ritm Contact GSM-9N User manual

Saint Petersburg, 2017
Control panels
“Contact GSM-9N”
“Contact GSM-9М”
“Contact GSM-9А”
Operating Manual. Rev. 1.0

www.ritm.ru 2 of 93
Operating Manual. Contact GSM-9N/А/М
Contents
Designations..........................................................................................................................4
Introduction...........................................................................................................................5
Panel Overview.....................................................................................................................6
Designation..............................................................................................................6
Basic capabilities ................................................................................................... 7
Design..................................................................................................................... 10
Contact GSM-9N.................................................................................... 10
Contact GSM-9А.................................................................................... 12
Contact GSM-9М ................................................................................... 15
Specications....................................................................................................... 18
Commissioning .................................................................................................................. 19
GSM tariff plan selection ................................................................................. 19
Selecting and Installing SIM cards............................................................... 19
Installation and connection.......................................................................................... 20
Installation Procedure....................................................................................... 20
Indication............................................................................................................................. 22
Contact GSM-9N.................................................................................................. 22
Contact GSM-9А .................................................................................................. 24
Contact GSM-9М ................................................................................................. 25
Standalone conguration .............................................................................................. 26
Panel conguration.......................................................................................................... 28
Conguration software sections.................................................................... 34
Global Settings...................................................................................... 36
System Events (Customizable)......................................................... 38
System Events (Non-Customizable) ............................................... 40
GPRS parameters .................................................................................. 42
Communication channels .................................................................. 45
Hardwired zones properties.............................................................. 49
Areas Conguration ............................................................................. 52
Hardwired zones settings .................................................................. 56

www.ritm.ru 3 of 93
Operating Manual. Contact GSM-9N/А/М
Keypads .................................................................................................... 62
Keypad codes ......................................................................................... 64
Touch Memory keys.............................................................................. 68
Output terminals................................................................................... 72
Engineering Numbers ......................................................................... 74
SMS-messages....................................................................................... 76
History....................................................................................................... 78
Update ...................................................................................................... 81
Service ...................................................................................................... 83
Adding to GEO.RITM ........................................................................................................ 85
Maintenance........................................................................................................................87
Safety Measures ................................................................................................................ 88
Transportation and Storage .......................................................................................... 89
Manufacturer’s Warranties............................................................................................. 90
Contact Details .................................................................................................................. 91
Change history................................................................................................................... 93

www.ritm.ru 4 of 93
Operating Manual. Contact GSM-9N/А/М
Designations
Term Designation
Battery Accumulator battery
Zone A part of a guarded facility controlled by one hardwired
zone or by a combination of hardwired zones.
Area Independently controlled and logically
dedicated part of a security system.
Monitoring server A server to which the device transmits data through
congured communication channels.
Tamper A contact located under the device cover and triggered on
removal the cover or tearing-off the device from surface.
Hardwired zone
A circuit connecting output nodes of signaling devices
and designed for transmitting to the device details
on controlled by signaling devices parameters.

www.ritm.ru 5 of 93
Operating Manual. Contact GSM-9N/А/М
Introduction
This operating manual covers the following control panels:
• “Contact GSM-9N control panel”;
• “Contact GSM-9А control panel”;
• “Contact GSM-9М control panel”.
These control panels are designed for setting up security at remote real
estate objects: apartments, ofces, country houses, and other real estate
objects.
This manual contains data on the design, principle of operation, properties
of devices, their parts, and guidelines for proper and safe operation of
devices (intended use, maintenance, storage, and transportation).
This operating manual provides necessary information for training and
further use of panels.

www.ritm.ru 6 of 93
Operating Manual. Contact GSM-9N/А/М
Panel Overview
Designation
These control panels are designed for setting up security at remote real
estate objects: apartments, ofces, country houses, and other objects.
Messages to the monitoring software are transmitted via GSM network
through GPRS, CSD, SMS channels.
The panels features are the following:
• Connection up to 3 hardwired zones of “dry contact”
type or up to 6 resistive hardwired zones;
• Non-volatile memory for 65535 events;
• Remote conguration;
• 2 outputs for connection of actuation devices;
• Main power supply monitoring;
• Battery discharge monitoring.

