with
a Euro-plug. This cable is to be connected to a 230Volt/50Hz socket.
The average electrical power consumption is about 20 Watt in
heating operation. And approx. 150 Watt during automatic ignition.
The connection cable must be laid so that there is no contact to any
sharp edges or hot surfaces of the stove.
Technical data
Description Measure Data
Heating capacity range [kW] 3 - 10
Room heating capacity depending
on house coating [m3] 70 - 260
Pellet consumption [kg/h] 2,4
Pellet container capacity* [l]/[kg] 51/~33
Electric supply [V]/[Hz] 230/50
Average electrical input [W] ~ 20
Fuse [A] 2,5 T
Pellet Operation Measure Data
Heating capacity range [kW] 3 - 10
Efficiency in pellet mode [%] 91
CO2[%] 13,3
CO-emission on 13% O2[mg/mN
3] 42
Dust emission [mg/mN
3] 10
Exhaust [g/s] 5,4
Exhaust temperature [°C] 178,9
Chimney draft requirement [Pa] 3
Log Operation Measure Data
Heating capacity range [kW] 5 - 10
Efficiency in log mode [%] 86
CO2[%] 9,7
CO-emission on 13% O2[mg/mN
3]792
Dust emission [mg/mN
3] 27
Exhaust [g/s] 10,1
Exhaust temperature [°C] 180,2
Chimney draft requirement [Pa] 12
*The capacity in kg may deviate due to different pellet bulk
densities.
The owner of small firing systems or the person authorised for the
small firing system is to keep the technical documentation and is to
submit it to the authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as
local regulations concerning the installation and operation of
firing installations!
Packaging
Your first impression is important to us!
The packaging of your new stove provides excellent protection
against damage. However damage to the stove and accessories
may still occur during transport.
Note
Therefore please check your stove on receipt for damage and
completeness! Report any deficiencies to your dealer immediately!
Pay particular attention during unpacking that the stone panels
remain intact. Scratches to the material can easily occur. Stone
panels are excluded from the warranty
The packaging of your new stove is environmentally neutral to a
great extent.
Tip
The wood used in the packaging has not been surface treated and
may therefore be burnt in your stove. The cardboard and film (PE)
can be disposed of via the municipal waste collection for recycling.

|9
8
EN
2. IMPORTANT INFORMATION
General warning and safety information
Observance of the introductory general warning information is
imperative.
QRead the entire manual thoroughly before installing and putting
the stove into service. Observe the national provisions and laws
as well as the regulations and rules applicable locally.
QRIKA stoves should only be installed in rooms with normal humidity
(dry areas according to VDE 0100 Part 200). The furnaces are not
splash water protected and may not be installed in wet areas.
QOnly approved transport equipment with sufficient load carrying
capacity may be used with your heating appliance.
QYour heating appliance is not suitable for use as a ladder or
stationary scaffolding.
QThe burning of fuel releases heat energy that lead to extensive
heating of the stove surfaces, doors, door and operating handles,
glass, flue pipes and possibly the front wall. Refrain from touching
these parts without appropriate protective clothing or equipment
e.g. heat-resistant gloves or means of operation (operating
handle).
QMake your children aware of this particular danger and keep
them away from the stove during heating.
QOnly burn approved heating materials.
QThe combustion or introduction of highly flammable or explosive
materials such as empty spray cans etc. in the combustion
chamber and storing them near the stove is strictly prohibited
due to the danger of explosion.
QNo light or inflammable clothing is to be worn when post-heating.
QUse the heat-resistant gloves supplied to open the doors of your
stove.
QOnly use suitable tools from our range of accessories when
handling embers and make sure that no embers fall out of the
combustion chamber onto inflammable material.
QPush the embers together to form a firebed when you add new
fuel (logs).
QPlacing non-heat resistant objects on the stove or near it is
prohibited.
QDo not place clothing on the stove to dry.
QLaundry racks etc. must be placed at a sufficient distance to the
stove – ACUTE DANGER OF FIRE!
QWhen your stove is burning, the use of highly inflammable and
explosive materials in the same or adjacent rooms is prohibited.
QIf the stove is heated in continuous operation, the cleaning
intervals are shorter. Increased wear, especially of the thermally
stressed parts, is the result. Please therefore strictly follow the
requirements for cleaning and maintenance!
Note
Waste and liquids may not be burnt in the stove!
Note
To prevent your stove from overheating of the internal components,
do never cover the convection fins!