www.ritm.ru 7 of 93
Operating Manual. Contact GSM-9N/А/М
Basic capabilities
Security areas
Areas are independently controlled and logically dedicated parts of the
security system. The main function of these areas is to combine zones
controlled by the system related to one security eld to make one or
several areas.
You can create up to 6 independent security areas.
A security area enables grouping zones by rooms, managing arming and
disarming of these rooms independently and identifying which room or
zone has a triggered sensor.
Transmitting messages to the monitoring software or to a user using the
Ademco Contact ID protocol specify the names of areas and zones directly
in the software settings.
Event history
All events and alarms detected or initiated by the panel are stored in the
panel event history. The panel memory can store up to 65535 entries. As
the event history is full newer events replace the older ones automatically.
The event history can be exported into a .txt le for convenience of the
user.
Built-in communicator and communication channels
The panel has a built-in GSM modem. This allows to transmit details on
events in the system without connecting additional devices. It is possible
to install 2 SIM cards into the panel.

www.ritm.ru 8 of 93
Operating Manual. Contact GSM-9N/А/М
Tamper
The tamper button triggers on removal the panel cover or tearing-off the
enclosure from the installation surface and generates an alarm message to
send it to the monitoring server or to a user as an SMS.
Device Setup using PC
You can connect and setup the panel using any of the following ways:
1. Remotely using GEO.RITM and RITM-Link cloud software
2. Locally by connecting to the device through a
conguration cable and using Ritm.conf and Ritm
Congure multiuse conguration software
3. Remotely using CSD-modem
Partial panel setup without using PC1
The “Contact GSM-9N” panel could be partly setup in standalone mode. In
this case the setup is performed with a built-in keypad. Commands for
device setup with a keypad are listed in the “Standalone setup” section.
Touch Memory keys and RFID-tags2
To arm a facility Touch Memory keys could be used and for the “Contact
GSM-9M” version could be used RFID-tags as an option. This requires
installation of the proper reading devices connected to the panel.
16 keys/tags may be used at the same time.
1) Available for “Contact GSM-9N” version.
2) The “Contact GSM-9M” version could be delivered with a built-in Touch Memory key
reader or a RFID reader.

www.ritm.ru 9 of 93
Operating Manual. Contact GSM-9N/А/М
Outputs for actuation device connection
2 outputs of the panel can host a number of various actuation devices,
such as sirens, illuminated panels, and indicators.
Hardwired zones
The panel allows to connect up to 3 dry contact hardwired zones or up to 6
resistive hardwired zones simultaneously.

www.ritm.ru 10 of 93
Operating Manual. Contact GSM-9N/А/М
Design
Contact GSM-9N
The panel is made in plastic enclosure and has 2 versions:
1. With built-in GSM-antenna
2. With external GSM-antenna In this case the device has a
connector for the antenna (SMA connector on the g. 1).
Figure 1.
XS1
SA1
TM LED GND
+ 1 - + 2 - + 3 -
ZONES
STAY
ZONES
EXIT
BYPASS
CANCEL
ARMED
INSTANT
FIRE
READY
POWER
SERVICE
1 2 3
4 5 6
7 8 9
0
*#
+12V
GND
+12V
CPW GND
U(OK)
OK2 OK1
SIM1SIM2
1 2 3 4
5 6 7 8
9 10 11 12
13 1514 16
SMA
Contact GSM-9N

www.ritm.ru 11 of 93
Operating Manual. Contact GSM-9N/А/М
Part Designation
CPW, +12V, GND
Panel power supply terminals:
• GND — a negative terminal of main power supply
• +12V — a positive terminal of main power supply
• CPW — 220V power supply availability check
+12V, GND Terminals for powering security sensors (+12 V constant
voltage is applied to connector when the panel is on)
"+1-"; +2-"; +3-" Connectors for hardwired zones connection
OK1, OK2, U(OK)
Connectors for external actuation devices connection (siren, visual
indicator or relay). Maximum load current — 300 mA.
A visual indicator duplicating statuses of areas assigned to the EXIT
button is connected to terminals ОК1 and +U(OK)
A siren is connected to ОК2 and +U(OK) terminals.
TM, LED, GND
Terminals for Touch Memory reader connection:
• TM: output (positive terminal) for
connecting red Touch Memory wire;
• LED: output (positive terminal) for connecting
yellow wire of Touch Memory indicator;
• GND: common terminal for connecting black and
blue (and/or black-blue) Touch Memory wire.
Colours of the Touch Memory wires may vary depending on the
manufacturer.
SA1 Enclosure break-in or supporting surface (i.e.,
wall) tear-off tamper of control panel
XS1 Conguration cable connector
SIM1 SIM card 1 holder
SIM2 SIM card 2 holder
SMA-connector
(optionally)
Connector for external GSM antenna (not available
in devices with built-in antenna)

www.ritm.ru 12 of 93
Operating Manual. Contact GSM-9N/А/М
Contact GSM-9А
The device is delivered in the "Contact" 1.2 Ah enclosure or in the
"Contact"
7 Ah enclosure.
The panel is equipped with a built-in Touch Memory reader and a visual
frame with “Armed”, “Battery” and “Ready” indicators.
Figures 2, 3, and 4 show panel circuit board design and dimensions of
enclosures.
Figure 2.
SA1
SIM1
SIM2
TM PROG
INDIC
XT1
VD12
VD11
XS1
HL1
BAT+
GND
GND
+12V
OK1 OK2 TM GND +12V LED
+ 1 _+ 2 _+ 3 _
“Contact GSM-9А” panel card

www.ritm.ru 13 of 93
Operating Manual. Contact GSM-9N/А/М
Figure 3.
ARMED
BATTERY
READY
“Contact 1.2Ah” enclosure
Figure 4.
ARMED
BATTERY
READY
“Contact 7Ah” enclosure

www.ritm.ru 14 of 93
Operating Manual. Contact GSM-9N/А/М
Part Designation
XT1 220V power supply connector
+1-; +2-; +3- Connectors for hardwired zones connection
ОК1, ОК2, +12V
Connectors for external actuation devices connection
(siren, visual indicator etc.). Maximum load current — 300 mA.
The ОК1, ОК2 terminals are negative and the
+12V terminal is positive for the device.
+12V, GND Terminals for power supply of security sensors (+12 V constant
voltage is applied to the connector when the control panel is on)
GND, BAT+ Lead-acid battery connector The GND terminal is negative
and the BAT+ terminal is positive for the battery.
TM, LED, GND
Terminals for Touch Memory reader connection:
• TM: output (positive terminal) for
connecting red Touch Memory wire;
• LED — an output (positive terminal) for connecting
orange wire of the Touch Memory indicator
• GND — a common terminal for connecting
black and yellow Touch Memory wire
SA1 Enclosure break-in or supporting surface
(i.e., wall) tear-off tamper of control panel
PROG Conguration cable connector
SIM1, SIM2 SIM card slots
XS1 GSM antenna connector
TM Connector for Touch Memory reader connection using a 4-pin cable
INDIC Connector for indication board connection (on the enclosure)

www.ritm.ru 15 of 93
Operating Manual. Contact GSM-9N/А/М
Contact GSM-9М
The panel is made in plastic enclosure and has 2 versions:
1. “Contact GSM-9M” TM control panel is equipped with a
Touch Memory key reader built in the enclosure.
2. “Contact GSM-9M” TM control panel is equipped
with a RFID key reader built in the enclosure.
Figure 5. “Contact GSM-9М”: front and side view

www.ritm.ru 16 of 93
Operating Manual. Contact GSM-9N/А/М
Figure 6. “Contact GSM-9М”