Note
CAUTION when filling the pellet container. The opening of the pellet
container is sufficiently dimensioned to ensure easy filling. Take
great care that no pellets drop to the convection fins and the hot
stove body. This can cause a lot of smoke.
Tip
Therefore we recommend refilling the pellet container at a cold
stove.
Note
Your stove will expand and contract during the heating and cooling
phase. This can sometimes lead to slight bending or cracking
noises. This is normal and is no reason for a complaint.
First heating
The stove body, just as various steel parts, cast iron parts and the
flue pipes are painted with a heat resistant paint. During the first
heating the paint dries out completely. This may cause a slight smell.
Touching or cleaning the painted surfaces during the curing should
be avoided. The hardening of the paint is finished after the first
heating with high power.
Safety distances
Note
1. To non-combustible objects
a > 40 cm, b > 10 cm
2. To combustible objects and reinforced concrete load-bearing
walls
a > 80 cm, b > 20 cm
Tip
Please observe a minimum distance of 20 cm behind and sideways
the stove for maintenance.

10
Prior to set up
Floor bearing capacity
Ensure that the substructure is capable of bearing the weight of the
stove prior to set-up.
Note
No modifications may be made to the firing installation. This also
leads to loss of warranty and guarantee.
Floor protection
A glass, sheet steel or ceramic plate is required, if the floor is
combustible (wood, carpet, etc.).
Flue pipe connection
QFlue pipes pose a particular source of hazard regarding gas leaks
and fire. Get the advice of an authorised specialist company for
the layout and assembly.
QPlease observe the corresponding installation guidelines for walls
panelled with wood when connecting your flue pipes to the stove,
QObserve the formation of flue gas (atmospheric inversion) and
draughts when the weather is unfavourable.
QInfeed of too little combustion air can lead to smoke in the rooms
or to flue gas leaks. Hazardous deposits in the stove and chimney
may also occur.
QIf flue gas escapes, let the fire burn out and check whether all the
air inlet openings are free and the flue gas pipes and the stove
pipe are clean. If in doubt notify the master chimney sweep since
draught malfunctions may be connected to your chimney.
Stoves type 1 (BA 1):
QThese may only be operated with the combustion chamber door
closed.
QSuitable for multiple occupancy. (note the different country
regulations)
QThe combustion chamber door may only be opened to add fuel
and must then be closed again otherwise other firing installations
connected to the chimney may be endangered.
QThe combustion chamber door is to be kept closed when the
stove is not in operation.
QFouling of the chimney i.e. deposits of highly inflammable materials
such as soot and tar and subsequently fire in the chimney may
occur if the chimney is miscalculated and dimensioned wrong
and if wet wood is used.
If fire in the chimney occurs, disconnect the mains plug of the stove.
Phone the fire brigade and get yourself and other residents out of
harm’s way.
Note
Due to the size of the combustion chamber door it is necessary
not to open the door abruptly, to prevent the flames coming out.
Especially when reheating into blazing flames.
Note
on ROOM-AIR DEPENDENT and
ROOM-AIR INDEPENDENT OPERATION:
Your stove has been tested as a room-air independent stove
according to EN13240 and to EN14785 and can be installed as well
room-air dependent and independent. In Germany it does not
conform to the requirements for room-air independent operation.
When installed room-air dependent in combination with room-
air installations (e.g. controlled ventilation and venting systems
(extractors etc.) it must be ensured that the stove and the room
air system are monitored and safeguarded mutually (e.g. via a
differential pressure controller etc.).
The combustion air infeed of approx. 20 m3/h must be ensured.
Please observe the respective local regulations and rules in
consultation with your master chimney sweep. For changes after
the printing of this manual, we can not assume any liability. We
reserve the right to change without notice.
Convection air conduction
only for stoves with MULTIAIR
The MULTIAIR equipped stove is delivered with a cover on the
convection air outlet to prevent direct heat to the wall.
Operation without this cover or without attached convection pipes is
not allowed. If you do though no warranty and no liability is accepted
for damage.
QThe amount of air and temperature of one fan is designed to heat
one additional room.
QNote the regional specific fire safety regulations and clarify the
connection situation with the competent authority
QThe max. temperature of the convection air is 180 °C at the air
outlet.
QThe convection air canal should be as short as possible.
QKeep the number of deflections as small as possible.
Note
Please pay attention to the national and country-specific building
and fire regulations when connecting the convection air pipes.
Installation and assembly must be performed by a trained
specialist only.
example