www.ritm.ru 17 of 93
Operating Manual. Contact GSM-9N/А/М
#Part Designation
1 LEDs Device indication is described in the section "Indication"
2 Blank plug A mounting hole designed for cable inlet/outlet
3Touch Memory
reader
ТМ reader built in the enclosure (optionally,
depending on the version)
4GSM antenna
connector External GSM antenna connector
5 SIM card slots Vertical slots for SIM cards
6Conguration
cable connector Conguration cable connector for PC communication
7 RFID reader RFID reader built in the enclosure (optionally,
depending on the version)
8 Spring contacts Spring contacts are connected to the indication
board (on the top cover of the enclosure).
9 Battery location Backup battery compartment
+1-; +2-; +3- Connectors for hardwired zones connection
ОК1, ОК2, Uok Connectors for actuation devices. The ОК1, ОК2 terminals
are negative and the Uok terminal is positive for devices.
TM, LED, GND
Terminals for Touch Memory reader connection:
• TM — output (positive) for connecting
Touch Memory signaling wire
• LED — output (positive) for connecting
Touch Memory indicator wire
• GND: Common.
+BAT- Lead-acid battery connector The «–» terminal is negative
and the «+» terminal is positive for the battery.
220V 50Hz 220V power supply connector

www.ritm.ru 18 of 93
Operating Manual. Contact GSM-9N/А/М
Specications
Option Value
GSM channel frequency, MHz 850/900/1800/1900
Communication channels CSD, GPRS, SMS to the property
owner, SMS ContactID
Status monitoring of communication lines Yes
Number of SIM cards installed, pcs 2
Security arming by area +
Conguration of (resistance) thresholds
for each ribbon cable +
Arming/disarming from keypad +
(for “Contact GSM-9N” version)
Arming/disarming from monitoring software Yes (in GPRS Online mode)
Arming/disarming with TM keys +
Arming/disarming with TM/RFID keys +
(for “Contact GSM-9М” version)
Max. number of TM keys, pcs 16
Number of events in history 65,535
Conguring parameters using PC Yes
GSM signal strength indication using keypad +
(for “Contact GSM-9N” version)
Number of bare collector outputs
(with 300 mA maximum load), pcs 2
Number of connected hardwired zones, pcs up to 3 of “dry contact” type or
up to 6 resistive
Main power source voltage, V 220
(12±2 for “Contact GSM-9N” version)
Backup power source voltage, V 12±2
Current consumption in standby mode, mA max 80
Current consumption in GSM data
transmission mode, mA max 300
Dimensions, mm
160×100×30 (9N)
108×142×42 (9А)
170×120×50 (9М)
Maximum weight (without battery and enclosure), g 370
Operating temperature range (non-condensing), °С -30 – +50
The delivery package is specied in the Device Data Sheet.

www.ritm.ru 19 of 93
Operating Manual. Contact GSM-9N/А/М
Commissioning
GSM tariff plan selection
To start operation install SIM cards of a GSM mobile operator to the device.
Use your mobile operator’s plans with enabled GPRS, CSD data and fax
messaging channel, SMS messaging and disabled voice communication.
The best plan should have the following features:
1. The GPRS connection has the highest priority
(if GPRS is used as the main channel).
2. The GPRS session opening is not charged.
3. The trafc is charged at the end of the day / session.
4. The rounding threshold for the trafc charging is the lowest.
Selecting and Installing SIM cards
!
To install and remove SIM cards power off panel.
The panel uses one or two standard size SIM cards (mini SIM).
i
To operate the panel under low temperatures it is
recommended to use temperature-resistant SIM cards with
extended operating temperature range and life cycle.
Before installing a SIM card into the panel please insert it into a mobile
phone and disable PIN code identication in accordance with the phone’s
operating manual.

www.ritm.ru 20 of 93
Operating Manual. Contact GSM-9N/А/М
Installation and connection
Installation Procedure
Mount the precongured panel to an even vertical surface.
!
Do not mount the panel in close proximity to the following:
• EMI sources
• Massive metal objects and assemblies
• Power cable main lines
• Heaters and ventilation systems.
Protect the panel from moisture.
1. Open the panel enclosure.
2. Run all wires through an opening in the enclosure back cover.
3. Securely fasten the back enclosure cover on a wall.
4. Connect hardwired zones to connectors (terminals) of inputs.
5. Connect circuits with actuation devices (LEDs, sirens, etc.) to
connectors of outputs, and, if necessary, the TM reader.
i
If it is necessary to take the device out of the guarded
perimeter, protect power circuits by fuses.
